Sequential Supersaturated Designs for Effective Screening

1
Sequential Supersaturated Designs for Effective
Screening

• Angela Jugan
• University of Missouri Rolla
• October 21st 2005

2
Aknowledgements

• This research was conducted under the guidance of
  my advisor Dr. David Drain for my Thesis
• A Sequential Approach to Supersaturated Design
• Which was completed in June 2005

3
Continuing Research

• We will be explaining the thought process behind
  the work and progress
• We have learned how to adjust our parameters and
  the algorithm to improve our results.
• Each simulation tells us something about where to
  go next.

4
Purpose

• Experimentation in science or industry can
  involve a great number of variables that need to
  be tested for effects on a response or the
  outcome of a process.
• Researchers are looking for ways to reduce the
  number of trials needed in experiments, while
  still achieving accurate conclusions.

5
Supersaturated Designs

• SSDs have trials numbering fewer than the number
  of parameters being estimated
• Assumptions
• Effect sparsity very few factors have an
  effect on the response
• Linear relationship

6
Original Contributions

• Create SSD sequentially, using information from
  previous trials to chose the next trial.
• Use of a hybrid of genetic algorithm, an
  evolutionary computing technique, to search a
  space of candidate designs to find optima.

7
Scope

• 18 variable 16 run design
• Start with initial 8 runs then add 8 additional
  runs sequentially based on previous results

8
Heuristic Optimization

• Heuristic means related to improving
  problem-solving performance, it is also used in
  regard to any method or trick used to improve the
  efficiency of a problem-solving system.

9
History of Heuristic Methods

• In 1961, Marvin Minsky found to be worthwhile to
  introduce a heuristic method, which happens to
  cause occasional failures, if there was an
  over-all improvement in performance.
• Minsky did a great deal of work toward the
  discovery and mechanization of problem-solving
  processes in general-purpose computers
• Search, Pattern-Recognition, Learning, Planning,
  and Induction

10
Methods

• Hill climbing
• Simulated Annealing
• Genetic Algorithm

11
Genetic Algorithm Structure

• The algorithm searches a population of candidate
  designs to identify the best one based on a
  measure of fitness
• Fitness measures optimization
• A new population is created from selected parents
• Repeat until optimum is achieved

12
(No Transcript)
13
Starting Population

• Best to start with the best designs
• Search the space efficiently in the first
  generations

14
Fitness Evaluation

• Every candidate design goes through an evaluation
  of fitness.
• Fitness is defined before the experiment and is
  the same for every candidate in every generation.

15
Allowed to Breed

• The number of Elites, these have the highest
  fitness values
• Percentage of highly fit models
• Random selection of low fit models, called a
  Roulette Rate
• These rates and numbers are parameters to the
  experiment and can change throughout the
  generations

16
Breeding

• A crossover creates a new individual from the
  information contained within two or more parents.

• Mutation is an operation that applies some kind
  of randomized change to the offspring.

17
Tuning the Algorithm

• The performance of heuristic optimization methods
  was studied by Wolpert and Macready and they
  developed a theorem called No Free Lunch
  (1997)
• It states that if an algorithm does particularly
  well on average for one class of problems then it
  must do worse on average over the remaining
  problems.

18
Tuning the Algorithm

• NFL Theorem also shows that no heuristic method
  can be applied to all problems successfully
  rather, the method must be chosen to match the
  problem being solved.
• Not a black box tool
• Many choices to make and adjust to optimize
  specific problem

19
Starting Population

• I chose the initial population
• Placed existing designs into population
• Start with good designs to breed and create
  better designs

20
Choosing the additional runs

• The original choice for the new run was based on
  breaking the highest aliasing between the
  variables found to be significant and the
  variables found to be not significant.
• Alias Matrix (X1' X1)-1X1 'X2
• This is only one possible choice for the new run.


21
Choosing the Additional Runs

• Changed the new run to break all aliasing found
  between the significant variables and
  nonsignificant variables higher than a preset
  value.
• If the Matrix X1 is singular, then a the new run
  was chosen to help balance the design

22
Classic Analysis Methods

• Westfall, Young, and Lin suggested a forward
  selection error control (1998)
• Lin and Li proposed a method based on non-convex,
  penalized least squares (2003)
• Holcomb, Montgomery, and Carlyle used contrasts
  to determine active factors by checking for a
  significant response change when the factor
  setting was changed (2003)
• Lu and Wu introduced a new way to search for
  active factors in SSDs based on the idea of
  staged dimensionality reduction

23
Chosen Analysis Method

• Stepwise regression
• Adding one variable at a time to the model based
  on partial correlations to the response
• Checks variables already entered in model once
  the new variable has been added
• Alpha risk 0.15
• The constant term is included in the model, and
  up to three variables
• Forward regression procedure was used in earlier
  simulations

24
Fitness Evaluation Details

• The fitness evaluation was based on how
  accurately the design identified the true
  significant factors.
• This was done by comparing the results of the
  stepwise regression to a challenging variety of
  test vectors
• Type I error received weight of -1
• Type II error received weight of -3

25
Fitness Evaluation

• Test vector chosen to create response values
• Stepwise regression found significant variables
• Alias Matrix used to create new run
• Repeat until eight additional runs added
• Fitness assessed on alpha and beta risks
• New test vector chosen to simulate data and
  repeat the above process, this done several times
• An average Fitness score is given to the design

26
(No Transcript)
27
Regression Using Matrix Algebra

• The regression procedure was carried out through
  a series of matrix manipulations described by
  Jennrich in 1977, and Thisted in 1988.
• These manipulations start with the Sum of Squares
  Cross-Products matrix, SSCP, and use the SWEEP
  operator. The results are given in a matrix
  which contains all necessary information for
  regression analysis.

28
GA-SA

• This research uses a genetic algorithm
  simulated annealing (GA-SA) hybrid to select a
  supersaturated design.
• The GA-SA first explores the space effectively,
  then in future generations exploits the good
  solutions for the global optima.

29
GA-SA Hybrid

• Predetermined set of starting candidates
• Crossover set at midpoint
• Mutation rate from .05 to .0001
• Roulette rate .3 to .05
• Proportion Breeding .3
• Three Elites
• 20 to 100 test vectors
• 5 Generations

30
Tuning the Algorithm
31
Tune the Objective Function
32
Benchmark Designs

• Comparisons were made to 16 run 18 variable
  designs.
• Nguyens cyclic replication of the BIBD
• D-optimal design

33
Forward Regression Results

• Design Fitness
• Replicated BIBD 0.69
• D-Optimal 0.56
• Winner 0.40
• Effect size 0.75 to 1.5
• Replicated BIBD 0.18
• D-Optimal 0.16
• Winner 0.13
• Effect size 0.25 to 0.75

34
Adjustments to Algorithm

• Wanted to balance alpha and beta risk
• Changed weight on beta risk to -3
• More efficient use of each new run
• Break several aliased variable in new run
• Add balance to design
• Added to initial Candidates

35
Adjustments to Algorithm

• Stepwise Regression
• Stepwise regression significantly raised the
  fitness evaluation.
• More accurate check of variables found
  significant by the design
• Necessary data in the SWEEP matrix

36
Stepwise Regression Results
Effect sizes 0.75 to 1.5
Effect sizes 0.25 to 0.75
37
Future Work

• Improve the performance of objective function,
  the fitness value
• Explore different choices for new run
• Different weights for alpha and beta risk
• Continue tuning the algorithm parameters
• Continued improvement of the designs

38
Questions?
