Distributed Embedded Systems

1
Distributed Embedded Systems
2
Distributed Embedded Systems

• A system implemented on several processing
  elements connected by one or more networks that
  allows them to communicate

3
Distributed Embedded Architectures

• Many alternatives
• basic units processing elements and the network

4
Why Distributed?

• The devices that PEs communicate with may be
  physically separated
• One part of the system can be used to help
  diagnose problems in another part
• Distributing work on multiple PEs may be more
  cost effective than one powerful PE
• Some off the shelf components may have embedded
  processors pre-designed for network interfacing

5
Network Abstractions

• In initial stages, there was chaos
• Solution - the ISOs OSI model
• ISO ?International Standards Organization
• OSI ? Open Systems Interconnect Model

6
(No Transcript)
7
Physical Layer

• Defines the basic properties of the interface
  between systems, including
• the physical connections (plugs and wires),
• electrical properties,
• basic functions of the electrical and physical
  components, and
• the basic procedures for exchanging bits

8
Data Link Layer

• Primary - error detection and control across a
  single link
• if the network requires multiple hops over
  several data links - layer does not define the
  mechanism for data integrity between hops only
  within a single hop

9
Network Layer

• Defines the basic end-to-end data transmission
  service
• Particularly important in multihop networks

10
Transport Layer

• Defines connection-oriented services that ensure
  that data are delivered in the proper order and
  without errors across multiple links
• May also try to optimize network resource
  utilization

11
Session Layer

• Provides mechanisms for controlling the
  interaction of end-user services across a
  network, such as data grouping and checkpointing

12
Presentation Layer

• Defines data exchange formats and provides
  transformation utilities to application programs

13
Application Layer

• Provides the application interface between the
  network and end-user programs

14
Hardware and Software Architectures

• Architecture - a function of type of
  interconnection network

15
Point-to-Point

• A connection between exactly two processing
  elements

16
(No Transcript)
17
Buses

• Interconnection for multiple processing elements
  (PEs)
• requires message formatting

18
Responsibility of transmitting PE to
divide data into PACKETS
Responsibility of receiving PE to reassemble
message from PACKETS
19
ARBITRATION SCHEME

• Necessary when multiple devices must try to
  access bus

20
Fixed-Priority Arbitration

• Always gives priority to competing devices in
  the same way
• If a high-priority and a low-priority device
  both have long data transmissions ready at the
  same time - quite possible that the low-priority
  device will not be able to transmit until the
  high-priority device has sent all data packets

21
Fair Arbitration

• Makes sure that no device is starved
• Round robin arbitration -- the most commonly
  used of the fair arbitration schemes
• PCI bus -- requires that the arbitration scheme
  used on the bus be fair but does not specify a
  particular arbitration scheme

22
Crossbar Network

• Not only allows any input to be connected to any
  output - allows all combinations of input/output
  connections to be made
• a crosspoint is a switch that connects an input
  to an output
• The major drawback of the crossbar network is
  expense
• the size of the network grows as the square of
  the number of inputs

23
For example - can simultaneously connect in1 to
out4, in2 to out3, in3 to out2, in4 to out1
or any other combinations of inputs.
Multicast connections can also be made from one
input to several outputs
24
Multistage Networks
25

• Blocking gt there are some combinations of
  sources and destinations for which messages
  cannot be delivered simultaneously
• Bus gt maximally blocking
• An alternative to a nonbus network is to use
  multiple networks
• may be cheaper to use two slow, inexpensive
  networks than a single high-performance,
  expensive network

26
Sending A Message

• C Procedure
• send_packet(address, data)
• Code segment
• for (i 0iltmessage.length iipacket_size
  )
• send_packet(address,message.datai
• uses the loop to break up an arbitrary-length
  message into packet-size chunks

27
Receiving A Message

• Reception of a packet will probably be
  implemented with interrupts
• Simplest procedural interface will simply check
  to see whether a received message is waiting in
  a buffer
• In a more complex RTOS-based system, reception
  of a packet may enable a process/task for
  execution

28
Communication may be blocking or nonblocking

• Simplest implementation of message passing is
  blocking, with the routine not returning until
  it has transmitted or received
• A nonblocking network interface requires a queue
  of data to be sent, with network driver sending
  packets off the head of the queue and placing
  received packets on the tail of the queue
• a nonblocking communication mechanism makes
  sense only when concurrency is available between
  computing and data transfer

29
Networks for Embedded Systems

• Several system buses
• Multibus and VME bus were developed by Intel and
  Motorola, respectively, for multicard computer
  systems and have been widely used in industrial
  applications
• ISA bus has been used to support many I/O cards
  for PC-based embedded systems
• PCI bus has replaced ISA for high-speed
  interfaces in PC-based applications

30
Network Examples

• I2C Bus
• ETHERNET
• INTERNET

31
I2C BUS

• Commonly used to link microcontrollers
• Multiple nodes may be bus masters
• Some nodes may be slaves -gt respond only

32
Serial Data Line
Serial Clock Line
33
Electrical Interface
34
Operation

• Bus master responsible for generating SCL clock
• as a result no global master to generate clock
• Each bus master must listen to the bus while
  transmitting to be sure there is no interference
• if a different value is received than is being
  sent gt interference

35
Data Link Layer

• Each device has 7 bit address
• Addr 0000000 broadcast
• Addr 11110XX extended 10 bit address
• Bus transaction a series of one byte
  transmissions
• an address followed by one or more data bytes

36
(No Transcript)
37
Bus Transaction

• Initiated by a start signal and completed with
  an end signal
• Start is signaled by leaving the SCL high and
  sending a 1 to 0 transition on SDL
• Stop is signaled by setting the SCL high and
  sending a 0 to 1 transition on SDL

38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
Bus Arbitration

• When sending, devices listen to the bus
• if a device is trying to send a logic 1 but hears
  a logic 0, it immediately stops transmitting and
  gives the other sender priority

42
(No Transcript)
43
Microcontroller Implementation

• The I2C interface on a microcontroller can be
  implemented with varying percentages of the
  functionality in software and hardware
• One of the microcontrollers timers is typically
  used to control the length of bit on the bus
• Interrupts may be used to recognize bits

44
ETHERNET A bus organization but NOT
synchronized like I2C or CAN gt cannot detect
collision in a single bit time as I2C or CAN
45
Arbitration Scheme

• CSMA/CD -- Carrier Sense Multiple
  Access/Collision Detection
• a node that has a message waits for the bus to
  become silent and then starts transmitting
• it simultaneously listens, and if it hears
  another transmission that interferes with its
  transmission, it stops transmitting and waits to
  retransmit
• the waiting time is random, but weighted by an
  exponential function of the number of times the
  message has been aborted

46
(No Transcript)
47
Randomness makes performance analysis
difficult Almost precludes hard real time control
48
(No Transcript)
49

• Maximum length of an Ethernet is limited by a
  nodes ability to detect collisions
• Worst case two nodes at opposite ends
• Length several hundred meters

50
Internet

• Protocol Internet Protocol (IP)
• Provides connectionless, packet based
  communication
• OSI network layer

51
(No Transcript)
52

• IP creates the packets
• Router a node that transmits data (packets)
  among different types of networks
• As data pass through several layers of the
  protocol stack, the IP packet data are
  encapsulated in packet formats appropriate to
  each layer

53
Originally 32 bits Now 128 bits
lt 64K in length
54

• IP Address Format XXX.XX.XX.XX
• Domain Name Server (DNS) translates
• YY.ZZ.COM etc into IP addresses
• IP at the network layer ?no guarantee that a
  packet is delivered to destination or that
  packets take same path and arrive in the same
  order
• Responsibility of higher layers

55
Higher level services are built on top of IP

• TCP Transmission Control Protocol best known
  example
• provides connection oriented service that
  ensures that data arrive and are placed in
  appropriate order
• uses an acknowledgement protocol to ensure that
  packets arrive

56
Other Services

• FTP file transport protocol batch file
  transfers
• HTTP hypertext transport protocol www
• SMTP simple mail transfer protocol email
• Telenet virtual terminals
• UDP user datagram protocol basis for network
  management
• SNMP simple network management protocol

57
(No Transcript)
58
Network-Based Design

• Similar analysis and design tasks as necessary
  for accelerator based systems
• must schedule computations in time and allocate
  them to processing elements on the networks
• Network can become the bottleneck in the system

59
Communication Analysis

• To determine the delay incurred by transmitting
  messages
• Message delay (tm) for a single message with no
  contention
• tm txtntr
• tx - transmitter side overhead
• tn - network transmission time
• tr - receiver side overhead

60
Example Simple Message Delay for an I2C Message

• Assume that an I2C bus runs at the rate of 100
  kilobits per second and that we need to send
  one 8-bit byte
• npacket start bit addressdatastop bit
• 1881 18bits
• tn npacket x tbit 1.8X10-4 sec.

61

• The loops that send bytes to and receive bytes
  from the network interface will run
  concurrently with the message transmission
• If we assume that 20 instructions outside of
  these loops are executed by the transmitter and
  receiver, overhead on an 8 MHz microcontroller
  would be as follows
• tx tr20 x 0.125 x 10-6 2.5 x 10-6
• tm 2.5 x 10-6 1.8X10-4 2.5 x10-6 1.85X10-4
• Overhead is less than 3

62

• If messages can interfere with each other in the
  network, analyzing communication delay becomes
  difficult
• Message delay is
• ty tdtx
• where td is the network availability delay
  incurred waiting for the network to become
  available

63
The main problem is calculating td

• If the network uses fixed-priority arbitration,
  the network availability delay is unbounded for
  all but the highest-priority device
• If the network uses fair arbitration, the network
  availability delay is bounded
• in the case of round-robin arbitration, if there
  are N devices, then the worst-case network
  availability delay is N(tx tarb), where tarb is
  the delay incurred for arbitration
• tarb is usually small compared to transmission
  time

64
Example

• Adjusting Messages to Improve Network Delay

65
Assume we want to implement the following task
graph
66
Assume also that we want to implement the task
graph on the following network
67

• Allocate
• P1 ---gt M1 - requires 3 units
• P2 ---gt M2 - requires 3 units
• P3 ---gt M3 - requires 4 units
• Transmission times
• d1d2 4 units

68
The simplest implementation transmits all the
required data in one large message.
Total schedule length 3444 15 units
69

• If P3 is redesigned so that it doesnt require
  all of both messages to begin processing
• program can be modified so that it reads one
  packet of data each from d1 and d2 and starts
  computing on that
• if it finishes what it can do on that data before
  the next packets from d1 and d2 arrive, it
  waits otherwise, it picks up the packets and
  keeps computing

70
Total schedule length 381 12 units
71

• Adding acknowledgement and data corruption into
  the analysis, requires complex probability
  analysis

72
Arbitration

• A form of prioritization
• hence techniques such as those in RTOS can be
  employed e.g. rate monotonic scheduling
• since packet transmission, in general, cannot be
  interrupted, networks exhibit priority
  inversion
• when a low priority message is on the network,
  higher priority messages are effectively blocked
• deadlock cannot occur

73
System Performance Analysis

• Very difficult for distributed embedded systems
• Consider a simple case

74
Two processes and one n-packet data communication
worst case time to completion tp1ntxtp2
If situation allows computations and
communications to interfere, complexity increases
75
Consider this example task graph is
superimposed on target architecture
76

• Data dependency from P1 to P2 translates any
  uncertainty in the execution time of P1 into
  uncertainty about the start time of P2
• Collocation of P2 and P3 to processing element
  M2 means that variations in the ready time of P2
  can affect the completion time of P3
• variations in the execution time of P2 can also
  affect P3

77

• Data dependency from P3 to P4 translates
  variations in the completion time of P3 to the
  start time of P4
• Therefore, even though P2 and P3 are separate
  tasks, the fact that they are allocated to the
  same PE causes them to interact with each other
  in ways that affect the completion time of every
  task in the system

78

• Complex distributed embedded systems require CAD
  tools to accurately analyze performance
• If you dont have tools to help you analyze
  performance, care is essential when
  hand-designing a system that has to meet hard
  real-time deadlines
• It is important to make sure that only one task
  the critical task is active
• When there are several critical tasks that must
  occur simultaneously, hand design requires
  allocating them to share nothing no PEs nor
  communication links

79
Hardware Platform, Design, Allocation Scheduling

• Design choices
• number of PEs required
• types of all PEs
• number of networks required
• types (and data rates) of the networks

80
Two Strategies

• For I/O intensive systems
• start with the I/O devices and their associated
  processing
• For computation intensive systems
• start with the processes/tasks

81
I/O Intensive System Design

• Inventory the required I/O devices
• Determine which processing has deadlines short
  enough that they cannot be met by any network
  within your price range
• I/O devices that do not require local processing
  may be attached to the network with the
  simplest available interface
• Determine which devices can share a processing
  element or network interface

82
I/O Intensive System Design

• Analyze communication times to determine whether
  critical communications may interfere with each
  other
• determine whether a complex network or multiple
  networks may be required to satisfy
  communication deadlines
• Allocate the minimum required PE to go with each
  I/O device
• Design the rest of the system using the procedure
  for computation-intensive systems

83
Computation Intensive System Design

• Start with the tasks with the shortest deadlines
• the shorter the deadline for a task, the more
  likely it is to require its own processing
  element or elements
• if a high-priority task shares a PE with a
  low- priority task, not only will a more
  expensive PE be required, but scheduling
  overhead will be paid for at the nonlinear rate

84
Computation Intensive System Design

• Analyze communication time to determine whether
  critical communications may interfere with each
  other
• Allocate lower-priority tasks to shared PEs
  where possible
• After designing a basic system that meets
  performance goals, improve it to satisfy power
  consumption or other requirements
