Irrigation Scheduling

1
Irrigation Scheduling
2
New Legislation

• Act 148 Water use reporting, mapping of
  groundwater information, consider need for
  addition legislation
• Act 177 Water use conflict resolution
• Governor - Water Legacy Act
• http//www.michiganlegislature.org/

3
Irrigation Scheduling

• Know available soil water for each unit
• Known depth of rooting for each crop
• Know allowable soil moisture depletion at each
  stage of plant growth
• Use evapotranspiration data to estimate crop
  water use
• Measure rainfall in each field
• Use container capacity for nursery crops

4
Why Schedule

• Prevent stress health of plant - yield loss
  appearance
• Maximize water use efficiency beneficial use
  of resource
• Minimize leaching of nitrates or pesticides

5
Irrigation amount

• The amount of water available to the plant is a
  function of root depth and soil available water
• For example plant with a rooting depth of 2 ft
  on Coarse-textured loamy sand has .08 in/in X 2
  ft X 12 in/ft 1.98 in
• For an allowable depletion of 50 - a 1 in
  application would replenish available water

6
Reference Evapotranspiration

• ETo or potential evapotanspiration represents a
  well watered, fully developed plant such as grass
• Reference evapotranspiration is multiplied by a
  crop coefficient to obtain the ET rate for a
  specific crop
• The crop coefficient varies throughout the
  growing season
• For Example Corn at 20 0.67 at 501

7
Estimates of ET

• Max and min temperatures
• Relative humidly
• Wind
• Net radiation
• Modified Penman to estimate ETo
• U of Wisconsin web site
• http//www.soils.wisc.edu/wimnext/et/miet.html

8
ET Measurements

• Weighing Lysimeters
• Uniformity of soil important
• Representative plant growth

9
For Annual Crops

• Depth of root zone increases during the growing
  season
• Allowable soil moisture depletion varies with
  each stage of plant growth

10
(No Transcript)
11
Methods to Estimate Soil Moisture

• Feel and Appearance
• Electrical resistance electrodes on blocks in
  soil
• Tensiometers measures soil moisture tension
• Must be measured at a range of depths in root
  zone

12



13
(No Transcript)
14
Irrigation Scheduling Methods

• All methods require keeping sufficient records
• Appearance and feel of soil must look at a
  range of depths in the root zone
• Checkbook method inputs are rainfall and
  irrigation output ET Automated spreadsheet
  will be available by Jan 15
• http//www.extension.umn.edu/distribution/cropsyst
  ems/DC1322.html
• SCS-Microcomputer Irrigation Scheduling Package
  1992
• Computer simulations

15
