Title: GOES-R Support to Future NWS Weather Applications


1
GOES-R Support to Future NWS Weather Applications
NOAAs National Weather Service
  • Dr. Frank P. KellyNWS Office of Science and
    Technology
  • Third GOES-R Users Conference
  • May 12, 2004Broomfield, CO

2
Future Observing Systems Observing System Trends
to Support Weather Applications
  • How Can GOES-R Contribute to Each of These
    Categories?
  • Integrated Observing Systems
  • Increasing Resolution (temporal, spatial, and
    spectral)
  • Increasing Parameters Observed
  • Improving User End of the End-to-End Process

3
Integrated Observing Systems
  • Improve temporal, spatial, and spectral
    resolution
  • Obtain observations of new environmental elements
  • Integrate multi-purpose observing systems and
    networks within an extensible enterprise
    architecture (EA)
  • Determine where GOES-R data can complement the
    current and planned systems

4
Integrated Observing Systems Objectives
  • Deliver required improvements in observational
    capabilities
  • - Focus improvements to do more with existing
    capabilities
  • - Provide complete sets of weather water data
    and applications when and where needed
  • - Leverage non-NOAA resource opportunities and
    partnerships
  • Build an effective system-of-systems
    infrastructure
  • - Enhance performance, continuity and
    interoperability across NOAA
  • - Bridge and coordinate research-to-operations
    across NOAA
  • Establish efficient business processes
  • - Exercise seamless control and timely ST
    infusion into operations
  • - Balance investment strategy for near-term
    acquisition vs long-term RD

5
Integrated Observing Systems Increasing
Resolution - Temporal
  • NWS Requirements (from GOES Operational
    Requirements Documents)
  • Imager
  • Threshold CONUS every 5 min full disk every 15
    min
  • Goal CONUS every 1 min full disk every 15 min
  • Sounder
  • Threshold 12000x12000 km every 60 min
  • Goal full disk every 60 min
  • Alleviate the current full disk versus mesoscale
    conflict
  • Better monitoring and detection of significant
    weather events (continuous 5 min imagery)
  • - Hurricanes, thunderstorms

6
Integrated Observing Systems Increasing
Resolution - Temporal
  • For example, RSO is integral to NWS operations
  • GOES-R capability available in normal
    operating mode

7
Integrated Observing Systems Increasing
Resolution - Spatial
  • NWS Requirements
  • Imager
  • Threshold VIS 0.5 km IR 2 km
  • Goal VIS 0.2 km IR 0.5 km
  • Sounder
  • Threshold 10 km
  • Goal 2 km
  • Better monitoring and detection of significant
    weather events
  • Inside eye of hurricane, thunderstorm outflows,
    fog, fires, smoke, turbulence, instability,
    winter storms

8
Integrated Observing Systems Increasing
Resolution - Spatial
  • For example, monitor fires and smoke plumes
  • Monitor fog/stratus
  • Monitor hurricanes

9
Integrated Observing Systems Increasing
Resolution - Spectral
  • NWS Requirements
  • Imager
  • Threshold 8 channels
  • Goal 19 channels
  • Sounder
  • Threshold temp 1K/1km humidity 10
  • Goal temp 1K/1km humidity 10
  • Increased spectral resolution will allow
    discrimination among different parameters
  • Better vertical resolution in profiles (0.5-2 km)

10
Integrated Observing Systems Parameters Observed
  • GOES-R can measure increased number of parameters
  • - Lightning (land and ocean), solar (energetic
    particles, auroral boundary, neutral density
    profile, etc), cloud characteristics (particle
    size distribution, phase, etc)
  • GOES-R can better measure key parameters
  • - Fog, winds, stability, SST, ozone, aerosols,
    profiles, soil moisture, vegetative
    type/greenness, etc

11
Integrated Observing Systems Parameters Observed
  • Higher resolution SST, vegetation, cloud phase
  • New services ozone forecasts

12
Improving User End of the End-to-End Process
  • Need to develop strategies for
  • Dissemination
  • Display/Application
  • Assimilation
  • Training

13
Strategy to Improve Dissemination
  • Increase in data volumes would overload current
    bandwidth
  • What is the concept of operations?
  • - Central production of images/products (current
    paradigm)
  • - Delivery of raw data to WFOs/RFCs and produce
    images/products locally
  • Algorithms could be centrally managed
  • Strategy
  • Coordination and collaboration among NWS and
    NESDIS is necessary to ensure a cost effective
    solution is chosen
  • Form Integrated Work Team to deal with
    dissemination issues

14
Strategy to Improve Display/Applications
  • AWIPS is the NWS vehicle for display and
    interaction with satellite data
  • Current capabilities
  • Imagery is good
  • Others need work
  • For example, profiles and winds are not easy to
    load and/or manipulate
  • Strategy
  • Collaboration among NESDIS, OAR (FSL), and NWS to
    improve display/applications capabilities
  • Inclusion of satellite data in digital forecast
    process
  • Tailored products to aid the digital forecast
    paradigm
  • - Form Integrated Work Team to deal with data
    display/applications issues

15
Strategy to Improve Assimilation
  • Needed in the new digital forecast paradigm
  • - Development of Analysis of Record
  • Satellite data to fill in gaps in existing
    observing systems
  • Used to verify digital forecasts
  • Used in digital forecast process
  • - Short term forecasting
  • Tools needed to blend satellite data trends into
    digital forecast
  • Strategy
  • Collaboration among NESDIS and NCEP to ensure
    optimal use of new data
  • Incorporate this into the Joint Center for
    Satellite Data Assimilation

16
Strategy to Improve Training
  • Many new products unfamiliar to forecasters
  • Application of existing and new products in new
    ways
  • Blending into short-term digital forecasts
  • Verification of digital services
  • Strategy
  • Include training resources in overall GOES-R
    budget
  • Develop training material for blended learning
  • Distance learning
  • Residence workshops
  • Teletraining

17
Summary
  • GOES-R will provide service enhancements
  • Improved support to core missions
  • - Protection of life and property
  • - Enhance the National Economy
  • New services supported
  • - Air quality
  • Homeland Security
  • Coast, estuaries, oceans
  • Goals
  • Integrate GOES-R in the Integrated Observing
    System
  • Take advantage of increased resolution and
    parameters observed
  • Improve the End-to-End Process
  • Implement new satellite data/products more
    quickly after launch
  • Size end-to-end system processing and computing
    resources to accommodate data volume increase
