DEVT1-56: ASP.NET Best Practices

1
Best Practices for ASP.NET Development
Joe Healy Microsoft Corporation
2
What we will cover

• Designing ASP.NET Web forms
• Use code-behind for best performance and
  scalability
• ASP.NET caching techniques
• State management options
• Recommendations for communicating with COM
  components from ASP.NET

3
Session Prerequisites

• Understand .NET architecture
• Working knowledge of either VB.NET or C
• Knowledge of ASP.NET application architecture
• Knowledge of ASP

Level 300
4
Agenda

• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

5
Language and Code PracticesCode Performance

• .NET Common Language Runtime (CLR) provides big
  runtime performance wins
• No perf difference in .NET languages
• Equivalent code written in VB and C provides
  equivalent performance at runtime

6
Language and Code PracticesBinding in VB.NET

• Early binding in VB performs better than late
  binding

VB Late Binding Example Dim j, obj obj New
System.Collections.ArrayList() for j 0 To i
obj.Add(j) Next VB Early Binding Example Dim
j as integer, obj As ArrayList obj New
System.Collections.ArrayList() for j 0 To i
obj.Add(j) Next
7
Language and Code PracticesLanguage
Recommendations

• Avoid using late binding in VB and JScript
• Explicitly declare all variable types (Dim a as
  Long)
• Avoid late bound methods on Object type
• Use lt_at_ Page LanguageVB Explicittrue gt
• Requires all variables to be declared (DIM
  required)
• Still enables late bound code to exist though
• lt_at_ Page LanguageVB Stricttrue gt
• Disallows any late bound code to be used

8
Language and Code PracticesCOM interop Issues

• Transitions between managed and unmanaged
  code can be expensive
• With methods having complicated structures as
  arguments and return types
• Use chunky over chatty APIs
• Apartment threaded components are must b e
  handled appropriately in ASP.NET
• ASP.NET now uses MTA thread pool by default. If
  not deal with MTA pool has very bad perf side
  effects when running STA components
• This affects all VB6( STA) components!

9
Language and Code Practicesinterop
Recommendations

• Ideally migrate COM code to .NET
• Alternatively structure APIs to be less chatty
  and more chunky in usage
• Use COM interop through System.Runtime.interopServ
  ices
• If using apartment components, mark page to run
  in STA compat mode
• lt_at_ Page ASPCompattrue gt
• Generate early bound .NET wrappers for COM
  components (using TLBIMP.exe)
• Note this does not remove aspcompattrue
  requirement for apartment components

10
Language and Code Practicesinterop
Recommendations

• Be careful not to declare any STA component in
  constructor of page

bad!!!! Public Sub New() mathtest New
STATest.MathClass() End Sub good!!! Private
Sub Page_Load() Handles MyBase.Load mathtest
New STATest.MathClass() End Sub
11
Demonstration 1Language Best Practices Early
binding vs. Late Binding Using COM objects in
ASP.NET
12
Agenda

• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

13
Server Control Design PracticesOptimizing Server
Control Rendering

• Server controls provide a very clean programming
  model abstraction
• Recommended way to build ASP.NET pages
• Server controls do more rendering/postback work
  that old-style lt gt code
• Should understand what this work is and optimize
  for it accordingly
• Two areas to think about and optimize
• Rendering Content
• ViewState Postback

14
Server Control Design PracticesOptimizing Server
Control Rendering

• Server controls encapsulate rendering markup
  logic at runtime
• Handle style and automatic uplevel/downlevel
  functionality management
• individual server controls each add slight
  additional rendering cost
• Additional allocations for style management
• Additional allocations for control itself
• Net take the more individual server controls on
  page, the more this overhead can be noticed
• Need to be especially aware of this w/ composite
  list controls that generate multiple controls per
  data row

15
Server Control Design PracticesOptimizing Use of
Viewstate

• ASP.NET allows pages/controls to maintain state
  across round trips by storing state within hidden
  viewstate field
• Disabled with EnableViewState attribute
• Some downsides
• increases network payload
• Performance overhead to serialize this
• Recommendation
• Always review your usage of this feature
• Always disable if you are not doing postback
• Disable on per control basis if possible
• Use lt_at_ Page Tracetrue gt to track usage size


16
Server Control Design PracticesData Validation
Techniques

• Leverage client side scripting capabilities to
  perform validations
• Perform validation on both server client side
  to avoid validation bypass
• Make appropriate use of the RequiredFieldValidator

• Use RegularExpressionValidator for validating
  complex field types like Credit Card

17
Demonstration 2Server Control Design Practices
Optimizing Server Control RenderingOptimizing
Use of ViewstateData Validation Best Practices
18
Agenda

• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

19
Component User Control PracticesImproving User
Experience

• ASP.NET built-in caching features
• Output Caching
• Fragment Caching
• Caches the static result of an ASP.NET page
• Use the lt_at_ OutputCache gt directive to control
  caching behavior

20
Component User Control PracticesImproving User
Experience

• Caching Options
• Duration - Time item exists in the cache
• VaryByParam - Varies cache entries by Get/Post
  params. Name param, separate by semi-colons,
  supports
• VaryByHeader - Varies cache entries by Http
  header
• VaryByCustom - Override method within Global.asax
  to custom vary by whatever you want (you control
  the cache key)

21
Component User Control PracticesImproving User
Experience

• Caching the entire page isnt always possible
• Partial page personalization, etc.
• Fragment Caching allows caching regions of a page
  by using user controls (.ascx)
• User controls define lt_at_ OutputCache gt directive

22
Component User Control PracticesOptimizing
Data Flow Across Tiers

• Minimize the number of post backs
• Leverage client side capabilities to avoid post
  backs
• Control the amount of view state information
  passed during a post back
• Use EnableViewState at page or control level to
  configure view state usage.

23
Demonstration 3Component User Control Best
Practices Buffered OutputFragment Caching
Code Behind, User Controls Components
24
Agenda

• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

25
State Management Recommendationsin Proc Session
State

• Session state is stored in the ASP.NET worker
  process
• Recycling the process will cause all session
  state to be lost
• Session state performance is maximum in this mode

26
State Management RecommendationsOut of Proc
Session State

• Session state can be stored in a State server
  process running on the same machine or a
  different machine
• State can also be stored in a SQL Server database
• Restarting the web server does not cause the
  session state to be lost
• More reliable than in process session state but
  less performant

27
State Management RecommendationsConfiguring
Session State

• Session state can be configured via the
  ltsessionStategt element in the web.config file
• Change causes ASP.NET application to be
  restarted, all new sessions will be stored as per
  the updated session configuration
• Out of process session state stores like State
  Server or SQL Server must be started configured
  properly

28
Demonstration 4State Management Best Practices
State ManagementSession State in A State Server
29
Agenda

• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

30
Caching TechniquesDesign for Caching

• Leverage the built-in ASP.NET built-in caching
  features
• Output Caching
• Fragment Caching
• Cache API
• Recommendation
• Specifically design your pages around these
  features can lead to massive perf wins

31
Caching TechniquesOutput Caching

• Caches the static result of an ASP.NET page
• Declarative lt_at_ OutputCache gt directive
• Optional Output Cache APIs can also be called
• Caching Options
• Duration
• Time item exists in the cache
• VaryByParam
• Varies cache entries by Get/Post params
• Name param, separate by semi-colons, supports
• VaryByHeader
• Varies cache entries by Http header
• VaryByCustom
• Override method within Global.asax to custom vary
  by whatever you want (you control the cache key)

32
Caching TechniquesFragment Caching

• Caching the entire page isnt always possible
• Partial page personalization, etc.
• Fragment Caching allows caching regions of a page
  by using user controls (.ascx)
• User controls define lt_at_ OutputCache gt directive
• Additional Features
• VaryByControl Varies cached items by controls
• VaryByCustom Allows user cache key method

33
Caching TechniquesCache API

• Caching output isnt always possible
• Cache API allows objects to be cached
• in memory Hashtable
• System.Web.Caching.Cache class
• Page intrinsic property (Cache)
• Features
• Dependencies (key, file, time)
• Unused items automatically expire
• Supports Callbacks

34
Demonstration 5Caching Techniques Output
CachingCustom Caching
35
Agenda

• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

36
Deployment Best PracticesLogical Design

• Design your applications using logical 3-Tier
  Design Practices
• Pages (.aspx) and User Controls (.ascx)
• Reusable Biz Classes in \bin dir (.vb .cs)
• Data within a SQL Database
• Design your Web application so that it can be
  distributed across a Web farm
• Your code shouldnt assume that a client will
  always return to the same machine
• Be careful of assumptions regarding statics and
  application state

37
Deployment Best PracticesPhysical Deployment

• Deploy your applications such that the pages and
  components run in same process
• Deploying onto remote servers connected via DCOM
  or Web Services will almost always hurt your
  performance/scalability
• Leverage Web services only for application to
  application communication -- not intra app calls
• Leverage ISA Server for configurations where a
  DMZ security zone is required
• Enables you to restrict app server access from
  browser clients

38
Deployment Best PracticesISA for DMZ
Configurations
39
Agenda

• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

40
Measurement TechniquesOverview of Application
Center Test

• Application Center Test (ACT) is a tool designed
  for stress testing web servers
• The tool assists in determining performance and
  scalability of a given web site
• The tool also collect useful statistical
  information during the stress test
• ACT also exposes a programming interface, which
  can be used for creating stress test scripts

41
Measurement TechniquesKey Performance indicators

• The key performance indicators of a web
  application are
• Processor utilization
• Low value indicates blocking on other resources
• ASP.NET
• Requests/Sec Requests Queued
• Memory
• Pages Faults/Sec lower the better, high numbers
  indicate insufficient memory condition

42
Measurement TechniquesStress Testing

• Stress testing is a defensive mechanism to
  creating scalable web sites
• Stress runs will indicate the scalability of the
  application
• Can be used to determine scale of operation, when
  to add new hardware etc
• Stress testing should not be the final step in
  building a web application. It should be
  integrated into the development life cycle
• Narrow the scope of a stress run to get more
  accurate, actionable results

43
Measurement TechniquesStress Testing

• Use the web site logs to determine operational
  load
• Stress tools like WAS (Homer) allow log files
  to be replayed on a web site and record
  statistical performance information
• Run performance monitoring tools on the live
  servers to identify scalability issues

44
Measurement TechniquesDesigning Scalable
Applications

• Two ways to quantify Web performance
• Machine Throughput (requests/sec)
• Response Time (time to first/last bytes)
• Measure performance by stressing server
• Utilize multiple client stress machines
• Use Application Center Test tool
• Measure multiple scenarios
• Simulate end to end scenario walkthroughs of site
• Measure individual page performances

45
Measurement TechniquesDesigning Scalable
Applications

• Quantify performance for a range of load
  conditions
• Request/sec using different loads (100, 250, 500,
  750, 1000, etc concurrent clients)
• Identify maximum client load that fits into
  acceptable TTFB/TTLB response time range
• Use ASP.NET Caching to cache page output
• Design pages to maximize use of cache

46
Demonstration 6Measurement TechniquesPerformanc
e Measurement
47
Session Summary

• in this session we discussed
• Language and Code Practices
• Server Control Design Practices
• Component and User Control Usage Practices
• State Management Recommendations
• Caching Techniques
• Deployment Best Practices
• Measurement Techniques

48
Thank You To Our Sponsors!
49
Thank You To Our Sponsors!
50
How-To ResourcesSimple, Step-By-Step Procedures

• Embedded Development How-To Resources
• General How-To Resources
• integration How-To Resources
• JScript .NET How-To Resources
• .NET Development How-To Resources
• office Development Resources
• Security How-To Resources
• Visual Basic .NET How-To Resources
• Visual C .NET How-To Resources
• Visual Studio .NET How-To Resources
• Web Development How-To Resources (ASP, IIS, XML)
• Web Services How-To Resources
• Windows Development How-To Resources
• http//msdn.microsoft.com/howto

51
MSDN Webcastsinteractive, Live Online Event

• interactive, Synchronous, Live Online Event
• Discuss the Hottest Topics from Microsoft
• Open and Free for The General Public
• Takes Place Every Tuesdays
• http//www.microsoft.com/usa/webcasts

52
MSDN Subscriptions THE way to get Visual Studio
.NET
MSDN Subscriptions
Visual Studio .NET

• Enterprise Architect
• Software and data modeling
• Enterprise templates
• Architectural guidance

MSDN Universal2799 new2299 renewal/upgrade

• Enterprise Developer
• Enterprise lifecycle tools
• Team development support
• Core .NET Enterprise Servers

MSDN Enterprise2199 new1599 renewal/upgrade
NEW

• Professional
• Tools to build applications and XML Web services
  for Windows and the Web

MSDN Professional1199 new899 renewal/upgrade
53
Where Can I Get MSDN?

• Visit MSDN Online atmsdn.microsoft.com
• Register for the MSDN Flash Email Newsletter at
• msdn.microsoft.com/flash
• Become an MSDN CD Subscriber at
  msdn.microsoft.com/subscriptions
• MSDN online seminars
• msdn.microsoft.com/training/seminars
• Attend More MSDN Events

54
MS PressEssential Resources for Developers
Microsoft Visual Studio .NET is here! This is
your chance to start building the next big thing.
Develop your .NET skills, increase your
productivity with .NET Books from Microsoft
Press www.microsoft.com/mspress
55
TrainingTraining Resources for Developers

• Course Title introduction to Microsoft ASP.NET

• Course Number2063
• Availability Now
• Detailed Syllabus www.microsoft.com/traincert

To locate a training provider for this course,
please access www.microsoft.com/traincert
Microsoft Certified Technical Education Centers
are Microsofts premier partners for training
services
56
New Application Developer Certification

• What is MCAD?
• Microsoft Certified Application Developer
• A certification for developers who use Microsoft
  tools and technologies to develop and maintain
  department-level applications, components, Web or
  desktop clients, or back-end data services.
• How do I attain the MCAD certification?
• 2 core exams
• 1 elective exam
• For complete information visit
  www.microsoft.com/mcad

57
Become A Microsoft Certified Solution Developer

• What is MCSD?
• Microsoft Certified Solution Developer
• The premier certification for lead developers who
  design and develop leading-edge enterprise
  solutions with Microsoft development tools,
  technologies, and the Microsoft .NET Framework.
• How do I attain the MCSD for Microsoft .NET
  certification?
• 4 core exams
• 1 elective exam
• For complete information visit
  www.microsoft.com/mcsd

58
(No Transcript)
