Title: Envisat


1
  • Experiences with Envisat ASAR WM Wave Product
  • Harald Johnsen
  • Norut IT, Tromsø, Norway

2nd workshop on Coastal Marine Applications of
SAR,Longyearbyen, 8 12 September 2003

2
Content
  • The ASAR Wave Algorithm
  • what it does
  • what it doesnt
  • Experiences with the Wave Product
  • validation approach
  • validation results
  • Summary
  • Future work (that needs to be done!)

3
The ASAR Wave Algorithmwhat it does
Level 1 Product
Inversion Model
Processing Set-Up File
Look-Up Table
Cross Spectra Estimation
where

Clutter SNR Estimation
Wind Speed Retrieval
Ocean Wave Spectra Retrieval
Level 2 Product Generation
Level 2 Product
4
SAR Ocean Image
5

what it doesnt
  • bathymetry/tidal flow signature
  • current shears, atmospheric fronts
  • internal waves
  • surfactants
  • ship wakes
  • upwelling
  • mesoscale circulation features
  • etc..

6
Experiences with the Wave Product Validation
Approach, http//www.oceanor.no/projects/enviwave
7
(No Transcript)
8
(No Transcript)
9
Scatter Plot of CMOD-IF2 Intensity Versus ASAR
SLC Intensity
March 2003
April 2003
ECMWF, K-47.80dB, BUOYS, K-47.19dB,
Transponders, K-47.35dB
10
Azimuth Cut-Off and Normalized Image Variance
11
ASAR versus WAM 1 D- Spectra
12
ASAR/WAM/BUOY 1 D- Spectra
13
Significant Waveheight March 2003
ASAR
WAM
14
Significant Waveheight (Swell) March 2003
WAM
ASAR
15
Significant Waveheight April 2003
ASAR
WAM
16
Significant Waveheight (Swell) April 2003
ASAR
WAM
17
Scatter Plot of WAM Versus ASAR Significant
Waveheight
18
Histogram of ASAR/WAM Significant Waveheight
Difference
19
ASAR/WAM Waveheight Difference versus Wind Speed
20
Mean Wave Period March 2003
WAM
ASAR
21
Mean Wave Period April 2003
ASAR
WAM
22
Mean Wave Period (Swell) March 2003
WAM
ASAR
23
Mean Wave Period (Swell) April 2003
24
Histogram of ASAR/WAM Mean Period Difference
25
Scatter Plot of WAM versus ASAR Mean Wave Period
26
WAM versus ASAR Wave Peak Period
27
Scatter plot of WAM versus ASAR Mean Wave
Direction
28
Histogram of ASAR/WAM Mean Wave Direction
Difference
29
ASAR versus WAM Spectral Peak Direction
30
Wind Speed March 2003
ASAR
ECMWF
31
Wind Speed April 2003
ASAR
ECMWF
32
ASAR Versus ECMWF Wind Speed
33
ASAR Level 2 Azimuth Cut-Off
ASAR Cut-Off
ECMWF wind speed
34
WAM ASAR Level 2 Summary
Hs (m) RMS Bias Hs12 (m) RMS Bias Tp (s) RMS Bias Tp12 (s) RMS Bias Mean Dir. (rad) RMS Bias Mean Dir.12 (rad) RMS Bias
0.6 -0.2 0.4 0.1 1.6 1.1 1.0 0.7 1.0 0. 1.0 -0.3
Peak Period (s) RMS Bias Peak Dir. (rad) RMS Bias U10 (m/s) RMS Bias Calibration diff. (dB) Buoy ECMWF
3.1 0.5 1.1 0.1 2.2 0.5 0.16 0.45
35
Summary
  • Conclusions so far
  • The ASAR Wave Mode is able to produce independent
    and ambiguity free information on ocean swell
    systems
  • Main WAM ASAR Swell difference
  • Bias in swell peak period ASAR tends to measure
    longer period
  • Bias in swell energy ASAR tends to measure
    higher energy for swell
  • BUOY/ASAR/WAM comparison
  • Examples shown where ASAR consistently add swell
    information beyond WAM

36
Future Work
  • Improve the flaging of data that are not within
    the domain of the algorithm model
  • Extend the algorithm to work on other swaths and
    polarizations
  • Update the look-up table with better resolution
    and dynamic ranges
  • Keep on with the validation and long term QA
  • Transition to other modes (ex. Wide Swath
    (complex data))
