Normalisation

1
Normalisation

• delivered by John Stockwell

2
Objectives

• At the end of this lecture you will be able to
• describe the use of normalisation
• describe how normalisation and E-R modelling may
  be used together
• use the principles of normalisation to produce
  third normal form

3
Introduction

• It is very important that we do not keep a data
  item in more than one place
• The only exception to this rule is when we are
  using primary or foreign keys

4
Introduction

• The reasons for this are
• Data inconsistency may occur where we change the
  data in some places but not in others
• It is simpler to change any data item if it only
  occurs in one place
• It simplifies the use of queries to select data
  from the database

5
Normalisation

• A series of steps that enable us to take a
  collection of data items and distribute them into
  related tables without duplicating values
• The tables will contain data items relating to a
  particular concept within the problem domain

6
E-R diagrams and normalisation

• Havent we just been doing this?
• Yes
• E-R diagrams use a top-down approach
• Normalisation works from the bottom-up
• Data items (known as attributes when drawing E-R
  diagrams) are taken and grouped together into
  tables

7
E-R diagrams and normalisation

• How do these two techniques fit together?
• Both of them may be used at different stages in
  the development of an information system
• They are used to complement one another

8
E-R diagrams and normalisation

• In a large project normalisation can be used on
  all the data items gathered together from
  existing documentation and forms
• The resulting grouping may then be compared with
  the results of the E-R diagram developed from an
  analysis of the case study description
• Any anomalies are then investigated and resolved

9
E-R diagrams and normalisation

• Another way to use normalisation is to check that
  the tables we have derived are in the correct
  form before we move towards implementing our
  design
• This is the way we will use normalisation in this
  module
• For relatively simple data bases we may find we
  have built an E-R diagram that already
  corresponds to third normal form !

10
Producing third normal form

• Three processes are to be carried out on the
  collection of data items
• They produce first, second and then third normal
  form
• This is usually sufficient for most purposes
• Before normalising can take place it is essential
  that the designer completely understands the
  meaning of the data and any restrictions or
  business rules imposed upon it

11
Producing third normal form

• Let us assume we have only one table
• The example is chosen to demonstrate clearly each
  of the subsequent three processes
• In reality we may need only some of the
  procedures or even none if the table we are
  testing is already in third normal form

12
Figure 1 Un-normalised table
13
Figure 1

• Shows information relating to a patient in a
  hospital
• The patient may be administered drugs with a
  certain dosage as part of a prescription
• The prescription also includes the time for which
  the dosage should be given
• The patient is placed in a ward in the hospital

14
Figure 1

• It is important to understand what this data
  means
• There may be more than one patient in any ward
• Two patients may have the same surname and
  fore-name
• No two wards can have the same number or name
• More than one patient may receive a prescription
  on any one day
• This prescription could be identical to another
  patients prescription

15
Figure 1

• Any one patient may receive more than one
  prescription on any one day
• A drug code is for one named drug only
• If a patient is prescribed a drug on a particular
  day they cannot receive another prescription for
  the same drug on that day
• Where there are spaces shown they indicate the
  same values as in the cells vertically above them

16
Pick a primary key

• The table seems to be showing data about a
  patient, where they are and what is prescribed to
  them
• It makes sense to pick a non-textual primary key
• Use the smallest number of attributes possible
• In this case we choose Patient No.

17
First Normal Form

• Remove any repeating groups of attributes to
  separate relations
• Pick keys for any relations identified
• A repeating group is defined as any attribute or
  attributes that may occur with multiple values
  for a single value of the primary key attribute.
• In this case we are looking for attributes or
  data items that have more than one possible value
  for a single value of Patient No.
• Which attributes here may take on more than one
  value for a particular patient?

18
First Normal Form

• Each patient may receive a number of
  prescriptions but may not be placed in more than
  one ward
• Therefore the repeating attributes are
  Prescription date, Drug code, Drug name, Dosage
  and Length of treatment
• These repeating attributes are placed in a group
  by themselves and have to have their own primary
  key

19
First Normal Form

• This primary key will be a combination of the
  primary key of the un-normalised group and one or
  more other attributes
• We need to choose the primary key of the
  repeating group so that a particular row may be
  uniquely identified
• Which of the other attributes when combined with
  Patient No. would uniquely identify a row in the
  table ?

20
First Normal Form

• Patient No. and Prescription date ?
• (patient could have more than one prescription on
  a given date)
• Patient No. and Drug code will also not quite do
  as a patient could be prescribed the same drug on
  different days
• Patient No., Prescription date and Drug code
  together would provide what is called a compound
  primary key
• (assuming that a patient cannot be prescribed the
  same drug more than once on a given day)

21
First Normal Form

• The repeating attributes are separated from the
  other group and added to Patient No. to form a
  new group
• So if we are given the Patient No., Prescription
  date, and Drug code the values of the other
  attributes Drug name, Dosage and Length of
  treatment will be automatically determined
• The attributes left behind in the original table
  produce a row which is uniquely identifiable by a
  value of the primary key

22
Figure 2 Two tables in first Normal Form
23
Figure 2

• If we know the Patient No. is 681 we can be sure
  of the surname, Forename, Ward No. and Ward name
• Notice that we have the start of a relational
  database as the two tables are related through
  the common field or attribute Patient No.

24
Figure 4.2

• It is a common mistake amongst beginners to
  forget to include the primary key of the
  non-repeating group in the repeating group
• It is possible to have more than one repeating
  group and also a repeating group within a
  repeating group but examples of these types are
  not shown here

25
Second normal form

• Represent the data in Second Normal Form by
  removing any attributes that only depend on part
  of the key
• This only applies to groups having a compound key
• Any group with a simple primary key (one
  attribute in the primary key) may be left as it is

26
Second normal form

• We look at the groups with a compound key and
  decide if any of the attributes in the group
  depend on only part of the compound key. This is
  sometimes known as functional dependency or part
  key dependency
• Where an attribute depends on only part of the
  key we remove it to another group which has as
  its primary key that part of the original
  compound key on which it was dependent

27
Second normal form

• In our example we only consider the data items of
  the second table We consider all the data items
  including those that make up the compound key
• In this case we consider each attribute in turn
  and find that Patient No., Prescription date and
  Drug code all depend on the whole of the compound
  key

28
Second normal form

• However we see that Drug name does not depend on
  Patient No. or on Prescription date
• The Drug name is independent of the patient to
  whom it is prescribed or the date on which it is
  prescribed

29
Second normal form

• It is dependent on the Drug code only
• The Dosage and Length of Treatment are not more
  dependent on part of the primary key compared
  with the whole key and so are left in their
  original group

30
Figure 3 Tables in Second Normal Form
31
Third Normal Form

• Remove any attributes that are not directly
  dependent on any of the key attributes but are
  more dependent on a non-key attribute in that
  group
• We look at each attribute in a group and ask Is
  it directly dependent on the key?

32
Third Normal Form

• If it is not we look at the other non-key
  attributes in the group to find what it is
  dependent upon
• When we have found such a relation we remove it
  to a different group with a suitable key
• We also need to leave behind the attributes
  forming the key for the new group so the tables
  may be related to one another. This is in fact
  the foreign key that we have already met. Many
  beginners forget to do this !

33
Third Normal Form

• Look at every non-key attribute in turn and ask
  if it really does depend on the key
• The groups at the Second Normal form stage have
  an identity indicated by their primary key
• The three tables shown in Figure 4.3 could be
  said to be representing
• Patient
• Prescription
• Drug

34
Third Normal Form

• Taking the attributes of the Patient table first
  we ask
• Does Surname depend upon the patient ? Yes, it
  does.
• Does Fore-name depend upon the patient ? Yes,
  it does.
• Does Ward no. depend upon the patient ? No, it
  doesnt.

35
Third Normal Form

• Does Ward no. depend upon any other attributes
  in this group? Yes, it depends upon Ward nameOf
  course ward name depends upon Ward No.
• These two attributes are then removed to form a
  new group. The primary key chosen for this is
  Ward no. We must leave a copy of that key behind
  in the Patient table to form a foreign key.

36
Figure 4 Tables in third normal form
37
Tables in third normal form

• The tables we now have could be called Patient,
  Ward, Prescription and Drug
• The presentation here shows the normalisation
  procedure and at each step also shows a little
  sample data
• In practice when performing normalisation we
  would only deal with the data item names
• The SSADM way of doing this is given in Figure 5

38
Figure 5

• UNF 1NF 2NF 3NF
• Patient No. Patient No. Patient No. Patient
  No.
• Surname Surname Surname Surname
• Forename Forename Forename Forename
• Ward No. Ward No. Ward No. Ward No.
• Ward name Ward name Ward name
• Prescription date Ward No.
• Drug code Patient No. Patient No. Ward name
• Drug name Prescription date Prescription date
• Dosage Drug code Drug code Patient No.
• Length of Drug name Dosage Prescription date

• treatment Dosage Length of treatment Length
  of treatment
• Length of treatment
• Drug code Drug code Drug name Drug
  name

39
Figure 6
40
Use of Normalisation

• Normalisation may be used to check that tables
  derived from our E-R diagram are in third normal
  form.

41
Summary

• This section has dealt with
• a description of the use of normalisation
• how normalisation and E-R modelling may be used
  together
• the principles of normalisation to produce Third
  Normal Form

42
References

• Goodland M., Slater C., SSADM A Practical
  Approach, McGraw Hill, 1995
• Britton Doake, Software System Development a
  gentle introduction,3e, McGraw Hill,2003, ISBN
  0077099745
• Kendall K., Kendall J., Systems Analysis and
  Design, Prentice Hall, 2002 (fifth edition)
