Multi-class SVM

• Jieping Ye
• Department of Computer Science and Engineering
• Arizona State University
• http//www.public.asu.edu/jye02

2
Outline

• Single machine approaches
• Error correcting code approaches
• Tree-structured approaches
• Experiments.

3
Watson Watkins (1998)

• Binary-class Learn one function. Penalize each
  machine separately based on the margin
  violations
• Multi-class Pay a penalty based on the relative
  values output by the machines.

4
Watson Watkins (1998)

• Learn N functions. If a point x is in class i,
  make

(k-1)n
5
Watson Watkins (1998)

• Too many constraints and slack variables (k-1)n
• Not easy to decompose (not scalable)
• Experimental setup is problematic.

6
Crammer Singer (2001)

• Watson Watkins paying each class
  for which
• Crammer Singer Penalize for the largest


7
Crammer Singer (2001)

• Watson Watkins
• Crammer Singer

n(k-1)
n
8
Crammer Singer (2001)

• Fewer slacks (compared to Watson Watkins )
• Can be decomposed (more scalable)
• Many tricks are developed and implemented for
  efficient training
• C and R source codes available
• http//www.cis.upenn.edu/crammer/code/MCSVM/MCSV
  M_1_0.tar.gz
• R (http//www.r-project.org/ ) kernlab package

9
Outline

• Single machine approaches
• Error correcting code approaches
• Tree-structured approaches
• Experiments

10
Error-Correcting Code (ECC) Dietterich Bakiri
(1995)
0 1 0 0 0 0 0 0 0 0
Source Dietterich and Bakiri (1995)
11
(No Transcript)
12
(No Transcript)
13
One-against-rest
14
One-against-one
15
Special cases of ECC
Source http//www-cse.ucsd.edu/users/elkan/254spr
ing01/aldebaro1.pdf
16
Outline

• Single machine approaches
• Error correcting code approaches
• Tree-structured approaches
• Experiments

17
Large Margin Directed Acyclic Graph (DAG)

• Identical to one-against-one at training time
• At test time, DAG is used to determine which
  classifiers to test on a given point
• Classes i and j are compared, whichever class
  achieves lower score is removed from further
  consideration
• Repeat N-1 time, only one class remained.

18
Large Margin DAGs for Multiclass Classification
Source Platt et al. (2000)
19
Margin tree (Tibshirani and Hastie 2006)

• SVM is constructed for each pair of classes to
  compute pair-wise margins
• Agglomerative clustering uses the pair-wise
  margins as distances to construct the
  hierarchical structure bottom up.
• Three approaches Greedy, single linkage, and
  complete linkage.

20
Margin tree
Source Tibshirani and Hastie (2006)
21
Outline

• Single machine approaches
• Error correcting code approaches
• Tree-structured approaches
• Experiments (Compare five ECC approaches).

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Observations

• In nearly all cases, the results of compared
  methods are very close
• In majority of experiments, 0 is in the
  confidence interval, meaning the classifiers are
  not statistically different

27
Implementations in R

• e1071 one-against-one (LIBSVM)
• kernlab one-against-one, Crammer Singer,
  Weston Watkins
• klaR one-against-rest (SVMlight)
• marginTree
• http//www-stat.stanford.edu/tibs/marginTree_1.0
  0.zip
