DePaul Bears

1
DePaul Bears

• Try Your Luck!

2
Why buy this product?

• Approximately 1,000,000 cell phone users
• Approximately 2,000,000 or more people play the
  lottery
• New concept, the Illinois State Lottery website
  does not provide this service
• Lottery sales revenue will go up between 5-10

3
Illinois Lottery Number Wireless Retrieval System

• Retrieval of lottery numbers from cell phone
• Administrator functions from web site
• Informational links
• Future growth of ILNWRS

4
Retrieval of lottery numbers from cell phone

• Wireless cell phone with WAP Browser and
  connection
• Web Server that supports the ASP.Net, WML MIME
  types, and Microsoft Access
• Back up Server running in another facility that
  supports ASP.NET, WML mime types, and Microsoft
  Access
• ASP.NET embedded with WML will be used to view
  the data through the cell phone browser

5
Requirements for the Web

• The Website must be up and running 24 hours a
  day, seven days a week.
• Customers must easily navigate through the
  website.
• A copy of the Web site will also be maintained on
  a backup server.

6
Requirements (cont.)

• The winning numbers that the customer will see
  should be in the proper format.
• For Lotto Field there would be 6 numbers together
  separated by (-) ranges from 01-52 for example
  (01-14-33-22-34-24).
• For Little Lotto Field there would be 5 numbers
  together separated by (-) ranges from 01-39 for
  example (01-23-33-21-14).

7
Testing of the Web

• The tester will type the correct URL in the
  browser 24 times during each hour of the day to
  see if the website is up and running.
• 10 people will visit the website and rate it with
  the rating scale of 1-10 with 1 the lowest and 10
  the highest.

8
Testing of the Web (cont).

• The tester will select each month from the drop
  down menu to find out that if the winning numbers
  for that specific month are coming up.
• The tester will click on the contact us link on
  the main web page and must be able to see the
  address, telephone number and the email address
  of the company.

9
Administrator functions from the website

• Must have login id and password for security
  reasons
• Administrator will add, update, and delete
  lottery numbers from the GUI based database
  interface
• Administrator will add the winning numbers at
  least 2-3 minutes from the drawing

10
Requirements for the Admin functions

• Only the Administrator will be able to login into
  the Administrative Section with a given URL.
• The username and password will be supplied to the
  Admin.
• Only the Admin will be able to a. add, b. delete
  and c. update the winning lottery numbers.

11
Requirements for the Admin function cont.

• The Administrator will update the winning number
  2-3 minutes after the draw so that the website
  has the updated information with the 2-3 minute
  difference from the real draw.
• The Administrator will delete winning numbers
  that are 365 days old

12
Testing for the Admin functions

• The Internet Browser can take the Administrator
  to the URL of the login page of the
  Administrative Section of the Website after
  typing the correct URL.
• User Id text box appears correctly
• Password text box appears correctly
• Login Button appears correctly

13
Testing for the Admin functions (cont).

• User Id text box functions correctly
• Password Text box functions correctly
• The tester will get the username and password
  from the company and test the username and
  password by logging in to the Administrative
  Website.
• The tester must be able to add the winning
  numbers. So hell add a winning number to the
  database.

14
Requirements for the Wireless Part of the
Application

• Customers must easily read and navigate the
  application through their cell phones
• The date entered must be in (mmddyy) format.
• ASP.NET embedded with WML will be used to view
  the data through the cell phone browsers.

15
Requirements for the Wireless Part of the
Application (cont).

• If user enters a date that is not valid for lotto
  or little lotto the user will receive an Invalid
  Date reply.
• Data retrieved will not be greater than 2 screens
  to reduce the need for scrolling on the WAP phone

16
Test for the Wireless Part

• The Tester will use Cell Phone browser and type
  the correct URL of the application
• The Tester will enter the aabbcc to the date to
  see if it that input can be accepted then the
  tester would enter 10 dates to obtain the winning
  numbers.

17
Test for the wireless part (cont).

• The tester will review the code of the files used
  for the wireless application development.
• The Tester will try to find a way to reach the
  database through the cellular phone.

18
Informational links

• The website will provide contact information
• The website will have a calculator to project how
  much money you would win if you opted for the one
  lump sum payment or the 30 year plan
• The website will show the latest big jackpot
  winners
