Title: SOUTH AFRICAN NAVY HYDROGRAPHIC OFFICE


1
SOUTH AFRICAN NAVYHYDROGRAPHIC OFFICE
  • CREATED BY RUTH FARRE

2
SOUTH AFRICAN NAVYHYDROGRAPHIC OFFICE
  • HISTORICAL SUMMARY
  • PRESENT SITUATION
  • SRD TIDE GAUGE
  • KALESTO RADAR TIDE GAUGE
  • FUTURE PROSPECTS

3
HISTORICAL SUMMARY
  • SAN HO began installing own float- actuated
    KENT gauges in 1958.
  • By the mid 1980s the tide gauge (TG) network was
    aging and spares were becoming difficult to come
    by. Replacement of the network was urgently
    needed on a significant scale.
  • A project with CSIR resulted in the development
    of a modern Acoustic Water Level Recorder.
  • Came into service in 1990
  • Total of 8 installed throughout RSA and Namibia
  • These gauges were a total failure. They were
    erratic, difficult to tune and grossly
    inaccurate.
  • Virtually no usable data was obtained
  • These gauges were abandoned between 1996 and 1998

4
HISTORICAL SUMMARY
  • Replacement gauges were tendered for, with SRD
    Acoustic Gauges meeting SAN HO and IMTs
    (Institute of Maritime Technology)
    specifications.
  • Somewhat hurriedly installed in 1996, in tubes as
    per manufacturers recommendations.
  • SRD data was unsatisfactory, independent study
    done
  • Recalibration of SRD gauges and check calibration
    in situ devised.
  • Performance has subsequently been just acceptable
    but not to the standard required.
  • OTT KALESTO Radar Tide Gauge put on trial in
    2002 by the SAN HO and IMT.
  • Performs with a high degree of accuracy and
    stability than encountered in the past.

5
SOUTH AFRICAN NAVYHYDROGRAPHIC OFFICE
  • HISTORICAL SUMMARY
  • PRESENT SITUATION
  • SRD TIDE GAUGE
  • KALESTO RADAR TIDE GAUGE
  • FUTURE PROSPECTS

6
TIDAL STATIONS IN RSA
7
PRESENT SITUATION
  • There are 10 tidal stations throughout South
    Africa covering the West, East and Southern
    coast.
  • PORT NOLLOTH ? SRD Acoustic Gauge
  • SALDANHA ? SRD Acoustic Gauge
  • CAPE TOWN ? SRD Acoustic Gauge
  • SIMONS TOWN ? SRD Acoustic Gauge, KALESTO
    Radar, GPS
  • MOSSEL BAY ? SRD Acoustic Gauge
  • KNYSNA ? SRD Acoustic Gauge
  • PORT ELIZABETH ? SRD Acoustic Gauge
  • EAST LONDON ? SRD Acoustic Gauge
  • DURBAN ? SRD Acoustic Gauge
  • RICHARDS BAY ? KALESTO Radar, GPS
  • (GPS IS OWNED AND OPPERATED BY HARTRAO -
    HARTEBEESHOEK RADIO ASTRONOMICAL OBSERVATORY)

8
SOUTH AFRICAN NAVYHYDROGRAPHIC OFFICE
  • HISTORICAL SUMMARY
  • PRESENT SITUATION
  • SRD TIDE GAUGE
  • KALESTO RADAR TIDE GAUGE
  • FUTURE PROSPECTS

9
SRD TIDE GAUGE
  • TECHNICAL DATA, The system is as follows
  • Data logger, transducer, control box, junction
    box, modem telephone line. (Rather bulky)
  • Measuring range ? 15 meters
  • Measuring range ? selectable up to 30 min
  • Averaging period ? between 1 and 32 measurements
  • Acoustic frequency ? 50 kHz
  • Powered by ? electricity, back-up lead battery
  • Data dumped once a week via modem to office PC.

10
SRD TIDE GAUGE
  • Independent study with IMT showed
  • Data errors due to temperature gradients formed
    in tubes
  • Solution remove or modify existing tubes to
    maintain a well mixed air column around the
    transducer.
  • Claimed accuracy of 0.05 by the manufacturers
    was not achieved
  • no response to this by manufacturers.
  • Solution post data processing after calibration
    in situ to establish each gauges individual
    calibration factors.
  • In Situ calibration process devised
  • Allows the following to be reliably established
    on site
  • ABSOLUTE ACCURACY
  • MEASUREMENT REPEATABILITY
  • INSTRUMENT DATUM OFFSET
  • RSA network calibrated and levelled to TG
    benchmark every 6 months.

11
CALIBRATION OF SRD GAUGES
12
SRD TIDE GAUGE
  • Data has high spike density that has to be edited
    out by hand annually
  • This is very unscientific, time consuming and
    human error comes into play.
  • (Graphics to follow indicate this spike density.)

13
GRAPHIC OF SRD ACTUAL VALUES18 FEBRUARY 2003 - 1
MARCH 2003
14
GRAPHIC OF SRD ACTUAL VALUES11 MARCH 2003 - 17
MARCH 2003
15
GRAPHIC OF SRD ACTUAL VALUES vs PREDICTED
VALUES11 MARCH 2003 - 17 MARCH 2003
16
GRAPHIC OF SRD ACTUAL VALUES vs SRD PREDICTED
VALUES11 FEBRUARY 2003 - 31 MARCH 2003
17
EFFECT OF LIGHTNING STRIKE ON SRD HARDWARE.
(LIGHTENING PROTECTION IS INADEQUATE FOR SOUTH
AFRICAN WEATHER SYSTEMS)
18
SRD TIDE GAUGE
  • Technical assistance is unsatisfactory
  • Periodically the power supply has to be
    disconnected from the gauge for 30 seconds and
    then restored.
  • This is the solution to the periodic
    unwillingness to download via modem
  • This is becoming more and more frequent, and is
    creating considerable down time.
  • The transducers are beginning to rust
  • This is becoming worse and could be a reason for
    poor data quality.

19
SOUTH AFRICAN NAVYHYDROGRAPHIC OFFICE
  • HISTORICAL SUMMARY
  • PRESENT SITUATION
  • SRD TIDE GAUGE
  • KALESTO RADAR TIDE GAUGE
  • FUTURE PROSPECTS

20
KALESTO RADAR GAUGE IN SITU
21
KALESTO RADAR TIDE GAUGE
  • On trial, under calibration ? Analysis of 1443
    readings (mean of 2.496)
  • 81 of readings were within 2mm of the above mean
  • 93 of readings were within 3mm of the above mean
  • 97 of readings were within 5mm of the above mean
  • TECHNICAL DATA, The system is as follows
  • Data logger, sensor, modem telephone line.
  • Measuring range ? 1.5 - 30 meters
  • Averaging period ? 17 seconds (40 values,
    creating mean values)
  • Sensor technology ? 24, 125 GHz, 5mW
  • Powered by ? electricity, small battery
  • Data dumped twice a week via modem to office PC.

22
KALESTO RADAR GAUGEPLATFORM FOR EASY ACCESS TO
GAUGE DURING LEVELING AND CALIBRATION.
23
KALESTO CABINET CONTENTS
24
KALESTO RADAR TIDE GAUGE
  • Independent study with IMT showed
  • KALESTO performed consistently within the
    manufactures claimed accuracy parameters.
  • Confirmed results achieved by SAN HO
  • In Situ calibration process devised
  • Allows the following to be reliably established
    on site
  • ABSOLUTE ACCURACY
  • MEASUREMENT REPEATABILITY
  • INSTRUMENT DATUM OFFSET
  • RSA network calibrated and levelled to TG
    benchmark every 6 months.

25
CALIBRATION OF KALESTOAT LONG STAY.
26
MEASUREMENTS OF THE KALESTO RADAR GAUGE
  • FROM TOP OF BLACK BOX TO THE TRANSDUCER FACE
    (Tx) IS 0.400m

27
CALIBRATING THE KALESTO RADAR GAUGE
  • Example of a calculation for check calibration of
    radar gauge, if A 3.422m (known value)
  • Av. A above CD Av B
  • Av A MSL 3.422
  • ? (D-B) 1.063
  • less E to Tx - 0.400
  • ? Ref Face MSL 4.085
  • CD MSL - 1.015
  • 5.100
  • ? Ht of Tx 5.100m above CD
  • ? readings _at_ short stay
  • 5.100 - (2.750 - 0.400) 2.750m
  • ? readings _at_ long stay
  • 5.100 - (3.750 - 0.400) 1.750m

28
KALESTO RADAR TIDE GAUGE
  • Data has an extremely low spike density that has
    to be edited out by hand annually
  • This is now a lot less time consuming and there
    is now less chance for human error comes into
    play.
  • (Graphics to follow indicate this spike density.)
  • Adequate lightening protection.
  • Technical assistance is satisfactory.

29
GRAPHIC OF SRD ACTUAL VALUES vs KALESTO ACTUAL
VALUES11 MARCH 2003 - 17 MARCH 2003
30
GRAPHIC OF SRD ACTUAL VALUES vs KALESTO ACTUAL
VALUES18 FEBRUARY 2003 - 1 MARCH 2003
31
GRAPHIC OF KALESTO ACTUAL VALUES vs SRD
PREDICTED VALUES.31 JULY 2003 - 10 AUGUST 2003
32
KALESTO RADAR TIDE GAUGE
  • Technical assistance is satisfactory
  • Periodically the power supply has to be
    disconnected from the gauge for 30 seconds and
    then restored.
  • This is the solution to the periodic
    unwillingness to download via modem
  • This is becoming more and more frequent, and is
    creating considerable down time.
  • The transducers are beginning to rust
  • This is becoming worse and could be a reason for
    poor data quality.

33
SOUTH AFRICAN NAVYHYDROGRAPHIC OFFICE
  • HISTORICAL SUMMARY
  • PRESENT SITUATION
  • SRD TIDE GAUGE
  • KALESTO RADAR TIDE GAUGE
  • FUTURE PROSPECTS

34
FUTURE PROSPECTS
  • SAN HO intends to upgrade entire RSA network with
    the KALESTO Radar Tide Gauge
  • upgrade will take place as budget permits
  • Have two new gauges awaiting installation
  • Port Nolloth (to get GPS as well)
  • Port Elizabeth
  • Will keep bast of SRD gauges installed for
    back-up and data quality checks.
  • Proposal to install a gauge and GPS at Marion
    Island
  • Fast Data to continue being sent to PSMSL and
    GLOSS.
