Consistency and Replication

1
Consistency and Replication

• Chapter 6

2
Update Propagation

• Three possibilities
• Propagate only a notification of an update
• Transfer data from one copy to another
• Propagate the update operation to other copies

3
Pull versus Push Protocols

• Push-based approach
• Also called a server-based protocol
• Server initiates the transfer without the client
  asking for it
• Pull-based approach
• Transfer happens when the client asks for it
• Advantages depend on the type of workload
• Amount of data, frequency of update, frequency of
  read-only operations

4
Pull versus Push Protocols
Issue Push-based Pull-based
State of server List of client replicas and caches None
Messages sent Update (and possibly fetch update later) Poll and update
Response time at client Immediate (or fetch-update time) Fetch-update time

• A comparison between push-based and pull-based
  protocols in the case of multiple client, single
  server systems.

5
Lease Protocols

• Have the copy expire after a period of time
• A client can ask to renew a lease
• A short lease can be given for a client than only
  uses the item infrequently the server doesnt
  have to maintain state for as long
• Have to worry about different clocks!
• Fast client, slow server
• Fast server, slow client

6
Lease Protocols

• Three kinds of leases
• Age-based leases given out on data items
  depending on the last time the item was modified
  for long-lasting data, reduce number of update
  messages
• Renewal-frequency based the client can receive
  an update to its cached copy often
• State-space overhead the server lowers the
  lease time as it becomes overloaded, thus
  reducing the amount of state information it has
  to maintain
• In all of the cases updates are pushed by the
  server as long as the lease has not expired.

7
Epidemic protocols

• Goal is to propagate replicas in as few messages
  as possible based on the model of infectious
  diseases!
• A server is infective if it holds an update that
  it is willing to spread to other servers
• A server that has not been updated yet is
  susceptible
• An updated server not willing or able to spread
  its update is said to be removed

8
Epidemic protocols

• A popular propagation model is that of
  anti-entropy
• A server P picks another Q at random and
  exchanges updates. Choices include
• P only pushes its own update to Q
• Not as rapid for spreading updates
• P only pulls in new updates from Q
• Works best when many servers are infective
• P and Q send updates to each other
• An initial push to several servers helps spread
• A variant is gossiping if a server tried to
  spread a rumor to a server that already knows it,
  it become removed with probability 1/k
• See the papers on Spinglass for more information!

9
Remote-Write Protocols (1)

• Primary-based remote-write protocol with a fixed
  server to which all read and write operations are
  forwarded.

10
Remote-Write Protocols (2)

• The principle of primary-backup protocol.

11
Local-Write Protocols (1)

• Primary-based local-write protocol in which a
  single copy is migrated between processes.

12
Local-Write Protocols (2)

• Primary-backup protocol in which the primary
  migrates to the process wanting to perform an
  update.

13
Quorum-Based Protocols

• Three examples of the voting algorithm
• A correct choice of read and write set
• A choice that may lead to write-write conflicts
• A correct choice, known as ROWA (read one, write
  all)

14
TreadMarks

• TreadMarks Shared Memory Computing on Networks
  of Workstations, by Christiana Amza, Alan L. Cox,
  Sandhya Dwarkadas, Pete Keleher, Honghui Lu,
  Ramakrishnan Rajamony, Weimin Yu, Willy
  Zwaenepoel, IEEE Computer, 29(2), 1996.
• Rice University early 1990's
• Network of workstations
• Goal - distributed shared memory

15
TreadMarks

• Runs at the user level in Unix
• Uses many techniques to reduce the communication
  overhead.
• Lazy release consistency
• A multiple writer protocol
• An API allows programs to create shared variables
  and to call synchronization primitives

16
Synchronization Primitives

• Two kinds
• Simple barrier Tmk_barrier()
• Mutex lock
• Tmk_lock_acquire()
• Tmk_lock_release()

17
Example program Jacobi decomposition

• an application to solve partial differential
  equations.
• y1 -x1 - x2 .... x3 ...
• y2 x1 x2 .... x3 .....
• Use a grid (matrix) to estimate differentiation.
• The initial configuration is Generation 1. You
  move to the next generation by modifying the
  first. Each position is modified according to its
  neighbor's values.
• Look at the guy above, below, to the right and to
  the left and calculate their numeric average.
• When new results have been computed, put them in
  the temporary scratch grid, then swap grids and
  keep going until 'youre close enough'.

18
Example program Jacobi decomposition

• If you have a really large grid, split the grid
  in half, assign p0 to one half, p1 to the other.
  Each computes their results, then they stop and
  exchange rows. Then go again.
• Each process do
• compute my portion
• Tmk_barrier()
• get new grid
• Tmk_barrier()
• // make sure everyone has fully copied to their
  new grid
• until done // until you're satisfy with your
  results.

19
TreadMarks view of memory

• At each processor
• Some portion of physical memory that is mapped to
  global shared memory
• Local memory (including cache)
• Kernel (OS memory)

20
TreadMarks compared to IVY

• IVY is a DSM system that uses sequential
  consistency and virtual memory on each
  workstation
• Memory is stored in pages
• Invalidations are sent out before writes to
  shared memory
• The next time this data item is accessed in IVY a
  page fault will be issued

21
TreadMarks compared to IVY

• For example, say processor 1 gets a page fault
  when it tries to access a page in its global
  virtual memory (the page is not there)
• This causes an interrupt to the OS
• A network message is sent to processor 2 global
  shared memory to get the page
• The mechanism then copies the page to some cache
  location of processor 1 local physical resources

22
Other problems with IVY

• False sharing
• Since memory is shared in units of a page, more
  than one process may write to the same page (but
  not to the same location)
• There is a lot of overhead and communication for
  each DSM access
• Context switch to OS kernel
• Network messages
• Interrupt processing when new page arrives

23
TreadMarks

• To reduce communication and overhead
• Use lazy consistency
• only communicate the data when it is requested
• Operate in user space
• Avoid overhead for context switches
• Adds responsibility to programmer, since the
  programmer must be aware of the use of shared
  memory
• All synchronization must be done with the
  TreadMark primitives

24
TreadMarks

• To reduce cost of false sharing use a multiple
  writer protocol
• most systems use single writer protocol
• In this protocol, the writer owns the page and no
  one else can write to the page
• Blocking to wait for access (causes delay in the
  application that may not have to be there)
• With multiple writer protocol you wait to
  communicate updates until synchronization occurs.
  (consistency traffic is deferred)
• Lowers the communication costs

25
Multiple Writer Protocol

• Idea
• When you read you acquire a copy
• When you write you make a twin (make another
  copy) in system space, then you write to the
  twin.

26
Multiple Writer Protocol

• Suppose another process makes a request then
• - compare twin with original and make a diff
  file (the diff between the twin and the original)
• - the diff's are then sent
• - at the same time, discard the twin (since you
  have a record of changes in the diff file).
• Since the diff is smaller than the whole page,
  the amount of communication is smaller.
• Caveat is you have to use appropriate TreadMarks
  synchronization tools to ensure program
  correctness.
