SEEGRIDSCI Operations Procedures and Tools

1
SEE-GRID-SCI Operations Procedures and Tools

• Regional SEE-GRID-SCI Training for Site
  Administrators
• Institute of Physics Belgrade
• March 5-6, 2009

Antun Balaz Institute of Physics Belgrade,
Serbia antun_at_scl.rs
The SEE-GRID-SCI initiative is co-funded by the
European Commission under the FP7 Research
Infrastructures contract no. 211338
2
Overview

• SEE-GRID operational and monitoring tools (and
  their relation to EGEE tools)
• HGSM/GOCDB
• Helpdesk/GGUS
• BBmSAM/SAM
• GStat
• Nagios/CIC portal
• Accounting portal
• Downtime procedures
• Upgrade procedures
• Grid-Operator-On-Duty (GOOD)
• Service Level Agreement (SLA)

3
Operational monitoring tools
GSTAT (Taiwan)
HELPDESK
VOMS
BDII
SAM
Accounting
NAGIOS
BBmSAM
R-GMA
HGSM
4
HGSM/GOCDB (1)
5
HGSM/GOCDB (2)
6
HGSM/GOCDB (3)

• Static database containing all relevant data
  about all SEE-GRID and AEGIS sites
• Must be kept synchronized with the real situation
• All sheets must be properly updated
• Site Info
• Contacts
• Site Nodes
• Downtimes
• XML dumps the easiest way to apply changes is
  to download XML dump of the data, edit it
  appropriately, and then upload the new XML file
  this also allows keeping of backups

7
HGSM/GOCDB (4)

• The essential fields in HGSM
• GIIS URL
• Monitoring Yes
• Status certified
• Type seegrid_production, seegrid_certified,
  egee_production
• Site Commitments
• Contacts and administrators
• All fields have to have correct values!
• URL https//hgsm.grid.org.tr/

8
Helpdesk/GGUS (1)
9
Helpdesk/GGUS (2)
10
Helpdesk/GGUS (3)

• Central reference point for tracking of all
  operational and user problems
• Identified problems are reported through the
  Helpdesk and assigned to the appropriate
  supported
• If problems cannot be solved within the SEE-GRID
  community, they are propagated to other
  projects/initiatives/support systems (e.g. GGUS)
• URL https//helpdesk.see-grid.eu/

11
BBmSAM/SAM
12
BBmSAM History
13
BBmSAM

• Portal that provides access to the database of
  SAM tests results
• Central tools for identification of operational
  problems
• Should be checked by each site admin on a daily
  basis
• Should be used to troubleshoot problems
• Also provides SLA figures
• URL https//c01.grid.etfbl.net/

14
GStat (1)
15
GStat (2)

• Central tool for monitoring of the information
  system of SEE-GRID infrastructure
• Provides useful data
• Identifies problems with sites
• Should be checked by each site admin on a daily
  basis and used for troubleshooting
• Useful ldapsearch commands can be found on GStat
  pages!
• URL http//goc.grid.sinica.edu.tw/gstat/seegrid/

16
Nagios/CIC portal (1)
17
Nagios/CIC portal (2)
18
Nagios/CIC portal (3)

• Collection of alarms raised by various tools
• The aim is to integrate all the tools and make
  the life of site admins and infrastructure
  managers easier
• In the future, automatic creation of Helpdesk
  tickets will be implemented
• URL https//portal.ipp.acad.bg7443/seegridnagios
  /

19
Accounting portal (1)

• Accounting by site
• Accounting by countries and institutions
• Accounting by applications

20
EGEE Accounting portal
21
Accounting portal (2)

• Collects the accounting data from all SEE-GRID
  and AEGIS sites through apel accounting publisher
  developed by the project
• Provides aggregated accounting data by site,
  country, institution, application
• Each site must publish the accounting data
  properly
• URL https//gserv1.ipp.acad.bg8443/Welcome/

22
Downtime procedures

• Downtimes must be announced well in advance (1
  week is reasonable time)
• There are always downtime due to hardware etc.
  failures that cannot be anticipated
• All downtimes must be entered properly in HGSM
• That way they are not be counted against the
  sites availability
• In addition, all downtimes must be broadcasted by
  e-mail to the GIM, APP and proper VO mailing
  lists
• Downtime should not exceed 10 of the total time
  (monthly, quarterly)
• If yes, explanation must be provided
• If the explanation is not accepted by the project
  management, SA1 claims will be rejected

23
Upgrade procedures

• All upgrades/updates are announced over the GIM
  list
• The broadcasts contain links to further
  instructions for upgrades for each Grid service
• Site admins should carefully examine them before
  performing the update!
• In addition, possible SEE-GRID-specific
  instructions are given in the e-mail
• For especially important updates/changes, tickets
  are created for each site
• For some upgrades/updates to be performed,
  downtimes may be required
• OS updates must be regularly installed, to
  minimize security risks

24
Grid-Operator-On-Duty (GOOD)

• Rotating shifts on a weekly basis
• Each countrys GIM is responsible to monitor
  sites during his/her shift
• Tickets are submitted to sites with problems,
  according to the status of sites in various
  monitoring tools (BBmSAM, GStat, Nagios,
  Accounting portal, etc.)
• Older tickets that are not resolved are escalated
• Support is given to sites that cannot resolve
  earlier identified operational problems
• User tickets are assigned to the appropriate
  supporters
• Wiki documentation is updated, or new wiki pages
  created if necessary
• URLs
• http//wiki.egee-see.org/index.php/SG_GOOD
• http//wiki.egee-see.org/index.php/SG_Helpdesk_tic
  kets

25
Usual problems and links to (possible) solutions

• BDII
• siteBDII (GIIS) or top-level BDII is
  Unreachablehttp//faq.twgrid.org/faq/index.php?ac
  tionartikelcat14id11artlangen
• No info publishedhttp//goc.grid.sinica.edu.tw/go
  cwiki/No_data_published_by_top_level_BDII
• CA
• CA version test failed with error messageThis
  CA is an old one and time allowed to upgrade is
  overhttp//grid-deployment.web.cern.ch/grid-deplo
  yment/lcg2CAlist.html
• CE (Computing Element)
• Job submission failed with error
  messageBrokerhelper Cannot plan. No compatible
  resourceshttp//goc.grid.sinica.edu.tw/gocwiki/B
  rokerhelper3A_Cannot_plan._No_compatible_resource
  s
• Job submission failed with error messageGot a
  job held event, reason Unspecified gridmanager
  errorhttp//goc.grid.sinica.edu.tw/gocwiki/Unspec
  ified_gridmanager_error
• Job submission failed with error messageCannot
  read JobWrapper output, both from Condor and from
  Maradonahttp//goc.grid.sinica.edu.tw/gocwiki/Can
  not_read_JobWrapper_output2e2e2e
• Job submission failed with error message7
  authentication failedhttp//goc.grid.sinica.edu.t
  w/gocwiki/7_authentication_failed
• Job submission failed with error message10 data
  transfer to the server failedhttp//goc.grid.sini
  ca.edu.tw/gocwiki/10_data_transfer_to_the_server_f
  ailed
• 4444 Waiting jobs in the GRIShttp//goc.grid.sini
  ca.edu.tw/gocwiki/4444_Waiting_jobs_in_the_GRIS
• SE (Storage Element)
• File copy and registration failed with error
  message535 535-FTPD GSSAPI error GSS Major
  Status General failurehttp//goc.grid.sinica.edu
  .tw/gocwiki/535_535-FTPD_GSSAPI_error3A_GSS_Major
  _Status3A_General_failure

26
Service Level Agreement (SLA)

• Old URL http//wiki.egee-see.org/index.php/SG_SLA

• The change to the current one is that the
  required availability is 80, and that the
  availability is calculated on 3h basis, not on a
  daily basis
• BBmSAM portal provides SLA figures
• Sites not fully conforming to the SLA will have
  reduced funding
• Sites with the availability lt50 will be
  uncertified
• Sites fully conforming to the SLA will be put
  into seegrid_certified status and become visible
  to the whole SEE region (i.e. not only SEE-GRID,
  but also EGEE-SEE etc.)
