Title: Chapter 16 Content Management Systems


1
Chapter 16 Content Management Systems
2
The Content Management Process
3
Overview CMS for UCS
  • Content is created in a authoring tool, then
    saved into CMS (repository)
  • Content is saved into the repository as
    individual element
  • Metadata is added
  • Within the repository, content is managed and
    then delivered to the appropriate media

4
Content Management Process
5
Overview CMS for UCS (Cont.)
  • A CMS must save content so that it can be reused
    two parts of saving content
  • The content itself is divided into elements of
    the appropriate sizes for intended reuse
  • Metadata is added into the elements to define
    these elements for effective reuse, retrieval,
    and tracking
  • A CMS does more than save content
  • The content needs to be accessible for various
    projects or people
  • Archives need to be built to allow access to
    previous versions and to track change over time
  • Security is required to control access to various
    authors and content users
  • Access control, version control, updates,
    archives, and translation

6
"Saved as" Elements
  • As content is saved into CMS, it is "saved as"
    individual elements in the repository and the
    metadata is added
  • To assist authors in writing contextually,
    content is usually authored in documents or large
    components, although content may be reused at a
    much more granular level
  • Before being stored in the repository, content is
    broken apart into its individual elements and
    then saved
  • Segmentation or bursting
  • You define the level of segmentation in a
    segmentation map
  • Organizations typically have different
    segmentation maps for different types of content

7
"Saved as" Elements (Cont.)
  • For nested reuse map
  • You may decided to keep all the nested content
    together in one larger element because the
    content is only reused within itself
  • Take B-Brother product description in Chapter 2
    as an example
  • You would store the description as an element and
    use a filter to take out the pieces that are not
    relevant in a given information product
  • In this case, the segmentation map would identify
    that the content should not be segmented ? it
    should be stored at the paragraph level
    (un-segmented)
  • Flexible segmentation maps are important to UCS
    to ensure the content can be stored at an
    appropriate level for retrievability, reuse, and
    management

8
Content Stored as a paragraph Element VS. Stored
as Separate Elements
9
"Saved as" Elements (Cont.)
  • Vendor questions
  • Does the CMS support segmentation or bursting?
  • Can you define the level of granularity?
  • Can you define multiple levels of granularity
    depending on the type of content?
  • Can you change the level of granularity at a
    later date?

10
Metadata
  • Metadata can be applied to the content in AT, or
    it can be applied as the content is checked into
    CMS
  • Whenever possible, you want metadata
    automatically applied to the elements of content
  • For example when metadata is inherited to all
    sub-elements
  • Metadata is the key to effective retrieval and
    reuse of content in UCS.
  • Metadata needs to be easy to create and easy for
    authors to apply to ensure the metadata is
    applied correctly

11
Contact Container with Inherited Metadata
12
Metadata (Cont.)
  • Vendor questions
  • Can metadata be applied in AT? Is metadata
    applied as content is checked in? How simple is
    it for authors to select and apply metadata?
  • Can sub-elements of a container element
    automatically inherited the metadata of the
    container element?
  • What types of metadata can be automatically
    applied?
  • How easy is it to create a new metatag?
  • Can the facility for creating/changing metatags
    be secured so that only the system administrator
    can make changes?

13
Access Control
  • Access control secures content and identifies who
    can read, create, modify, and delete content
  • Access is based on roles authors, editors,
    reviewers
  • Certain elements may be accessible only to a
    certain group
  • Check to ensure you can set access control at any
    level of granularity
  • If the information product is secured at a
    specific level, then all the content in it should
    be secured at the same level
  • Ex. Company logo.

14
Access Control (Cont.)
  • Vendor questions
  • What security features are provided to protect
    sensitive documents from unauthorized access and
    modification?
  • What levels of security are provided (create,
    read only, modify)?
  • At what level of granularity can content be
    secured?
  • Is an element's level of security maintained
    wherever it is reused?

15
Check-in/Check-out
  • When authors want to work on content they check
    it out and check it back in again when they are
    finished with it
  • This ensures only one person is working on the
    same content at any one time and that multiple
    people cannot concurrently change (or save) the
    content and create a conflict or even destroy the
    version that was saved by the first person
  • Possible to check out previous and current
    versions
  • When changes occur to both versions, the content
    branches
  • Should be discouraged unless it is required
    because it could cause confusion or inaccuracies
    if the wrong version is used

16
Check-in/Check-out
  • Vendor questions
  • How easy is it to check-in/check-out content? Is
    content then locked so other authors cannot also
    check it out and change it?
  • Can the system administrator check in content
    that is checked out by someone else (useful, for
    example, if an author is sick)?

17
Version Control
  • Version control ensures that each time content is
    checked in, another version (copy) is created and
    it is assigned a new version number
  • Ensure that every change to content is saved and
    that every change can be tracked
  • Enable you to use multiple versions of the same
    content in different situations
  • It is important to be able to version each
    element, not just at the container level or
    information product level
  • It is also important to be able to version an
    entire approved information product as it is
    deivered

18
Version Control (Cont.)
  • Version control can be saved as complete new
    versions (previous version change) or as deltas
    (changes only)
  • Vendor questions
  • Is every element versioned individually?
  • What types of versioning are provided?
  • Are changes stored as complete new versions of an
    element or does CMS store the deltas (changes
    only) from the current/original version?

19
Updates
  • Three types of update for reuse
  • Automatically update -- Optionally update -- No
    update
  • Authors reusing the content are responsible for
    determining what type of update they want on the
    reused elements
  • The system default is usually optionally update
  • Different elements can have different update
    options
  • Vendor questions
  • What are the update options?
  • How easy is it to change a selected update (for
    example, automatic update to no update)

20
Repository
  • CMS repository manages the content RDBMS,
    OODB
  • Vendor questions
  • What content formats does the CMS support, and at
    what level of granularity does it support them
    (file, section, paragraph)
  • What type of database does the CM software use?
  • Can the CMS accommodate the demands of enterprise
    implementations (ex. of users and volume of
    documents)

21
Search and Retrieval
  • It should be possible to search and retrieve
    content based on individual elements, containers,
    and whole information products
  • Authors should also be able to find edits, find
    edits made by particular people or at particular
    times, search for comments, and search and
    retrieve on any type of information contained in
    CMS
  • Full-text retrieval, metadata retrieval
  • Vendor questions
  • What type of search engine is available? Can you
    add your own?
  • What types of searching are supported?
  • Can search criteria be restricted based on user
    security profiles?

22
Archive
  • Previous versions of content that are finalized
    and approved but no longer current should be
    archived (stored)
  • Content is archived based on a set of rules that
    specify the period of time in which the content
    is considered to be valid or accurate
  • CMS can automatically delete expired content or
    can prompt a manager to review the content and
    determine whether it should be archived
  • Vendor questions
  • How is archiving, obsoleting, and deleting
    handled? How do you set the rules?
  • How can you reinstate an archive? How can
    archives be searched? Can archives be summarized
    or commented for easy access later?

23
Translation
  • Store the multiple language versions of the
    content
  • Ensure that CMS can create a relationship between
    the source content and the translated content
  • Ensure that when the source content changes, the
    localized content is identified (through
    metadata) as requiring new translation
  • Vendor questions
  • Can CMS create a relationship between the source
    content and multiple translated versions of the
    content
  • Can CMS integrate with a memory translation tool?
    With what memory translation tools can it
    integrate? Can CMS be modified to integrate with
    other memory translation tools if necessary?

24
Workflow
  • See Chapter 17

25
The Types of Content Management Systems
26
Web Content Management System (WCMS)
  • WCMS assists an organization in automating
    various aspects of web content creation, content
    management, and delivery
  • Delivery to the Web is its primary format, but
    many WCMS systems also deliver to wireless
    devices

27
Web Content Management System (WCMS) (Cont.)
  • Advantages
  • The interface and functionality of a WCMS are
    designed to support the web site creation and
    management content cycle, and provide strong
    support for collaborative authoring, testing, and
    controlled delivery of content to the web site
  • Authoring and management is managed in stages
  • Authors work in their own content work areas to
    create content, view and review the content, and
    test functionality
  • When content has been approved, it is moved into
    a staging area, where it is assembled according
    to your design and integrated with content from
    other work areas
  • Approved edition (version) archived
  • Personalization
  • Delivery to the web (and wireless devices) is
    directly integrated

28
Web Content Management System (WCMS) (Cont.)
  • Disadvantages
  • Designed to create, manage, and deliver web-based
    content only
  • In an enterprise environment where paper, and the
    complexities of paper is also required, WCMS
    fails to meet these needs
  • The level of granularity of reuse may be
    insufficient for your requirements
  • Granularity of a web page and page components is
    supported
  • Functionality such as nested reuse and granular
    content that can be exchanged among different
    types of content is rarely supported
  • If WCMS relies on an HTML editor or forms for
    input, the complexities of other types of content
    will not be supported

29
Transaction CMS (TCMS)
  • Designed to manage e-commerce transactions
  • Focus on managing the exchange of money through
    web-based product e-catalogs
  • Typically integrate with legacy systems for
    inventory, pricing, and shipping
  • Shopping cart functionality
  • A key component of TCMS is security
  • Many provide personalization features and provide
    personalized product recommendations to customers
  • Most TCMSs manage transactional information and
    provide full WCMS

30
Transaction CMS (TCMS) (Cont.)
  • Advantages
  • Strong support of e-commerce interactions and
    their capability to interface with legacy systems
    for the transfer of product information
  • Disadvantages
  • TCMSs are web-based only and do not support the
    requirements of enterprise content

31
Integrated Document Management Systems (IMDS)
  • Initially manage enterprise (whole) documents
  • Have moved to the management of elements of
    content
  • IDMSs can interface with multiple types of
    authoring tools to manage multiple types of
    content
  • Need to convert into common format for reuse
  • IDMSs can deliver content in the original source
    format, or converted into other formats
  • A common function of many IDMSs is imaging of
    content
  • Widespread acceptance in organizations where
    security of content and strong control of content
    is required
  • Audit trails, electronic signatures
  • CRM and web content management components

32
Integrated Document Management Systems (IMDS)
(Cont.)
  • Advantages
  • Longevity stable interface and financially
    secure vendors
  • Very strong on traditional content management
  • Some provide the capability to deliver
    publications and web content
  • Disadvantages
  • Longevity interface may be hard for users
    (before Windows)
  • Do not always provide effective content
    management
  • Granularity of the elements may be only at the
    section or sub-section level
  • Many do not support nested reuse or systematic
    reuse
  • Not all support the web content life cycle

33
Publication Content Management Systems (PCMS)
  • PCMSs have served the needs of the technical
    publication industry and book publishing industry
    for years
  • SGML ? XML
  • Can handle the complexities of paper with
    automated TOC generation, indexes,
    cross-references
  • Most support compound documents or virtual
    documents
  • The majority support granular reuse (paragraph or
    smaller)
  • Systematic reuse is supported in XML-based
    systems
  • Support delivery to a large variety of media

34
Publication Content Management Systems (PCMS)
(Cont.)
  • Advantages
  • Provide standard CMS capabilities
  • Provide robust content management for
    publications-oriented content
  • Support multiple levels of granularity of content
    and compound documents
  • Support most type of reuse
  • Strong multiple media delivery capabilities
  • Disadvantages
  • Do not support the web content management life
    cycle

35
Learning Content Management Systems (LCMS)
  • LCMSs are content management systems that support
    the web-based learning materials content life
    cycle and the components of learning content
    (text, graphics, simulations, sound, video,
    animation)
  • The majority are now SCORM-compliant (reuse and
    share)
  • Many are web-based authoring tools combined with
    a CMS that handles traditional CMS functionality
  • May include tools for the creation of
    simulations, animations, and multimedia
  • Most support opportunistic reuse and locked or
    derivative reuse, but few support systematic
    reuse. Some support nested reuse
  • Some LCMSs contain Learning Management System
    (LMS) functionality such as registration, course
    tracking, and evaluation, but most integrate with
    a separate LMS

36
Learning Content Management Systems (LCMS) (Cont.)
  • Advantages
  • Specifically designed to manage the web-based
    learning materials content life cycle (no other
    CMS can effectively handle this cycle)
  • LCMSs deliver the functionality of an e-learning
    authoring tool with the added functionality of a
    CMS
  • Disadvantages
  • Only a few provide paper output, but it is very
    rudimentary
  • LCMS is a closed environment ? very difficult to
    share reusable content with other content areas
    in the organization

37
Enterprise Content Management Systems (ECMS)
  • Many WCMS and some IDMS vendors have started to
    use the phrase Enterprise Content Management to
    describe their products
  • WCM is good, but need to manage other types of
    content as well
  • Approaching ECM in different ways
  • Some now provide XML-based systems that can
    interface with XML-based publishing tools to
    provide paper output
  • Some have continued to focus on web-based
    delivery but now include e-commerce or CRM
    functionality
  • Some have simply incorporated PDF delivery
  • Some IDMS vendors now support more robust web
    delivery and now call themselves enterprise
    content management systems

38
Enterprise Content Management Systems (ECMS)
(Cont.)
  • Advantages
  • ECM vendors support a broader-based content
    management life cycle
  • Disadvantages
  • No consistency in systems that are called ECMS
  • The increased functionality may or may not meet
    your ECM needs

39
Others
  • Knowledge management systems (KMS)
  • Manage both structured and unstructured knowledge
    within the enterprise
  • Focus on the discovery and synthesis of
    information, and on collecting together all the
    knowledge in the organization and indexing it for
    fast retrieval
  • Make organizational information accessible
    through a portal
  • Typically manage documents and data, not elements
    of content
  • May interface with a CMS and make both structured
    and unstructured content available through a
    portal

40
Others (Cont.)
  • Customer Relationship Management System (CRMS)
  • CRMSs collect and integrate customer information
    manage information such as customer contact
    information, products and configurations of
    products they have purchased, the kinds of
    questions they have asked, and buyer profiles
  • Tend to manage data, but they often need to share
    data and content with other systems in the
    organization
  • Application server/development tools
  • A number of CMS tools are built from traditional
    application server development tools
  • Typically the functionality provided is that of
    web content management

41
Database versus CMS
  • CMSs use a database for storing content
  • A database provides only a portion of the
    functionality of a CMS
  • A database begins life as a blank slate no
    structure, no functionality, no interface until
    you create it
  • CMS can be thought as an intelligent layer on top
    of the database that provides both a UI and adds
    business logic

42
Database versus CMS (Cont.)
  • A CMS provides a tremendous amount of
    functionality out of the database, such as
  • Predefined content repository model
  • Support for content relationships
  • Built-in reports (such as where used, history, or
    relationships)
  • Simplified creation of metadata
  • Pre-configured system triggers (notification of
    change)
  • Version control
  • Access control (security)
  • Integration with authoring tools
  • Workflow

43
Can one CMS do it all?
  • MAYBE
  • The key to a single solution is the capability to
    share content among the CMS, the authoring tools,
    and the delivery tools
  • If your organization decides to go with best of
    breed tools
  • Common information models (structures)
  • Common ways of tagging content (style/structure
    tags)
  • Common metadata
Write a Comment
User Comments (0)
About PowerShow.com
