FP5000

1
FP5000
Refer to www.eatonelectrical.com for the latest
information on this constantly evolving product
2
FP5000 Product Overview

• Microprocessor design combines protection,
  metering and control into a single compact
  package
• Flexible configuration and programmable logic
  control for custom applications
• Easy navigation keys and menu structure make it
  simple and safe to use
• Meets ANSI, UL and CUL standards

3
FP5000 Product Overview

• User Interface
• Latching cover and Password protection for
  security
• 4 x 20 character vacuum fluorescent display for
  improved readability
• 18 status LEDs for trip, alarm, breaker status
  and display mode indication
• Battery backed up trip LED for target indication
  even if station is dead
• Direct access to monitoring, view settings, logs
  and status/control screens
• Breaker open/close buttons can provide direct
  breaker control when enabled

4
FP5000 Product Overview

• Hardware
• Advanced 32 bit Microprocessor design
• Compact drawout case design for easy installation
  and removal
• Four currents inputs (1A or 5A)
• Measured three phase and ground currents
• Calculated residual ground current
• Four voltage inputs
• Three phase plus fourth auxiliary voltage
  measurement

5
FP5000 Product Overview

• Hardware
• 8 optically isolated contact inputs
• 5 trip rated a contact outputs
• 2 outputs with circuit continuity monitoring
• 2 form c alarm contacts
• One is for relay healthy alarm
• C-H Zone Interlocking Circuitry
• Inputs and outputs are user configurable

6
FP5000 Protection Features
One-line Drawing
7
Instantaneous Overcurrent 50 (P,X,R)
8
FP5000 Protection Features

• Three phase and ground overcurrent (50P-1, 50P-2,
  50P-3, 51P and 50R-1, 50R-2,50R-3,51R,
  50X-1,50X-2,50X-3,51X)
• Measured (X) and calculated (R) ground currents
• Negative sequence overcurrent (46-1, 46-2)
• Three phase over and under voltage protection
  (27M-1, 59M-1, 27M-2, 59M-2)
• Single phase over and under voltage protection
  (27A-1, 27A-2, 59A-1, 59A-2)
• Over and under frequency protection (81U-1,
  81U-2, 81O-1, 81O-2)

9
FP5000 Protection Features

• Negative sequence over voltage protection
  (47-1,47-2)
• Breaker failure (50BF)
• Internal Breaker Failure Initiation
• External Breaker failure Initiation
• Apparent and Displacement Power factor (55A,55D)
• Four setting groups available

10
Time Overcurrent 51 (P,X,R)
11
Current Unbalance 46
12
Voltage Unbalance 47
13
Main Over Voltage 59M
14
Main Under Voltage 27M
15
Auxiliary Over Voltage 59X
16
Auxiliary Under Voltage 27X
17
Over Frequency 81O
18
Under Frequency 81U
19
Breaker Failure Logic
20
FP5000 Protection Features

• Zone Interlocking
• Faster fault clearing times with better zone
  coordination
• Stuck breaker (breaker failure) accelerated
  remote fault clearing
• Phase and ground selectable
• Extended range up to 1000
• Works with DT3000

21
FP5000 Protection Features

• Zone Interlocking
• Fault _at_ Location 2
• Relay _at_ CB2 sees fault sends interlocking
  signal to upstream devices at CB1
• Upstream devices continues to operate on normal
  set time for remote backup protection
• CB2 fast trips to interrupt fault
• If CB2 fails to interrupt fault in 10 cycles
  remote clearing of CB1 occurs
• Fault _at_ Location 1
• Relay _at_ CB2 does not see the fault - no signal is
  sent to relay _at_ CB1
• Relay _at_ CB1 sees fault but does not receive
  interlocking signal - Fast Trips

CB1
Zone 1
Fault 1
CB2
Zone 2
Fault 2
22
FP-5000 Metering Features

• RMS Load Values
• Currents - Ia, Ib, Ic, IX, IR, I Average
• Voltages - LL, LN, VX, LL Average, LN Average
• System Power - Watts, vars, VA
• Power Factor, Frequency
• THD Voltage and Current
• Magnitude THD Voltage and Currents
• Current accuracy 0.5 or 0.025 A
• Voltage accuracy 0.5 or 0.02 V
• Power accuracy 1.5 worse case

23
FP5000 Metering Features

• Fundamental phasor measurements
• Magnitude and phase angle of voltages and
  currents
• Magnitude and phase angle of positive, negative
  and zero sequence voltages and currents
• Percent voltage unbalance and phase rotation
  (V2/V1)
• Percent current unbalance and phase rotation
  (I2/I1)

24
FP-5000 Metering Features

• Energy Measurements
• System Watt Hours - Forward, Reverse, Net
• System var Hours - Forward, Reverse, Net
• System VA Hours
• Start Date Time for Energy Accumulation
• Minimum maximum values
• Phase and Ground Currents
• Voltages - LL and LN
• System Power
• Frequency
• Power Factor
• time and date stamp

25
FP-5000 Monitoring Features

• Relay self-diagnostics and Relay Healthy Alarm
  Output (failsafe operation)
• Memory and setting checks
• Calibration and A/D monitoring
• Power supply monitoring
• Watchdog timer
• Trip circuit monitoring and alarming
• Close circuit monitoring and alarming

26
FP-5000 Monitoring Features

• Circuit breaker monitoring and Alarming
• Breaker open/close state and indication
• Operation counter and alarm
• Breaker wear alarm (accumulated interrupted
  current per phase)
• 52 auxiliary contact monitoring with 52a and 52b
  contact inputs connected
• Sluggish breaker operation monitoring
• Loss of Vacuum monitoring
• Stuck breaker (breaker failure)

27
Breaker Duty
28
Breaker Monitoring Logic
29
FP5000 Logic Control Features
30
FP-5000 Logic Control Features

• Breaker open and close logic with front panel
  open/close control
• Power factor monitoring and cap bank switching
  control
• Output contact logic gate control
• Overcurrent blocking gates
• Multiple setting group selection and control
• Main-tie-main transfer schemes

31
FP-5000 Logic Control Features

• Programmable logic control function
• Six programmable logic gates
• AND OR, NAND, NOR
• 4 programmable inputs
• Six programmable timers
• Pick up time delay
• Drop out time delay
• Two Latching logic gates
• Use internal or external signals

32
(No Transcript)
33
FP-5000 Data Logging Features

• Event Log
• Trip Log
• History Log
• Data Logger (communication access only)
• Waveform Capture (communication access only)

34
FP-5000 Data Logging Features

• Event log records 100 events with date and time
  stamp ( 1 ms resolution)
• Event Types
• General
• Control power on/off
• Breaker open/close
• Reset demand, min/max, energy
• Change settings
• Trip, alarm, pickup, dropout
• Input / output state change
• Self-test warning

35
FP-5000 Data Logging Features

• Trip log records last 16 trips
• Date time stamp (1 ms resolution)
• Fault type, status
• Trip counter, event number, osc buffer
• Time to trip (51 elements)
• Phase currents voltages (rms. and phasor)
• Frequency
• I/O and logic states

36
FP-5000 Data Logging Features

• History log records accumulated values
• Number of operating hours
• Number of trips
• Number of breaker operations
• Accumulated interrupted amps per phase
• Times powered up
• Number of setting changes
• Date and time stamp of last reset

37
FP-5000 Data Logging Features

• Data logger
• 1024 records in 128 blocks
• Each block timestamp 8 records
• Log 8 quantities in each record
• Default configuration logs currents voltages
• Select from V, I, Power, PF, Freq, THD, Demand,
  Contact inputs/outputs
• Select logging interval from 1 s to 1 hour
• Select continuous or single pass logging
• Trigger auto, Cin, Logic, PB, Comm.

38
FP-5000 Data Logging Features

• Waveform Capture
• 256 cycles of data storage
• Select Trigger Pickup, Trip, Cin, dV/dI, Logic,
  PB, Comm.
• Number of pre-trigger cycles is configurable
• Stored Parameters
• 32 samples per cycle 4 Currents, 4 Voltages
• Once a cycle
• rms and phasor Voltages Currents
• Frequency, Fault Type
• Input Output States
• Pickup, Trip, Alarm, Logic States

39
Power Port Main Screen

• Device Status
• Communication Settings

40
FP-5000 Display Setpoints

• System Configuration Settings

41
FP-5000 Display Setpoints

• Trip1 Output Relay Settings

42
FP-5000 Change Setpoints

• System Configuration Settings

43
FP-5000 Change Setpoints

• Protection Setting Group 1 Overview

44
FP-5000 Change Setpoints

• Phase Overcurrent Settings
• 51P ITOC
• 50P-1 IOC
• 50P-2 IOC

45
FP-5000 Change Setpoints

• Current Voltage Unbalance
• Under Over Voltage Protection

46
FP-5000 Change Setpoints

• Breaker Failure
• Power Factor
• Over Under Frequency Protection

47
FP-5000 Change Setpoints

• Datalogger Configuration

48
FP-5000 Change Setpoints

• Waveform Capture Configuration

49
FP-5000 Change Setpoints

• Contact Input Configuration

50
FP-5000 Change Setpoints

• Trip 1 Output Relay Settings

51
FP-5000 Change Setpoints

• Indicator Settings

52
FP-5000 Monitoring

• Metering Overview

53
FP-5000 Monitoring

• Voltage Phasors

54
FP-5000 Monitoring

• Overcurrent Protection Function Status

55
FP-5000 Monitoring

• Input Status

56
FP-5000 Monitoring

• Output Status

57
FP-5000 Control

• Relay Control
• Reset Functions
• Active Setting Group Control
