Fundamentals of CS 2: Databases REVISION WEEK 2

1
Fundamentals of CS 2DatabasesREVISION WEEK 2

• John Barnden
• Professor of Artificial Intelligence
• School of Computer Science
• University of Birmingham, UK

2
What Is a Database? contd.

• A database is generally a regularly (but often
  complexly) structured body of information about
  entities of various specific, precisely defined
  types.
• The entities are generally in various specific
  types of relationship to each other
• Each entity has a specific set of (intrinsic)
  attributes of interest.
• The values of intrinsic attributes are generally
  of fairly basic, simple sorts (e.g., numbers,
  dates, names).
• Generally there are many entities of some of the
  types or rather the expectation is that the
  numbers could get large.
• The entities of a given type are typically not in
  any special order.

3
What Is a Database(?) contd.

• The individual data elements held, though of
  simple sorts, are generally close to end-user
  concepts and concerns -- they are directly
  meaningful interesting to users. E.g., price of
  a car.
• Contrast the detailed meteorological
  measurements across the country and beyond, used
  in a weather forecasting system for the UK.
• The data held and retrieved is generally of exact
  form (no vagueness expressed) and of definite
  form (no uncertainty expressed or expected).
• The operations provided to users for extracting,
  inserting and updating data are of conceptually
  straightforward sorts, not requiring elaborate
  reasoning, problem-solving or analysis.
• However, aggregate/overview/statistical
  information (counts, averages, maxima, graphs,
  histograms, etc.) often needs to be computed from
  the data.

4
What We Mainly Studied

• The nature of relational databases, the central
  modern type of database. Entity types represented
  as tables, holding relations.
• Some basic mathematical concepts underpinning
  relational databases, and useful also in many
  other branches of CS.
• Key aspects of how to develop the
  conceptual/logical design of relational
  databases.
• In particular, how to achieve certain types of
  good structuring, to help achieve certain types
  of correctness and efficiency.
• How to create and manipulate databases using a
  particular database language, PostgreSQL (a
  version of Structured Query Language very widely
  used in various forms).

5
Data Redundancy, Data Anomalies, and Data
Integrity

• See Ch.1 and many other parts of book.
• Data Redundancy replicating data in different
  places in a data repository.
• E.g., in a recipe book, saying how to fry onions
  every time fried onions are needed in a recipe.
• Encourages data anomalies and lack of
  integrity basically, inconsistency between
  the different places.
• Such problems arise with insertions, deletions
  and modifications in general.
• Also causes a type of inefficiency replicated
  updates.

6
Redundancy, etc., contd. 1

• Redundancy implies that if you want to
  modify/delete a piece of information, you need to
• know that there is (or is not) replication, or
  check for possible replications
• go to the effort of repeating changes when the
  item is replicated
• avoid errors in such repeated changes.

7
A Conceptual Model

• Represents global view of the database
• Enterprise-wide representation of data as viewed
  by high-level managers
• Basis for identification and description of main
  data objects and relationships, avoiding
  details

8
The Entity Relationship Model

• Introduced by Chen in 1976
• Most widely used conceptual model of DBs
• The ER model strictly speaking is just the
  approach of thinking of things as composed of
  entities, attributes and relationships it has
  nothing intrinsically to do with diagrams
  J.A.B.
• We also say that applying this approach to a
  particular body of data gives rise to an ER model
  of the specific intended database
• But diagrams based on the model are a widely
  accepted and adapted graphical approach to data
  modeling

9
Entity Relationship Diagrams (ERDs)

• The ER model of a database forms the basis of an
  ER diagram (or several diagrams).
• The ERDs represent the database as viewed by end
  users.
• There are several markedly different styles of
  ERD, and for each main style there are several
  variants.
• And the style in the module handouts will differ
  somewhat from that in the textbook and these
  lectures
• An ERD depicts (some of) the ER models entities,
  attributes and relationships, and (depending on
  the diagram style) varying amounts of other info
  such as connectivities, cardinalities, keys,
  weakness,

10
Meriting Tables

• The question of what types of thing should
  correspond to entity types and hence tables
  depends on the application and your design
  judgment.
• It all depends on things like
• what variety of data is needed about something
• how separate the pieces of data about a given
  thing are
• what operations are needed
• how often theyre needed.

11
Restrictions on our Tables

• We will apply the following restrictions amongst
  others
• Regular overall shape rows all same length,
  similarly columns. No division into different
  regions (with a certain exception).
• No labels for rows, as opposed to columns. No
  significance to the order or number of rows (the
  number can change).
• All cells in any one column given same intuitive
  interpretation.
• One data item per cell (but it can be a
  variable-length character string, containing
  anything).
• Each cells item restricted to a pre-specified,
  fairly simple format, and all cells in any given
  column restricted to same format. No exceptional
  entries.
• Uncertainty markers not recognized though
  tolerated in principle.
• Some columns not supposed to have empty or vague
  entries.
• No additional comments, footnotes, etc.

12
A Bad Table
13
Extra, Crucial Restriction

• No row can be repeated in a table. (I.e., no two
  rows can contain be exactly the same in terms of
  the values they contain.) Exception
  dynamically-created, temporary tables.
• Equivalent to saying
• Rows are uniquely determined (picked out) by the
  values in some set of columns. That is, given
  some values for those columns, there is at most
  one row that has those values in those columns.

14
Attribute Determination

• A collection of one or more attributes determines
  another attribute A if only one value for A is
  possible given the values for the former
  attributes.
• E.g., the collection DAY-NUMBER, MONTH and YEAR
  could determine DAY-NAME.
• Also write this as DAY-NUMBER, MONTH, YEAR ?
  DAY-NAME
• We alternatively say that DAY-NAME is
  functionally dependent on DAY-NUMBER, MONTH and
  YEAR.

15
Keys(RC pp.82/3)

• A key for a table is a collection of one or more
  attributes that determines some other
  attribute(s) in that same table.
• A superkey for a table is a collection of one or
  more attributes that determines all the other
  attributes in the table, i.e. determines a whole
  row.
• Trivially, the collection of all the attributes
  is a superkey.
• A candidate key is a minimal superkey (i.e., you
  cant remove attributes from it and still have a
  superkey.)

16
Primary Keys

• A primary key for a table (entity type) is a
  candidate key that the DB designer has chosen as
  being the main way of uniquely identifying a row
  (entity). Extra restriction Its attributes are
  not allowed to have null values.
• It could be that theres only one candidate key
  in practice anyway, such as a persons ID number.
• Primary keys are the main way of identifying
  target entities in entity relationships, e.g.,
  the way to identify someones employing
  organization.
• For efficiency reasons, the simpler primary keys
  are the better.
• Identity numbers (of people, companies, products,
  courses, etc.), or combinations of them with one
  or two other attributes, are the typical primary
  keys in examples in RC.

17
Strong and Weak Relationships

• Also called identifying and non-identifying
  relationships respectively.
• A relationship from entity type A to entity type
  B, mediated by having As primary key (PK) as an
  attribute of B, is strong when Bs PK contains
  As.
• E.g., A People, B Dependents, where each
  entity in People is identified by a PERS_ID (As
  PK) and each entity in Dependents is identified
  by a PERS_ID plus a first name and a
  kinship/friendship attribute.
• So a PK value in B could be (1698674, Mary,
  child), meaning that this entity is the child
  called Mary of person 1698674.
• A relationship is weak when it isnt strong.

18
Strong and Weak Entity Types

• A weak entity type is one to which there is at
  least one strong relationship going to it from
  another entity type.
• So on previous slide, Dependents is weak, because
  there is a strong relationship to it from People.
• A strong entity type is one that is not weak!
  i.e. there are no strong relationships going to
  it from another type.
• A weak entity is existence-dependent on every
  entity type that has a strong relationship going
  to it.
• Marys existence in the database as a member of
  Dependents relies on the existence of person
  1698674 in the database. (Doesnt mean Mary would
  vanish from the planet if person 1698674 left the
  database! And indeed Mary could herself be an
  entity in type People even if 1698674 leaves.)

19
Connectivity Cardinality

• Relationships are importantly categorized as to
  uniqueness or multiplicity of entities at either
  end connectivity. Has big effect on DB design.
• Relationships can be further specified as to how
  many entities allowed or required at either end
  cardinality.
• Also has significant effect on DB design.

20
Relationship Participation

• Optional in a particular direction, X to Y
• an X entity occurrence does not require a
  corresponding Y entity occurrence
• i.e. the minimum number of Ys per X is 0
• Mandatory in a particular direction, X to Y
• an X entity occurrence requires a corresponding Y
  entity occurrence
• i.e. the minimum number of Ys per X is 1 or more

21
Relationships and Foreign Keys

• A foreign key in a table T is a chosen collection
  of attributes intended to match the attributes in
  the primary key in another table. In essence, the
  foreign key is that primary keys ambassador in
  T.
• Standardly, a relationship is represented by
  means of foreign keys.

22
1M Connectivity between Tables
More than one employee allowed per organization,
but no more than one employer per person. NOTE
direction of use of a foreign key. Why so??
People
Organizations
23
MN Connectivity between Tablesusing a Bridging
Entity Type
People
Employments
Organizations
24
Creating ER Models/Diagrams

• Designing an ER model for a database is an
  iterative process, because, e.g.
• As you proceed, you think of new ways of
  conceiving whats going on (much as in ordinary
  programming)
• Multivalued attributes need to be re-represented
• MN relationships can be included as such at an
  early stage, but generally need to be replaced by
  bridging entity types at some point
• 11 relationships raise a red flag may indicate
  poor design (though standard in supertype/subtype
  representation)
• Special supertype/subtype notation may need to be
  converted into more standard diagram notation
• Conversion to a Normal Form

25
Examples in Two Styles of Diagram
26
Multivalued Attributes in ERMs and ERDs
27
Splitting the Multivalued Attribute into New
Namable Component Attributes
28
OR, Replace the Attribute by a New Entity Set
with an Attribute identifying the Original
Attributes Separate Components
29
Generalization Hierarchies in ERMs and ERDs
30
A Generalization Hierarchy with Overlapping
Subtypes (Gs)and Disjoint Subtypes (G)
31
Supertypes/Subtypes in ERDs
A supertype maintains a 11 relationship with
each subtype optional in the super-to-sub
direction and mandatory in the other
32
Non-Binary and Recursive Relationships in ERMs
and ERDs
33
Tables for a Ternary Relationship
CFR is just like a bridging entity type for a
binary MN relationship, but has 3 foreign keys
instead of 2
34
Recursive Relationships

• Relationship can exist between occurrences of the
  same entity set
• E.g. marriage, management, parthood,

35
Table for the 1M EMPLOYEE Manages EMPLOYEE
Recursive Relationship
36
Tables for the MN Recursive PART Contains PART
Relationship
The COMPONENT entity type is just a bridging type
37
Alternative Implementations of a 11 Recursive
Relationship

• As previously.
• MARRIED_VI is just a bridging entity type.
• MARRIAGE together with MARPART act similarly as
  bridge.

38
NORMALIZATION(Ch. 5 of RC)
39
In this chapter, you learn

• What normalization is and what role it plays in
  the database design process
• About the normal forms 1NF, 2NF, 3NF, BCNF, and
  4NF
• How normal forms can be transformed from lower
  normal forms to higher normal forms
• That normalization and ER modeling are used
  concurrently to produce a good database design,
  helping to eliminate data redundancies
  anomalies.
• That some situations require denormalization to
  generate information efficiently

40
First Normal Form

• Tabular format in which
• All attributes are dependent on a chosen
  primary key
• Primary-key attributes do not have NULL values
• There are no repeating groups in the table
• All relational tables satisfy 1NF requirements

41
A Table that is Not in 1NF because of repeating
groups
42
Second Normal Form

• Table is in second normal form (2NF) if
• It is in 1NF and
• It includes no partial dependencies
• Convert to 2NF by creating a new table for each
  part of the primary key that provides partial
  dependencies, and moving out the corresponding
  dependent attributes into the new tables.

43
A Dependency Diagram for a Table that is merely
in 1NF (by having a partial dependency)
44
Second Normal Form (2NF) Conversion Results
45
Third Normal Form

• A table is in third normal form (3NF) if
• It is in 2NF and
• It contains no transitive dependencies

46
Conversion to Third Normal Form

• For every transitive dependency, take its
  determinant (the attribute or collection of
  attributes on which the dependency rests) as a
  PK for a new table.
• Move the attributes dependent on the determinant
  to that new table.

47
Third Normal Form (3NF) Conversion Results
48
The Boyce-Codd Normal Form (BCNF)

• A table is in BCNF if every one-attribute
  determinant in the table is a candidate key
• i.e., every attribute that determines any other
  attribute determines all the attributes, and
  therefore determines a unique row, so theres no
  redundancy problem

49
A Table in 3NF but not in BCNF
50
Decomposition to BCNF
The middle diagram shows that changing the PK so
as to include C doesnt work
51
Plusses/Minusses of Normalization

• PLUS Unnormalized tables in a production
  database tend to have these defects
• Data updates are less efficient because programs
  that read and update tables must deal with larger
  tables
• Indexing is much more cumbersome
• MINUS Joining larger number of tables takes
  additional disk input/output (I/O) operations and
  processing logic
• Reduces system speed
• Conflicts among design efficiency, information
  requirements, and processing speed are often
  resolved through compromises that may include
  denormalization

52
MATHEMATICAL VIEW
53
Tuples in a Table
People

• The tuples are
• ?9568876A, Chopples, 37gt
• ?2544799Z, Blurp, 21gt
• ?1698674F, Rumpel, 88gt

54
Cartesian Product of Domains

• The set of all possible tuples formed from the
  domains is called the Cartesian product of the
  domains.
• (This applies to any sets, not just domains in
  tables.)
• Notation, e.g. D ? E ? F ? G ? H
• if D, E, F, G, H are the sets (domains)not
  necessarily different.
• In discrete mathematics, any subset at all of
  that Cartesian product is called a relation on
  the sets in question (D, E, )
• even the whole of the product (even if infinite)
• and even the empty set.
• (The notion of relation is very useful in CS as a
  whole.)

55
Relation from a Table
People

• The relation at the moment is
• ? ?9568876A, Chopples, 37gt
• ?2544799Z, Blurp, 21gt
• ?1698674F, Rumpel, 88gt ?

56
A Table as a Relation?

• People loosely talk about tables being relations.
• This is mathematically inaccurate for two
  reasons
• The table properly speaking includes not just the
  rows but also the attributes themselves, their
  domains, specification of primary and foreign
  keys, etc.
• Its only the rows at any given moment that form
  a relation.
• But OK if you know what you (and they) mean.

57
Relations from Somewhere to Somewhere

• Some convenient terminology of my own
• A relation R from A1, A2, A3, to B1, B2, B3,
  is a subset of A1 ? A2 ? A3 ? B1 ? B2 ? B3 .
• i.e., R ? A1 ? A2 ? A3 ? B1 ? B2 ? B3 .
• Same thing as a relation on A1, A2, A3, B1, B2,
  B3, just different terminology.

58
Totality and Partiality

• A relation R from A to B is total (on A) if it
  relates everything in A to one or more things in
  B.
• I.e., for every member a of A, there is at least
  one b in B such that ?a, bgt is in R.
• A relation that is not total is (merely) partial
  (on A above).
• But we can always make R total by slimming A
  down enough!
• Can generalize
• A relation R from A, B, C, to D, E, is total
  (on A, B, C, ) if for every member a of A, b of
  B, c of C, etc. there is at least one d in D, e
  in E, etc. such that ?a, b, c, , d, e, gt is in
  R.

59
Partiality of Tables

• The relation in a table, considered as a relation
  from its first attribute domain to the remaining
  attribute domains, will almost always be merely
  partial.
• Similarly, any attribute-reordered version of the
  tables relation will be merely partial.
• We can sum this up by saying that the relation is
  partial on each of its attribute domains.

60
Functional Relations

• A relation from A to B is functional if, for any
  a in A, there is at most one b in B such that ?a,
  bgt is in R.
• A total functional relation from A to B is called
  a function from A to B.
• A (merely) partial functional relation from A to
  B is called a (merely) partial function from A to
  B.
• Can generalize a relation from A1, A2, A3 to
  B1, B2, B3, is functional if, for any a1, a2,
  a3, in A1, A2, A3, respectively, there is at
  most one b1, b2, b3, in B1, B2, B3,
  respectively such that ?a1, a2, a3, , b1, b2,
  b3, gt is in R.

61
Functional Relations arising from Dependency
Relationships

• Suppose attribute X is functionally dependent on
  ( determined by) attributes A, B, in a table.
• Restrict to the subtable that just has attributes
  X and A, B, , with A, B, first.
• Then the relation in this subtable is a partial
  function from the A, B, domains to the X
  domain.
• In particular, each attribute X outside the
  primary key of a table is functionally dependent
  on the primary key, so we have a partial function
  from the PK domains to the X domain.

62
Other Categories of Relation

• A relation R from A to B is one-to-one (1-1) if,
  for any a in A, there is at most one b in B such
  that ?a, bgt is in R, AND for any b in B, there is
  at most one a in A such that ?a, bgt is in R.
• That is, both the relation and its inverse from B
  to A are functional.
• To put it another way it is functional and
  different members of A map to different members
  of B.
• Or again Different members of A map to different
  members of B and different members of B map to
  different members of A.

63

• A relation R from A to B is many-to-one if it is
  functional but not necessarily one-to-one i.e.,
  there may be at least one case of different
  members of A mapping to the same member of B.
• A relation R from A to B is one-to-many if it is
  NOT necessarily functional but its inverse from B
  to A is functional i.e., there may be at least
  one case of a member of A mapping to more than
  one member of B, but each member of B can map to
  at most one member of A.
• A relation R from A to B is many-to-many if
  neither it nor its inverse is necessarily
  functional i.e., there may be at least one case
  of a member of A mapping to more than one member
  of B, and there may be at least one case of a
  member of B mapping to more than one member of A.

64
Relations from Entity Relationships

• E.g., the EMPLOYED-BY relationship from the
  People entity type to the Organizations entity
  type says that the database (at any moment)
  stores a relation from the People entity set to
  the Organizations entity set.

65
Example Continued

• So at any given moment the relation might be
• ?Person1, Org1gt, ?Person2, Org1gt, ?Person3,
  Org1gt,
• ?Person4, Org2gt, ?Person3, Org2gt
• Each Person.. and Org.. is an entity ...
  therefore represented as a row of the
  corresponding table ... therefore itself
  mathematically represented as a tuple of
  attribute values
• So ?Person1, Org1gt could be, in more detail,
• ? ?E156, Sam, Finks, I678gt, ?I678, IBM,
  USAgt gt
• Note the nested tuples.

66
Bridging Entity Types

• Recall that bridging entity types are brought in
  to represent MN relationships (and similarly
  MNP relationships, etc.)
• People/Organizations again the relation in the
  bridging table would look like ? E156, I678gt, ?
  E257, I996gt, ?E714, I678gt, .
• This relation can also be said to correspond to
  the original People-Organization relationship,
  but is abstracted from the above relation by
  replacing tuples representing entities, such as
  ?E156, Sam, Finks, I678gt, by the PK values in
  them, such as E156.

67
Connectivities

• If a relationship from an entity type to another
  is 11, then at any moment the actual relation
  must be one-to-one (1-1).
• If the relationship is 1M then the relation at
  any moment is allowed to be one-to-many (but may
  by chance be one-to-one).
• If the relationship is MN then the relation at
  any moment is allowed to be many-to-many (but may
  by chance be one-to-one, one-to-many, or
  many-to-one).

68
Optionality/Mandatoriness

• If a relationship from an entity type E to
  another type F is mandatory then the relation at
  any moment is total when restricted to the set
  of entities currently in E (and NOT on the whole
  entity set of E, unless all possible entities of
  type E are in the E table!!).
• Observation So if it is also one-to-one or
  many-to-one it is in fact a function on the
  current set of E entities to the set of
  organizations.
• If a relationship from an entity type E to
  another type F is optional then the relation is
  not required to be total in the above sense (but
  may happen to be).

69
Maths continued towards Relational Operators
in Databases
70
Some Operations on Sets in General

• Union of sets A and B
• A ? B the set of things that are in A or B (or
  both).
• NB no repetitions allowed!
• Intersection of sets A and B
• A ? B the set of things that are in both A and
  B.
• Difference of sets A and B
• A ? B the set of things that are in A but not
  B.
• Note also notated by a backslash instead of a
  minus sign.

71
General Set Operations contd.

• I need to define also the non-standard notion of
  flattened Cartesian product of two sets A and
  B, applicable when the members of A and B are
  already tuples. Notated by the symbol ?
  (underlined multiplication symbol).
• A ? B the set of tuples that are the
  concatenations of members of A and members of B.
  E.g., if lta,b,cgt is in A and ltd,e,fgt is in B then
  lta,b,c,d,e,fgt is in A ? B.

72
General Set Operations contd.

• So if A is the People relation and B is the
  Organizations relation,
• A ? B has members of form
• ? ?E156, Sam, Finks, I678gt, ?I459,
  Dell, UKgt gt
• BUT
• A ? B has members of form
• ?E156, Sam, Finks, I678, I459, Dell,
  UKgt

73
Relational Database Operators

• Relational algebra
• Defines theoretical way of manipulating tables
  using relational operators that mainly
  manipulate the relations in the tables.
• SELECT
• PROJECT
• JOIN (various sorts)
• INTERSECT
• Use of relational algebra operators on existing
  tables produces new tables

• UNION
• DIFFERENCE
• PRODUCT
• DIVIDE

74
Select

• SQL
• SELECT FROM WHERE
• Note its the WHERE part that is actually doing
  the selection according to a criterion.
• Maths of relations
• No particular notation for result relation. Could
  express as
• t ?R t satisfies C
• where R is the relation in the given table and C
  is the criterion.
• Relational algebra notation in handout
• Result table is ?C(T) where T is the given table.
• More compact than SQL notation.
• Problem relations and RA dont account for
  duplicates of rows, if there are any in the given
  table.

75
Project

• SQL
• SELECT FROM
• Note its the after the SELECT that is
  actually doing the projection (selection of
  specified attributes)!!
• Maths of relations
• No particular concise notation for result
  relation. Could express as
• t ?P there is a tuple u in R such that t is u
  with such and such components removed
• where R is the relation in the given table and P
  is the Cartesian product of the domains of the
  selected attributes.
• Relational algebra notation in handout
• Result table is ?X(T) where T is the given table
  and X is the list of selected attributes.
• Problem relations and RA dont account for
  duplicates of rows, if there are any in the given
  or result tables.

76
Union and Intersection

• SQL
• UNION, INTERSECT (UNION ALL, INTERSECT ALL)
• Maths of relations
• Result relations are R1 ? R2 and R1 ? R2
• where R1and R2 are the relations in the given
  tables (under the assumption that they have their
  attributes listed in the same order).
• Relational algebra notation in handout
• Result tables are T1 ? T2 and T1 ? T2 where T1
  and T2 are the given tables.
• Problem relations and RA dont account for
  duplicates of rows, so dont handle UNION ALL or
  INTERSECT ALL.

77
Difference

• SQL
• MINUS or EXCEPT (MINUS ALL or EXCEPT ALL)
• Maths of relations
• Result relation is R1 ? R2
• where R1and R2 are the relations in the given
  tables (under the assumption that they have their
  attributes listed in the same order).
• Relational algebra notation in handout
• Result table is T1 ? T2 where T1 and T2 are the
  given tables.
• Problem relations and RA dont handle EXCEPT ALL.

78
Product or Cross Join

• SQL
• SELECT FROM two or more tables
• NB its the mere listing of the tables that does
  the Product, but its possible also to write
• SELECT FROM T1 CROSS JOIN T2 CROSS JOIN ...
• Maths of relations
• Result relation is R1 ? R2 where R1and R2 are the
  relations in the given tables.
• Relational algebra notation
• Result table is T1 ? T2 where T1 and T2 are the
  given tables.
• Problem relations and RA dont account for
  duplicates of rows, if there are any in the given
  tables.

79
Natural Join

• Links two tables by finding rows in each that
  match on the attributes the two tables have in
  common (if any), and then joining the matching
  rows together in a natural way.
• The common attributes or columns are called the
  join attributes or columns) just the AGENT_CODE
  attribute in above example
• Can be thought of as the result of a three-stage
  process
• the PRODUCT of the tables is created
• a SELECT is performed on the resulting table to
  yield only the rows for which the join-attribute
  values (e.g. AGENT_CODE values) are equal
• a PROJECT is now performed to yield a single copy
  of each join attribute, thereby eliminating
  duplicate columns

80
Natural Join (continued)

• SQL
• SELECT FROM T1, T2 WHERE explicit
• statements of equality of ALL the shared
  attributes ...
• NB its possible also to write
• SELECT FROM T1 NATURAL JOIN T2
• and see book section 7.2 for more.
• Maths of relations
• No standard concise notation. Result relation
  could be expressed as the result of Project and
  Select operations on R1 ? R2 where R1 and R2 are
  the relations in the given tables.
• Relational algebra notation
• Result table is T1 ... T2 where T1 and T2 are the
  given tables and the is a symbol I cant find
  in PowerPoint!

81
Other Forms of Join

• Equijoin (often what you have been doing in SQL
  work)
• Links tables on the basis of an equality
  condition that compares SPECIFIED attributes of
  each table, rather than automatically taking the
  common attributes.
• These specified join attributes do not have to
  have the same name.
• Result does not eliminate duplicate columns
• Outer Join (various forms) includes (some)
  non-matching rows
