Introduction to Link Analysis

1
Introduction to Link Analysis

• September 11, 2007
• Analysis of Social Media Seminar
• Natalie Glance

2
Content adapted from

• CS345 Data Mining Class Slides
• Anand Rajaraman, Jeffrey D. Ullman
• IMA Tutorial on Measuring Modeling the Web
• Andrew Tomkins

3
Problem formulation (1998)

• Suppose we are given a collection of documents on
  some broad topic
• e.g., universities, evolution, iraq
• perhaps obtained through a text search
• Can we organize these documents in some manner?
• Link analysis techniques use links, not text

4
Link Analysis Algorithms

• Page Rank
• Hubs and Authorities
• Both proposed at about the same time (1998)
• Topic-Specific Page Rank
• Spam Detection Algorithms
• Mining for Communities
• Further Reading Link Analysis for Web 2.0

5
PageRank

• The PageRank citation ranking Bringing order to
  the Web, L. Page, S. Brin, R. Motwani, T.
  Winograd, 1999.
• The Anatomy of a Large-Scale Hypertextual Web
  Search Engine, S. Brin, L. Page (1998).

6
Ranking web pages

• Web pages are not equally important
• www.silly-billy.com v www.stanford.edu
• Inlinks as votes
• www.stanford.edu has 23,400 inlinks
• www.silly-billy.com has 1 inlink
• Are all inlinks equal?
• Recursive question!

7
Simple recursive formulation

• Each links vote is proportional to the
  importance of its source page
• If page P with importance x has n outlinks, each
  link gets x/n votes

8
Simple flow model

• The web long ago

y y /2 a /2 a y /2 m m a /2
y/2
y
a/2
y/2
m
a/2
m
a
9
Solving the flow equations

• 3 equations, 3 unknowns, no constants
• No unique solution
• All solutions equivalent modulo scale factor
• Additional constraint forces uniqueness
• yam 1
• y 2/5, a 2/5, m 1/5
• Gaussian elimination method works for small
  examples, but we need a better method for large
  graphs

10
Matrix formulation

• Matrix M has one row and one column for each web
  page
• Suppose page j has n outlinks
• If j links to i, then Mij1/n
• Else Mij0
• M is a column stochastic matrix
• Columns sum to 1
• Suppose r is a vector with one entry per web page
• ri is the importance score of page i
• Call it the rank vector

11
Example
Suppose page j links to 3 pages, including i
r
12
Eigenvector formulation

• The flow equations can be written
• r Mr
• So the rank vector is an eigenvector of the
  stochastic web matrix
• In fact, its first or principal eigenvector, with
  corresponding eigenvalue 1

13
Example
y a m
y 1/2 1/2 0 a 1/2 0 1 m 0 1/2 0
y y /2 a /2 a y /2 m m a /2
14
Power Iteration method

• Simple iterative scheme (aka relaxation)
• Suppose there are N web pages
• Initialize r0 1/N,.,1/NT
• Iterate rk1 Mrk
• Stop when rk1 - rk1 lt ?
• x1 ?1iNxi is the L1 norm
• Can use any other vector norm e.g., Euclidean

15
Power Iteration Example
y a m
y 1/2 1/2 0 a 1/2 0 1 m 0 1/2 0
y a m
1/3 1/3 1/3
1/3 1/2 1/6
5/12 1/3 1/4
3/8 11/24 1/6
2/5 2/5 1/5
. . .
16
Random Walk Interpretation

• Imagine a random web surfer
• At any time t, surfer is on some page P
• At time t1, the surfer follows an outlink from P
  uniformly at random
• Ends up on some page Q linked from P
• Process repeats indefinitely
• Let p(t) be a vector whose ith component is the
  probability that the surfer is at page i at time
  t
• p(t) is a probability distribution on pages

17
The stationary distribution

• Where is the surfer at time t1?
• Follows a link uniformly at random
• p(t1) Mp(t)
• Suppose the random walk reaches a state such that
  p(t1) Mp(t) p(t)
• Then p(t) is called a stationary distribution for
  the random walk
• Our rank vector r satisfies r Mr
• So it is a stationary distribution for the random
  surfer

18
Existence and Uniqueness

• A central result from the theory of random walks
  (aka Markov processes)
• For graphs that satisfy certain conditions, the
  stationary distribution is unique and eventually
  will be reached no matter what the initial
  probability distribution at time t 0.

19
Spider traps

• A group of pages is a spider trap if there are no
  links from within the group to outside the group
• Random surfer gets trapped
• Spider traps violate the conditions needed for
  the random walk theorem

20
Microsoft becomes a spider trap
Yahoo
y a m
y 1/2 1/2 0 a 1/2 0 0 m 0 1/2 1
Msoft
Amazon
y a m
1 1 1
1 1/2 3/2
3/4 1/2 7/4
5/8 3/8 2
0 0 3
. . .
21
Random teleports

• The PageRank solution for spider traps
• At each time step, the random surfer has two
  options
• With probability ?, follow a link at random
• With probability 1-?, jump to some page uniformly
  at random
• Common values for ? are in the range 0.8 to 0.9
• Surfer will teleport out of spider trap within a
  few time steps

22
Matrix formulation

• Suppose there are N pages
• Consider a page j, with set of outlinks O(j)
• We have Mij 1/O(j) when j links to i and Mij
  0 otherwise
• The random teleport is equivalent to
• adding a teleport link from j to every other page
  with probability (1-?)/N
• reducing the probability of following each
  outlink from 1/O(j) to ?/O(j)
• Equivalent tax each page a fraction (1-?) of its
  score and redistribute evenly

23
PageRank

• Construct the NXN matrix A as follows
• Aij ?Mij (1-?)/N
• Verify that A is a stochastic matrix
• The page rank vector r is the principal
  eigenvector of this matrix
• satisfying r Ar
• Equivalently, r is the stationary distribution of
  the random walk with teleports

24
Previous example with ?0.8
1/2 1/2 0 1/2 0 0 0 1/2
1
1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3
0.2
Yahoo
0.8
y 7/15 7/15 1/15 a 7/15 1/15 1/15 m
1/15 7/15 13/15
Msoft
Amazon
y a m
1 1 1
1.00 0.60 1.40
0.84 0.60 1.56
0.776 0.536 1.688
7/11 5/11 21/11
. . .
25
Dead ends

• Pages with no outlinks are dead ends for the
  random surfer
• Nowhere to go on next step

26
Microsoft becomes a dead end
1/2 1/2 0 1/2 0 0 0 1/2
0
1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3 1/3
0.2
Yahoo
0.8
y 7/15 7/15 1/15 a 7/15 1/15 1/15 m
1/15 7/15 1/15
Msoft
Amazon
y a m
1 1 1
1 0.6 0.6
0.787 0.547 0.387
0.648 0.430 0.333
0 0 0
. . .
27
Dealing with dead-ends

• Teleport
• Follow random teleport links with probability 1.0
  from dead-ends
• Adjust matrix accordingly
• Prune and propagate
• Preprocess the graph to eliminate dead-ends
• Might require multiple passes
• Compute page rank on reduced graph
• Approximate values for deadends by propagating
  values from reduced graph

28
Computing PageRank

• Key step is matrix-vector multiply
• rnew Arold
• Easy if we have enough main memory to hold A,
  rold, rnew
• Say N 1 billion pages
• We need 4 bytes for each entry (say)
• 2 billion entries for vectors, approx 8GB
• Matrix A has N2 entries
• 1018 is a large number!

29
Comparison of Query for University
Google vs. AltaVista, circa 1998
30
Problems with PageRank

• Measures generic popularity of a page
• Biased against topic-specific authorities
• Ambiguous queries e.g., Michael Jordan
• Uses a single measure of importance
• Other models e.g., hubs and authorities
• Susceptible to Link spam
• Artificial link topographies created in order to
  boost page rank

31
Topic-Specific Page Rank

• Taher H. Haveliwala. Topic-Sensitive PageRank.
  11th International World Wide Web Conference,
  2002
• Instead of generic popularity, can we measure
  popularity within a topic?
• E.g., computer science, health
• Bias the random walk
• When the random walker teleports, he picks a page
  from a set S of web pages
• S contains only pages that are relevant to the
  topic
• E.g., Open Directory (DMOZ) pages for a given
  topic (www.dmoz.org)
• For each teleport set S, we get a different rank
  vector rS

32
Matrix formulation

• Aij ?Mij (1-?)/S if i in S
• Aij ?Mij otherwise
• Show that A is stochastic
• We have weighted all pages in the teleport set S
  equally
• Could also assign different weights to them

33
How well does TSPR work?

• Experimental results Haveliwala 2000
• Picked 16 topics
• Teleport sets determined using DMOZ
• E.g., arts, business, sports,
• Blind study using volunteers
• 35 test queries
• Results ranked using Page Rank and TSPR of most
  closely related topic
• E.g., bicycling using Sports ranking
• In most cases volunteers preferred TSPR ranking

34
Which topic ranking to use?

• User can pick from a menu
• Use Bayesian classification schemes to classify
  query into a topic
• Can use the context of the query
• E.g., query is launched from a web page talking
  about a known topic
• History of queries e.g., basketball followed by
  jordan
• User context e.g., users My Yahoo settings,
  bookmarks,

35
Scaling with topics and users

• Suppose we wanted to cover 1000s of topics
• Need to compute 1000s of different rank vectors
• Need to store and retrieve them efficiently at
  query time
• For good performance vectors must fit in memory
• Even harder when we consider personalization
• Each user has their own teleport vector
• One page rank vector per user!

36
Web spam

• Spamming any deliberate action solely in order
  to boost a web pages position in search engine
  results, incommensurate with pages real value
• Spam web pages that are the result of spamming
• This is a very broad defintion
• SEO industry might disagree!
• SEO search engine optimization
• Approximately 10-15 of web pages are spam

37
Boosting techniques

• Term spamming
• Manipulating the text of web pages in order to
  appear relevant to queries
• Link spamming
• Creating link structures that boost page rank or
  hubs and authorities scores

38
Link Farms

• Spammers goal
• Maximize the page rank of target page t
• Technique
• Get as many links from accessible pages as
  possible to target page t
• Construct link farm to get PageRank multiplier
  effect

39
Link Farms
One of the most common and effective
organizations for a link farm
40
TrustRank idea

• Combating Web Spam with TrustRank, Z. Gyongyi, H.
  Garcia-Molina, J. Pedersen, VLDB, 2004.
• Basic principle approximate isolation
• It is rare for a good page to point to a bad
  (spam) page
• Sample a set of seed pages from the web
• Have an oracle (human) identify the good pages
  and the spam pages in the seed set
• Expensive task, so must make seed set as small as
  possible

41
Trust Propagation

• Call the subset of seed pages that are identified
  as good the trusted pages
• Set trust of each trusted page to 1
• Propagate trust through links
• Each page gets a trust value between 0 and 1
• Use a threshold value and mark all pages below
  the trust threshold as spam

42
Example
1
2
3
good
4
bad
5
6
7
43
Rules for trust propagation

• Trust attenuation
• The degree of trust conferred by a trusted page
  decreases with distance
• Trust splitting
• The larger the number of outlinks from a page,
  the less scrutiny the page author gives each
  outlink
• Trust is split across outlinks

44
Simple model

• Suppose trust of page p is t(p)
• Set of outlinks O(p)
• For each q in O(p), p confers the trust
• bt(p)/O(p) for 0ltblt1
• Trust is additive
• Trust of p is the sum of the trust conferred on p
  by all its inlinked pages
• Note similarity to Topic-Specific Page Rank
• Within a scaling factor, trust rank biased page
  rank with trusted pages as teleport set

45
Picking the seed set

• Two conflicting considerations
• Human has to inspect each seed page, so seed set
  must be as small as possible
• Must ensure every good page gets adequate trust
  rank, so need make all good pages reachable from
  seed set by short paths

46
Approaches to picking seed set

• Suppose we want to pick a seed set of k pages
• PageRank
• Pick the top k pages by PageRank
• Assume high PageRank pages are close to other
  highly ranked pages
• We care more about high PageRank good pages

47
Inverse page rank

• Pick the pages with the maximum number of
  outlinks
• Can make it recursive
• Pick pages that link to pages with many outlinks
• Formalize as inverse PageRank
• Construct graph G by reversing each edge in web
  graph G
• PageRank in G is inverse page rank in G
• Pick top k pages by inverse PageRank

48
Hubs and Authorities

• J. Kleinberg. Authoritative sources in a
  hyperlinked environment. Proc. 9th ACM-SIAM
  Symposium on Discrete Algorithms, 1998. Extended
  version in Journal of the ACM 46(1999).

49
HITS Model

• Interesting documents fall into two classes
• Authorities are pages containing useful
  information
• course home pages
• home pages of auto manufacturers
• Hubs are pages that link to authorities
• course bulletin
• list of US auto manufacturers

50
Idealized view
Hubs
Authorities
51
Mutually recursive definition

• A good hub links to many good authorities
• A good authority is linked from many good hubs
• Model using two scores for each node
• Hub score and Authority score
• Represented as vectors h and a

52
Transition Matrix A

• HITS uses a matrix Ai, j 1 if page i links to
  page j, 0 if not
• AT, the transpose of A, is similar to the
  PageRank matrix M, but AT has 1s where M has
  fractions

53
Example
y a m
Yahoo
y 1 1 1 a 1 0 1 m 0 1
0
A
Msoft
Amazon
54
Hub and Authority Equations

• The hub score of page P is proportional to the
  sum of the authority scores of the pages it links
  to
• h ?Aa
• Constant ? is a scale factor
• The authority score of page P is proportional to
  the sum of the hub scores of the pages it is
  linked from
• a µAT h
• Constant µ is scale factor

55
Iterative algorithm

• Initialize h, a to all 1s
• h Aa
• Scale h so that its max entry is 1.0
• a ATh
• Scale a so that its max entry is 1.0
• Continue until h, a converge

56
Example
1 1 1 A 1 0 1 0 1 0
1 1 0 AT 1 0 1 1 1 0
. . . . . . . . .
1 0.732 1

1 1 1
1 1 1
1 4/5 1
1 0.75 1
a(yahoo) a(amazon) a(msoft)
. . . . . . . . .
h(yahoo) 1 h(amazon)
1 h(msoft) 1
1 2/3 1/3
1 0.73 0.27
1.000 0.732 0.268
1 0.71 0.29
57
Existence and Uniqueness

• h ?Aa
• a µAT h
• h ?µAAT h
• a ?µATA a
• Under reasonable assumptions about A,
• the dual iterative algorithm converges to vectors

• h and a such that
• h is the principal eigenvector of the matrix AAT
• a is the principal eigenvector of the matrix ATA

58
Bipartite cores
Hubs
Authorities
Most densely-connected core (primary core)
Less densely-connected core (secondary core)
59
Secondary cores

• A single topic can have many bipartite cores
• corresponding to different meanings, or points of
  view
• abortion pro-choice, pro-life
• evolution darwinian, intelligent design
• jaguar auto, Mac, NFL team, panthera onca
• How to find such secondary cores?

60
Non-primary eigenvectors

• AAT and ATA have the same set of eigenvalues
• An eigenpair is the pair of eigenvectors with the
  same eigenvalue
• The primary eigenpair (largest eigenvalue) is
  what we get from the iterative algorithm
• Non-primary eigenpairs correspond to other
  bipartite cores
• The eigenvalue is a measure of the density of
  links in the core

61
Finding secondary cores

• Once we find the primary core, we can remove its
  links from the graph
• Repeat HITS algorithm on residual graph to find
  the next bipartite core
• Technically, not exactly equivalent to
  non-primary eigenpair model

62
Creating the graph for HITS

• We need a well-connected graph of pages for HITS
  to work well
• Add all pages linking into and out of search
  results

63
Sample results search engines

• Authorities (in 1998)
• .346 http//www.yahoo.com/ Yahoo!
• .291 http//www.excite.com/ Excite
• .239 http//www.mckinley.com/ Welcome to
  Magellan!
• .231 http//www.lycos.com/ Lycos Home Page
• .231 http//www.altavista.digital.com/ AltaVista
  Main Page

64
PageRank and HITS

• PageRank and HITS are two solutions to the same
  problem
• What is the value of an inlink from S to D?
• In the PageRank model, the value of the link
  depends on the links into S
• In the HITS model, it depends on the value of the
  other links out of S
• The destinies of Page Rank and HITS post-1998
  were very different
• Why?

65
Trawling the Web for Emerging Communities KRR 98

• (slides in separate ppt)

66
Link analysis over weblogs

• How are Blogs different than the Web
• Time-stamps -gt time ordering of posts/links
• Blog-blog links (blogrolls) post-post links
• Friends lists
• Reciprocal links built in as trackbacks
• Rank of post vs. rank of blog
• Search results timeliness vs. relevance/authority

• Research topics
• Information diffusion
• Ranking blogs
• Cascades
• Community mining

67
Information diffusion ranking

• Implicit Structure and the Dynamic of Blogspace,
  Eytan Adar, WWE-2004
• Macroscopic microscopic patterns of blog
  epidemics
• Implicit explicit ranking algorithms that take
  advantage of infection patterns
• iRank acts on the implicit link structure to find
  those blogs that initiate these epidemics

68
Information diffusion in blogs

• Information diffusion through blogspace, Gruhl et
  al, WWW 2004
• How topics spread through blogs
• Macroscopic long-running chatter topics vs.
  bursty spike topics
• Microscopic model topic diffusion as infectious
  disease

69
Information cascades

• Finding patterns in blog shapes and blog
  evolution, M. McGlohon, J. Leskovec, C.
  Faloutsos, M. Hurst and N. Glance
• Study topology of cascades implicit in blog post
  linking behavior
• Temporal evolution of types of cascades for given
  blogs

70
Ranking blogs EigenRumor Algorithm

• The EigenRumor Algorithm for Ranking Blogs, Ko
  Fujimura, WWE-2005
• "EigenRumor" algorithm scores each blog entry
  based on eigenvector calculations.
• Higher score assigned to the blog entries
  submitted by a good blogger but not yet linked to
  by any other blogs based on acceptance of the
  blogger's prior work.

71
Mining weblog communities

• Extracting Latent Weblog Communities A
  Partitioning Algorithm for Bipartite Graphs,
  Kazunari Ishida, WWE-2005
• Builds on Trawling for communities KRR 1998
• Bipartite graphs derived from weblog update
  information and cited webpages
• Partitioning method weakest pairs (WP) method to
  divide a bipartite graph into complete bipartite
  subgraphs
• Discovery of Blog Communities Based on Mutual
  Awareness, Yu-Ru Lin,Hari Sundaram, Yun Chi, Jun
  Tatemura and Belle Tseng, WWE 2006.
• Compute mutual awareness matrix based on
  reciprocal links
• Use an iterative, ranking-based clustering scheme
  on the mutual awareness matrix to determine the
  communities
• PageRank is used to determine the seeds at each
  step, followed by diffusion of association to
  determine the community members.

72
Combining sentiment link analysis

• Modeling Trust and Influence in the Blogosphere
  Using Link Polarity,A. Kale, A. Karandikar, P.
  Kolari, A. Java, T. Finin and A. Joshi, ICWSM
  2007
• Steps
• Identify polarity of blog-blog link
• Use trust propagation models to spread sentiment
  from subset of connected blogs to other blogs
• Seed with computed base polarity of known source
  blog (blog or blog post)
• Take into account magnitude of strength or
  weakness of sentiment
• Uses lexicon of positive and negative words

73
Beyond blogs

• Why We Twitter Understanding Microblogging Usage
  and Communities,Akshay Java, Xiaodan Song, Tim
  Finin, and Belle Tseng, Joint 9thWEBKDD and 1st
  SNA-KDD Workshop, August 2007.
• Dataset includes about 1350K posts from over 75K
  users
• Presents usage trends, network properties, top
  hubs and authorities, community structure and
  geographic distribution.
