A Project on Internet Banking

1
Distributed E-commerce
A Project on Internet Banking
Team Aravind Reddy Vijay Kumar Harsha
2

• What is it?
• Banking on the Net

Our Goal To develop a prototype of a banking
application.
3

• The system
• A normal client/middleware/server architecture
• Major components
• Clients
• Server
• Databases

4
Physical Structure
Application Server
Database
CLIENT
Web Server
5

• Our application supports the following
• Account checking
• Transfer funds
• Online bill payment

6
Start
Basic Flow
Client contacts the server
Server checks for authentication
No
IF Valid
Yes
Display choice
Perform Transactions
Update database
No
If end
Yes
Stop
7
Technologies and protocols TCP/IP protocols
Client side application in Java EJB for the
Server JBOSS2.4.1 application server ANT1.4 for
deploying beans JETTY3.1.0 Web Server MS Access-
Database.
8

• Why EJB
• Online services can be delivered rapidly.
• Can be carried to Mobile Banking channel.
• Component Technology.
• One solution is built and can be deployed across
  different platforms.
• Location Independent Banking

9
Proposed Architecture for Mobile channel
Web Server
Application Server
RMI IIOP
HTTP
Gateway
SQL
Database
WAP
Client
