Concurrency: Background and Implementation

1
Concurrency Background and Implementation
Fred Kuhns (fredk_at_arl.wustl.edu,
http//www.arl.wustl.edu/fredk) Department of
Computer Science and Engineering Washington
University in St. Louis
2
Concurrency Origins and problems

• Context
• Processes need to communicate
• Kernel communication/controlling hardware
  resources (for example I/O processing)
• Issues
• How is information exchanged between processes
  (shared memory or messages)?
• How to prevent interference between cooperating
  processes (mutual exclusion)?
• How to control the sequence of process execution
  (conditional synchronization)?
• How to manage concurrency within the OS kernel?
• Problems
• Execution of the kernel may lead to concurrent
  access to state
• Deferred processing pending some event
• Processes explicitly sharing resource (memory)
• Problems with shared memory
• Concurrent programs may exhibit a dependency on
  process/thread execution sequence or processor
  speed (neither are desirable!)
• race condition whos first, and who goes next.
  affects program results.
• There are two basic issues resulting from the
  need to support concurrency
• Mutual exclusion ensure that processes/threads
  do not interfere with one another, i.e. there are
  no race conditions. In other words, program
  constraints (assumptions) are not violated.
• Conditional synchronization Processes/threads
  must be able to wait for the data to arrive or
  constraints (assertions) to be satisfied.

3
Definitions

• Process sequence of statements which are
  implemented as one or more primitive atomic
  operations (hardware instructions)
• Concurrent program results in the interleaving
  of statements from different processes
• Program state value of a programs variables at
  a given point in time.
• Execution viewed as a sequence of states si.
• Atomic actions transform states.
• Program history specific sequence of program
  states s0 -gt s1 -gt ... -gt sN
• Synchronization constrains the set of possible
  histories to only those that are desirable
• Mutual Exclusion combines a sequence of actions
  into a critical section which appear to execute
  atomically.

4
Interference or Race Conditions

• If two or more process access and modify shared
  data concurrently, and the final value of the
  shared data depends on the order in which it was
  accessed.
• Race condition manifest themselves as
  intermittent problems and are generally difficult
  to debug.
• To prevent race conditions, concurrent processes
  must synchronize their access to the shared
  memory locations known as the critical section
  problem.

5
Race Conditions - Example
Example 1 int y 0, z 0 Task A x y
z Task B y 1 z 2 Results x 0,
1, 2, 3 load y into R0 load z into R1 set R0
R0 R1 set x R0

• There are 4 cases for x
• case 1 task A runs to completion first loading
  y0 then z0. x 0 0 0
• case 2 Task B runs loading y1, then Task A runs
  loading y1 and z0. x 1 0 1
• case 3 Task A runs loading y0, then Task B runs
  to completion, then Task A runs loading z2. x
  0 2 2
• case 4 Task B runs to completion, then Task A
  runs loading y1, z2,x 1 2 3

6
Race Condition OS Example
Task A ... get KFT_NextFree (7) -- preempted
- KFT_NextFree 1 update entry 7
Task B ... get KFT_NextFree (7) KFT_NextFree
1 update Entry 7 -- preempt
KFT_NextFree 7

• Final value of kernel table entry 7 is
  indeterminate.
• Final value of KFT_NextFree is 9
• Kernel File Table entry 8 is not allocated

7
Properties

• Property something that is always true of a
  program
• Safety never enter a bad state
• Examples absence of deadlock, providing mutual
  exclusion
• Liveness eventually enter a good state, in
  particular that a process or thread makes
  progress toward a goal state.
• Examples process eventually enters a critical
  section, a service request is eventually honored,
  a message eventually reaches its destination
• May depend on the fairness of scheduler
• Partial Correctness if the program terminates
  then the final answer is correct.
• Safety property.
• It says nothing about whether the program will
  terminate only that if it does then the answer
  will be correct.
• Total Correctness combines partial correctness
  with termination.
• Liveness property
• Says that a program will indeed always terminate
  (i.e. complete) and produce a valid (correct)
  answer.
• Mutual exclusion is a safety property (no bad
  states).

8
Fairness

• Unconditional fairness a scheduling policy is
  unconditionally fair if every unconditional
  atomic action that is eligible is executed
  eventually.
• round-Robin is unconditionally fair in the
  absence of conditional atomic expressions (atomic
  expression awaits some condition to be true
  before being executed).
• If conditional expressions are present then need
  stronger guarantees.
• Weak fairness A scheduling policy is weakly fair
  if 1) it is unconditionally fair and 2) every
  conditional atomic action that is eligible is
  executed eventually, assuming that its condition
  becomes true and then remains true until it is
  seen by the process executing the conditional
  atomic action.
• ensures that every process keeps getting chances
• progress then depends on the possibility that the
  process will get a chance at the right time
• Strong fairness A scheduler is strongly fair if
  1) it is unconditionally fair and 2) every
  conditional atomic action that is eligible is
  executed eventually, assuming that its condition
  is infinitely often true.

9
Some Definitions

• Independent processes Two processes are
  independent if the write set of each is disjoint
  from both the read and write sets of the other.
• Critical reference reference to a variable
  changed by another process. Assume the variable
  is written or read atomically.
• Critical assertion A pre/post condition that is
  not in a critical section.
• Noninterference An assignment a and its
  precondition pre(a) in process A does not
  interfere with a critical assertion C in another
  process if the following is always true. C
  pre(a) a CThat is, C is not affected by the
  execution of a when pre(a) is true.

10
Avoiding Race Conditions

• At-Most-Once property If the assignment
  statement x e satisfies1) e contains at most
  one critical reference and x is not read by
  another process or 2) e contains no critical
  references, in which case x may be read by
  another process.In other words, there can be at
  most one critical reference within the expression
  S x e
• Four techniques for avoiding interference
• Disjoint variables write set of one process is
  disjoint from the reference set of another.
  Reference set is the set of variables appearing
  in assertions.
• Weakened assertions if variables are not
  disjoint then loosen constraints (i.e. the set of
  assertions).
• Global invariants expresses relationships
  between shared variables
• Synchronization define atomic actions

11
Consumer Producer Example
define BUFSZ 10 typedef struct . . .
item item bufferBUFSZ int in 0 int out
0 int counter 0

• Producer
• item nextProduced
• while (TRUE)
• while (counter BUFSZ)
• bufferin nextProduced
• in (in 1) BUFSZ
• counter

Consumer item nextConsumed while (TRUE) while
(counter 0) nextConsumed
bufferout out (out 1)
BUFSZ counter--
critical section.
Must protect the counter write critical section.
12
Bounded Buffer

• If both the producer and consumer attempt to
  update the buffer concurrently, the assembly
  language statements may get interleaved.
• Interleaving depends upon how the producer and
  consumer processes are scheduled.
• Assume counter is initially 5. One interleaving
  of statements isproducer register1
  counter (register1 5)producer register1
  register1 1 (register1 6)consumer
  register2 counter (register2 5)consumer
  register2 register2 1 (register2
  4)producer counter register1 (counter
  6)consumer counter register2 (counter 4)
• The value of count may be either 4 or 6, where
  the correct result should be 5.

13
Critical Section Problem

• Entry/exit protocol satisfies
• Mutual Exclusion At most one process may be
  active within the critical section
• Absence of deadlock (livelock) if two or more
  processes attempt to enter CS, one will
  eventually succeed.
• Absence of Unnecessary delay If one process
  attempts to enter CS and all other processes are
  either in their non-critical sections or have
  terminated then it is not prevented from
  entering.
• Eventual entry (no starvation, more a function of
  scheduling) if a process is attempting to enter
  CS it will eventually be granted access.

Task A while (True) entry
protocol critical section exit
protocol non-critical section
14
Mutual Exclusion

• First we look at mutual exclusion alone, also
  known as busy waiting
• Simplest approach (on single processor systems)
  is to disable interrupts
• why does this work?
• traditional kernels use this approach
• less attractive for user process. why?
• Algorithms implemented in software without
  support from the hardware
• Hardware support for atomic read/write operations
• Then we look at a solution which puts a process
  to sleep when a resource is not available,
  permitting more efficient use of the system
  (conditional synchronization sleep until the
  condition is true)

15
Mutual Exclusion - Interrupt Disabling

• Process runs until requests OS service or
  interrupted
• Process disables interrupts for mutual exclusion
• Processor has limited ability to interleave
  programs
• Efficiency of execution may be degraded
• Multiprocessing
• disabling interrupts on one processor will not
  guarantee mutual exclusion. Why?
• Entry/exit protocol satisfies (single CPU)
• Mutual Exclusion Yes
• Absence of deadlock Yes
• Absence of Unnecessary delay Yes
• Eventual entry Yes

16
Lock Variables
int lock 0

• Process A
• while (True)
• //entry protocol
• while (lock 1)
• lock 1
• critical section
• // exit protocol
• lock 0
• non-critical

Process B while (True) // entry
protocol while (lock 1) lock
1 critical section // exit protocol lock
0 non-critical
17
Lock

• Entry/exit protocol satisfies
• Mutual Exclusion No
• Absence of deadlock Yes
• Absence of Unnecessary delay Yes
• Eventual entry No

18
Taking Turns
int turn 0
Task B int myid 1 while (True) //
entry protocol while (turn ! 1) critical
section // exit protocol turn
0 non-critical

• Task A
• int myid 0
• while (True)
• // entry protocol
• while (turn ! 0)
• critical section
• // exit protocol
• turn 1
• non-critical

19
Taking turns

• Entry/exit protocol satisfies
• Mutual Exclusion Yes
• Absence of deadlock Yes
• Absence of Unnecessary delay No
• Eventual entry Yes

20
Combined Approach
aka Petersons Solution
Process A int myid 0 while (1)
enter(myid) critical section leave(myid)

define N 2 int last 0 int wantN
0,0 void enter(int proc) int other proc
? 1 0 wantproc 1 last proc while
(last proc wantother) void leave(int
proc) wantproc 0
Process B int myid 1 while (1)
enter(myid) critical section leave(myid)

21
Petersons Solution

• Entry/exit protocol satisfies
• Mutual Exclusion Yes
• Absence of deadlock Yes
• Absence of Unnecessary delay Yes
• Eventual entry Yes

22
Help from Hardware

• Special Machine Instructions
• Performed in a single instruction cycle
• Not subject to interference from other
  instructions
• Reading and writing
• Reading and testing
• For example the test and set instruction
• boolean TSL (boolean lock)
• boolean tmp lock
• lock True
• return tmp
• You have the lock iff False is returned.
• if lock False before calling TSL(lock)
• it is set to True and False is returned
• if lock True before calling TSL(lock)
• it is set to True and True is returned

23
Mutual Exclusion with TSL

• Shared data boolean lock False //
  initialize to false
• Task Pi
• do
• // Entry protocol
• while (TSL(lock) True) // spin wait for
  lock
• // execute critical section code
• -- critical section --
• // Exit protocol
• lock False
• // Non-critical section code
• -- remainder section --
• while (1)

24
Using a Swap Instruction

• Atomic swap
• void Swap(boolean a, boolean b)
• int temp a a b b temp
• Atomically swap values, after calling swap, a
  original value of b, b original value of a
• Implementing a mutex. Shared data (initialized to
  False)
• boolean lock False
• boolean waitingn
• Process Pi
• do
• // Entry protocol
• key True
• // when lock is false key becomes false
• while (key True) Swap(lock, key)
• // Execute critical section code
• -- critical section --
• // Exit protocol
• lock false

25
Machine Instructions

• Advantages
• Can be used on single or multi-processor systems
  (shared memory)
• It is simple and therefore easy to verify
• It can be used to support multiple critical
  sections
• Disadvantages
• Busy-waiting consumes processor time
• Starvation possible when a process leaves a
  critical section and more than one process is
  waiting.
• Who is next? Lowest priority process may never
  acquire lock.
• Deadlock - If a low priority process has the
  critical region (i.e. lock) but is preempted by a
  higher priority process spinning on lock then
  neither can advance.

26
Must we always busy wait?

• While busy waiting is useful in some situations
  it may also lead to other problems inefficient
  use of CPU and deadlock resulting from a priority
  inversion
• What we really want is a way to combine mutual
  exclusion schemes with conditional
  synchronization.
• In other words, we want the option of blocking a
  process until it is able to acquire the mutual
  exclusion lock.
• Simple solution is to add two new functions
• sleep() and wakeup()

27
Adding Conditional Synchronization Almost a
Complete Solution
int N 10 int bufN int in 0, out 0, cnt
0
Task consumer item_t item while (TRUE)
if (cnt 0) sleep() item
bufout out (out 1) N lock(lock)cnt-
-unlock(lock) if (cnt N-1) wakeup(produc
er) consume(item)
Task producer int item while (1) item
mkitem() if (cnt N) sleep() bufin
item in (in 1) N lock(lock)cntunlo
ck(0) if (cnt 1) wakeup(consumer)
28
Lost wakeup problem

• Assume that the lock() and unlock() functions
  implement a simple spin lock
• Ive left out the details to simplify the
  previous example
• There is a race condition that results in a lost
  wakeup, do you see it?
• We will solve this problem when we talk about
  semaphores and monitors.

29
Intro to Semaphores

• Synchronization mechanism
• No busy waiting
• No lost wakeup problem.
• Integer variable accessible via two indivisible
  (atomic) operations
• P(s) or wait(s) If s gt 0 then decrementelse
  block thread on semaphore queue
• V(s) or signal(s)If (s 0 and waiting
  threads) then wake one sleeping threadelse
  increment s
• Kernel guarantees operations are atomic
• Can define a non-blocking version trylock.
• Each Semaphore has an associated wait queue.
• Ways to use a semaphore
• (1) Mutual Exclusion binary semaphore
  initialized to 1
• (2) Event Waiting binary semaphore initialized
  to 0
• (3) Resource counting Initialized to number of
  available resources
• If using for mutual exclusion, semantics ensure
  lock ownership transfers to waking thread
• Threads are woken up in FIFO order
• May result in unnecessary context switches,
  Semaphore convoys. A thread currently running on
  another CPU may attempt to lock resource
  immediately after it has been transferred to a
  sleeping thread. May be better to allow the
  already running thread to acquire lock and waking
  thread to wait on ready queue. This reduces the
  number of context switches.

30
Critical Section of n Tasks

• Shared data
• semaphore mutex // initialize mutex 1
• Process Ti do wait(mutex) --
  critical section --
• signal(mutex) -- remainder section

• while (1)

31
Semaphore Implementation

• Define a semaphore as a record
• typedef struct
• int value // value of semaphore
• queue_t sq // task/thread queue
• // also need lock(s) to protect value and
  thread queue
• semaphore
• Assume two simple operations wait() and signal()
• Is the below a complete solution? How do we
  protect the semaphore object from concurrent
  access by other threads?

void signal(sem_t S) thread_t
t S-gtvalue if (S-gtvalue ? 0) t
getthread(S-gtsq) wakeup(t) return
void wait(sem_t S) S-gtvalue-- if (S-gtvalue
lt 0) addthread(S-gtsq) sleep() return

32
Some Reference Background

• Semaphores used in Initial MP implementations
• Threads are woken up in FIFO order (convoys)
• forcing a strictly fifo order may result in
  unnecessary blocking
• Used to provide
• Mutual exclusion (initialized to 1)
• Event-waiting (initialized to 0)
• Resource counting (initialized to number
  available)
• High level abstraction built using lower-level
  primitives.
• Always caries the overhead of sleep queue
  management (event notification mechanism)
• Always caries the overhead of locking (mutual
  exclusion mechanism)
• Hides whether thread has blocked, may want to
  actively wait for resource (i.e. spin lock)

33
Potential Problems

• Incorrect use of semaphores can lead to problems
• Critical sections using semaphores must keep to
  a strict protocol
• wait(S) critical section signal(S)
• Problems
• No mutual exclusion
• Reverse signal(S) critical section wait(S)
• Omit wait(S)
• Deadlock
• wait(S) critical section wait(S)
• Omit signal(S)

34
Other Synchronization Mechanisms

• Mutex - Mutual Exclusion Lock, applies to any
  primitive that enforces mutual exclusion
  semantics
• Condition variables event notification, usually
  has an associated predicate and lock to protect
  predicate.
• Read/Write Locks there are other paradigms, for
  example only requiring exclusive access to a
  resource if it is being modified. Otherwise any
  number of readers.
• Reference Counting the kernel often has to
  maintain resources while they are actively used.
  A thread may indicate its interest in a resource
  by incrementing a reference count then
  decrementing when it is done. When the reference
  count goes to 0 then resource may be freed
  (garbage collection).

35
Multiprocessor Support

• The traditional approaches do not work.
• Lost wakeup problem Between checking a locked
  flag and placing a thread on a sleep queue (and
  setting wanted flag) the event may occur.
• thundering heard problem waking all threads
  sleeping on a resources may cause them to all to
  run in parallel (on different CPUs), but only one
  can lock resource so remainder go back to sleep.
• Kernel relies on interrupt disabling to protect
  one processors context but this is not enough for
  multiple processors
• need both interrupt disabling and spin locks
• Leverage Hardware support for synchronization
• Atomic test-and-set test bit, set it to 1,
  return old value.
• load-linked and store-conditional
  (read-modify-write) load variable, modify then
  store. A flag is set indicating if the write was
  successful can be used to implement semaphores
  (atomic increment, keep trying until you succeed
  in incrementing variable).

36
Spin Locks (MP Support)

• The idea is to provide a basic, HW supported
  primitive with low overhead.
• Lock held for short periods of time
• If locked, then busy-wait on the resource
• Must not give up processor if holding lock!
• I show interrupts being blocked
• For a mutual exclusion lock you must also block
  interrupts!

void lock (spinlock_t s) while (testNset(s)
! 0) while (s ! 0)
void unlock (spinlock_t s) s 0
37
Blocking Locks/Mutex

• Allows threads to block
• Interface lock(), unlock () and trylock ()
• Consider traditional kernel locked flag
• Mutex allows for exclusive access to flag,
  solving the race condition
• flag can be protected by a spin lock.

38
Condition Variables

• Associated with a predicate which is protected by
  a mutex (usually a spin lock).
• Useful for event notification
• Can wakeup (signal) one or all (broadcast)
  sleeping threads.
• Up to 3 or more mutex locks are typically
  required
• one for the predicate
• one for the sleep queue (or CV list)
• one or more for the scheduler queue (swtch ())
• Deadlock avoided by requiring a strict order

39
Condition Variables
update predicate
wake up one thread
Thread sets event
40
CV Implementation
void signal (cv c) lock (cv-gtlistlock) remo
ve a thread from list unlock (cv-gtlistlock) if
thread, make runnable return void
broadcast (cv c) lock (cv-gtlistlock) while
(list is nonempty) remove a thread make it
runnable unlock (cv-gtlistlock) return
void wait (cv c, mutex_t s) lock
(cv-gtlistlock) add thread to queue unlock
(cv-gtlistlock) unlock (s) swtch () /
return after wakup / lock (s) return
41
Monitors

• High-level synchronization construct that allows
  the safe sharing of an abstract data type among
  concurrent processes.
• monitor monitor-name
• shared variable declarations
• procedure body P1 () . . .
• procedure body P2 () . . .
• procedure body Pn () . . .
• initialization code

42
Monitors Condition Variables

• To allow a process to wait within the monitor, a
  condition variable must be declared, as
  condition x, y
• Condition variable can only be used with the
  operations wait and signal
• x.wait() the process invoking this operation is
  suspended until another process invokes
  x.signal()
• x.signal resumes exactly one suspended process.
  If no process is suspended, then the signal
  operation has no effect.
• If a task A within a monitor signals a suspended
  task B, there is an issue of which process is
  permitted to execute with the monitor
• signal-and-wait Task A must wait while process B
  is permitted to continue executing within the
  monitor
• signal-and-continue Task A continues to execute
  within the monitor, task B must wait
• A case can be made for either approach

43
Monitor With Condition Variables
44
Monitor Implementation

• Since only one task may be active in a monitor
  there must be a mutex protecting the monitor.
• The mutex effectively serializes access to the
  monitor.
• We also need to account for sending signals
  within a monitor that is, guard against having
  more than one active task within the monitor.
• Our implementation uses semaphores for both
  mutual exclusion (initialized to 1 for a mutex)
  and counting the number of tasks waiting to be
  resumed within the monitor (initialized to 0
  counting semaphore)

45
Example using Hoare Semantics signal-and-wait
for CV x define semaphore xSem 0 int xCnt
0 x.wait() xCnt if (urgCnt gt 0)
signal(urgent) else
signal(mutex) wait(xSem) xCnt-- x.signa
l() if (xCnt gt 0) urgCnt signal(xS
em) wait(urgent) urgCnt--

• semaphore mutex 1
• semaphore urgent 0
• int urgCnt 0
• methodX()
• // entry protocol
• wait(mutex)
• body of M
• // exit protocol
• if (urgCnt gt 0)
• signal(urgent)
• else
• signal(mutex)

46
CV Hoare signal-and-wait
semaphore mutex 1 semaphore urgSem 0, cvSem
0 int urgCnt 0, cvCnt 0
wait() cvCnt if (urgCnt gt
0) signal(urgSem) else signal(mutex) wait(
cvSem) cvCnt--
signal() urgCnt if (cvCnt gt 0)
signal(cvSem) wait(urgSem) urgCnt--

47
CV Mesa signal-and-continue

• Implement so that the signaling task continues

semaphore monLock 1 // monitor mutex semaphore
cvSem 0
cv.wait() wait(cvSem) wait(monLock)
cv.signal() signal(cvSem)
48
More on Monitor Implementations

• How can we control the task resumption order?
• Conditional-wait construct x.wait(c)
• c integer expression evaluated when wait
  executed.
• value of c (a priority number) stored with the
  name of the process that is suspended.
• when x.signal is executed, process with smallest
  associated priority number is resumed next.
• Verifying correctness Check two conditions
• User processes must always make their calls on
  the monitor in a correct sequence.
• Must ensure that an uncooperative process does
  not ignore the mutual-exclusion gateway provided
  by the monitor, and try to access the shared
  resource directly, without using the access
  protocols.

49
Critical Regions

• High-level synchronization construct
• A shared variable v of type T, is declared as
• v shared T
• Variable v accessed only inside statement
• region v when B do Swhere B is a Boolean
  expression.
• While statement S is being executed, no other
  process can access variable v.

50
Critical Regions

• Regions referring to the same shared variable
  exclude each other in time.
• When a process tries to execute the region
  statement, the Boolean expression B is evaluated.
  If B is true, statement S is executed. If B is
  false, the process is delayed until B becomes
  true and no other process is in the region
  associated with v.

51
Reader/Writer Locks

• Many readers, one writer
• Writer can only acquire lock if no readers are
  active - lockexclusive (rwlock_t r)
• Any reader can acquire lock if no writers are
  active - lockshared (rwlock_t r)
• There is a perhaps subtle issue with releasing
  the lock, do you schedule a waiting writer or the
  readers?
• wake all waiting threads, readers and writers
• wake a waiting writer
• wake the waiting readers

52
RW Locks

• Preferred solution limits both the number of
  context switches and addresses the starvation
  issue
• writer wakes up all sleeping readers, or another
  writer if no waiting readers.
• last reader to release lock wakes one waiting
  writer.
• to avoid writer starvation, if there is a waiting
  writer then future readers are blocked until all
  readers release lock and a writer gets to run.
• What about when a reader wants to upgrade to an
  exclusive lock?
• if two readers both call upgrade while holding
  the shared lock, then deadlock. So require shared
  lock to be released, but this means a writer
  could sneak in and change object, solution would
  be to give preference to reader's upgrade
• multiple upgrade requests are problematic, could
  return fail and release lock, thread then would
  know that it must request an exclusive lock.

53
Reference Counts

• Protects object when there are outstanding
  references
• Consider the case where several threads have a
  reference (i.e. pointer) to a data object. If one
  thread releases the object (i.e. free) and the
  kernel reallocates the object then the other
  threads have invalid references (which they may
  try to use!).
• fix kernel reference counts objects.
• When kernel provides reference to object it
  increments the reference count
• when process releases the object then reference
  count is decremented.
• when reference count goes to zero, there are
  guaranteed to be no outstanding references to the
  object.

54
Considerations

• Deadlock avoidance
• hierarchical - impose order on locks
• stochastic locking - when violating hierarchy,
  use trylock so you do not block.
• Recursive Locks - attempting to acquire a lock
  already owned by a thread succeeds.
• Adaptive Locks (Mutex)
• depending on circumstances and performance
  considerations, either a spin or blocking lock is
  used.
• Protecting invariants, predicates, data,
  operations (monitors).
• Granularity and Duration.

55
SVR4.2/MP

• Basic Locks nonrecursive mutex, short-term,
  thread may not block
• Read-Write Locks nonrecursive short-term
  thread may not block single-writer, multiple
  reader semantics.
• Sleep Locks nonrecursive locks, long-term,
  thread may block.
• Synchronization variable (condition variable).

56
Solaris

• Types
• Mutexes - spin, adaptive.
• Condition Variables
• Counting Semaphores
• Multiple-Reader, Single-Writer
• Queuing mechanism
• turnstiles - used for mutexes, reader/writer and
  semaphores
• sleep queues - condition variables.

57
NT

• Spin lock, kernel executive only.
• Executive resources. Provide exclusive and
  shared read. Kernel mode only.
• Dispatcher object (kernel supplies to executive).
  Exposed to win32 apps. Essentially an event
  queue. Only two states Signaled or NonSignaled.

58
Traditional UNIX kernel

• Kernel is
• reentrant
• nonpreemptive
• Interrupt masking
• interrupt priority level (ipl)
• kernel can set the current ipl to block
  interrupts
• Synchronization uses two flags locked and wanted
• process wanting resource
• if locked then sleep, otherwise set locked flag
• process holding resource
• when done,
• if wanted flag, then call wakeup on wait channel
• How is access to these two flags synchronized?

59
Wait Channel

• sleep (wait_channel, priority)
• special wait channels
• lbolt - awakened by scheduler once per second
• wait syscall - parent waits on its proc structure
• sigpause syscall - wait on user structure
  (u.area)
• wakeup (wait_channel) - all processes sleeping on
  a wait channel are made ready.

60
Wait Channels and Sleep Qs
Owns resource
0xf1023450
Sleep Queues
Hash function
Index
P4
P5
P6
X
X
X
Queue of processes waiting for some
resources which hashes to this index value.
61
Wait Channel Limitations

• Multiple events map to the same wait channel
• Multiple resources map to the same wait channel
• Does not support more complex protocols such as
  readers-writers

62
Wait Channels - Limitations
Sleep Queues
Hash function
Resource Y
P4
P5
P6
locked 1
Y
X
X
wanted 1
63
Classical Problems of Synchronization

• Bounded-Buffer Problem
• Readers and Writers Problem
• Dining-Philosophers Problem

64
Bounded-Buffer Problem Semaphore Solution

• Solves the lost wakeup problem
• Shared datasemaphore full 0, empty n, mutex
  1

Producer do produce item
wait(empty) wait(mutex) add item to
buffer signal(mutex) signal(full) while
(1)
Consumer do wait(full) wait(mutex)
remove item signal(mutex) signal(empty)
consume item in while (1)
65
Bounded Buffer using Monitors
monitor ProduceConsume cv full, empty int
cnt 0 insert(item_t item) if (cnt N)
wait(full) insert item if (cnt 0)
signal(empty) item_t remove() if (cnt
0) wait(empty) remove item if (cnt--
N) signal(full) monitor ProduceConsume PC
produce () while (1) produce item
PC.insert(item)
consume () while (1) item
PC.remove() consume item
66
Critical Regions Bounded Buffer

• struct buffer
• int pooln
• int count, in, out

• Producer
• region buffer
• when (count lt n)
• poolin nextp
• in (in1) n
• count

Consumer region buffer when (count gt
0) nextc poolout out (out1)
n count--
67
Readers-Writers

• Reader tasks and writer tasks share a resource,
  say a database
• Many readers may access a database without fear
  of data corruption (interference)
• However, only one write may access the database
  at a time (all other readers and writers must be
  locked out of database.
• Solutions
• simple solution gives priority to readers.
  Readers enter CS regardless of whether a write is
  waiting
• writers may starve
• second solution requires once a write is ready,
  it gets to perform its write as soon as possible
• readers may starve

68
Readers-Writers Problem

• semaphore mutex 1, wrt 1
• int rdrcnt 0

Reader // enter rdrcnt C.S. wait(mutex) rdrcnt
if (rdrcnt 1) // get reader
lock wait(wrt) // exit rdrcnt
C.S. signal(mutex) reading is performed //
enter rdrcnt C.S wait(mutex) rdrcnt-- if
(rdrcnt 0) // release reader
lock signal(wrt) signal(mutex) // exit rdrcnt
C.S.
Writer // get exclusive lock wait(wrt) modify
object // release exclusive lock signal(wrt)
69
Dining-Philosophers Problem

• semaphore chopstick5 1, 1, 1, 1,
  1

Philosopher i do wait(chopsticki) wait(chop
stick(i1) 5) eat signal(chopsticki)
signal(chopstick(i1) 5) think
while (1)
This solution can suffer from starvation, do you
see why?
70
Dining Philosophers Example

• monitor dp
• enum think,hungry,eat state5
• condition self5
• void pickup(int i)
• void putdown(int i)
• void test(int i)
• void init()
• for (int i0 ilt5i)
• statei think

void putdown(int i) statei think // test
left and right test((i4)5) test((i1)5)
void pickup(int i) statei
hungry test(i) if (statei !
eat) selfi.wait()
void test(int i) if ((state(i4)5 ! eat)
(statei hungry) (state(i1)5 !
eat)) statei eat selfi.signal()

Solution dp.pickup(i) ... eat
... dp.putdown(i)
