Title: RMON


1
RMON
2
Basics
  • Remote monitoring of networks, not just devices
  • Implemented via additional MIBs (SNMP is
    extensible!)
  • RMON1 layers 1 2 (like a remote-control
    protocol analyzer)
  • RMON2 layers 3 through 7
  • SMON special needs of switches

3
RMON Advantages
  • Locally collected information reduces SNMP
    polling, can collect continuously
  • RMON is your fly on the wall even if the
    network is down between you and it

4
RMON Servers Probes
  • Can be implemented in internetworking devices
    such as switches, routers . . .
  • Can be small dedicated hardware devices
  • Can be software on a PC
  • Maintain their own database

5
The RMON MIBs
  • 1.3.6.1.2.1.16 RMON
  • 1.3.6.1.2.1.16.1-9 RMON1 (RFCs 1271 1757)
  • 1.3.6.1.2.1.16.10 Token Ring Extension (RFC
    1513)
  • 1.3.6.1.2.1.16.11-20 RMON2 (RFC 2021)

6
Configuring RMON Probes
  • Control tables
  • Define data rows to be collected
  • Configure filters, etc.
  • Coordinate multiple manager access
  • Data tables
  • Collect the requested data

7
Hey, whats this?
8
(No Transcript)
9
RMON Switch Issues
  • A probe on every port?
  • Software-selectable roving probes?
  • External probes?
  • Track full duplex traffic both ways?

10
Application Management
  • RMON2 features
  • Private MIBs for servers other hosts
  • Windows NT example
  • SNMP is extensible!

11
(No Transcript)
