Topic 11

1
Topic 11 Structures and Unions
2
Introduction to Structures

• We have seen that an array is a list of the same
  type of elements.
• A structure is a collection of differing data
  types. It is usually used to implement a record
  (as in a database record).
• For example, a good use of a structure would be
  to represent a students record in a class /
  grading database.

3
Introduction to Structures

• For each student, the program needs to store the
  students last, middle, and first names, their
  student ID number, their numerical grade (course
  average) and their final course grade.
• Thus, for each student record, we need four
  strings (each name and the ID number), a float
  (numerical grade), and a character (letter grade).

4
Introduction to Structures

• Thus, we can define a structure to hold a student
  record as
• typedef struct
• char last20
• char middle20
• char first20
• float numerical_grade
• char letter_grade
• student_record

5
Structures

• What this structure definition does is to define
  a new data type, named student_record.
• This new data type holds three strings of 20
  characters each, one floating point number, and
  one character.

typedef struct char last20 char
middle20 char first20 float
numerical_grade char letter_grade
student_record
Then, inside the braces, we list (declare) the
member variables that will compose the structure.
6
Structures

• A structure definition goes outside of any
  function, including main().
• This is similar to function prototypes which
  precede main. A good idea is to place structure
  definitions immediately before function
  prototypes.
• Once the structure definition is present,
  variables of the structure data type can now be
  declared inside functions.

7
Structures

• For example,

typedef struct char last20, middle20,
first20 float numerical_grade char
letter_grade student_record int
main() float a, b, c student_record
TopStudent student_record others175 int x,
y, z . . .
8
Structures

• Note that for each variable of type
  student_record, we can store 3 strings, 1
  floating point number, and one character.
• So, the question remainshow do we access all of
  these variables contained within our new
  programmer-designed data type?

9
Structure Component Referencing

• To do this, we can use the direct component
  selection operator, also known as a period .
• In our previous example, to reference the last
  name string (named last) inside the variable
  TopStudent, we would write
• TopStudent.last

10
Structure Component Referencing
student_record TopStudent student_record
others175 strcpy(TopStudent.last,Six) strc
py(TopStudent.middle,Alan) strcpy(TopStudent.fi
rst,Jeffrey) TopStudent.numerical_grade
100 TopStudent.letter_grade A printf(The
top student was\n) printf(s s s who got a
f which is a c.\n, TopStudent.first,
TopStudent.middle, TopStudent.last,
TopStudent.numerical_grade, TopStudent.letter_grad
e)
11
Structure Component Referencing

• We can see that a structure component (one of the
  variables that make up the structure) can be
  accessed using the . operator.
• Thus, variable_name.component_name can be used in
  the exact same way as a regular variable of the
  same type.

12
Structure Component Referencing

• Looking at our previously example,
  TopStudent.numerical_grade can be used in any
  manner a float data type can be.
  TopStudent.letter_grade can be used just like any
  other character.
• Also, others9.numerical_grade can be used like
  any other float and others9.letter_grade can be
  used just like any other char.

13
Array Structure Referencing

• Notice that in the reference
• others9.letter_grade
• We can see that the array referencing
  operator takes precedence over the structure
  referencing operator .
• Thus, first we use the operator to get one
  student_record from the array of student_records
  and then we use the . operator to get the
  letter_grade floating point variable from within
  that student_record.

14
Structures as Function Arguments

• We can pass a structure into a function

void print_record(student_record
a) printf(Name s,s s\n, a.last,
a.first, a.middle) printf(Numerical Grade
f\n, a.numerical_grade) printf(Letter
Grade c\n, a.letter_grade)
15
Structures asFunction Arguments

• We could write a function to compare two student
  records (1 if true, 0 else)

int compare_records(student_record a,
student_record b) if (strcmp(a.last,b.last)
0 strcmp(a.middle,b.middle) 0
strcmp(a.first,b.first) 0
a.numerical_grade b.numerical_grade
a.letter_grade b.letter_grade) return
1 else return 0
16
Structure Pointers

• Just like other variables, we can have pointers
  that point to structures. As such, they will
  contain the address of the structure in memory.

student_record TopStudent student_record
best_p best_p TopStudent
17
Structure Pointers

• We can use pointers to structures in the same way
  we can use pointers to other variables

student_record TopStudent student_record best_p
TopStudent strcpy((best_p).last,Six) (be
st_p).numerical_grade 100 printf(Student s
has a grade of f.\n, (best_p).last,(best_p)
.numerical_grade)
18
Structure Pointers
Notice the precedence. The is put in parens
so we evaluate it first. This operator
dereferences the pointer, which gives us a
structure of type student_record. The .
operator has higher precedence than the
operator so it is evaluated next, giving us the
component. Finally, the operator
is evaluated, giving the address that scanf needs.

• We can also use structure pointers to make a
  structure function output parameter

int read_record(student_record record_p) int
result result scanf(s s s f
c, (record_p).last, (record_p).middle, (
record_p).first, (record_p).numerical_grade,
(record_p).letter_grade) if (result 5)
return 1 else return 0
19
Structure Pointers

• The precedence issue can get confusing. As the
  . operator has higher precedence than the
  operator, the pointer name and the dereferencing
  operator must be put in parens if we want to
  access a structure component using a pointer.
• Fortunately, C provides a much cleaner operator
  to remedy this confusing situation.

20
Structure Pointers

• C provides the indirect component selection
  operator -gt. This is a dash followed by a
  greater-than sign, which forms an arrow-like
  operator.
• This new, indirect operator takes a pointer to a
  structure variable on the left side and the
  component name to be accessed on the right side.
• This is a contrast to the direct component
  selection operator . This operator takes a
  structure variable on the left side and the
  component name to be accessed on the right side.

21
Structure Pointers

• Thus, the following expressions are equivalent
• (best_p).last best_p-gtlast
• (best_p).first best_p-gtfirst
• (best_p).letter_grade
• best_p-gtletter_grade
• Note that either form is correct, however, the
  form on the right side is more clear and
  straight-forward.

22
Structure Pointers

• Thus, we can rewrite our function output
  parameter example

int read_record(student_record record_p) int
result result scanf(s s s f
c, record_p-gtlast, record_p-gtmiddle, recor
d_p-gtfirst, record_p-gtnumerical_grade, recor
d_p-gtletter_grade) if (result 5) return 1
else return 0
23
Functions Returning Structures

• Structures can also be used as function return
  types

student_record read_record(void) student_record
input_record result scanf(s s s f
c, input_record.last, input_record.middle,
input_record.first, input_record.numerical_gra
de, input_record.letter_grade) return
input_record
24
Functions Returning Structures

• We would call this function is the same manner as
  a function that returns any other datatype.

student_record record1 record1 read_record()
25
Unions

• A union is very similar to a structure, except
  that where a structure contains all of the
  variables present in their definitions, a union
  contains any one of the variables present in
  their definitions.
• A union is declared as

typedef union int wears_wig char
color20 hair_data
26
Unions
typedef union int wears_wig char
color20 hair_data

• This definition says that a variable of type
  hair_data contains either an integer named
  wears_wig or a 20 character string named color.
• A component of a union is accessed the same way a
  structure component is, using the . operator or
  the -gt operator.

27
Unions

• Note that when a variable is declared that is a
  union type, space is allocated in memory for the
  largest of the component variables.
• If the program accesses the union variable using
  the integer component name, the memory for that
  union variable is treated as a integer. If the
  program accesses the union variable using the
  string component name, the memory for the union
  variable is treated as a string.

28
Unions

• Therefore, once a union variable is used, i.e. it
  is referenced using one of its components, it is
  important to ONLY use that component name to
  reference the union variable in further
  statements.
• If the program first uses the previous union
  using the component wears_wig (an integer), an
  integer will be stored at the memory allocated
  for that union variable.

29
Unions

• If, at a later point, the program references the
  union using the component color (a string), it
  will attempt to find a string at the memory
  allocated for the union variable.
• As we previously put an integer there, this will
  cause an unpredictable result.
• Sofor each union-type variable, use only one
  component. And use only that component for that
  variable throughout the program. Anything else
  will cause errors!

30
Summary

• A structure is a programmer-defined datatype that
  is a record (a collection of variables of varying
  datatypes).
• An individual component of a structure can be
  accessed using a structure variable name and the
  . operator.
• We can make a pointer to a structure in the same
  way we can make a pointer to any other datatype.

31
Summary

• An individual component of a structure can be
  access using a pointer to a structure and the
  -gt operator.
• A union is similar to a structure except that
  containing all of the component variables, it
  contains ONE.
• Once a union-type variable is declared and
  referenced using one of its components, that
  variable can only be referenced using that
  component throughout the program.
