Title: APRS Equipment and Software


1
APRSEquipment andSoftware
K5PAV - Paul
2
Internet Tools
  • APRS Internet servers
  • Find U.com

3
APRS - IGate
Getting APRS data to the internet
APRS IGate (APRS Software)
TNC and Radio
Via the internet
APRS Base Station
APRS Internet Server
4
APRS - Internet Server
APRS Internet Server
APRS Software
APRS Software
FindU.com
APRS Software
APRS Software
APRS Software
5
Find U - Call Search
http//www.findu.com/cgi-bin/find.cgi?k5pav
6
Position Data
7
Local Map
8
Regional Map
9
Wide Area Map
10
Tracks
http//www.findu.com/cgi-bin/track.cgi?callk5pav-
14start24length24
call k5pav-14 start 24 length 24
11
Near by Stations
12
Messages
13
Weather
14
Software Tools
  • APRS Applications

15
ARRLs APRS book
  • Book covers use ofAPRS software
  • WinAPRS
  • MacAPRS
  • APRS-SA
  • Pocket APRS
  • APRS (DOS)
  • Simple H/W setupguide

16
APRS software
17
APRS-SA - Windows
Uses Street Atlas for Maps
18
UI-View - Windows
19
Pocket APRS - Palm
Maps
Station Lists
Direction Finding
20
APRS - DOS
21
WinAPRS
22
MacAPRS
23
XAPRS - Linux
24
XASTIR - Linux
25
AFilter
26
Hardware
  • Tiny Trak II
  • TNCs
  • Radios with built in TNC

27
Hardware Setup
GPS
PC
GPS can also be attached to the PC
TNC
Radio
28
Tiny Trak II
www.byonics.com
29
Tiny Trak Installation
30
TNCs
  • Use as a Tracker with GPS
  • Use with PC/Mac/Palm
  • Use with GPS and computerwith special cable

31
TNC for Visor
shinemicro.com
32
Kenwood Radios
33
Alinco with TNC
34
Other APRS stuff
35
APRS via Satellite
PCSat
http//www.findu.com/cgi-bin/pcsat.cgi
5W - 1200 baud 145.827MHz
36
Normal APRS 144.39Mhz
PCSat 145.827Mhz
