Title: Java Database Connectivity JDBC


1
Java Database Connectivity (JDBC)
  • Presented by
  • Rola Othman
  • Pat Wiseman
  • Mary Gleason

8 April 2003
2
Objectives
  • Relational database tables
  • SQL (Structured Query Language)
  • Register a database as an ODBC data source
  • Connecting to a database from Java
  • Build a database using JDBC and SQL
  • Query a database with java
  • Metadata and Result set
  • Aggregate Functions
  • The use of Prepared statements
  • Use database GUI
  • Process database Transactions with the GUI

3
Database Tables and SQL Queries
  • SQL
  • Allows for the creation, updating, and querying a
    database
  • Standard commands are used
  • Relational Database Tables
  • Data is stored in tables

Customer Table
4
Relational Databases Cont
  • Rows represent info needed for one customer
  • Fields are assigned
  • The key is a unique identifier
  • Keys are used to retrieve information from the
    data
  • Relationships
  • Association established between common fields
    (columns) in two tables.
  • 1-1
  • 1-M
  • M-M

5
Relational Database Cont
  • primary key One or more fields (columns) whose
    value or values uniquely identify each record in
    a table. A primary key cannot allow Null values
    and must always have a unique index. A primary
    key is used to relate a table to foreign keys in
    other tables
  • foreign key One or more table fields (columns)
    that refer to the primary key field or fields in
    another table. A foreign key indicates how the
    tables are related.

6
SQL-Structured Query Language
  • Standardized language that retrieves and updates
    info to the database
  • SQL statements are executed within Java
  • Statements that are used
  • CREATE
  • CREATE TABLE Customer (CustomerID VARCHAR(4),
    CustomerName VARCHAR(25), Address VARCHAR(25),
    BalanceDue CURRENCY)
  • INSERT
  • INSERT INTO Customer VALUES (5678,'Darnell
    Davis','33 Second St.',130.95)
  • DELETE
  • DELETE FROM Item WHERE Description 'CD player'
  • UPDATE
  • UPDATE Item SET Quantity 12
  • SELECT (Mostly with Querying), WHERE, AND, OR
  • Query- Retrieval of information from a database
  • SELECT FROM Customer
  • WHERE CUSTID 1
  • WHERE-Specific conditions need to be met

7
Connecting to a Database
  • Two-tiered
  • Database server
  • Resides on one machine
  • Various clients connect when access to data is
    needed
  • Three-tiered
  • Application Server
  • Acts as a server to various application clients
  • Client of database server

8
JDBC
  • Java Database Connectivity
  • Write Java programs that will work no matter
    which database system
  • JDBC Driver
  • Provides a uniform interface to Java programs
  • Vendors provide JDBC drivers for use with each
    database system
  • Translates JDBC statements to the specific
    commands of a particular database system
  • ODBC bridge to work with Access
  • Open Database Connectivity (ODBC)

9
Lab Time
  • Lab 1
  • Creating an ODBC Data Source

10
Connecting from Java
11
Building the Database
Once a connection is made to the database SQL
statements are used to create to populate the
database
12
Retrieving Information
  • JDBC can be used to extract information from a
    database
  • executeQuery method
  • Returns
  • ResultSet

13
Lab Time
  • Lab 2
  • Connect, Create, and Extract information from a
    Database

14
Metadata and Aggregate Functions
  • Metadata
  • Database
  • Properties of the database
  • Table Names
  • Column types and names
  • Result sets that are obtained
  • Result Set
  • Information about each table
  • Aggregate
  • Functions that compute values
  • Uses rows to produce results

15
Lab Time
  • Lab 3
  • Metadata, Result set metadata, and Aggregate
    functions

16
Prepared Statements and Transactions
  • Translates statement to low level database
    commands once
  • Execution possible many times
  • No more redundancy
  • Transactions must be complete
  • Commitment must occur after transaction
    completion
  • Execution of several transactions
  • Bank example

Withdraw
Deposit
Commit
17
Lab Time
  • Lab 4
  • Statements and Transactions

18
GUI for database queries
  • Graphical User Interface
  • User Composes queries
  • User controls actions

19
Lab Time
  • Lab 5
  • GUI

20
If you have any questions
  • Please call Rola in Florida!

The End
