Database Optimisation and Database Benchmarking

1
Database Optimisation and Database Benchmarking

• David Nelson
• April 2007

2
Contents

• Introduction
• Database Benchmarking
• Wisconsin, TPC-A, TPC-B, TPC-C, AS3AP, OO7,
  BUCKY
• Query Performance and Optimisation
• Query Processing
• Indexes
• Summary and Further Reading

3
Introduction

• Software and systems development projects include
  performance evaluation work, but sometimes not
  sufficient to prevent major performance problems
• Tools available
• Prototyping
• Benchmarking
• Query processing
• Its a black art!

4
Database Benchmarking

• A tool for comparing the performance of DBMS
• summarise relative performance in a single figure
• Usually measured in transactions per second (tps)
• with a cost measure in terms of system cost over
  5 years
• Two principal uses of benchmarks
• providing comparative performance measures
• a source of data and queries that represent
  experimental approximations to other problems

5
Data Generation Approaches

• Artificial
• generation of data with entirely artificial
  properties
• designed to investigate particular aspects of a
  system, e.g. join
• e.g. Wisconsin
• Synthetic Workload
• produce a simplified version of an application
• use synthetically generated data with similar
  properties to real system, e.g. a banking
  application
• e.g.Transaction Processing Performance Council
  (TPC)

6
Benchmarks

• Relational Benchmarks
• Arfiticial Wisconsin, AS3AP
• Synthetic TPC-C (successor of TPC-A and TPC-B)
• OO Benchmarks
• Synthetic oo7 (successor of oo1)
• Object-Relational Benchmarks
• Synthetic BUCKY
• There are many other benchmarks, these are the
  most well known

7
Wisconsin Benchmark

• First systematic benchmark definition
• compares particular features of DBMS rather than
  a simple overall performance metric
• A single-user series of tests, comprising
• selections and projections with varying
  selectivities on clustered, indexed non-indexed
  attributes
• joins of varying selectivities
• aggregate functions (e.g. min, max, sum)
• updates/deletions involving key/non-key attributes

8
Wisconsin Benchmark

• Straightforward to implement
• Scalable, e.g. parallel architectures
• Useful readily understandable results
• Lack of highly skewed attribute distribution
• Simple join queries

9
TPC-A and TPC-B

• Measures performance of a simple banking
  transaction
• from initiation at a terminal until response
  arrives back from server
• benchmark encompasses time taken by server,
  network and other system components
• terminals emulated using a negative-exponential
  transaction arrival distribution
• TPC-B only measures performance of the database
  server

10
TPC-C

• Based on an order entry application
• Scope of system similar to TPC-A, but more
  complex, i.e. 9 tables rather than 5, and a
  larger range of queries
• closer to typical database applications
• more comprehensive test of DBMS features
• TPC-A and TPC-B now obsolete

11
TPC-C Schema
Taken from TPC-C Standard Specification
available at www.tpc.org
12
TPC-C

• 5 transactions covering
• New order
• A payment
• Order status enquiry
• A delivery
• A stock level inquiry
• 10 terminals at each warehouse
• All 5 transactions available at each terminal
• produce an equal number of New-Order and Payment
  transactions and to produce one Delivery
  transaction, one Order-Status transaction, and
  one Stock-Level transaction for every ten
  New-Order transactions
• Metric
• number of New-Order transactions executed per
  minute

13
Other TPC Benchmarks

• TPC-H
• Ad-hoc decision support environments
• TPC-R (now obsolete)
• Business reporting in decision support
  environments
• TPC-W (now obsolete!)
• Transactional web benchmark for e-commerce
• TPC-App
• Application server and web services benchmark
• Further info on
• www.tpc.org

14
AS3AP

• ANSI SQL Standard Scalable and Portable Benchmark
• based on Wisconsin
• series of two tests
• single-user basic features of RDBMS
• multi-user characteristics of DB workload, e.g.
  parallel and main memory DB applications
• based on throughput, excludes terminal time etc.
• queries are scalable

15
oo7

• A benchmark for Object Database Systems
• An improvement on previous oo1 benchmark
• Examines the performance characteristics of
  different types of retrieval/traversal, object
  creation/deletion and updates and query processor
• A number of sample implementations are provided
• Based on a complex parts hierarchy
• Further info
• ftp.cs.wisc.edu

16
oo7 Tests

• Test 1
• Raw traversal speed, traversal with updates,
  operations on manuals
• Tests with/without full cache
• Test 2
• Exact matches, range searches, path lookup, scan,
  make, join
• Test 3
• Insert/update a group of composite parts

17
BUCKY

• An Object-Relational Benchmark
• Objective
• To test the key features that add the object to
  object-relational database systems, as defined by
  Stonebraker
• Inheritance, Complex Objects, ADTs
• Not triggers
• Based on a university database schema
• Exists as an object-relational and a relational
  schema
• can compare performance tradeoffs between using
  object aspects of DBMS compared to purely
  relational

18
BUCKY Schema
Taken from The BUCKY Object-Relational
Benchmark, Carey, el. al
19
BUCKY Queries

• Aim is to test various object queries,
  involving
• 1. row types with inheritance
• 2. inter-object references
• 3. set-valued attributes
• 4. methods of row objects
• 5. ADT attributes and their methods
• Two BUCKY performance metrics
• O-R Efficiency Index, for comparing O-R and
  relational implementations
• O-R Power Rating, for comparing O-R systems

20
Query Performance

• Query performance is necessary to achieve
  acceptable performance of a RDBMS
• Various ways in which this can be achieved
• De-normalisation of data to reduce joins
• Creating indexes on frequently retrieved
  attributes
• Clustering tables to reduce the number of disk
  reads
• Automatic optimisation of queries

21
Query Performance

• Automatic query optimisation can dramatically
  improve query execution time
• e.g. Consider the simple SQL query
• select s.student_no, s.student_name,
  c.course_name
• from student s, course c
• where s.course_id c.course_id
• and s.age gt 25
• This query is more optimal if the selections and
  projections are performed before the join

22
Example

• 1000 students of which only 100 are over the age
  of 25, and there are 50 courses
• Alternative 1 Join first
• read the 1000 students, read all courses 1000
  times (once for each student), construct an
  intermediate table of 1000 records (which may be
  too large to fit in memory)
• restrict the result to those over the age of 25
  (100 rows at most)
• project the result over the required attributes

23
Example

• Alternative Restrict first
• read 1000 tuples but restrict to those over the
  age of 25, returning an intermediate table of
  only 100 rows - which has a much better potential
  of being storable in main memory
• join the result with the course table, again
  returning an intermediate table of only 100 rows
• project the result over the required attributes
• Obviously this version is BETTER!
• Could be improved further by doing the projection
  before the join.

24
Query Processing Stages

• Four stages in query processing
• 1. Cast the query into internal form
• normally tree based (relational algebra)
• 2. Convert to canonical form
• 3. Choose candidate low-level procedures
• using indexes, clustering, etc.
• 4. Generate query plans and choose and run
  the optimal query
• based on cost formulas and database statistics
• Rule or cost based in Oracle

25
Query Cast into Internal Form
RESULT
PROJECT over student_no,
RESTRICT where age gt 25
JOIN over course_id
S
C
26
Canonical Form

• Canonical form
• given a set Q of queries, and a notion of
  equivalence between two queries q1 and q2 in set
  Q, then there exists a subset C of Q, the set of
  canonical forms for Q, if and only if every query
  q in Q is equivalent to only one query c in C.
• The query c is the canonical form of the query q
• Uses expression transformation rules

27
Expression Transformation Rules

• Examples (not complete)
• (A WHERE p1) WHERE p2 A WHERE p1 and p2
• (A PROJECT x,y) PROJECT y A PROJECT y
• (A UNION B) PROJECT x (A PROJECT x) UNION (B
  PROJECT x)
• (A JOIN B) PROJECT x (A PROJECT x1) JOIN (B
  PROJECT x2)
• A JOIN B B JOIN A
• (A JOIN B) JOIN C A JOIN (B JOIN C)
• (A JOIN B) PROJECT x A PROJECT x
• where x is FK from B to A

28
Choose Candidate Low-Level Procedures

• How to execute the query represented by that
  converted form
• Take into consideration
• Indexes
• Other physical access paths
• Distribution of data values
• Clustering
• Specify as a series of low-level operations
• Each low level operation has a set of predefined
  implementation procedures

29
Generate Query Plans/Choose Cheapest

• Each query plan from stage 3 will have a cost
  formula generated from the cost formula for each
  low-level procedure
• Oracle supports
• Rule Based
• Rank queries according to algebra operations
• 15 rules in Oracle
• Cost Based
• Optimal rule based query may not in fact be
  optimal due to cost of operating query, e.g. join
  order
• Need to gather statistics

30
Indexes

• Indexes can be created on relations to increase
  search/access performance
• Types of index
• Primary
• Clustering
• Secondary
• Can be sparse or dense
• Most DBMSs use B-trees to hold indexes

31
Summary

• Have looked at methods for performance
  optimisation
• benchmarking is a tool for evaluating and
  comparing performance of real systems
• OO7 benchmark is to ODBS what Wisconsin is to
  RDBMS
• RDBMS systems normally include query optimisers
  to attempt to convert user queries into optimal
  queries
• Indexes and clustering can significantly improve
  query optimisation

32
Further Reading

• Bitton, De Witt and Turbyfill Benchmarking
  Database Systems A Systematic Approach, Proc.
  9th VLDB 1983.
• Carey, et. al The BUCKY Object-Relational
  Benchmark,
• http//www.cs.wisc.edu/naughton/bucky.html
• Date, chapter on Query Optimisation
• Connolly and Begg, OODB chapter has information
  on benchmarking and indexes
