Modular Telephony Hardware Design

1
(No Transcript)
2
Modular Telephony Hardware Design

• How separating interfaces improves reliability
  and reduces costs

3
Problem 2001 Obsolescence

• Designs were extensions of ISA card adapters
• Based on 8-bit technology
• On board software was highly optimized to get
  maximum performance from minimal hardware
• Shared memory interface low throughput, high use
  of PCI bus

4
Problem 2001 Obsolescence

• Adequate for speeds to 2Mbps but impossible to
  scale
• Expensive to make
• Hard to debug because of on-board microcode
• Conclusion We had to move to modern FPGA-based
  bus master designs

5
Advanced Flexible Telephony (AFT)

• AFT architecture splits the host interface,
  telephony interface and DSP resources
• Common host interfaces forall cards
• Common telephony interfaces for both PCI and
  the newer PCI Express motherboards
• DSP resources also separated so that different
  DSP functions can be integrated across all
  designs

6
A family of telephony cards
Base PCI or PCI Express card
Optional DSP module for echo cancellation and
transcoding
Personality Card Quad port analog module
Personality Card Octal port T1/E1 module
Personality Card Quad port T1/E1 module
Personality Card Dual port analog module
7
Compared to dedicated designs

• Does it cost more than dedicated designs?
• ABSOLUTELY!
• Extra circuit boards
• Expensive inter-PCBconnectors
• Added assembly costs
• Complications related to security and FPGA
  programming

8

• WHAT DO WE GET FOR THE MONEY???

9
ExperienceReliability
10

• So for a start we get a lot better reliability
  for the money!

11
Manufacturing and Support cost
Costs on the Production Side
Similar total cost of production
12
Total Cost of Ownership
Costs on the Ownership Side
Lower TCO
RMAs, troubleshooting, Field replacements, etc.
13
Manufacturing management

• Sangoma sells 30 different card/Telco
  combinations, for example the A101 single T1/E1
  card has four variations
• A101 PCI
• A101 PCI with hardware EC
• A101 PCI Express
• A101 PCI Express with hardware EC
• Total volume of all cards is high, but volumes of
  individual products can be very small
• Inventory control, manufacturing management and
  parts ordering would be a huge job for 35
  designs.

14
Manufacturing management (2)

• Because of the modular design there are much
  fewer manufactured circuit boards than products,
  leading to large production volumes.
• Statistically, it is much easier to predict the
  demand for large volumes than small volumes
• Commonality of parts makes for easier ordering
  processes
• The result is that we are much more likely to be
  able to supply from stock, especially for items
  that are less popular

15

• We also get better stock and Manufacturing
  Control

16
Stocking Benefits
Reseller Stocking levels
Saving in capital investment
Six weeks supply
Two weeks supply
17
Stocking Benefits (2)
Out-of-stock Supplier and Customer
18
Conclusions

• Modular telephony card construction has higher
  manufacturing costs
• Reduced support costs allow us to sell these
  expensive cards competitively
• Additional hard cost benefits accrue to both the
  supplier and the customer in terms of
• Lower support costs for VARs, OEMs and customers
• Reduced capital expenditure in standing inventory
• Fewer out-of-stock occurrences, leading to lower
  irritation factor and lower shipping costs.

19
Questions?
