Normalization

1
Normalization

• By Albert Lin

2
Basics

• Process of efficiently organizing data in a
  database.
• Goals
• Eliminate redundant data
• Ensure data dependency sensibility

3
Benefits

• Faster sorting and index creation
• Larger clustered indexes
• Narrow and compact indexes
• Fewer indexes per table.
• Fewer null values
• Less inconsistencies

4
Brief Description of Normal Forms

• 1st Normal Form
• No repeating groups
• 2nd Normal Form
• Each column depends entirely on the primary key.
• 3rd Normal Form
• Each column depends directly on the primary key.
• 4th Normal Form
• Isolate independent multiple relationships.
• 5th Normal Form
• Isolate Semantically related multiple
  relationships.
• Boyce-Codd Normal Form
• Non Trivial dependencies between candidate keys.
• Optimal Normal Form
• Limited to simple Facts
• Domain-Key Normal Form
• No modification anomolies

5
Additional Information

• 1st Normal Form
• Addresses the structure of an isolated table.
• 2nd, 3rd and Boyce Codd Normal Form
• Addresses 1-1 and 1-many relationships.
• 4th and 5th Normal Form
• Many-Many relationships.
• These forms are cumulative.

6
Anomalies

• Insertion Anomalies
• Duplication of data enforced
• impossible due to entity integrity
• Deletion Anomalies
• Leads to undesired loss of data.
• Modification Anomalies
• Modification of multiple rows can lead to
  inconsistencies.
• Databases that are sufficiently normalized can
  reduce anomalies from occurring.

7
Tips

• Make a table for each list.
• Use non-meaningful primary keys
• Eliminate Repeating Groups
• Eliminate Columns not dependent on Primary Key
• Each table should have an identifier
• Should only store data for a single type of
  entity.
• Avoid null columns

8
Additional Tips

• Records are free, new fields are expensive.
• Know when data requires duplication
• Use referential integrity
• The higher normal form generally results in
  faster data retrieval.

9
Questions to ask

• What data do you need?
• What are you going to do with the data?
• How are the data related?
• What is the future of the data?

10
Examples of Bad Databases
SID Class Time Location Prof_ID
0015 CS166 1030 MH226 34215
1205 CS146 1200 MH225 25123
0025 CS166 130 MH222 34215
0015 CS151 800 MH222 24215
2531 CS156 900 MH422 25124
1205 CS120 1030 DH251 12412
2522 CS046 800 MH224 34215
1523 CS140 500 MH422 25123
0015 CS140 300 MH422 34215
11
Problems with the database

• In a large scale database, information would be
  repeated numerous times, resulting in redundant
  data
• Retrieval of data would be difficult and long
• Index creation would be difficult.

12
In Practice

• Many databases are de-normalized to some
  degree.
• This is due to performance issues.
• It may require fewer joins and result in faster
  retrievals.
• However, before doing de-normalization
  performance issues must exist and
  de-normalization must dramatically improve it
  before introducing a suboptimal design
• A de-normalized table can be harder to update.

13
Overall topics

• Normalization helps organization and speed of
  organizing a database, which can help a company
  produce a database system that is quick and
  easily accessible.
• The higher the normal form, the less chance
  anomalies will arise.
• In case of performance issues, de-normalization
  can be done in order to increase performance.

14
Final Motto

• Strive for Single Themed Tables.

15
References

• Litt, Steve. Normalization. 1996
  http//www.troubleshooters.com/littstip/ltnorm.htm
  l
• Rules of Data Normalization. 2005.
  http//www.datamodel.org/NormalizationRules.html
• Normalization http//msdn.microsoft.com/library/
  default.asp?url/library/en-us/createdb/cm_8_des_0
  2_2oby.asp
• Chung,Luke. Database Normalization Tips. FMS.
  2001. http//www.fmsinc.com/tpapers/genaccess/data
  basenorm.html
• Janert, Phillip. Practical Database. IEEE.
  2004. http//www.devx.com/ibm/Article/20859
• Reus, Bernhard. Databases. University of
  Sussex. 2004. http//www.informatics.sussex.ac.uk/
  users/bernhard/db2005/Slides/dbXIII.pdf
• Wyllys, R.E. Steps in Normalization University
  of Texas at Austin. 2003. http//www.gslis.utexas.
  edu/wyllys/DMPAMaterials/normstep.htmlSection20
  6.20Anomalies20and20Normalization
