The Alta Operating System

1
The Alta Operating System

• Patrick Tullmann
• Masters Thesis Defense
• University of Utah

2
Alta

• Alta is an operating system in aJava Virtual
  Machine
• Manages multiple applications on a single JVM
• Supports the Fluke OS nested process model (NPM)

3
Research Goals

• Can I change the protection mechanism in an OS
  model?
• Can I provide safe, controlled sharing between
  Java processes?

4
Motivation Servlet Engine
5
Motivation

• Java Virtual Machine provides
• Safety
• Platform independence
• Java-based systems need
• Multiple user management
• Resource management
• Flexible extensible control

6
Approach

• Traditional OS a good model
• Hardware provides safety mechanism
• OS provides management
• Fluke OS nested process model

7
Fluke Background

• Microkernel
• Threads, mutexes, IPC,
• Manages CPU and memory
• User-level services
• File, Network,
• Nested process model
• Structured
• Well defined

8
Nested Process Model

• A model of how processes interact
• Hierarchical parent process provides resources

9
Mapping an OS into Java

• Type safety replaces hardware page protections
• Bytecodes replace simple instructions
• Native methods replace privileged instructions
• All higher-level abstractions are equivalent

10
Goals for Alta

• Support Fluke features for process management
• Mimic Fluke structure
• Provide parent process with control
• Acceptable performance
• Maintain backwards compatibility
• Existing Java apps should work

11
Design of Alta

• Four design aspects (really seven)
• Maintain whole JVM illusion
• Per-process, flexible typespaces
• Inter-process sharing
• Sharing resource control
• IPC-based interfaces
• Exportable kernel state
• Kernel implementation

12
Design of Alta

• Four design aspects
• Maintain whole JVM illusion
• Per-process, flexible typespaces
• Inter-process sharing
• Sharing resource control

13
Design of Alta

• Four design aspects
• Maintain whole JVM illusion
• Per-process, flexible typespaces
• Inter-process sharing
• Sharing resource control

14
Per-process Typespaces

• Typespace Set of name to class bindings in a
  process
• Extension of the NPM to Java
• Parent process resolves all class names
• Enables access controls
• Enables code control in child process
• Problems with native methods
• Poses problems for sharing

15
Per-process Typespaces

• Implies class has no fixed name
• Implies there can be inconsistencies
• Different notion of File
• Same notion of Directory

16
Design of Alta

• Four design aspects
• Maintain whole JVM illusion
• Per-process, flexible typespaces
• Inter-process sharing
• Sharing resource control

17
Inter-process Sharing

• Alta allows limited inter-process sharing
• Initial sharing via IPC
• Sharing through other shared objects
• Processes can have inconsistent types
• Inter-process type inconsistencies can destroy a
  JVM
• pointer forging

18
Inter-process Type Checking

• Alta ensures equivalent types for all shared
  objects
• Effective limits on shareable types
• Completely consistent field types
• Only allows non-polymorphic fields

19
Design of Alta

• Four design aspects
• Maintain whole JVM illusion
• Per-process, flexible typespaces
• Inter-process sharing
• Sharing resource control

20
Sharing Resource Control

• Sharing complicates resource control
• Termination of process that has exported
  objects
• Alta lets applications control sharing
• Nested process model enables constrained sharing

21
User-level Shared Objects

• Child allocates -gt Parent references
• Harmless. If parent dies then child dies
• Useful. Child can pass IPC arguments
• Sibling allocates -gt Sibling references
• Allowable. Parent trades communication costs
  for separation
• Parent allocates -gt Child references
• Standard server behavior
• Cannot deallocate without childs cooperation

22
Results Evaluation

• Micro-benchmark measurements
• Comparison with Fluke
• Structure
• Performance

23
Platform

• Base system
• Kaffe Java virtual machine
• Platform
• Measurements from a 300 Mhz PII
• Java code is JIT compiled

24
Micro-benchmarks

• Alta vs. Kaffe
• Basic VM operations are unchanged
• 50-100 cycle overhead on object allocation
• Kaffe/Alta vs. Microsoft JVM
• Three (or more) times slower

25
Alta vs. Fluke Structure

• Use similar internal organization
• Both implement a red line Back 1999
• Fully preemptible kernel
• Alta allows kernel / user data sharing
• Altas kernel is almost malloc-less
• Except some JVM-internal structures

26
Alta vs. Fluke Performance

• Alta wins
• Null system call
• 192 cycles (vs. 302 in Fluke)
• Optimal thread switch
• 185 cycles (vs. 519 in Fluke)
• Fluke wins everything else, e.g.,
• Null IPC round trip
• 18,524 cycles (64 µs) vs. 7,519 cycles in Fluke
• Process creation
• 11.9M cycles (39 ms) vs. 1M cycles in Fluke

27
Performance Evaluation

• Alta hampered by poor JIT compiler
• GCJ will improve this
• Alta kernel is C-like
• HotSpot, etc provide interesting opportunities
• Alta can be optimized, too
• Static definition of a typespace
• Better kernel synchronization
• Incorporate recent Fluke optimizations

28
Related Work Java

• Balfanz 1998, Bernadat 1998, Sun 1998
• J-Kernel Hawblitzel 1998
• Pure Java
• No inter-process sharing
• KaffeOS Back 1999
• More restrictive sharing
• Resource management focus
• Per-process heaps
• GC time accounting
• ...

29
Related Work OS

• Pilot / Cedar / Mesa Redell 1980, Swinehart
  1986
• Oberon / Juice Franz 1996
• Inferno Dorward 1998
• SPIN Bershad 1995
• Vino Seltzer 1996

30
Future Work

• Resource accounting GC
• Formal analysis of Alta type system
• Fluke Alta integration
• Alta-specific applications

31
Contributions

• Alta demonstrates applicability of OS
  abstractions to Java
• The Fluke NPM with a different protection
  mechanism
• Multiple application support in a JVM
• Type-safe sharing between inconsistent typespaces
