Mathematical Modelling of Power Units

1
Mathematical Modelling of Power
Units
2
Mathematical Modelling of Power Units

• What for
• Determination of unknown parameters
• Optimization of operational decision
• a current structure choosing - putting into
  operation or turn devices off
• parameters changing - correction of flows,
  temperatures, pressures, etc. load division in
  collector-kind systems

3
Mathematical Modelling of Power Units

• What for (cont.)
• Optimization of services and maintenance scope
• Optimization of a being constructed or modernized
  system - structure fixing and devices selecting

4
Mathematical Modelling of Power Units

• How main steps in a modelling process
• the system finding out
• choice of the modelling approach determination
  of
• the system structure for modelling
  simplifications and aggregation
• way of description of the elements
• values of characteristic parameters the model
  identification
• the system structure and the parameters writing
  in
• setting of relations creating the model
• (criterion function)
• use of the created mathematical model of the
  system for simulation or optimization
  calculations

5
Mathematical Modelling of Power Units

• The system finding out
• coincidence
• invariability
• completeness of a division into subsystems
• separable subsystems
• done with respect to functional aspects

6
fuel
SURROUNDINGS
electricity
SYSTEM
steam
7
Mathematical Modelling of Power Units

• choice of the modelling approach - determination
  of the system structure
• A role of a system structure in a model creation
• what system elements are considered objects of
  independent modelling
• mutual relations between the system elements
  relations which are to be taken into account and
  included into the model of the system
• additional information required parameters
  describing particular elements of the system

8
Mathematical Modelling of Power Units

• choice of the modelling approach
• -
  determination of the system structure
• Simplification and aggregation a choice
  between the model correctness and calculation
  possibilities and effectiveness

9
Simplified scheme
10
Mathematical Modelling of Power Units

• choice of the modelling approach
• - way of
  description of the elements
• basing on a physical relations
• basing on an empirical description

11
Mathematical Modelling of Power Units

• Basic parameters of a model
• mass accumulated
  and mass (or compound or elementary substance)
  flow
• energy, enthalpy, egzergy, entropy and their
  flows
• specific enthalpy, specific entropy, etc.
• temperature, pressure (total, static, dynamic,
  partial), specific volume, density,
• temperature drop, pressure drop, etc.
• viscosity, thermal conductivity, specific heat,
  etc.

12
Mathematical Modelling of Power Units

• Basic parameters of a model (cont.)
• efficiencies of devices or processes
• devices output
• maximum (minimum) values of some technical
  parameters
• technological features of devices and a system
  elements - construction aspects
• geometrical size - diameter, length, area, etc.
• empiric characteristics coefficients
• a system structure e.g. mutual connections,
  number of parallelly operating devices

13
Mathematical Modelling of Power Units

• Physical approach - basic relations
• equations describing general physical (or
  chemical) rules, e.g.
• mass (compound, elementary substance) balance
• energy balance
• movement, pressure balance
• thermodynamic relations
• others

14
Mathematical Modelling of Power Units

• Physical approach - basic relations (cont.)
• relations describing features of individual
  processes
• empiric characteristics of processes, efficiency
  characteristics
• parameters constraints
• some parameters definitions
• other relations technological, economical,
  ecological

15
Mathematical Modelling of Power Units

• Empiric approach - basic relations
• empiric process characteristics
• parameters constraints
• other relations - economical, ecological,
  technological

16
Physical approach a model of a boiler an
example
mass and energy balances
the boiler output and efficiency
17
Physical approach a model of a boiler an
example (cont.)
electricity consumption
boiler blowdown
constraints on temperature, pressure, and flow
18
Physical approach a model of a boiler an
example (cont.)
pressure losses
specific enthalpies
19
Physical approach a model of a group of stages
of a steam turbine boiler an example
mass and energy balances
20
Physical approach a model of a group of stages
of a steam turbine boiler an example (cont.)
Steam flow capacity equation
where
21
Physical approach a model of a group of stages
of a steam turbine boiler an example (cont.)
internal efficiency characteristic
where
0.000286 for impulse turbine 0.000333 for
turbine with a small reaction 0.15 - 0.3
0.000869 for turbine with reaction about 0.5
22
Physical approach a model of a group of stages
of a steam turbine boiler an example (cont.)
enthalpy behind the stage group
Pressure difference (drop) for regulation stage
23
empiric description of a 3-zone heat exchanger
Heating steam inlet
U pipes of a steam cooler
U pipes of the main exchanger
Steam-water chamber
Condensate level
Condensate inflow from a higher exchanger
Heated water outlet
Heated water inlet
U pipes of condensate cooler
Condensate outlet to lower exchanger
Water chamber
24
Scheme of a 3-zone heat exchanger
Load coefficient (Bosniakowicz)
25
The heat exchanger operation parameters

• mass flows
• inlet and outlet temperatures
• heat exchanged
• heat transfer coefficient
• load coefficient

26
Load coefficient for 3-zone heat exchanger with a
condensate cooler

• TC4 outlet condensate temperatureTx
  inlet condensate temperatureTC1 inlet heated
  water temperaturemA3 inlet steam mass
  flowmx inlet condensate mass flowmC1
  inlet heated water mass flow.

27
Empiric relation for load coefficient in changing
operation conditions (according to Beckman)

• ?0 load coefficient at reference
  conditions
• mC10 inlet heated water mass flow at reference
  conditions
• TC10 inlet heated water temperature at
  reference conditions.

28
An example an empiric model of a chosen heat
exchanger
Coefficients received with a linear regression
method
Covariance
Correlation coefficient
Standard deviation
Expected value
Random variables
X measured values Y simulated values
29
Changes of a correlation coefficient
Correlation coefficient
Sample size
30
An example of calculations
Load coefficient changes in relation to inlet
water temperature and reduced value of the pipes
diameter.
31
Empiric modelling of processes

• Modelling based only on an analysis of historical
  data
• No reason-result relations taken into account
• Black box model based on a statistical
  analysis

32
(No Transcript)
33
Most popular empiric models

• Linear models
• Neuron nets
• MLP
• Kohonen nets
• Fuzzy neron nets

34
Linear Models

• ARX model (AutoRegressive with eXogenous input)
  it is assumed that outlet values at a k moment is
  a finite linear combination of previous values of
  inlets and outlets, and a value ek
• Developed model of ARMAX type
• Identification weighted minimal second power

35
Neuron Nets - MLP

• Approximation of continuous functions
  interpolation
• Learning (weighers tuning) reverse propagation
  method
• Possible interpolation, impossible correct
  extrapolation
• Data from a wide scope of operational conditions
  are required

36
Neuron Nets - FNN

• Takagi Sugeno structure a linear combination
  of input data with non-linear coefficients
• Partially linear models
• Switching between ranges with fuzzy rules
• Neuron net used for determination of input
  coefficients
• Stability and simplicity of a linear model
• Fully non-linear structure

37
Empiric models where to use

• If a physical description is difficult or gives
  poor results
• If results are to be obtained quickly
• If the model must be adopted on-line during
  changes of features of the modelled object

38
Empiric models examples of application

• Dynamic optimization (models in control systems)
• Virtual measuring sensors or validation of
  measuring signals

39
Empiric models an example of application
Combustion in pulverized-fuel boilerDynamic
Optimization

• Control of the combustion process to increase
  thermal efficiency of the boiler and minimize
  pollution
• NOx emission from the boiler is not described in
  physical models with acceptable correctness
• Control is required in a real-time time
  constants are in minutes

40
Accessible measurements used only
41
(No Transcript)
42
Mathematical Modelling of Power Units

• Choice of the modelling approach
• Model identification
• Values of parameters in relations used for the
  object description
• technical, design data
• active experiment
• passive experiments
• (e.g. in the case of empiric, neuron models)
• data collecting on DCS, in PI

43
Data from PI system
44
Steam turbine an object for identification
45
A characteristic of a group of stages results
of identification
46
Mathematical Modelling of Power Units

• Model kind, model category
• based on physical relations or empiric
• for simulation or optimization
• linear or non-linear
• algebraic, differential, integral, logical,
• discrete or continuous
• static or dynamic
• deterministic or probabilistic (statistic)
• multivariant

47
Mathematical Modelling of Power Units

• the system structure and the parameters writing
  in numerical support

48
Chosen methods of computations

• Linear Programming
• SIMPLEX

49
Chosen methods of computations
Chosen methods of computations

• Linear programming with non-linear criterion
  function
• MINOS Method (GAMS/MINOS)

50
Chosen methods of computations

• Optimization with non-linear function and
  non-linear constraints
• Linearization of constraints
• MINOS method

51
Chosen methods of computations

• Solving a set of non-linear equations
• open equation method

52
Chosen methods of computations

• Solving a set of non-linear equations
• path of solution method

f2
f3
f1
1
4
5
3
2
x1 given
x2 given
x3
x4
x5
x6 given
53
Example of use of a mathematical model of a power
system determining of unmeasured parameters
measured p, t
possible calculation m
measured m,p,t
measured p,t
54
Example of use of a mathematical model of a power
system operation optimization of a CHP unit
Electricity output not optimized
Electricity output optimized
Optimal electricity output computed
Thermal output
55
Example of use of a mathematical model of a power
system a chose of structure of CHP unit
present situation
56
variant A
57
variant B
58
variant C
59
variant D
60
variant E
61
variant F
62
variant G
63
(No Transcript)
