Storage and File Organization

1
Storage and File Organization
2
General Overview - rel. model

• Relational model - SQL
• Formal commercial query languages
• Functional Dependencies
• Normalization
• Physical Design
• Indexing

3
Review

• DBMSs store data on disk
• Disk characteristics
• 2 orders of magnitude slower than MM
• Unit of read/write operations a block/page
  (multiple of sectors)?
• Access time seek time rotation time
  transfer time
• Sequential I/O much faster than random I/O
• Database Systems try to minimize the overhead of
  moving data from and to disk

4
Review

• Methods to improve MM to/from disk transfers
• Improve the disk technology
• Use faster disks (more RPMs)?
• Parallelization (RAID) some redundancy
• Avoid unnecessary reads from disk
• Buffer management go to buffer (MM) instead of
  disk
• Good file organization
• Other (OS based improvements) disk scheduling
  (elevator algorithm, batch writes, etc)?

5
Buffer Management

• Keep pages in a part of memory (buffer), read
  directly from there
• What happens if you need to bring a new page into
  buffer and buffer is full you have to evict one
  page
• Replacement policy
• LRU Least Recently Used (CLOCK)?
• MRU Most Recently Used
• Toss-immediate remove a page if you know that
  you will not need it again
• Pinning (needed in recovery, index based
  processing,etc)?
• Other DB specific RPs DBMIN, LRU-k, 2Q

6
File Organization

• Basics
• A database is a collection of files, file is a
  collection of records, record (tuple) is a
  collection of fields (attributes)?
• Files are stored on Disks (that use blocks to
  read and write)?
• Two important issues
• Representation of each record
• Grouping/Ordering of records and storage in
  blocks

7
File Organization

• Goal and considerations
• Compactness
• Overhead of insertion/deletion
• Retrieval speed sometime we prefer to bring more
  tuples than necessary in MM and use CPU to filter
  out the unnecessary ones!

8
Record Representation

• Fixed-Length Records
• Example
• Account( acc-number char(10), branch-name
  char(20), balance real)
• Each record is 38 bytes.
• Store them sequentially, one after the other
• Record1 at position 0, record2 at position 38,
  record3 at position 76 etc

Compactness (350 bytes)?
9
Fixed-Length Records

• Simple approach
• Store record i starting from byte n ? (i 1),
  where n is the size of each record.
• Record access is simple but records may cross
  blocks
• Modification do not allow records to cross block
  boundaries
• Insertion of record i Add at the end
• Deletion of record i Two alternatives
• move records
• i 1, . . ., n to i, . . . , n 1
• record n to i
• do not move records, but link all free records
  on a free list

10
Free Lists

• 2nd approach FLR with Free Lists
• Store the address of the first deleted record in
  the file header.
• Use this first record to store the address of the
  second deleted record, and so on
• Can think of these stored addresses as pointers
  since they point to the location of a record.
• More space efficient representation reuse space
  for normal attributes of free records to store
  pointers. (No pointers stored in in-use
  records.)?

Better handling ins/del
Less compact 420 bytes
11
Variable-Length Records

• 3rd approach Variable-length records arise in
  database systems in several ways
• Storage of multiple record types in a file.
• Record types that allow variable lengths for one
  or more fields.
• Record types that allow repeating fields or
  multivalued attribute.
• Byte string representation
• Attach an end-of-record (?) control character to
  the end of each record
• Difficulty with deletion (leaves holes)?
• Difficulty with growth

4
?
?
?
R1
Field Count
R2
R3
12
Variable-Length Records Slotted Page Structure

• 4th approach VLR-SP
• Slotted page header contains
• number of record entries
• end of free space in the block
• location and size of each record
• Records stored at the bottom of the page
• External tuple pointers point to record ptrs
  rec-id ltpage-id, slotgt

13
Rid (i,N)?
Page i
Rid (i,2)?
Rid (i,1)?
N
Pointer to start of free space
20
16
24
N . . . 2 1
slots
SLOT DIRECTORY
Insertion 1) Use FP to find space and insert
2) Find available ptr in the
directory (or create a new one)?
3) adjust FP and number of records
Deletion ?
14
Variable-Length Records (Cont.)?

• Fixed-length representation
• reserved space
• pointers
• 5th approach Fixed Limit Records (for VLR)?
• Reserved space can use fixed-length records of
  a known maximum length unused space in shorter
  records filled with a null or end-of-record
  symbol.

15
Pointer Method

• 6th approach Pointer method
• Pointer method
• A variable-length record is represented by a list
  of fixed-length records, chained together via
  pointers.
• Can be used even if the maximum record length is
  not known

16
Pointer Method (Cont.)?

• Disadvantage to pointer structure space is
  wasted in all records except the first in a a
  chain.
• Solution is to allow two kinds of block in file
• Anchor block contains the first records of
  chain
• Overflow block contains records other than
  those that are the first records of chairs.

17
Ordering and Grouping records

• Issue 1
• In what order we place records in a block?
• Heap technique assign anywhere there is space
• Ordered technique maintain an order on some
  attribute
• So, we can use binary search if selection on this
  attribute.

18
Sequential File Organization

• Suitable for applications that require sequential
  processing of the entire file
• The records in the file are ordered by a
  search-key

19
Sequential File Organization (Cont.)?

• Deletion use pointer chains
• Insertion locate the position where the record
  is to be inserted
• if there is free space insert there
• if no free space, insert the record in an
  overflow block
• In either case, pointer chain must be updated
• Need to reorganize the file from time to time to
  restore sequential order

20
Clustering File Organization

• Simple file structure stores each relation in a
  separate file
• Can instead store several relations in one file
  using a clustering file organization
• E.g., clustering organization of customer and
  depositor

SELECT account-number, customer-name FROM
depositor d, account a WHERE d.customer-name
a.customer-name

• good for queries involving depositor
  customer, and for queries involving one single
  customer and his accounts
• bad for queries involving only customer
• results in variable size records

21
File organization

• Issue 2 In which blocks should records be
  placed
• Many alternatives exist, each ideal for some
  situation , and not so good in others
• Heap files Add at the end of the file.Suitable
  when typical access is a file scan retrieving all
  records.
• Sorted FilesKeep the pages ordered. Best if
  records must be retrieved in some order, or only
  a range of records is needed.
• Hashed Files Good for equality selections.
  Assign records to blocks according to their value
  for some attribute

22
Data Dictionary Storage
Data dictionary (also called system catalog)
stores metadata that is, data about data, such
as

• Information about relations
• names of relations
• names and types of attributes of each relation
• names and definitions of views
• integrity constraints
• User and accounting information, including
  passwords
• Statistical and descriptive data
• number of tuples in each relation
• Physical file organization information
• How relation is stored (sequential/hash/)?
• Physical location of relation
• operating system file name or
• disk addresses of blocks containing records of
  the relation
• Information about indices (Chapter 12)

23
Data dictionary storage

• Stored as tables!!
• E-R diagram?
• Relations, attributes, domains
• Each relation has name, some attributes
• Each attribute has name, length and domain
• Also, views, integrity constraints, indices
• User info (authorizations etc)?
• statistics

24
A-name
name
position
1
N
relation
has
attribute
domain
25
Data Dictionary Storage (Cont.)?

• A possible catalog representation

Relation-metadata (relation-name,
number-of-attributes,
storage-organization, location)Attribute-
metadata (attribute-name, relation-name,
domain-type, position, length)? User-metadata
(user-name, encrypted-password,
group)? Index-metadata (index-name,
relation-name, index-type, index-attributes)? Vi
ew-metadata (view-name, definition)
26
Large Objects

• Large objects binary large objects (blobs) and
  character large objects (clobs)?
• Examples include
• text documents
• graphical data such as images and computer aided
  designs audio and video data
• Large objects may need to be stored in a
  contiguous sequence of bytes when brought into
  memory.
• If an object is bigger than a page, contiguous
  pages of the buffer pool must be allocated to
  store it.
• May be preferable to disallow direct access to
  data, and only allow access through a
  file-system-like API, to remove need for
  contiguous storage.

27
Modifying Large Objects

• If the application requires insert/delete of
  bytes from specified regions of an object
• B-tree file organization (described later in
  Chapter 12) can be modified to represent large
  objects
• Each leaf page of the tree stores between half
  and 1 page worth of data from the object
• Special-purpose application programs outside the
  database are used to manipulate large objects
• Text data treated as a byte string manipulated by
  editors and formatters.
• Graphical data and audio/video data is typically
  created and displayed by separate application
• checkout/checkin method for concurrency control
  and creation of versions
