Column-Stores vs. Row-stores

• Harikrishna Bikmal
• 05d05019

2
Row vs. Column Stores
3
Column Stores

• Really good for read-mostly data-warehouses
• Lots of column scans and aggregations
• Writes tend to be in batch
• Top 3 in TPC-H rankings are column stores(Exasol,
  ParAccel and Kickfire)
• Yahoos world largest data warehouse is a column
  store

4
Paper Looks At Key Question

• How much of the buzz around column-stores just
  marketing hype?
• Do you really need to buy Sybase IQ or Vertica?
• How far will your current row-store take you?
• Can you get column-store performance from a
  row-store?
• Can you simulate a column-store in a row-store?

5
Benchmark

• Star Schema Benchmark (SSMB)
• Fact table 17 columns, 60,000,000 rows
• Table LineOrder
• 4 dimension tables largest one 80,000 rows
• Tables Customer, Supplier, Part, Date
• Contains 13 queries divided into four categories
  or flights
• Used System-x row-store database and for column
  store they used C-store

6
Simulate Column-Store Inside Row-Store
7
Average Query Time
8
Vertical Partitioning

• Tuple overheads
• Traditional row store takes 4GB (compressed)
• Vertical partitioning takes 0.7 to 1.1 GB per
  column(compressed)
• Column joins
• Expensive hash joins
• Were unable to use merge join

9
Vertical Partitioning

• Horizontal Partitioning
• Fact table is vertically partitioned using year
  attribute of date table (dimension table)
• Most queries in SSMB have predicate on year
  attribute
• Vertically partitioned tables do not contain date
  foreign key (except one table)

10
Index only plans

• Common type of query
• SELECT store_name, SUM(revenue)FROM Facts,
  Stores WHERE fact.store_id atores.store_id AND
  stores.country Canada GROUP BY store_name
• Contains predicates on fact table using dimension
  tables and need to extract SELECT attributes for
  these tuple ids

11
Index only plans

• Available Index maps values to tuple ids
• Required Tuple ids to attribute values
• Tuple construction is slow !
• Expensive hash joins of the columns of the
  fact table before filtering using dimension tables

12
So..

• All indexes approach is a poor way to simulate a
  column-store
• Problems with vertical partitioning are NOT
  fundamental
• Store tuple header in a separate partition
• Allow virtual TIDs
• Allow HP using a foreign key on a different VP
• So can row-stores simulate column-stores?

13
Optimal set of Materialized Views
14
Column-Store Experiments

• Start with column-store (C-Store)
• Remove column-store-specific performance
  optimizations
• End with column-store with a row-oriented query
  executer

15
Column Store

• Column Store specific optimizations
• Compression
• Late Materialization
• Block Processing
• In visible Join

16
Column Store

• Compression
• Higher data value locality in column-stores
• Better ratio - reduced I/O
• Can use schemes like
• run-length encoding
• Easy to operate on directly for improved
  performance

17
Column Store

• Late Materialization
• Select and Aggregate operations render the
  construction of some tuples unnecessary
• Delays decompression
• Better cache performance
• Block Iteration
• Attributes extraction can be done in blocks
  instead of iterating on rows

18
Column Store

• Invisible Join
• Typical query

19
Invisible Join

• Typical query
• Contains selection predicates on fact table using
  one or more dimension tables, need to extract
  SELECT attributes for these tuple ids,
  aggregation using other dimension tables
• Joins between fact table and dimension tables for
  each selection predicate, aggregate grouping

20
Invisible Join

• Previous approaches either used early
  materialization or the ones with late
  materialization had many out of order attribute
  extraction from the dimension tables

21
Invisible Join

• Step 1

22
Invisible Join

• Step 2

23
Invisible Join

• Step 3

24
Invisible Join

• Between-Predicate Rewriting
• Use of range predicates instead of hash lookup in
  step 1 of invisible join
• If the set of keys obtained for join in step 1
  results in a complete range of keys
• Use of dictionary table in case of predicates on
  sorted fields
• Invisible join gave up to 75 improvement in some
  queries

25
Break down of column store advantages
t block processing (T) C compression (c) I
Invisible join (i) L late Materialization(l)
26
Conclusions

• Attempt to emulate the physical layout of a
  column-store in a row-store
• Broke down the reasons why a column-store is able
  to process column-oriented data so efficiently
• Introduced Invisible join

27
