Computational methods for genetic mapping of quantitative traits

1
Computational methods for genetic mapping of
quantitative traits

• Kajsa Ljungberg
• February 17, 2006

2
Kajsa Ljungberg

• M.Sc. Biotechnology Engineering (civilingenjör
  Molekylär bioteknik), Uppsala.
• Ph.D. Scientific Computing, Uppsala.
• Various computational projects at e.g.
  AstraZeneca and UC San Francisco

3
Overview

• Background of my Ph.D. project Quantitative
  traits, genetics, experiments.
• My work Mathematical problem, methods
  (principles only), results.
• Two related problems in computational biology.
• Lessons learned in industry and academia.

4
Heritable traits, examples

• Earlobes Loose or attached
• Blood group A, B, AB or 0

5
Qualitative traits

• Can be divided into classes in a natural way.
• Often governed by a single gene, and in such
  cases the genetic basis is relatively easy to
  study
• Examples Earlobes, blood group, Huntingtons
  disease.

6
Heritable traits, more examples

• Height
• Hair colour
• Blood pressure

7
Quantitative traits

• Vary continuously on some scale.
• Often governed by multiple interacting genes and
  the environment.
• Examples Blood pressure, cholesterol levels,
  growth rate in e.g. farm animals.
• Most traits of economic or medical importance are
  quantitative.

8
QTL

• Abbreviation of Quantitative Trait Locus
• Region in the genome where one or several genes
  influencing a quantitative trait are located.
• Can be found using QTL mapping, and is an
  important step in the process of finding the
  individual genes.

9
HUGO and QTL mapping

• HUGO project
• Sequence ? Gene ? Function/Trait
• QTL mapping
• Function/Trait ? QTL ( ? Gene)

10
Experiments in QTL mapping
0000000000000000000000000000000000
1111111111111111111111111111111111
0000000000000000000000000000000000
0000000000000000011111111111111111
0000000000000000011110000011111111
0000000000000000000011111111111110
0000000000000000000000001111111111
0000000000000000000000000001111111
0000000000000000011111111100000111
11
Fit model A(x)by (bb0 b1). b0 denotes the
mean weight and b1 the effect of the genotype.
Experiment? model
1111000001111111111 0001111111111111000 1111111111
110000000 0000000111111111111 0000000000111111111
1111111111111000111 ...
11 11 11 10 10 11 .. A(x)
1672g 945g 213g 1212g 418g 744g .. y
x
12
If 1 QTL only

Residual norm
x
The genome, all chromosomes lined up
Model
Experiment data A(x), y
Least-squares problem
Residual norm
13
If 1 QTL only, contd.




Residual norm
















x
The genome, all chromsomes lined up
The genome position with the smallest residual
norm (best model fit) indicates the most likely
position of the QTL.
14
If 2 QTL
Searching for two QTL corresponds to a
two-dimensional optimization problem.
15
Computational problem
Searching for n QTL corresponds to
an n-dimensional optimization problem, where the
objective function is the residual norm of a
least-squares problem.
16
My project

• Minimize f(x), i.e. find the genome positions
  giving the best model fit, faster.
• Two main strategies
• 1) Speed up the computation of the residual norm.
  Linear algebra, updated QR factorizations...
• 2) Speed up the multidimensional search for the
  optimum. DIRECT algorithm

17
Results

• 2-3 orders of magnitude speed-up for typical
  problems, even more for complicated models.
  Computational times measured in minutes instead
  of days.
• This allows for more thourough data exploration
  and model testing.

18
(No Transcript)
19

• PSEUDOMARKER 2.02
• Hao Wu1, Saunak Sen2, Kajsa Ljungberg3, Karl W.
  Broman4, Gary A. Churchill1
• 1The Jackson Laboratory, Bar Harbor, ME
• 2Department of Epidemiology and Biostatistics,
  University of California San Francisco, San
  Francisco, CA
• 3Department of Information Technology, Division
  of Scientific Computing, Uppsala University,
  Uppsala, Sweden.
• 4Department of Biostatistics, Johns Hopkins
  University, Baltimore, MD
• http//www.jax.org/staff/churchill/labsite/softwar
  e/pseudomarker/

20
Related problems, 1

• Gene expression levels from microarray
  experiments are also quantitative traits.
• QTL analysis on microarray data can help
  distinguish between covariation and causation.
• Hot topic!

21
Related problems, 2

• QTL analysis in human populations (different
  statistical issues).
• Examples at AstraZeneca
• 1) Procardis risk factors heart disease.
• 2) Identify QTL related to adverse side
  effects, e.g liver problems (Exanta).

22
Lessons learned

• (as a computational expert among
  experimentalists)
• The importance of visualization
• Differences in language
• Real data is a pain
• People use what they know
• ? Future projects?

23

• End of presentation.

24
Thanks

• Sverker Holmgren
• Örjan Carlborg
• Kateryna Mishchenko
• Mahen Jayawardena
• Leif Andersson
• Martina Hägglund
• Forskarskolan i Matematik och Beräkningsvetenskap
• Linné-centrum

25
Paper 1
Standard method
Genetic info
Experiment data
Computation
Constant info
Prediction
Genetic info
Computa
-tion
Constant info
Prediction
26
Paper 1 (Ljungberg, Holmgren, Carlborg)

Model
Experiment data
Computation
Prediction Real value Difference
27
Paper 2 (Ljungberg, Holmgren, Carlborg)
Difference between prediction real value


























The genome, all chromosomes lined up
Search carefully in regions with good values, but
only sparsely in regions with bad values.
28
Paper 3 (Ljungberg, Mishchenko, Holmgren)
Difference between prediction real value

















The genome
When a region with good values has been found,
use a special algorithm which is efficient in
finding the bottom of the closest valley.
29
Paper 4 (Ljungberg)
100, 010, 000, 111 11 00 01 11
2
Model
Experiment data
Computation
Prediction
30
Paper 5 (Jayawardena, Holmgren, Ljungberg)

Difference between prediction real value


Model
Model
Model
Data
Computation
Computation
Data
Computation
Data
Perform several computations simultaneously in an
organized and efficient manner.
