DNS Solution User Plane Roaming LBS Roaming
Meeting, San Francisco November 28, 2006
2
Trusted User Plane Roaming

• Trusted user plane roaming seems straightforward
• The roaming MS can simply connect with the V-PDE
• Call flow (IS-801-1) same for MS/V-PDE
  MS/H-PDE
• However, there is an issue
• MS is provisioned to access the H-PDE
• MS needs to access the V-PDE
• How does the roaming MS know the IP address of
  the V-PDE?

3
High Level Solution Overview

• If the MS knows its own location
• It can map its location to the appropriate V-PDE
  IP address

Visited Operator (Gotham Wireless)
IP address 66.3.3.34
Where am I? Gotham Wireless Gotham Wireless PDE
IP address 66.3.3.34
V-PDE
IS-801-1
PDSN
4
Determining Location

• CDMA networks broadcast values that identify
  themselves uniquely
• System Identification Code (SID)
• EV-DO SectorID
• Mobile Country Code Mobile Network Code
  (MCCMNC)
• MS has access to these broadcasted values
• MS needs only to map a broadcasted value to the
  IP address of the V-PDE

5
Mapping Location to V-PDE IP Address

• SID/SectorID information broadcasted by CDMA
  networks changes over time
• MCCMNC is constant, but many operators dont
  broadcast these values
• Therefore, preferable to resolve mapping on a
  network server
• DNS solution
• MS creates URL based on network broadcast
  information
• DNS is provisioned to return IP address of V-PDE
  for possible URLs

6
DNS Solution Illustrated

• MS receives SID value from radio network
• MS creates SID-based URL (SID.Local.PDE)
• MS resolves URL to V-PDE IP address via DNS
  server
• MS accesses V-PDE

Visited Operator
IP address 66.3.3.34
SID10856
V-PDE
10856.Local.PDE 66.3.3.34
DNS
PDSN
URL10856.Local.PDE
7
DNS Solution with Mobile IP or L2TP Roaming

• Many roaming implementations use Mobile IP or
  L2TP
• Industry direction is Mobile IP (CDG resolution)
• In these cases, data traffic is tunneled back to
  the home operator
• H-DNS server or V-DNS server might be used
  (inconsistent between implementations)
• MS accesses V-PDE from home operator (security
  issue?)

Visited Operator
Home Operator
Network connection
MIP/L2TP tunnel
Internet
H-DNS Server
HA/LNS
PDSN/FA/LAC
PDSN
V-DNS Server
V-PDE
PCF
BSA
RAN
IS-801 signaling
8
V-PDE Port Issue

• Some LBS applications are configured to require
  PDE access via a unique port
• For the DNS solution, these applications will
  try and access the V-PDE via this unique port
  number
• The V-PDE must be configured to accept
  connections for roaming MS applications on these
  particular ports
• There could be ongoing operational requirements
  to reconfigure the V-PDE as new applications come
  on line

9
Advantages of DNS Solution

• No PDE changes required
• Provisioning of DNS information is relatively
  minor
• If no MS changes required, then DNS solution is
  fastest to market

10
Challenges with DNS Solution

• MS Behavior
• Can MS/application use network broadcast
  information to create URL?
• Need to verify with application/handset/chipset
  providers
• If new MS behavior is required
• Long delay in getting new MS behavior implemented
• Issue with legacy mobiles
• Inconsistent MS access of DNS server (home vs.
  visited)
• In some roaming implementations, visited operator
  DNS accessed
• In some roaming implementations, home operator
  DNS accessed
• Need to coordinate population of DNS servers with
  MS DNS access behavior
• V-PDE Port Issue
• Could require significant coordination and
  configuration

11
Challenges with DNS Solution (cont.)

• LBS and DNS server operational considerations
• LBS operations usually separate from DNS
  operations
• Requires significant coordination between two
  separate groups
• Security issues
• Operators must expose PDEs directly to roaming
  mobiles
• If Mobile IP or L2TP used, there are additional
  security issues
• Must expose PDE to all mobiles serviced by home
  operator HA/LNS
• This includes non-roaming mobiles in the home
  operator network
• No home operator awareness of V-PDE access
• No home operator logging possible
• Hinders any financial settlement process between
  operators

12
Actions Items

• Control plane L3 (Openwave), operators directly
  inter-connected?, RSP support of solution 2 (RSP
  in L3 call flow), full MSCID from RSP ok?,
  transport of L3
• OPWV gap analysis RLP/control plane, OPWV
  solution, official standards extension? Sprint
  to find analysis
• User Plane non-trusted use control plane A/Is
• User Plane trusted
• DNS solution work offline, Qcom check SID
  lookup, operators free to pursue privates
• IP redirection Iusacell to champion
• PDE interconnection solution qcom, sprint,
  telus, (RPC) transaction, BSA snipppets,
  IS-801 forwarding (USC any interconnection
  scheme)
• New initiative investigate settlement, retail
  billing, and transport (RSP/CRX) QCOM to
  coordinate w/ syniverse, versign (both will work
  on this), aicent to be contacted
