Title: WIMAX


1
WIMAX????????
?????????????????
2
Outline
  • I. Introduction
  • II. 802.16 Physical Layer
  • III. 802.16 MAC Layer
  • IV. QoS Support in IEEE 802.16
  • V. Handover Procedure

3
I. Introduction
4
  • The development of high-performance backbone
    networks was immediately followed by the rapid
    dissemination of broadband wired access
    technologies.
  • Such as leased lines based on fiber-optic links,
    cable modems using coaxial systems, and digital
    subscriber line (xDSL) access networks.

5
  • Many new services are based on multimedia
    applications
  • voice over IP (VoIP)
  • video conferencing
  • video on demand (VoD)
  • massive online gaming
  • peer-to-peer.

6
  • Unlike traditional TCP/IP services, multimedia
    applications usually require strict network
    guarantees
  • reserved bandwidth
  • bounded delays

7
Broadband wireless Access
  • The International Telecommunication Union (ITU),
    which reported that Broadband Wireless Access
    (BWA), although still in the early stage of its
    growth, is one of the most promising solutions
    for broadband access.

8
  • Standards for BWA are being developed within IEEE
    802.16.
  • To promote 802.16-compliant technologies, the
    Worldwide Interoperability for Microwave Access
    (WiMAX) Forum was founded, with more than 300
    member companies.

9
  • It is envisaged that the first 802.16-compliant
    products to be deployed will very likely be aimed
    at providing last-mile Internet access for
    residential users mainly high-speed Internet
    access and small and medium-sized enterprises
    (SMEs).

10
  • For the SME market, 802.16 will provide a
    cost-effective alternative to existing solutions
    based on very expensive leased-line services.

11
802.16 family
12
(No Transcript)
13
Deployment
  • 802.16 systems can be deployed effectively where
  • Users are dissatisfied with the current packet
    and/or network interface.
  • Network operators need to reach customers
    cost-effectively.
  • New service offerings are available for 2.5G/3G
    augmentation.

14
Salient Advantages
  • Some of the more salient advantages of a wireless
    system for broadband access based on the 802.16
    standard are as follows
  • Bandwidth on demand (BOD)
  • Higher throughput
  • Scalable system capacity
  • Coverage
  • Quality (CBR or UBR)
  • Cost (investment risk and end-user fee)

15
II. 802.16 Physical Layer
16
  • Physical Layer
  • The physical layer of the IEEE 802.16 air
    interface operates
  • 1066 GHz band for IEEE 802.16 (LOS)
  • 211 GHz band for IEEE 802.16a (NLOS)
  • The physical layer supports data rates in the
    range of 32130 Mb/s depending on the
    transmission bandwidth (e.g., 20, 25, or 28 MHz)
    as well as the modulation and coding schemes
    used.

17
  • In the 1066 GHz, the air interface used for this
    band is Wireless-SC (single carrier).
  • In the 211 GHz band three different air
    interfaces can be used as follows
  • WirelessMAN-SCa for single-carrier modulation
  • WirelessMAN-OFDM. The MAC scheme for the
    subscriber stations is TDMA.
  • WirelessMAN-OFDMA for OFDM-based transmission
    using2048 subcarriers.

18
  • To enhance data transmission rate, an adaptive
    modulation and coding (AMC) technique is
    supported in the IEEE 802.16 standard.

19
  • Since the quality of the wireless link between a
    BS and a subscriber station depends on the
    channel fading and interference conditions,
    through AMC the radio transceiver is able to
    adjust the transmission rate according to the
    channel quality (i.e., signal-to-noise ratio
    SNR at the receiver).
  • Reed-Solomon (RS) code concatenated with an inner
    convolution code is used for error correction.

20
III. 802.16 MAC Layer
21
  • Medium Access Control Layer
  • The 802.16 standard specifies two modes for
    sharing the wireless medium point-to-multipoint
    (PMP) and mesh (optional).

22
  • IEEE 802.16/WiMAX uses a connection-oriented MAC
    protocol that provides a mechanism for the
    subscriber stations to request bandwidth from the
    BS.
  • A 16-bit connection identifier (CID) is used
    primarily to identify each connection to the BS.

23
  • 802.16 MAC layer
  • Sublayer
  • Service Specific Convergence Sublayer (CS)
  • MAC-Common Part Sublayer (CPS)
  • Privacy Sublayer (PS)

24
  • On the downlink, the BS broadcasts data to all
    subscriber stations in its coverage area. Each
    subscriber station processes only the MAC
    protocol data units (PDUs) containing its own CID
    and discards the other PDUs.

25
  • For TDD-based access, a MAC frame (i.e.,
    transmission period) is divided into uplink and
    downlink subframes.
  • The lengths of these subframes are determined
    dynamically by the BS and broadcast to the
    subscriber stations through downlink and uplink
    MAP messages (DL-MAP and UL-MAP) at the beginning
    of each frame.
  • The MAC protocol in the standard supports dynamic
    bandwidth allocation.

26
  • PMP mode
  • The BS serves a set of SSs within the same
    antenna sector in a broadcast manner.

27
  • Mesh Operation Mode
  • In addition to the single-hop PMP operation
    scenario, the WiMAX standard (e.g., IEEE 802.16a)
    also defines the multihop mesh networking
    scenario among the subscriber stations (i.e.,
    client meshing).
  • Meshing among the BSs (i.e., infrastructure
    meshing) has not been standardized yet.

28
QoS Support in IEEE 802.16
  • The mesh mode traffic can be routed through
    other SSs and can occur directly among SSs.

29
  • Task Group 802.16j established by the IEEE 802.16
    mobile multihop relay (MMR) study group is
    working on the standardization of relay-based
    infrastructure meshing.

30
IV. QoS Support in IEEE 802.16
31
  • QoS in wireless networks is usually managed at
    the medium access control (MAC) layer.

32
  • In PMP mode, uplink (from SS to BS) and downlink
    (from BS to SS) data transmissions occur in
    separate time frames.
  • In the downlink subframe, the BS transmits a
    burst of MAC protocol data units (PDUs).
  • Since the transmission is broadcast, all SSs
    listen to the data transmitted by the BS.
  • In the uplink subframe, any SS transmits a burst
    of MAC PDUs to the BS in a time-division multiple
    access (TDMA) manner.

33
  • Based on measurements at the physical layer, any
    SS adapts over time the interval usage code (IUC)
    in use.
  • That is, modulation, rate, and forward error
    correction (FEC) scheme, for both downlink
    (downlink IUC, DIUC) and uplink (uplink IUC,
    UIUC) transmissions.

34
Duplex
  • Downlink and uplink subframes are duplexed using
    one of the following techniques
  • Frequency-division duplex (FDD)
  • Time-division duplex (TDD)

35
Frame structure with FDD and TDD
36
  • The MAC protocol is connection-oriented all data
    communications, for both transport and control,
    are in the context of a unidirectional
    connection.
  • At the start of each frame, the BS schedules the
    uplink and downlink grants in order to meet the
    QoS requirements.

37
  • Each SS learns the boundaries of its allocation
    within the current uplink subframe by decoding
    the UL-MAP message.

38
  • The DL-MAP message contains the timetable of the
    downlink grants in the forthcoming downlink
    subframe. Downlink grants directed to SSs with
    the same DIUC are advertised by the DL-MAP as a
    single burst.
  • Both maps are transmitted by the BS at the
    beginning of each downlink subframe for both FDD
    and TDD modes.

39
QoS functions within the BS and SSs
40
  • Since the BS controls the access to the medium in
    the uplink direction, bandwidth is granted to SSs
    on demand.

41
  • Bandwidth-request mechanisms
  • Unsolicited granting
  • Unicast poll
  • Broadcast polls

42
  • Unsolicited granting
  • A fixed amount of bandwidth on a periodic basis
    is requested during the setup phase of an uplink
    connection. After that phase, bandwidth is never
    explicitly requested.

43
  • Unicast poll
  • A unicast poll consists of allocating to a polled
    uplink connection the bandwidth needed to
    transmit a bandwidth request.
  • If the polled connection has no data awaiting
    transmission (backlog, for short), or if it has
    already requested bandwidth for all of its
    backlog, it will not reply to the unicast poll,
    which is thus wasted.

44
  • Broadcast polls
  • A collision occurs whenever two or more uplink
    connections send a bandwidth request by
    responding to the same poll, in which case a
    binary exponential backoff algorithm is employed.

45
  • Bandwidth requests can be piggybacked on a PDU.
  • Bandwidth requests are used on the BS for
    estimating the residual backlog of uplink
    connections.

46
  • Based on the amount of bandwidth requested (and
    granted) so far, the BS uplink scheduler
    estimates the residual backlog at each uplink
    connection and allocates future uplink grants
    according to the respective set of QoS parameters
    and the virtual status of the queues.

47
  • Although bandwidth requests are per connection,
    the BS nevertheless grants uplink capacity to
    each SS as a whole.
  • When an SS receives an uplink grant, it cannot
    deduce from the grant which of connections it
    was intended for by the BS.

48
  • An SS scheduler must also be implemented within
    each SS MAC, in order to redistribute the granted
    capacity to all of its own connections.

49
  • The 802.16 MAC specifies four different
    scheduling services in order to meet the QoS
    requirements of multimedia applications UGS,
    rtPS, nrtPS, and BE.

50
  • Unsolicited Grant Service (UGS)
  • UGS is designed to support real-time applications
    (with strict delay requirements) that generate
    fixed-size data packets at periodic intervals
  • Ex T1/E1 and VoIP without silence suppression.

51
  • The guaranteed service is defined so as to
    closely follow the packet arrival pattern, with
    the base period equal to the unsolicited grant
    interval and the offset upper bounded by the
    tolerated jitter.
  • The grant size is computed by the BS based on the
    minimum reserved traffic rate.

52
  • real-time Polling Service (rtPS)
  • rtPS is designed to support real-time
    applications (with less stringent delay
    requirements) that generate variable-size data
    packets at periodic intervals
  • Ex MPEG video and VoIP with silence suppression.

53
  • The key QoS parameters for rtPS connections are
    the minimum reserved traffic rate and the maximum
    latency.
  • The BS periodically grants unicast polls to rtPS
    connections.

54
QoS Support in IEEE 802.16
  • non-real-time Polling Service (rtPS) and Best
    Effort (BE)
  • nrtPS and BE are designed for applications that
    do not have any specific delay requirement.
  • The main difference between the two is that nrtPS
    connections are reserved a minimum amount of
    bandwidth, which can boost performance of
    bandwidth-intensive applications, Ex FTP.

55
QoS Support in IEEE 802.16
  • nrtPS and BE uplink connections request bandwidth
    by either responding to broadcast polls from the
    BS or piggybacking a bandwidth request on an
    outgoing PDU.
  • Ex
  • For nrtPS FTP
  • For best-effort HTTP, SMTP

56
V. Handover Procedure
57
  • The handover process may be used in the following
    examples
  • When the MS moves and needs to change the BS to
    which it is connected in order to provide a
    higher signal quality.
  • When the MS can be serviced with higher QoS at
    another BS.

58
  • Network topology advertisement
  • A BS shall broadcast information about the
    network topology using the MOB_NBR-ADV message.
  • The message provides channel information for
    neighboring base station normally provided by
    each BSs own DCD/UCD message transmissions.

59
  • MS scanning of neighbors BSs
  • An MS may request an allocation of a group of
    scanning intervals with interleaving intervals of
    normal operation using the MOB_SCN-REQ message.
  • Scanning interval and interleaving interval
    repeat with the number of Scan iteration.
  • The MS indicates in this message the estimated
    duration of time it requires for the scan.

60
  • In the MOB_SCN-REQ message the MS shall indicate
    group of neighbor BSs of which only Scanning or
    Scanning with Association are requested by MS
    (recommended by BS).
  • Upon reception of the MOB_SCN-REQ message, the BS
    shall respond with a MOB_SCN-RSP message.

61
  • The MOB_SCN-RSP message shall either grant the
    requesting MS a scanning interval that is at
    least as long as requested by that MS, or deny
    the request.
  • Following reception of a MOB_SCN-RSP message
    granting the request, MS may scan for one or more
    MS during the time interval allocated in the
    message.

62
  • When a BS is identified through scanning, the MS
    may attempt to synchronize with its downlink
    transmissions, and estimate the quality of the
    PHY channel.
  • The serving BS may buffer incoming data addressed
    to the MS during the scanning interval and
    transmit that data after the scanning interval
    during any interleaving interval of after exit of
    the Scanning mode.

63
  • Association procedure
  • Association Level 0
  • Scan/Association without coordination
  • The serving BS and the MS negotiate about the
    association duration and intervals.
  • Association Level 1
  • Association with coordination
  • The Serving BS provides association parameters to
    the MS and coordinates association between the MS
    and neighboring BSs.

64
  • Association Level 2
  • Network assisted association reporting
  • The Serving BS will then coordinate the
    association procedure with the requested
    neighboring BSs in a fashion similar to
    association Level 1.
  • The MS is required only to transmit the CDMA
    ranging code at the neighbor BS. Then The MS does
    not have to wait for RNG-RSP from the neighbor
    BS.
  • The RNG-RSP information on PHY offsets will be
    sent by each neighbor BS to the Serving BS. The
    Serving BS may aggregate all ranging related
    information into a single MOB_ASC_REPORT message.

65
  • Handover Process
  • Cell reselection
  • Handover Decision and Initiation
  • Synchronization to Target BS downlink.
  • Ranging
  • Termination of MS Context.

66
  • Cell reselection
  • MS may use Neighbor BS information acquired from
    a decoded MOB_NBR-ADV message, or may make a
    request to schedule scanning intervals to scan.
  • Neighbor BS for the purpose of evaluating MS
    interest in handover to potential target BS.

67
Cell selection with ranging
68
  • HO Decision and Initiation
  • The decision may originate either at the MS or
    the serving BS.
  • The HO Decision consummates with a notification
    of MS intent to handover through MOB_MSHO-REQ or
    MOB_MSHO-REQ.

69
  • Synchronization to Target BS downlink
  • MS shall synchronize to downlink transmissions of
    Target BS and obtain DL and UL transmission
    parameters.
  • If MS had previously received a MOB_NBR-ADV
    message including
  • Target BSID
  • Physical Frequency
  • DCD/UCD
  • this process may be shortened.

70
  • Ranging
  • MS and target BS shall conduct Initial Ranging or
    Handover Ranging.
  • If MS RNG-REQ includes serving BSID, then target
    BS may make a request to serving BS for
    information on the MS over the backbone network
    and serving BS may respond.
  • Network re-entry proceeds may be shortened by
    target BS possession of MS information obtained
    from serving BS over the backbone network.

71
  • Termination of MS Context
  • The final step in handover.
  • Termination of MS Context is defined as serving
    BS termination of context of all connections
    belonging to the MS and context associated with
    them.
  • Information of queues
  • ARQ state-machine
  • Counters
  • Timers
  • Header suppression information

72
Handover and initial network entry
73
Thank you!
Write a Comment
User Comments (0)
About PowerShow.com
