Angiogenesis in Ovarian Cancer

1
Angiogenesis in Ovarian Cancer

• Christina M. Annunziata, MD, PhD
• Medical Oncology Branch
• National Cancer Institute
• Bethesda, MD

2
Ovarian Cancer

• Stage Description Incidence Survival
• I Confined to ovaries 20 90
• II Confined to pelvis 5 65
• III Spread IP or nodes 58 45
• IV Distant metastases 17 lt5

3
Stage shift at diagnosis might improve Ovarian
Cancer Outcome. Cases Deaths Fractional
DeathBreast 210,600 41,000 19Ovary 21,000 16,
414 78

Based upon ACS 2006
4
Ovarian Cancer Prognostic Factors

• Stage
• Extent of Cytoreduction
• Histology and Grade
• Performance Status
• p53 Status
• Vital Organ Function
• Physiologic Age

• PlatinumTaxane Primary Therapy
• Intraperitoneal therapy
• Information from Second-Look Surgery
• Genotype BRCA1/2
• VEGF Production

5
The State of Treatment for Newly Diagnosed
Ovarian Cancer

• First Precept Complete surgical staging
• Second Precept Optimal reductive surgery
• Third Precept Chemotherapy
• Fourth Precept Clinical Trials

6
The State of Treatment for Newly Diagnosed
Ovarian Cancer

• First Precept Complete surgical staging
• Full assessment of abdomen and pelvis
• Random biopsy of visually negative areas
• Lymph node dissection (except Stage I)
• Second Precept Optimal reductive surgery
• Third Precept Chemotherapy
• Fourth Precept Clinical Trials

7
Procedures required for surgical staging of
ovarian cancer. Scrapping of the underside of
the right, diaphragm, removal of the para-aortic
lymph nodes, removal of the pelvic lymph nodes,
removal of the omentum and peritoneal washing
8
The State of Treatment for Newly Diagnosed
Ovarian Cancer

• First Precept Complete surgical staging
• Second Precept Optimal reductive surgery
• Stage I, II - Complete removal of all disease
• Stage III, IV - Residual disease lt 1 cm
• Third Precept Chemotherapy
• Fourth Precept Clinical Trials

9
Optimal Cytoreduction
0 cm
Proportion surviving
0-1 cm
1-2 cm
gt2 cm
Time since initial surgery (years)
10
The State of Treatment for Newly Diagnosed
Ovarian Cancer

• First Precept Complete surgical staging
• Second Precept Optimal reductive surgery
• Third Precept Chemotherapy
• Platinum cisplatin or carboplatin
• AND
• Taxane paclitaxel or docetaxel
• Intraperitoneal if Stage III, optimal reduction
• Fourth Precept Clinical Trials

11
Timeline of Treatment and Outcome for Advanced
ovarian Cancer. ?In 1960 alkylators were
developed but the 5 year survival was 0. ?In
1970 cisplatin was developed and the 5 year
survival was 5. ?In 1980, cisplatin/alkylator
combinations were developed and the 5 year
survival was 15. ?In 1990 paclitaxel/carboplati
n was developed and the 5 year survival was
35.?In 2000 paclitaxel/carboplatin was given ip
and the 5 year survival was 40.
12
Representative Chemotherapy Agents include
Platinum, Paclitaxel, Topotecan, Gemcitabine and
Doxil
13
GOG 172 The new Standard of Care. ?Stage I
uses Cisplatin 75 mg/m2Paclitaxel 135 mg/m2 (24
h)?Stage II uses Cisplatin 100 mg/m2 IP
d1Paclitaxel 135 mg/m2 (24 h) IV d1Paclitaxel
60 mg/m2 IP d8
14
GOG 172 The new Standard of Care
Median survival 65.6 mo
Median survival 49.7 mo
15
GOG 218 The NEXT Standard of Care ? Stage I
uses Paclitaxel, Carboplatin, Placebo x 6
followed by Placebo x 22. Stage II uses
Paclitaxel, Carboplatin, Bevacizumab x 6 followed
by Placebo x 22. Stage III uses Paclitaxel,
Carboplatin, bevacizumab x 6 followed by
Bevacizumab x 22.
16
Angiogenesis in Ovarian Cancer

• Preclinical studies

17
Angiogenesis in Ovarian Cancer. Preoperative
VEGF serum levels for 101 ovarian cancer patients
were 549, for 16 borderline tumors were 200 and
for 34 benign cysts were 228.
18
Angiogenesis in Ovarian Cancer. VEGF levels in
peritoneal effusions were 2575 in ovarian cancer
patients, 182 in borderline tumors and 185 in
benign cysts.
19
Angiogenesis in Ovarian Cancer VEGF levels in
peritoneal effusions
over 2575
under 2575
20
Angiogenesis in Ovarian Cancer Micro-vessel
density and survival
ALIVE
DEAD
Status at median
21
The State of Treatment for Newly Diagnosed
Ovarian Cancer

• First Precept Complete surgical staging
• Second Precept Optimal reductive surgery
• Third Precept Chemotherapy
• Fourth Precept Clinical Trials

22
Angiogenesis in Ovarian Cancer

• Anti-VEGF therapy Bevacizumab
• GOG trial 170-D
• Recurrent ovarian cancer
• Second or third line therapy
• Overall response rate 18
• Stable disease 39
• Where do we go from here?

23
Angiogenic targets in ovarian cancer

• Microenvironment
• EGFR, PDGFR
• Single agents (gefitinib, imatinib)
• Angiogenesis
• VEGFR
• Single agent (bevacizumab) effective
• GOG-170D, 18 RR, 39 PFS at 6mo
• Combined agents (bev sorafenib) promising
• Ongoing clinical trial at NCI

24
Angiogenesis in Ovarian Cancer

• Targeted agents and tissue proteomics
• Hitting the target?

25
Microdissection of core biopsies Tumor Stroma
l
26
Reverse-Phase Protein Arrays. Quantitative
method for assessing proteins and activation
patterns from small quantities of cells or
tissue.
27
Functional proteomicsQuality optimization and
assurance
28
EGFR (ErbB1, Her1)

• Elevated in 50 - 70 ovarian ca
• Targeted therapy
• Gefitinib
• Erlotinib
• Cetuximab

29
Phase II trial of Gefitinib in ovarian cancer

• Primary Objective demonstrate inhibition of
  EGFR, Akt, and ERK activation in tumor and skin.
• Secondary Objectives
• Assess clinical activity and toxicity
• Correlate biochemical effects with outcome and
  toxicity
• Treatment Gefitinib 500 mg/d
• Biopsy before starting and at 4wk

30
Phase II trial of Gefitinib in ovarian cancer.
How / Why might gefitinib work in ovarian cancer?
What are downstream effectors of EGFR in ovarian
cancer?
31
Gefitnib Therapy Patient A
32
Gefitnib Therapy Patient B
33
Proteomic profile. Clinical Objective clinical
activity and toxicity profile of
imatinibTranslational Objectives?To describe
tumor cell signaling pathways and their
modification by imatinib and to correlate with
outcome (biopsy on study 4 wks) ?To
investigate anti-angiogenic activity of
imatinib?To investigate other potential
molecular targets of imatinib ?To apply
SELDI-AI to serial serum samples for prediction
of response and/or toxicity.
34
Proof of Target c-Kit Phosphorylation is
Reduced in Tumor and Stroma By Imatinib Therapy
35
Tissue proteomics can validate targets

• Is the target there?
• Did you hit the target?
• Did you affect downstream signals?
• Was it important?
• True for antitumor activity
• and toxicity

36
Angiogenic targets in ovarian cancer

• Microenvironment
• EGFR, PDGFR
• Single agents (gefitinib, imatinib) clinically
  ineffective
• Angiogenesis
• VEGFR
• Single agent (bevacizumab) effective
• GOG-170D, 18 RR, 39 PFS at 6mo
• Combined agents (bev sorafenib) promising
• Ongoing clinical trial at NCI

37
Combination TherapyLESS of each MORE is
better ? HypothesisPartial inhibition at
points in series or parallel pathways may
translate into greater therapeutic benefit of new
molecularly targeted agents in solid tumors.
38
Tumor angiogenesis involves 1. secretion of
angiogenic factors, 2. proteolytic destruction of
extracellular matrix, 3. endothelial cell
proliferation and migration, 4. appearance of new
tumor vasculature and 5. intravasation.
39
Hypothesis Combining VEGF-targeted agents will
be synergistic. Anti-VEGF (bevacizumab) and
sorafenib will inhibit endothelial cell
proliferation and migration resulting in
increased vascular permeability.
40
Phase I trial sorafenib bevacizumab in solid
tumors

• Primary Objective
• Safety and toxicity
• Biochemical changes in Ras-Raf-MAPK and VEGF
  pathways
• Secondary Objectives
• DCE-MRI and PET for tumor vascular flow CD31 IHC

• Pharmacogenomics of CYP3A4 on sorafenib
• Genotype Ras and Raf mutations
• Measure changes in circulating VEGF and other
  cytokines
• Eligibility Criteria
• All solid tumors (focused accrual in renal cell,
  melanoma, ovary)
• Biopsiable disease (cohort 2)
• Good end organ function
• No limitation for prior number of therapies

41
Expansion Translational Study Group, Cohort 2
(Sorafenib 200 mg bid/ Bevacizumab 5 mg/kg q 2
weeks). ?In phase I a PET, biopsy and MRI will
be performed at cycle 1 and day 15 of Sorafenib
or Bev. A MRI will be performed at cycle 2. ?In
phase II a PET, biopsy and MRI will be performed
at day 15 of both Sorafenib and Bev. The first
imaging reassessment will be performed at cycle 3.
First imaging reassessment
PET
Biopsy
MRI
42
Patient 6 - Epithelial ovarian cancerDL 1,
continued PR gt 2 yrs
C9d1
On study
43
Reduced vascular flow with single agent and
combination therapy
DCE-MRI yielded Rx-related changes
Azad, Choyke, Chen, Kohn, et al
44
Preliminary results proof of conceptGreater
reduction in ERK activation with sorafenib.ERK
is downstream of both VEGFR2 and Raf
Sorafenib
Bevacizumab
bx2/bx1
Yu and Henning
45
Targeted therapy in parallel. Hypothesis Dual
VEGFR- and EGFR-targeted agents will be
synergistic. Endothelial cell proliferation and
migrationIncreased vascular permeability
46
Vandetanib Study Design. At cycle 1 there is a
Bipsy and MRI. At day 3 there is a MRI. At day
15 there is a Biopsy and MRI. At cycle 3 there
is a first imaging reassessment.
47
Exciting new directions

• Bevacizumab dasatinib (src inhibitor)
• Extending successful bev sor combination
• Phase I -- Opening Fall 2008
• L-aspargase in ovarian cancer
• Translated from CCR labs
• Pilot trial in ovarian cancer -- under review
• Endothelin inhibitor MEK inhibitor
• Translated from Kohn lab, Oncogene 2005
• Toxin-conjugated Ab to tumor/stroma antigen
• First-in-human Phase I trial under development

48
Translational Oncology is based on observation,
hypothesis, experiment/trial, result and analysis

49
Angiogenesis in Ovarian Cancer

• a promising target
