Visibility Culling

1
Visibility Culling

• Markus Hadwiger Andreas Varga

2
Basics

• Hierarchical Subdivision
• Hierarchical Bounding Boxes
• Octrees
• K-D Trees ( K-Dimensional Space)
• BSP Trees ( Binary Space Partition )
• Potentially Visible Sets (PVS)

3
Hierarchical Bounding Box (HS)

• Construct a bounding box for each object
• Merge nearby bounding box into bigger ones
• Not very structured and systematic
• Perform well for certain viewpoint
• Shortcomings
• Highly dependent on the given scene(worse on
  the actual viewpoint)
• Unpredictable not very useful !

4
Hierarchical Bounding Box Example (HS)
WORLD
ROLLERCOASTER
CAR 2
CAR 1
GUY_BAD
GUY_BAD
GUN
GUY_BAD
5
Octrees (HS)

• Each node of and octree has form one to eight
  children if it is an internal node otherwise it
  is a leaf node
• Culling against the viewing frustum
• Shortcomings of regular subdivision
• Efficiently problem (inflexible)
• Depend on the location of each polygon
• The two dimensional version of an octree is
  called quadtree

6
Octrees Example (HS)
7
K-D Trees2/2 (HS)

• Hierarchically subdivide n-dimensional space
• A binary tree
• partitioning space into two halfspaces at each
  level
• two equal-sized partitions is not necessary
  (Octrees)
• Always done axial
• A separating hyperplane can depend on actual data
• Balance of binary tree
• One halfspace contains the same number of objects
  as the other halfspace

8
K-D Trees Example 1/2 (HS)
4
6
1
10
8
11
2
3
3
13
2
4
5
6
7
12
9
8
9
10
11
12
13
1
5
7
9
K-D Trees Example 2/2 (HS)
10
BSP Trees6 (HS)

• Generalization of k-D trees
• Space is subdivided along arbitrarily oriented
  hyperlpanes
• Subdivision of space into two halfspace at each
  step
• Produces a binary tree
• Internal node corresponds to the partitioning
  hyperplane
• Leaf nodes are empty halfspaces
• Exact visibility determination for arbitrary
  viewpoint
• For entirely static polygonal scenes
• Can be precalculated once and traversal at run
  time witharbitrary viewpoint

11
BSP Trees Example 1 (HS)
2
3
1
1
4
5
6
12
BSP Trees Example 2 (HS)
1
2
front
3
1
4a
2
4b
5
6
13
BSP Trees Example 3 (HS)
1
2
front
back
3
1
4a
3
2
4b
5
6
14
BSP Trees Example 4 (HS)
1
2
front
back
3
1
4a
3
2
4b
front
back
5
6
4a
4b
15
BSP Trees Example 5 (HS)
1
2
front
back
3
1
4a
3
2
4b
front
back
front
5
6
4a
4b
5
front
6
16
BSP Trees Example 6 (HS)
1
2
V1
front
back
3
1
3
2
4
front
back
front
5
6
4a
5
4b
V2
front
6
The painting order from V1 3, 5, 1, 4b, 2, 6,
4a The painting order from V2 3, 5, 1, 4b, 2,
4a, 6 We got correct picture of who is behind
whom no matter where we were looking from.
17
BSP Trees Example 6 (HS)
18
Cell-Portals

• Assume the world can be broken into cells
• Simple shapes
• Rooms in a building, for instance
• Define portals to be the transparent boundaries
  between cells
• Doorways between rooms, windows, etc
• In a world like this, can determine exactly which
  parts of which rooms are visible
• Then render visible rooms plus contents

19
Cell-Portals Example
A
B
A
B
-Portals can be one way (directed
edges) -Graph is normally stored in
adjacency list format -Each cell stores the edges
(portals) out of it
C
D
C
D
E
F
E
F
-Node are cells, edges are portals-K-D trees and
BSP trees are used to generate the cell
structure and find neighbors and portals
20
Cell and Portal Visibility

• Keep track of which cell the viewer is in
• Somehow walk the graph to enumerate all the
  visible regions
• Can be done as a preprocess to identify the
  potentially visible set (PVS) for each cell
• Cell-to-region visibility, or cell-to-object
  visibility
• Can be done at run-time for a more accurate
  visible set
• Start at the known viewer location
• Eye-to-region or Eye-to-cell visibility
• Trade-off is between time spent rendering more
  than is necessary vs. time spent computing a
  smaller set
• Depends on the environment, such as the size of
  cells, density of objects,

21
Potentially Visible Sets (PVS)

• PVS The set of cells/regions/objects/polygons
  that can be seen from a particular cell
• Generally, choose to identify objects that can be
  seen
• Trade-off is memory consumption vs. accurate
  visibility
• Computed as a pre-process
• Have to have a strategy to manage dynamic objects
• Used in various ways
• As the only visibility computation - render
  everything in the PVS for the viewers current
  cell
• As a first step - identify regions that are of
  interest for more accurate run-time algorithms

22
Cell-to-Cell PVS

• Cell A is in cell Bs PVS if there exist a
  stabbing line that originates on a portal of B
  and reaches a portal of A
• A stabbing line is a line segment intersecting
  only portals
• Neighbor cells are trivially in the PVS

I
J
PVS for I contains B, C, E, F, H, J
F
H
D
B
E
C
G
A
23
Finding Stabbing Lines
L
R
L

• In 2D, have to find a line that separates the
  left edges of the portals from the right edges
• In 3D, more complex because portals are now a
  sequence of arbitrarily aligned polygons
• Put rectangular bounding boxes around each portal
  and stab those

R
L
L
R
R
24
Stab Trees

• A stab tree indicates
• The PVS for a cell
• The portal sequences to get from one to the other
• Used in further visibility processing
• Restricts number of cells/portals that must be
  looked at

A
A
B
A/C
C
C/D2
C/E
C/D1
C
D
D
E
D
D/F
F
E
F
25
Run-Time Visibility

• PVS approaches are entirely pre-processing
• At run time, just render PVS
• Better results can be obtained with a little
  run-time processing
• Sometimes guided by PVS
• It appears that most games dont bother, the
  trade-off favors pre-processed visibility and
  over-rendering
• At run time the viewers location is known, hence
  Eye-to-Region visibility

26
Eye-to-Cell

• Recall that finding stabbing lines involved
  finding a line that passed through all the
  portals
• The viewer adds some constraints
• The stabbing line must pass through the eye
• It must be inside the view frustum
• The resulting problem is still reasonably fast to
  solve
• Results in knowledge of which cells are visible
  from the eye
• Use the stab tree from the PVS computation to
  avoid wasting effort
• Further optimization is to keep reducing the view
  frustum as it passes through each portal, which
  leads us to

27
Eye-to-Region Visibility

• Define a procedure
• Takes a view frustum and a cell
• Viewer not necessarily in the cell
• Draws the contents of the cell that are in the
  frustum
• For each portal out of the cell, clips the
  frustum to that portal and recurs with the new
  frustum and the cell beyond the portal
• Make sure not to go to the cell you entered
• Start in the cell containing the viewer, with the
  full viewing frustum
• Stop when no more portals intersect the view
  frustum

28
Eye-to-Region Example
View
29
Eye-to-Region Example
View
30
Eye-to-Region Example
View
31
Eye-to-Region Example
View
32
Eye-to-Region Example
View
33
Eye-to-Region Example
View
View
34
Eye-to-Region Example
View
35
Non-Invasive Interactive Visualization of
Architectural Environments

• Christopher Niederauer U.C. Santa Barbara
• Mike Houston Stanford University
• Maneesh Agrawala Microsoft Research
• Greg Humphreys University of Virginia

36
Problem

• Environments of video game are vast and tend to
  be densely occluded.
• Most 3D model viewing application lack the
  ability to simultaneously display the interior
  spaces and the external structure of the
  environment.

37
Motivation
Arcball style manipulator
Walkthrough
ArcBall Shoemake 1992
Teller 1992
Cant see overall interior/exterior structure!
38
Motivation
Quake IIIId Software c. 2002
The occlusions make it impossible to see all the
action at once!
39
The Idea

• Exploded view
• just below the ceilings
• Non-Invasive Mohr 2001
• without modification
• use Chromium Humphreys et al. 2002

Overall structure is visible!
40
How Its Done

• Example Architecture Soda Hall
• Geometric Analysis (once)
• Rendering (every frame)

OpenGL Stream
41
Gather Architectural Data

• Intercept the OpenGL stream
• Find downward facing polygons
• Requires up-vector

1
up
2
3
polygon normal (v2-v1) x (v3-v2)

• Compute the height of downward facing polygon

1
height v1?upVector
42
Gather Architectural Data

• Create Histogram

Height Ceiling Area
942
766
606
446
286
126
Soda Hall Side Profile
Geometric Analysis
Rendering
Floor
OpenGL Stream
Find Splits
Gather Data
Composite

Floor
43
Find Splitting Heights
Geometric Analysis
Rendering
Floor
OpenGL Stream
Find Splits
Gather Data
Composite

Floor
44
Offset Ceiling Heights
45
Offset Ceiling Heights
46
Geometric Analysis
Rendering
Geometric Analysis
Floor
Find Splits
Gather Data
OpenGL Stream

Composite
Floor
Find Downward Facing Polygons
Find Split Heights
Table MappingHeight to Surface Area
List of Split Height
47
Rendering

• Multiple Playback (Once per Floor)
• Viewpoint Control
• Clipping Planes
• Translate along Up Vector

Geometric Analysis
Rendering
Floor
OpenGL Stream
Gather Data
Find Splits
Composite

Floor
48
Rendering
OriginalApplicationOpenGL
List of SplitHeights
SeparationDistance
Viewpoint
Set ViewpointClip Plans Translation
NumSplits Passes of Modified OpenGL
NumSplits Passes ofOriginal OpenGL
NumSplits

Exploded viewvisualization
MultiplePlayback
MultipassComposite
Set ViewpointClip Plans Translation
49
Cluster Speedup
Complete Model
Floor 1
Floor 2
Floor 3
800 MHz Pentium III Xeon processorNVIDIA
GeForce4 graphics accelerator
Composite
50
Soda Hall
Trackball
Walkthrough
51
Results with Soda Hall
(Single Floor)
52
Quake III Arena
Trackball
Walkthrough
53
Results with Quake III Arena
(Single Floor)
54
Video
55
Transparent Back-Faces
56
Future Directions

• Make fully automated
• Semantic inputs
• Up vector
• Number of stories to split into

57
Future Directions
Salomon et al, 2003
58
Future Directions
(Hand Designed Mock-up)
59
Summary and Conclusions

• Can improve viewer comprehension

60
Resource

• Visibility Cullinghttp//www.cg.tuwien.ac.at/msh
  /
• Stephen Chenney http//www.cs.wisc.edu/schenney/

• Non-Invasive Interactive Visualization of Dynamic
  Architectural Environments http//graphics.stanfo
  rd.edu/papers/archsplit/
• Chromium Homepagehttp//chromium.sourceforge.net/

61
(No Transcript)
