VoIP Merdeka Architecture

1
VoIP Merdeka - Architecture

• Onno W. Purbo
• Onno_at_indo.net.id

2
VoIP Architecture

• Protocol
• H.323
• SIP (Session Initiation Protocol)
• VoIP Merdeka!!!
• At the moment uses H.323

3
H.323 Components
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Root Gatekeeper (RootGK)

• 202.53.224.172
• 202.155.39.157

8
Public Gatekeeper

• IP
• 218.100.4.194
• 202.43.162.189
• 202.150.8.15

• Prefix (Area Code)
• 6288888
• 6288999
• 6288925

9
International Neighbors
10
International Neighbors Gatekeeper (SoftSwitch)

• 217.160.169.175 149 Germany,Berlin
• 217.14.129.191720 822 London, England
• 61.201.199.150 8199 Japan
• netscafe.net 6588 Singapore
• voip.cisc.org 140388 Canada
• 212.0.145.164 24911 Sudan, Khartoum
• 202.53.224.172 6288 Indonesia, Jakarta
