Title: Data%20Mining%20Techniques%20Association%20Rule


1
Data Mining Techniques Association Rule
2
What Is Association Mining?
  • Association Rule Mining
  • Finding frequent patterns, associations,
    correlations, or causal structures among item
    sets in transaction databases, relational
    databases, and other information repositories
  • Applications
  • Market basket analysis (marketing strategy items
    to put on sale at reduced prices),
    cross-marketing, catalog design, shelf space
    layout design, etc
  • Examples
  • Rule form Body Head Support, Confidence.
  • buys(x, Computer) buys(x, Software) 2,
    60
  • major(x, CS) takes(x, DB) grade(x, A)
    1, 75

3
Market Basket Analysis
Typically, association rules are considered
interesting if they satisfy both a minimum
support threshold and a minimum confidence
threshold.
4
Rule Measures Support and Confidence
  • Let minimum support 50, and minimum confidence
    50, we have
  • A ? C 50, 66.6
  • C ? A 50, 100

5
Support Confidence
6
Association Rule Basic Concepts
  • Given
  • (1) database of transactions,
  • (2) each transaction is a list of items
    (purchased by a customer in a visit)
  • Find all rules that correlate the presence of one
    set of items with that of another set of items
  • Find all the rules A ? B with minimum confidence
    and support
  • support, s, P(A ? B)
  • confidence, c, P(BA)

7
Terminologies
  • Item
  • I1, I2, I3,
  • A, B, C,
  • Itemset
  • I1, I1, I7, I2, I3, I5,
  • A, A, G, B, C, E,
  • 1-Itemset
  • I1, I2, A,
  • 2-Itemset
  • I1, I7, I3, I5, A, G,

8
Terminologies
  • K-Itemset
  • If the length of the itemset is K
  • Frequent (Large) K-Itemset
  • If the length of the itemset is K and the itemset
    satisfies a minimum support threshold.
  • Association Rule
  • If a rule satisfies both a minimum support
    threshold and a minimum confidence threshold

9
Analysis
  • The number of itemsets of a given cardinality
    tends to grow exponentially

10
Fast Algorithms for Mining Association Rules
11
Mining Association Rules Apriori Principle
Min. support 50 Min. confidence 50
  • For rule A ? C
  • support support(A ? C) 50
  • confidence support(A ? C)/support(A)
    66.6
  • The Apriori principle
  • Any subset of a frequent itemset must be frequent

12
Mining Frequent Itemsets the Key Step
  • Find the frequent itemsets the sets of items
    that have minimum support
  • A subset of a frequent itemset must also be a
    frequent itemset
  • i.e., if AB is a frequent itemset, both A and
    B should be a frequent itemset
  • Iteratively find frequent itemsets with
    cardinality from 1 to k (k-itemset)
  • Use the frequent itemsets to generate
    association rules

13
Example
14
Example of Generating Candidates
  • L3abc, abd, acd, ace, bcd
  • Self-joining L3L3
  • abcd from abc and abd
  • acde from acd and ace
  • Pruning
  • acde is removed because ade is not in L3
  • C4abcd

15
Example
16
Apriori Algorithm
17
Apriori Algorithm
18
Apriori Algorithm
19
Exercise 4
min-sup 20 min-conf 80
20
Demo-IBM Intelligent Minner
21
Demo Database
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Multi-Dimensional Association
  • Single-Dimensional (Intra-Dimension) Rules
    Single Dimension (Predicate) with Multiple
    Occurrences.
  • buys(X, milk) ? buys(X, bread)
  • Multi-Dimensional Rules ? 2 Dimensions
  • Inter-dimension association rules (no repeated
    predicates)
  • age(X,19-25) ? occupation(X,student) ?
    buys(X,coke)
  • hybrid-dimension association rules (repeated
    predicates)
  • age(X,19-25) ? buys(X, popcorn) ? buys(X,
    coke)
  • Categorical (Nominal) Attributes
  • finite number of possible values, no ordering
    among values
  • Quantitative Attributes
  • numeric, implicit ordering among values

26
Exercise 5
min-sup 20 min-conf 80
27
Research Topics
  • Quantitative Association Rules
  • buys (bread, 5) buys (milk, 3)
  • Weighted Association Rules
  • High Utility Association Rules
  • Non-redundant Association Rule
  • Constrained Association Rules Mining
  • Multi-dimensional Association Rules
  • Generalized Association Rules
  • Negative Association Rules
  • Incremental Mining Association Rules
  • Data Stream Association Rule Mining
  • Interactive Mining Association Rules
