ECommerce Infrastructure

1
E-CommerceInfrastructure Security

• Lecture 11
• Encryption

2
Agenda

• Project 4 Demos next Thurs.
• Proj 4 5 due next Thurs.
• Cryptography Basics
• Symmetric vs. Asymmetric Cryptography
• Attack Methods
• PGP

3
Crypto Basics

• Cryptography is thousands of years old
• Caesar Cipher based upon substitution
• AD, BE, etc.
• rot13 is a simple example of substitution
  cryptography
• V ybir vasbezngvba grpubaybtl

4
Weaknesses in Older Crypto

• Patterns are easily discovered
• Letters are not randomized
• Frequency of letters (esp. vowels)
• Strength of the crypto is insufficient given
  modern computers
• Cryptoquotes for example

5
Encryption Decryption
Encryption
Plaintext
Ciphertext
Crypto Algorithm
Decryption
6
Symmetric Crypto

• Also known as private key cryptography
• Both sender and receiver have same key
• Problems
• Securing the key
• Number of keys O(n2) so 100 people
  communicating privately would need 10000 keys!

7
Symmetric Key Infrastructure
8
Asymmetric Crypto

• Also known as public key cryptography
• Sender and receiver have different keys
• Each has a public key and a private key
• Public keys are distributed via a KDC
• This scheme requires O(n) key pairs

9
Asymmetric Key Infrastructure
KDC
10
Public Key Cyrpto
Plain text
Encryptionwith Public KeyReceiver
Cipher text
Plain text
Decryptionwith Private KeyReceiver
11
How Public Key Crypto Works

• You get my public key from the KDC
• You encode a message to me using my public key
• Only my private key can unlock this
• I receive the message
• I decode it using my private key (that only I
  have)
• I can then read the message

12
Public Key Infrastructure

• Requires validation of keys
• Thus certificate authorities
• Public key certificate contains
• ID
• Identifying information (name, e-mail)
• Date created
• Certifying authorities (their signatures)

13
Public Key Encryption
Encrypted with Bobs Public Key
Encrypted with Alices Public Key
Alice
Bob
Message is Garbageto Third Party
14
Attack Methods

• Brute Force
• Requires recognition of plaintext
• Key length determines strength
• Cryptanalysis
• Mathematical attack
• Faults in system
• Hack into creator of the key pair

15
Attack Methods (cont)

• Factoring Attacks
• Security of asymmetric crypto resides in large
  number theory
• Its easy to generate a large composite number
  (multiply two large primes)
• But its (thought) difficult to factor these

16
Mathematical Underpinnings

• Pick two large primes
• P Q
• Pick another large number (e) which does not have
  common factors with (P-1)(Q-1)
• Public key PxQ e
• Private key e-1 mod ((p-1)(q-1))

17
Trap Door Theory

• Easy to create private key
• Difficult to reconstruct it
• Its easy to create the large number N
• But its difficult to factor it into P Q

18
An Example

• Took seconds to generate N 114,381,625,757,888,8
  67,669,235,779,976,146,612,010,218,296,721,242,362
  ,562,561,842,935,706,935,245,733,897,830,597,123,5
  63,958,705,058,989,075,147,599,290,026,879,543,541
  (RSA-129, 1977)
• But can you find the two primes P Q such that
  PxQN?

19
In Case You are Wondering

• After 17 years, it took 8 computer months and
  over 1600 computers working worldwide
• P3,490,529,510,847,650,949,147,849,619,903,898,13
  3,417,764,638,493,387,843,990,820,577
• Q32,769,132,993,266,709,549,961,988,190,834,461,4
  13,177,642,967,992,942,539,798,288,533
• And this was only a 429-bit key youll be using
  a key which is 2048 bits long (5 times as long)
  which would require MUCH more time to decrypt
  (about a million times more)

20
Publish or Perish?

• Should crypto algorithms be made public?
• Isnt the secrecy of the algorithm beneficial to
  security?
• How about a peer review process?

21
False Encryption
Falsely Encrypted
Falsely Encrypted
Alice
Bob
Carol
22
Current Technologies

• S/Mime - encrypted e-mail
• SSL - secure sockets layer for bi-directional
  communication (web)
• SET - secure credit card purchasing such that
  merchant doesnt see card
• SSH - secure shell like Telnet (putty)

23
PKI Digital Signatures
Plain text
Encryption of MDFwith Private KeySender
Plain text
Decryption of MDFwith Public KeySender
24
PGP

• Invented by Phil Zimmerman
• Originally released in 1991
• Used the RSA algorithm w/ legal issues
• Now it uses IDEA, CAST, and TripleDES
• Allows for variable crypto strengths

25
Key Strength

• Presumably, the larger the key, the harder the
  crypto is to crack
• Why not just make the key 100,000 bits or more?

26
Keep working on Project 4Dont forget Project 5
- PGP
FIN
