Confidentiality Policy

1
Confidentiality Policy
C. Edward Chow
CS691 Chapter 5 of Matt Bishop
2
Goals of Confidentiality Policies

• Confidentiality Policies emphasize the protection
  of confidentiality.
• Confidentiality policy also called information
  flow policy, prevents unauthorized disclosure of
  information.
• Example Privacy Act requires that certain
  personal data be kept confidential. E.g., income
  tax return info only available to IRS and legal
  authority with court order. It limits the
  distribution of documents/info.

3
Discretionary Access Control (DAC)

• Definition 4-13 Mechanism where a user can set
  access control to allow or deny access to an
  object
• Also called Identity-based access control (IBAC)
  Section 4.4.
• It is a traditional access control techniques
  implemented by traditional operating system such
  as Unix.
• Based on user identity and ownership
• Programs run by a user inherits all privileges
  granted to the user.
• Programs is free to change access to the users
  objects
• Support only two major categories of users
• Completely trusted admins
• Completely untrusted ordinary users

4
Problems with DAC

• Each users has complete discretion over his
  objects.
• What is wrong with that?
• Difficult to enforce a system-wide security
  policy, e.g.
• A user can leak classified documents to a
  unclassified users.
• Other examples?
• Only based users identity and ownership,
  Ignoring security relevant info such as
• Users role
• Function of the program
• Trustworthiness of the program
• Compromised program can change access to the
  users objects
• Compromised program inherit all the permissions
  granted to the users (especially the root user)
• Sensitivity of the data
• Integrity of the data
• Only support coarse-grained privileges
• Unbounded privilege escalation
• Too simple classification of users (How about
  more than two categories of users?)

5
Mandatory Access Control (MAC)

• Definition 4-14 Mechanism where system control
  access to an object and a user cannot alter that
  access.
• Occasionally called rule-based access control?
• Defined by three major properties
• Administratively-defined security policy
• Control over all subjects (process) and objects
  (files, sockets, network interfaces)
• Decisions based on all security-relevant info
• MAC access decisions are based on labels that
  contains security-relevant info.

6
What Can MAC Offer?

• Supports a wide variety of categories of users in
  system.
• For example, Users with labels (secret, EUR,
  US) (top secret, NUC, US).
• Here security level is specified by the
  two-tuple (clearance, category)
• Strong separation of security domains
• System, application, and data integrity
• Ability to limit program privileges
• Confine the damage caused by flowed or malicious
  software
• Processing pipeline guarantees
• Authorization limits for legitimate users

7
Mandatory and Discretionary Access Control

• Bell-LaPadula model combines Mandatory and
  Discretionary Access Controls.
• S has discretionary read (write) access to O
• means that the access control matrix entry
  for S and O corresponding to the discretionary
  access control component contains a read (write)
  right. A B C D OQS read(D)T
• If the mandatory controls not present, S would be
  able to read (write) O.

8
Bell-LaPadula Model

• Also called the multi-level model,
• Was proposed by Bell and LaPadula of MITRE for
  enforcing access control in government and
  military applications.
• It corresponds to military-style classifications.
• In such applications, subjects and objects are
  often partitioned into different security levels.

• A subject can only access objects at certain
  levels determined by his security level.
• For instance, the following are two typical
  access specifications Unclassified personnel
  cannot read data at confidential levels'' and
  Top-Secret data cannot be written into the
  files at unclassified levels''

9
Informal Description

• Simplest type of confidentiality classification
  is a set of security clearances arranged in a
  linear (total) ordering.
• Clearances represent the security levels.
• The higher the clearance, the more sensitive the
  info.
• Basic confidential classification system
• individuals documents
• Top Secret (TS) Tamara, Thomas Personnel Files
• Secret (S) Sally, Samuel Electronic Mails
• Confidential (C) Claire, Clarence Activity Log
  Files
• Unclassified (UC) Ulaley, Ursula Telephone Lists

10
Star Property (Preliminary Version)

• Let L(S)ls be the security clearance of subject
  S.
• Let L(O)lo be the security classification of
  object ).
• For all security classification li, i0,, k-1,
  liltli1
• Simple Security Condition S can read O if and
  only if loltls and S has discretionary read
  access to O.
• -Property (Star property) S can write O if and
  only if lsltlo and S has discretionary write
  access to O.
• TS guy can not write documents lower than TS. ?
  Prevent classified information leak.
• But how can different groups communicate?

11
Basic Security Theorem

• Let ? be a system with secure initial state ?0
• Let T be the set of state transformations.
• If every element of T preserves the simple
  security condition, preliminary version, and the
  -property, preliminary version, Then every
  state ?i, i0, is secure.

12
Categories and Need to Know Principle

• Expand the model by adding a set of categories.
• Each category describe a kind of information.
• These category arise from the need to know
  principle ? no subject should be able to read
  objects unless reading them is necessary for that
  subject to perform its function.
• Example three categories NUC, EUR, US.
• Each security level and category form a security
  level or compartment.
• Subjects have clearance at (are cleared into, or
  are in) a security level.
• Objects are at the level of (or are in) a
  security level.

13
Security Lattice
NUC, EUR, US
NUC, EUR
NUC, US
EUR, US
EUR
US
NUC
?

• William may be cleared into level (SECRET, EUR)
• George into level (TS, NUC, US).
• A document may be classified as (C, EUR)
• Someone with clearance at (TS, NUC, US) will be
  denied access to document with category EUR.

14
Dominate (dom) Relation

• The security level (L, C) dominates the security
  level (L, C) if and only if L ? L and C ? C
• ?Dom ? dominate relation is false.
• Geroge is cleared into security level (S, NUC,
  EUR)
• DocA is classified as (C, NUC)
• DocB is classified as (S, EUR, US)
• DocC is classified as (S, EUR)
• George dom DocA
• George ? dom DocB
• George dom DocC

15
New Security Condition and -Property

• Let C(S) be the category set of subject S.
• Let C(O) be the category set of object O.
• Simple Security Condition (not read up) S can
  read O if and only if S dom O and S has
  discretionary read access to O.
• -Property (not write down) S can write to O if
  and only if O dom S and S has discretionary
  write access to O.
• Basic Security Theorem Let ? be a system with
  secure initial state ?0Let T be the set of state
  transformations.If every element of T preserves
  the simple security condition, preliminary
  version, and the -property, preliminary version,
  Then every state ?i, i0, is secure.

16
Allow Write Down?

• Bell-LaPadula allows higher-level subject to
  write into lower level object that low level
  subject can read.
• A subject has a maximum security level and a
  current security level. maximum security level
  must dominate current security level.
• A subject may (effectively) decrease its security
  level from the maximum in order to communicate
  with entities at lower security levels.
• Colonels maximum security level is (S, NUC,
  EUR). She changes her current security level to
  (S, EUR). Now she can create document at Major
  is clearance level (S, EUR).

17
Data General B2 Unix System

• Data General B2 Unix (DG/UX) provides mandatory
  access controls (MAC).
• The MAC label is a label identifying a particular
  compartment.
• The initial label (assigned at login time) is the
  label assigned to the user in a database called
  Authorization and Authentication (AA) Database.
• When a process begins, it is assigned to MAC
  label of its parent (whoever creates it).
• Objects are assigned labels at creation. The
  labels can be explicit or implicit.
• The explicit label is stored as parts of the
  objects attributes.
• The implicit label derives from the parent
  directory of the object.
• IMPL_HI the least upper bound of all components
  in DG/UX lattice has IMPL_HI as label.
• IMPL_LO the greatest lower bound of all
  components in DG/UX lattice has IMPL_LO as the
  label

18
Three MAC Regions in DG/UX MAC Lattice
Figure 5-3 The three MAC regions in the MAC
lattice (modified from the DG/UX Security Manual
257, p. 4-7, Figure 4-4). TCB stands for
"trusted computing base.
19
Accesses with MAC Labels

• Read up and write up from users to Admin Region
  not allowed.
• Admin processes sanitize data sent to user
  processes with MAC Labels in the user region.
• System programs are in the lowest region.
• No user can write to or alter them.
• Only programs with the same label as the
  directory can create files in that directory.
• The above restriction will prevent
• compiling (need to access /tmp)
• mail delivery (need to access mail spool
  directory)
• Solution? multilevel directory.

20
Multilevel Directory

• A directory with a set of subdirectories, one for
  each label.
• These hidden directories normally invisible to
  the user.
• When a process with label MAC_A creates a file in
  /tmp, it actually create a file in hidden
  directory under /tmp with label MAC_A
• The parent directory of a file in /tmp is the
  hidden directory.
• A reference to the parent directory goes to the
  hidden directory.
• Process A with MAC_A creates /tmp/a. Process B
  with MAC_B creates /tmp/a. Each of them performs
  cd /tmp/a cd ..The system call stat(.,
  stat_buffer) returns different inode number for
  each process. It returns the inode number of the
  respective hidden directory.
• Try stat command to display file and related
  status.
• DG/UX provides dg_mstat(., stat_buffer) to
  translate the current working directory to the
  multilevel directory

21
Mounting Unlabeled File System

• All files in that file system need to be labeled.
• Symbolic links aggravate this problem. Does the
  MAC label the target of the link control, or does
  the MAC label the link itself? DG/UX uses a
  notion of inherited labels (called implicit
  labels) to solve this problem.
• The following rules control the way objects are
  labeled.
• Roots of file systems have explicit MAC labels.
  If a file system without labels is mounted on a
  labeled file system, the root directory of the
  mounted file system receives an explicit label
  equal to that of the mount point. However, the
  label of the mount point, and of the underlying
  tree, is no longer visible, and so its label is
  unchanged (and will become visible again when the
  file system is unmounted).
• An object with an implicit MAC label inherits the
  label of its parent.
• When a hard link to an object is created, that
  object must have an explicit label if it does
  not, the object's implicit label is converted to
  an explicit label. A corollary is that moving a
  file to a different directory makes its label
  explicit.
• If the label of a directory changes, any
  immediate children with implicit labels have
  those labels converted to explicit labels before
  the parent directory's label is changed.
• When the system resolves a symbolic link, the
  label of the object is the label of the target of
  the symbolic link. However, to resolve the link,
  the process needs access to the symbolic link
  itself.

22
Interesting Case with Hard Links

• Let /x/y/z and /x/a/b be hard links to the same
  object. Suppose y has an explicit label IMPL_HI
  and a an explicit label IMPL_B. Then the file
  object can be accessed by a process at IMPL_HI as
  /x/y/z and by a process at IMPL_B as /x/alb.
  Which label is correct? Two cases arise.
• Suppose the hard link is created while the file
  system is on a DG/UX B2 system. Then the DG/UX
  system converts the target's implicit label to an
  explicit one (rule 3). Thus, regardless of the
  path used to refer to the object, the label of
  the object will be the same.
• Suppose the hard link exists when the file system
  is mounted on the DG/UX B2 system. In this case,
  the target had no file label when it was created,
  and one must be added. If no objects on the paths
  to the target have explicit labels, the target
  will have the same (implicit) label regardless of
  the path being used. But if any object on any
  path to the target of the link acquires an
  explicit label, the target's label may depend on
  which path is taken. To avoid this, the implicit
  labels of a directory's children must be
  preserved when the directory's label is made
  explicit. Rule 4 does this.
• Because symbolic links interpolate path names of
  files, rather than store Mode numbers, computing
  the label of symbolic links is straightforward.
  If /x/y/z is a symbolic link to /a/b/c, then the
  MAC label of c is computed in the usual way.
  However, the symbolic link itself is a file, and
  so the process must also have access to the link
  file z.

23
Enable Flexible Write in DG/UX

• Provide a range of labels called MAC tuple.
• A range is a set of labels expressed by a lower
  bound and an upper hound. A MAC tuple consists of
  up to three ranges (one for each of the regions
  in Figure 5-3).
• Example A system has two security levels. TS and
  S, the former dominating the latter. The
  categories are COMP. NUC, and ASIA. Examples of
  ranges are
• (S, COMP ), (TS, COMP )
• ( S, ? ), (TS, COMP, NUC.
  ASIA )
• ( S, ASIA ), ( TS, ASIA, NUC )
• The label ( TS, COMP ) is in the first two
  ranges. The label ( S, NUC, ASIA ) is in the
  last two ranges. However,( S, ASIA ), ( TS,
  COMP, NUC )is not a valid range because ?( TS,
  COMP. NUC ) dom ( S, ASIA ).

24
Formal Model

• Let S be the set of subjects of a system and let
  O be the set of objects. Let P be the set of
  rights r for read, a for write, w for read/write,
  and e for empty.
• Let M be a set of possible access control
  matrices for the system. Let C be the set of
  classifications (or clearances), let K be the set
  of categories, and let L C x K be the set of
  security levels. Finally, let F be the set of
  3-tuples (fs,fo,fc), where fs and, fc associate
  with each subject maximum and current security
  levels, respectively, and, fo, associates with
  each object a security level.
• The system objects may be organized as a set of
  hierarchies (trees and single nodes).
• Let H represent the set of hierarchy functions h
  O?P(O). P(O) is the power set of O, i.e., the
  set of all possible subsets of O.
• The hierarchy functions have two properties Let
  oi, oj, ok ?O.
• If oi ?oj, then h(oi) ? h(oj) ?.
• There is no set o1, o2, ..., ok ? O such that
  for each i 1, ..., k, oi1 ? h(oi), and ok1
  o1.

25
Formal Model State, Request

• A state v ? V of a system is a 4-tuple (b, m, f,
  h), where
• b ? P(S x O x P) indicates which subjects have
  access to which objects, and what those access
  rights are
• m ? M is the access control matrix for the
  current state
• f ? F is the 3-tuple indicating the current
  subject and object clearances and categories and

• h ? H is the hierarchy of objects for the current
  state.
• The difference between b and m is that the rights
  in m may be unusable because of differences in
  security levels b contains the set of rights
  that may be exercised, and m contains the set of
  discretionary rights.
• R denotes the set of requests for access. Four
  outcomes of each request are possible
• y for yes (allowed),
• n for no (not allowed),
• i for illegal request, and
• o for error (multiple outcomes are possible).
• D denotes the set of outcomes. The set W ? R x D
  x V x V is the set of actions of the system. This
  notation means that an entity issues a request in
  R, and a decision in D occurs, moving the system
  from one state in V to another (possibly
  different) state in V.

26
Formal Model History, System

• Let N be the set of positive integers. These
  integers represent times. Let X RN be a set
  whose elements x are sequences of requests, let Y
  DN be a set whose elements y are sequences of
  decisions, and let Z VN be a set whose elements
  z are sequences of states. The ith components of
  x, y, and z are represented as xi, yi, and zi.
  respectively.
• The interpretation is that for some t ? N, the
  system is in state zt-1 ? V, a subject makes
  request xt ? R, the system makes a decision yt ?
  D, and as a result the system transitions into a
  (possibly new) state zt ? V
• A system is represented as an initial state and a
  sequence of requests, decisions, and states.
• In formal terms, ?(R, D, W, z0) ? X x Y x Z
  represents the system, and z0 is the initial
  state of the system.(x, y, z) ? ?(R, D, W, z0)
  if and only if (xt, yt, zt, zt-1) ? W for all t ?
  N.
• (x, y, z) is an appearance of ?(R, D, W, z0) .

27
Simple Security Condition, -Property

• Definition 5-2. (s, o, p) ? S x O x P satisfies
  the simple security condition relative to f
  (written as ssc rel f) if and only if one of the
  following holds
• a. pe or pa
• b. p r or p w and fc(s) dom fo(o)
• Define b(s p1, ..., pn) to be the set of all
  objects that s has p1, ..., pn access to.
• b(s p1, ..., pn) o o?O ? (s,o,p1)?b
  ?...?(s,o,pn)?b
• Definition 5-3. A state (h, m, f, h) satisfies
  the -property if and only if, for each s ? S.
  the following holda. b(s a) ? ? ? ? o?b(s a)
  fo(o) dom fc(s) b. b(s w) ? ? ? ? o?b(s w)
  fo(o) fc(s) c. b(s r) ? ? ? ? o?b(s r)
  fc(s) dom fo(o)

28
Discretionary Security Property, Action

• Definition 5-4. A state (b, m, f, h) satisfies
  the discretionary security property (ds-property)
  if and only if, for each triple (s, o, p) ? b, p?
  ms, o.
• Definition 5-5. A system is secure if it
  satisfies the simple security condition, the
  -property, and the discretionary security
  property
• Definition 5-6. (r, d, v, v') ? R x D x V x V is
  an action of ?(R, D, W, z0) if and only if there
  is an (x, y, z) ? ?(R, D, W, z0) and a t ? N such
  that (r, d, v, v') (xt, yt, zt, zt-1)
• An action is a request/decision pair that occurs
  during the execution of the system.

29
When the three properties hold

• Theorem 5-3. ?(R, D, W, z0) satisfies the simple
  security condition for any secure state z0 if and
  only if, for every action (r, d, (b, m, f, h),
  (b', m', f', h')), W satisfies the followinga.
  Every (s, o, p) ? b - b' satisfies ssc rel f.b.
  Every (s, o, p) ? b' that does not satisfy ssc
  rel f is not in b.
• Theorem 5-4. ?(R, D, W, z0) satisfies the
  -property relative to S' ? S for any secure
  state z0 if and only if, for every action (r, d,
  (b, m, f, h), (b', m', f', h')), W satisfies the
  following for every s ? S'a. Every (s, o, p) ?
  b - b' satisfies the -property with respect to
  S'.b. Every (s, o, p) ? b' that does not satisfy
  the -property with respect to S' is not in b.
• Theorem 5-5. ?(R, D, W, z0) satisfies the
  ds-property for any secure state z0 if and only
  if, for every action (r, d, (b, m, f, h), (b',
  m', f', h')), W satisfies the followinga.
  Every (s, o, p) ? b - b ' satisfies the
  ds-property.b. Every (s, o, p) ? b' that does
  not satisfy the ds-property is not in b.
• Theorem 5-6. Basic Security Theorem ?(R, D. W,
  z0) is a secure system if z0 is a secure state
  and W satisfies the conditions of Theorems 5-3,
  5-4, and 5-5.

30
Rules of Transformation

• A rule is a function ?R x V?D x V Intuitively, a
  rule takes a state and a request, and determines
  if the request meets the conditions of the rule
  (the decision). If so, it moves the system to a
  (possibly different) state.
• Definition 5-7. A rule p is ssc-preserving, if,
  for all (r, v) ? R x V and v satisfying ssc rel
  f, ?(r, v) (d, v') means that v' satisfies ssc
  rel f'.
• Similar definitions hold for the property and the
  ds-property. If a rule is sscpreserving,
  -property-preserving, and ds-property-preserving,
  the rule is said to be security-preserving.
• Definition 5-8. Let w ?1, ..., ?m be a set
  of rules. For request r ? R, decision d ? D, and
  states v, v' ? V, (r, d, v, v') ? W(?) if and
  only if d ? i and there is a unique integer i, 1
  i m, such that ?i(r, v) (d, v' ).
• This definition says that if the request is legal
  and there is only one rule that will change the
  state of the system from v to v', the
  corresponding action is in W(?).

31
When rule set preserves simple security condition?

• Theorem 5-7. Let ? be a set of ssc-preserving
  rules, and let z0 be a state satisfying the
  simple security condition. Then ?(R, D, W, z0)
  satisfies the simple security condition.
• When does adding a state preserve the simple
  security property?
• Theorem 5-8. Let v (b, m, f, h) satisfy the
  simple security condition. Let (s, o, p) ? b, b'
  b ? (s, o, p) , and v' (b', m, f, h). Then
  v' satisfies the simple security condition if and
  only if either of the following conditions is
  true.a. Either p e or p a.b. Either p r
  or p w, and fs(s) dom fo(o).
• Theorem 5-9. Let ? be a set of -property-preservi
  ng rules, and let z0 be a state satisfying the
  -property. Then ?(R, D, W, z0) satisfies the
  -property.

32
Properties

• Theorem 5-10. Let v (b, m, f, h) satisfy the
  -property. Let (s, o, p) ? b, b' b ? (s, o,
  p) , and v' (b', m, f, h). Then v' satisfies
  the -property if and only if one of the
  following conditions holds.a. p a and fo(o)
  dom fc(s) b. p w and. fo(o) fc(s) c. p r
  and fc(s) dom fo(o)
• Theorem 5-11. Let ? be a set of
  ds-property-preserving rules, and let z0 be a
  state satisfying the ds-property. Then ?(R, D, W,
  z0) satisfies the ds-property.
• Theorem 5-12. Let v (b, m,,f h) satisfy the
  ds-property. Let (s, o, p) ? b, b' b ? (s, o.
  p) , and v' (b', m, f, h). Then v' satisfies
  the ds-property if and only if p ? ms, o.
• Theorem 5-13. Let ? he a rule and ?(r, v) (d,
  v'), where v (b, m, f, h) and v' (b', m', f',
  h'). Thena. If b'? b, f',f, and v satisfies
  the simple security condition, then v satisfies
  the simple security condition.b. If b' ? h,
  f' f, and v satisfies the -property, then v'
  satisfies the -property.c. If b' ? h, , ms, o
  ? m' s, o for all s ? S and o ? O, and v
  satisfies the ds- property, then v' satisfies
  the ds-property.

33
Multics Example (Model Instantiation)

• The Multics system 68, 788 has I 1 rules
  affecting the rights on the system. These rules
  are divided into five groups. Let the set Q
  contain the set of request operations (such as
  get, give, and so forth). Then
• 1. R(1) Q x S x O x M. This is the set of
  requests to request and release access. The rules
  are get-read, get-append, get-execute, get-write,
  and release-read/execute/write/append. These
  rules differ in the conditions necessary for the
  subject to be able to request the desired right.
  The rule get-read is discussed in more detail in
  Section 5.2.4.1.
• 2. R(2) S x Q x S x O x M. This is the set of
  requests to give access to and remove access from
  a different subject. The rules are
  give-read/execute/write/append and
  rescind-read/execute/write/append. Again, the
  rules differ in the conditions needed to acquire
  and delete the rights, but within each rule, the
  right being added or removed does not affect the
  conditions. Whether the right is being added or
  deleted does affect them. The rule
  give-read/execute/write/append is discussed in
  more detail in Section 5.2.4.2.
• 3. R(3) Q x S x O x L. This is the set of
  requests to create and reclassify objects. It
  contains the create-object and change-object-secur
  ity-level rules. The object's security level is
  either assigned (create-object) or changed
  (change-object-security-Ievel ).
• 4. R(4) S x O. This is the set of requests to
  remove objects. It contains only the rule
  delete-object-group, which deletes an object and
  all objects beneath it in the hierarchy.
• 5. R(5) S x L. This is the set of requests to
  change a subject's security level. It contains
  only the rule change-subject-current-security-leve
  l, which changes a subject's current security
  level (not the maximum security level).
• Then, the set of requests R R(1) ? R(2) ? R(3)
  ? R(4) ? R(5)
• The Multics system includes the notion of trusted
  users. The system does not enforce the -property
  for this set of subjects ST ?S, however, members
  of ST are trusted not to violate that property.
• For each rule ?, define ?(?) as the domain of the
  request (that is, whether or not the components
  of the request form a valid operand for the rule).

34
The get-read Rule

• The get-read rule enables a subject s to request
  the right to read an object o. Represent this
  request as r (get, s, o, r) ? R(1) , and let
  the current state of the system be v (b, m, f,
  h). Then get-read is the rule ?1(r, v)
• if (r ? ?(?1)) then ?1(r, v)(i, v)
• else if ( fs(s) dom fo(o) and s ? ST or fc(s)
  dom fo(o) and r ? ms, o) then ?1(r, v)(y, (b
  ? (s, o, r) , m, f, h))
• else ?1(r, v)(n, v)
• The first if tests the parameters of the request
  if any of them are incorrect, the decision is
  "illegal" and the system state remains unchanged.

• The second if checks three conditions. The simple
  security property for the maximum security level
  of the subject and the classification of the
  object must hold. Either the subject making the
  request must be trusted, or the simple security
  property must hold for the current security level
  of the subject (this allows trusted subjects to
  read information from objects above their current
  security levels but at or below their maximum
  security levels they are trusted not to reveal
  the information inappropriately). Finally, the
  discretionary security property must hold. If
  these three conditions hold, so does the Basic
  Security Theorem. The decision is "yes" and the
  system state is updated to reflect the new
  access. Otherwise, the decision is "no" and the
  system state remains unchanged.

35
The give-read Rule

• The give-read rule enables a subject s to give
  subject s2 the (discretionary) right to read an
  object o. Conceptually, a subject can give
  another subject read access to an object if the
  giver can alter (write to) the parent of the
  object. If the parent is the root of the
  hierarchy containing the object, or if the object
  itself is the root of the hierarchy, the subject
  must be specially authorized to grant access.
• Some terms simplify the definitions and proofs.
  Define root(o) as the root object of the
  hierarchy h containing o, and define parent(o) as
  the parent of o in h. If the subject is specially
  authorized to grant access to the object in the
  situation just mentioned, the predicate
  canallow(s, o, v) is true. Finally, define m ?
  ms, o?r as the access control matrix m with the
  right r added to entry ms, o.
• Represent the give-read request as r (s1, give,
  s2, o, r) ? R(2), and let the current state of
  the system be v (b, m, f, h). Then, give-read
  is the rule ?6(r, v)
• if (r ? ?(?6)) then ?6(r, v) (i, v)
• else if ( o ? root(o) and parent(o) ? root(o)
  and parent(o) ? b(s1 w) or
• parent(o) root(o) and
  canallow(s1, o, v) or
• o root(o) and canallow(s1,
  root(o), v) )
• then ?6(r, v) (y, (b, m ? ms2, o?r,
  f, h))
• else ?6(r, v) (n, v)
• The first if tests the parameters of the request
  if any of them are incorrect, the decision is
  "illegal" and the system state remains unchanged.
  The second if checks several conditions. If
  neither the object nor its parent is the root of
  the hierarchy containing the object, then s1
  must have write rights to the parent. If the
  object or its parent is the root of the
  hierarchy, then s1 must have special permission
  to give s2 the read right to o. The decision is
  "yes" and the access control matrix is updated to
  reflect the new access. Otherwise, the decision
  is "no" and the system state remains unchanged.

36
Tranquility

• The principle of tranquility states that subjects
  and objects may not change their security levels
  once they have been instantiated.
• Suppose that security levels of objects can be
  changed, and consider the effects on a system
  with one category and two security clearances,
  HIGH and LOW. If an object's security
  classification is raised from LOW to HIGH, then
  any subjects cleared to only LOW can no longer
  read that object. Similarly, if an object's
  classification is dropped from HIGH to LOW, any
  subject can now read that object.
• Both situations violate fundamental restrictions.

• Raising the classification of an object means
  that information that was available is no longer
  available lowering the classification means
  that information previously considered restricted
  is now available to all.
• Raising the classification of an object is not
  considered a problem. The model does not define
  how to determine the appropriate classification
  of information. It merely describes how to
  manipulate an object containing the information
  once that object has been assigned a
  classification.
• declassification problem. Because this makes
  information available to subjects who did not
  have access to it before, it is in effect a
  "write down" that violates the
• -property. The typical solution is to define a
  set of trusted entities or subjects that will
  remove all sensitive information from the HIGH
  object before its classification is changed to
  LOW.

37
Strong/Weak Tranquility

• Definition 5-9. The principle of strong
  tranquility states that security levels do not
  change during the lifetime of the system.
• Strong tranquility eliminates the need for
  trusted declassifiers, because no
  declassification can occur. Moreover, no raising
  of security levels can occur. This eliminates
  the problems discussed above. However, strong
  tranquility is also inflexible and in practice is
  usually too strong a requirement.
• Definition 5-10. The principle of weak
  tranquility states that security levels do not
  change in a way that violates the rules of a
  given security policy.
• Weak tranquility moderates the restriction to
  allow harmless changes of security levels. It is
  more flexible, because it allows changes, but it
  disallows any violations of the security policy
  (in the context of the Bell-LaPadula Model, the
  simple security condition and -property).
• EXAMPLE In the Data General DG/UX system, only
  the security administrator, a trusted user, can
  change MAC labels on objects. In general, when a
  user wishes to assume a new MAC label, that user
  must initiate a new session the MAC labels of
  processes cannot be changed. However, a user may
  be designated as able to change a process label
  within a specified range. This makes the system
  more amenable to commercial environments.

38
Controversy Over Bell-LaPadula Modoel

• 1985 McLean define a -property which is not
  secure (allow write down) and show that the basic
  theorem is not correct.
• Definition 5-11. A state (b, m, f, h) satisfies
  the -property if and only if, for each subject s
  c S, the following conditions holda. b(s a) ?
  ? ? ? o?b(s a) fc(s) dom fo(o) b. b(s w)
  ? ? ? ? o?b(s w) fc(s) fo(o) c. b(s r)
  ? ? ? ? o?b(s r) fc(s) dom fo(o)
• McLean then proved the analogue to Theorem 5-4
• Theorem 5-16. ?(R, D, W, z0) satisfies the
  -property relative to S' ? S for any secure
  state z0 if and only if, for every action (r, d,
  (b, m, f, h), (b', m', f', h')), W satisfies the
  following conditions for every s ? Sa. Every (s,
  o, p) ? b - b' satisfies the -property with
  respect to Sb. Every (s, o, p) ? b' that does
  not satisfy the -property with respect to S' is
  not in b.
• From this theorem, and from Theorems 5-3 and 5-5,
  the analogue to the Basic Security Theorem
  follows.
• Theorem 5-17. Basic Security Theorem ?(R, D, W,
  z0) is a secure system if and only if zt is a
  secure state and W satisfies the conditions of
  Theorems 5-3, 5-16, and 5-5.
• But the system ?(R, D, W, z0) is clearly not
  secure.
• Bell-LaPadula argue that their model assumes the
  transition introduces no changes that violate
  security.

39
McCleans System Z

• In 1987, McClean presented System Z where system
  transitions can alter any system component,
  including b, f, m, and h, as long as the new
  state does not violate security. He demonstrated
  system satisfies the model but is not a
  confidentiality security policy.
• Bell 64 responded by exploring the fundamental
  nature of modeling. Newtonia math cannot explain
  planet movement while Einsteins theory of
  general relativity can.
• Bell-LaPadula Model is a tool for demonstrating
  certain properties of rules. Whether the
  properties of System Z is desirable is an issue
  the model cannot answer.
• Bell-LaPadula Model enforces the principle of
  strong tranquility.
• System Z deals with the case of weak tranquility
  (security level can change).

40
Problem with Traditional MAC

• Poor support for
• Data and application integrity (Clark Wilson
  Integrity model Chinese Wall security policy)
• Separation of duty
• Least privilege requirement
• Require special trusted subject that act outside
  of the access control model (e.g., lower security
  level to write down)
• Fail to tightly control the relationship between
  subject and the code it executes. This limits
• Limit protection based on function and
  trustworthiness of the code.
• Correctly manage permissions required for
  execution
• Minimize the likelihood of malicious code
  execution

41
History Security-Enhanced Linux (SELinux)

• National Security Agency (NSA) and Secure
  Computing Corporation (SCC) provide strong MAC.
• Flexible support for security policies (no single
  MAC policy can satisfy everyones security
  requirements)
• Cleanly separate the security policy logic from
  enforcing mechanism
• Developed DTMach, DTOS (Mach-based prototype)
• Apply formal method to validate the security
  properties of the architecture (High Assurance)
• Work with Univ. Utah Flux Research Group
• integrate the architecture to Fluke research
  operating system
• Result Flask architecture support dynamic
  security policies.
• NSA create SELinux integrate Flash architecture
  to Linux OS.
• NAI implements control on procfs and devpts fiel
  ssytems
• MITRE/SCC contribute application security
  policies, modified utility programs

42
SELinux

• Support
• Separation policies
• Enforce legal restriction on data
• Establish well-defined user roles
• Restrict access to classified data
• Containment policies for
• Restrict web server access to only authorized
  data
• Minimize damage caused by virues/malicious code
• Integrity policies that protect unauthorized
  modifications to data and applications
• Invocation policies that guarantee data is
  processed as required.
