Title: Internet2 Middleware Activities Progress


1
Internet2 Middleware Activities Progress
2
Acknowledgments
  • MACE and the working groups
  • NSF catalytic grant and meeting
  • Early Adopters
  • Higher Education partners - campuses, EDUCAUSE,
    CREN, AACRAO, SURA, NACUA, etc.
  • Corporate partners - IBM, ATT, Sun, Accord,
    Metamerge, et al.
  • Government partners - including NSF and the fPKI
    TWG

3
Activites
  • Integration
  • MACE RLBobMorgan (Washington)
  • Early Harvest / Early Adopters Renee Frost
    (Michigan)
  • Shibboleth - Steven Carmody (Brown)
  • Vid Mid - Ken Klingenstein (Colorado)
  • VC- Egon Verharen (SURFnet)
  • VoD- Mairead Martin (Tennessee)
  • NSF Middleware Initiative Internet2, EDUCAUSE,
    SURA and The GRIDs Center
  • Medical Middleware - Rob Carter (Duke), Jack
    Buchanan (UT Health Science Ctr)
  • Core
  • MACE- Dir Keith Hazelton(Wisconsin)
  • Groups- Tom Barton (Memphis)
  • Metadirectories - Keith Hazelton (Wisconsin)
  • Directory of Directories for Higher Ed - Michael
    Gettes (Georgetown)
  • EduPerson and EduOrg - Keith Hazelton (Wisconsin)
  • LDAP Recipe - Michael Gettes (Georgetown)
  • HEPKI-TAG and PAG - Jim Jokl (Virginia) and Ken
    Klingenstein (Colorado)
  • HEBCA - Mark Luker (EDUCAUSE)
  • PKI Labs - Dartmouth and Wisconsin

4
MACE (Middleware Architecture Committee for
Education)
  • Purpose - to provide advice, create experiments,
    foster standards, etc. on key technical issues
    for core middleware within higher education
  • Creates working groups in major areas, including
    directories, interrealm authentication, PKI,
    medical issues, etc.
  • Works via conference calls, emails, occasional
    serendipitous in-person meetings...
  • US Members
  • Bob Morgan (UW) Chair Scott Cantor (Ohio State)
    Steven Carmody (Brown)
  • Keith Hazelton (Wisconsin) Paul Hill (MIT)
    Michael Gettes (Georgetown)
  • Jim Jokl (Virginia) Mark Poepping (CMU) Bruce
    Vincent (Stanford)
  • David Wasley (California) Von Welch (Grid)
  • European members
  • Brian Gilmore (Edinburgh) Ton Verschuren
    (Netherlands)

5
National Science Foundation
  • Catalytic grant in Fall 99 started the organized
    efforts, with Early Harvest and Early Adopters
  • NSF Middleware Initiative - three year
    cooperative agreement, begun 9/1/01, with
    Internet2/EDUCAUSE/SURA and the GRIDs Center, to
    develop and deploy a national middleware
    infrastructure for science, research and higher
    education
  • Work products are community standards, best
    practices, schema and object classes, reference
    implementations, open source services, corporate
    relations
  • Work areas are identifiers, directories,
    authentication, authorization, GRIDs, PKI, video

6
Early Harvest
  • NSF funded workshop in Fall 99 and subsequent
    activities
  • Defined the territory and established a work plan
  • Best practices in identifiers, authentication,
    and directories (http//middleware.internet2.edu/i
    nternet2-mi-best-practices-00.html)
  • http//middleware.internet2.edu/earlyharvest/

7
Early Adopters The Campus Testbed Phase
  • A variety of roles and missions
  • Commitment to move implementation forward
  • Provided some training and facilitated support
  • Develop national models of deployment
    alternatives
  • Address policy standards
  • Profiles and plans are on Internet2 middleware
    site
  • http//middleware.internet2.edu/earlyadopters
    /
  • Participants Dartmouth, Hawaii, Johns Hopkins,
    Maryland-Baltimore County, Memphis, Michigan
    Tech, Michigan, Pittsburgh, Tennessee Health
    Science Center, Tufts, USC

8
What is Middleware?
  • specialized networked services that are shared by
    applications and users
  • a set of core software components that permit
    scaling of applications and networks
  • tools that take the complexity out of application
    integration
  • a second layer of the IT infrastructure, sitting
    above the network
  • a land where technology meets policy
  • the intersection of what networks designers and
    applications developers each do not want to do

9
A Map of Middleware
10
Core Middleware
  • Identity - unique markers of who you (person,
    machine, service, group) are
  • Authentication - how you prove or establish that
    you are that identity
  • Directories - where an identitys basic
    characteristics are kept
  • Authorization - what an identity is permitted to
    do
  • PKI - emerging tools for security services

11
The Major Projects
  • eduPerson and eduOrg (mace-dir)
  • the Directory of Directories for Higher Education
    (DoDHE)
  • Shibboleth (mace-shibboleth) and Webiso
    (mace-webiso)
  • Directories
  • metadirectories
  • groups
  • affiliated directories
  • HEBCA and PKI-Light (HEPKI-PAG and HEPKI-TAG)
  • PKI Labs at Dartmouth and Wisconsin
  • Videoconferencing and video on demand (vidmid)
  • OKI, JA-SIG and the Grids

12
eduPerson
  • A directory objectclass intended to support
    inter-institutional applications
  • Fills gaps in traditional directory schema
  • For existing attributes, states good practices
    where known
  • Specifies several new attributes and controlled
    vocabulary to use as values.
  • Provides suggestions on how to assign values, but
    it is up to the institution to choose.
  • Version 1.0 now done one or two revisions
    anticipated

13
eduPerson 1.0
  • parent objectclassinetOrgPerson
  • includes
  • affiliation (multi-valued)
  • primary affiliation (faculty/student/staff)
  • orgUnitDN (string)
  • nickname (string)
  • ePPN (identifier, user_at_securitydomain)
  • version 1.5 and beyond will contain other shared
    attributes

14
A Directory of Directories
  • an experiment to build a combined directory
    search service
  • to show the power of coordination
  • will highlight the inconsistencies between
    institutions
  • technical investigation of load and scaling
    issues, centralized and decentralized approaches
  • human interface issues - searching large name
    spaces with limits by substring, location,
    affiliation, etc...
  • to suggest the service to follow
  • Sun donation of server and 6 million DNs
  • http//dodhe.internet2.edu/dodhe/

15
Shibboleth
  • A word which was made the criterion by which to
    distinguish the Ephraimites from the Gileadites.
    The Ephraimites, not being able to pronounce sh,
    called the word sibboleth. See --Judges xii.
  • Hence, the criterion, test, or watchword of a
    party a party cry or pet phrase.
  • - Webster's Revised Unabridged Dictionary
    (1913)

16
Shibboleth
  • inter-institutional web authentication and basic
    authorization
  • authenticate locally, act globally - the
    Shibboleth shibboleth
  • emphasizes privacy through progressive disclosure
    of attributes
  • linked to commercial standards development in XML
    through OASIS
  • scenarios and architecture done coding has
    commenced with alpha code due in January, 2002 to
    pilot sites
  • coding and design teams feature IBM/Tivoli, CMU,
    and the Ohio State University
  • strong partnership with IBM to develop and deploy
  • http//middleware.internet2.edu/shibboleth/

17
Stage 1 - Addressing Three Scenarios
  • Member of campus community accessing licensed
    resource
  • Anonymity required
  • Member of a course accessing remotely controlled
    resource
  • Anonymity required
  • Member of a workgroup accessing controlled
    resources
  • Controlled by unique identifiers (e.g. name)
  • Taken individually, each of these situations can
    be solved in a variety of straightforward ways.
  • Taken together, they present the challenge of
    meeting the user's reasonable expectations for
    protection of their personal privacy.

18
Shibboleth ArchitectureConcepts - High Level
Browser
Pass content if user is allowed
Target Web Server
Authorization Phase
Authentication Phase
First Access - Unauthenticated
Target Site
Origin Site
19
Shibboleth, eduPerson, and everything else
Middleware Inputs Outputs
Licensed Resources
Embedded App Security
Grids
JA-SIG uPortal
OKI
Inter-realm calendaring
futures
Shibboleth, eduPerson, Affiliated Dirs, etc.
Enterprise authZ
Enterprise Directory
Enterprise Authentication
Legacy Systems
Campus web SSO
20
Project Status
  • Architecture definition finished (v0.9)
  • Design/Programming now Underway
  • Team membership drawn from IBM/Tivoli, CMU, Ohio
    State
  • First Face-to-Face meeting on Sept 27, 28 at CMU
  • First Set of Pilot Sites Selected
  • Chosen to test all 3 scenarios
  • UK participation
  • Timeline for programming
  • Stage I alpha code Feb 2002
  • Stage II beta code June 2002
  • Stage III release summer 2002

21
A Campus Directory Architecture
Border directory
Metadirectory
Enterprise directory
OS directories (MS, Novell, etc)
Departmental directories
Dir DB
Registries
Source systems
22
Metadirectories
  • The critical functions to glue together what
    inevitably turns out to be a number of campus,
    departmental and application-oriented directory
    services
  • Typically a coordinated set of services that
    watches updates to specific directories or from
    legacy data feeds and spreads those updates to
    other directories
  • Performs several subfunctions
  • an identity registry or crosswalk to relate
    entries in different directories
  • a set of connectors that take changes from one
    source and convert them for dissemination to
    other sources
  • Basic implementation from Metamerge is free to
    higher ed

23
Directories Group Management
  • Best practices in the use of core middleware to
    meet the authorization and messaging needs of
    applications
  • Initial foci are
  • the conduct of a survey of several organizations'
    practices in this area and
  • investigations into meaningful definitions of,
    and productive ways of representing and operating
    on, "groups", "affiliations", "roles", and
    "correlations".
  • Groups Practices Survey
  • http//middleware.internet2.edu/dir/groups/

24
PKI A few observations
  • Think of it as wall jack connectivity, except
    its connectivity for individuals, not for
    machines, and theres no wall or jackbut it is
    that ubiquitous and important
  • Does it need to be a single infrastructure? What
    are the costs of multiple solutions? Subnets and
    ITPs...
  • Options breed complexity managing complexity is
    essential
  • PKI can do so much that right now it does very
    little

25
A few more...
  • IP connectivity was a field of dreams. We built
    it and then the applications came. Unfortunately,
    here the applications have arrived before the
    infrastructure, making its development much
    harder.
  • No one seems to be working on the solutions for
    the agora.
  • A general-purpose PKI seems like a difficult
    task, but instituting a PKI Light as a first step
    may not have enough paybacks.

26
The general state of PKI
  • There are campus and corporate successes
  • Corporations use internally for VPN, some
    authentication, signed email (with homogeneous
    client base)
  • MIT, UT medical, soon VA, UCOP
  • Key is limited application use, lightweight
    policy approaches
  • There is very limited interrealm, community of
    interest or general interoperable work going on
  • Federal efforts
  • HealthKey
  • Higher Ed
  • Some European niches

27
The Four Planes of PKI
  • on the road to general purpose interrealm PKI
  • the planes represent different levels of
    simplification from the dream of a full
    interrealm, intercommunity multipurpose PKI
  • simplifications in policies, technologies,
    applications, scope
  • each plane provides experience and value

28
The Four Planes are
  • Full interrealm PKI - multipurpose, spanning
    broad and multiple communities, bridges to unite
    hierarchies, unfathomed directory issues
  • Simple interrealm PKI - multipurpose within a
    community, operating under standard policies and
    structured hierarchical directory services
  • PKI-Light - containing all the key components of
    a PKI, but many in simplified form may be for a
    limited set of applications may be extended
    within selected communities
  • PKI-Ultralight - easiest to construct and useful
    conveyance ignores parts of PKI and not for use
    external to the institution learn how to fly,
    but not a plane...

29
D. Wasleys PKI Puzzle
30
Uses for PKI and Certificates
  • authentication and pseudo-authentication
  • signing docs
  • encrypting docs and mail
  • non-repudiation
  • secure channels across a network
  • authorization and attributes
  • secure multicast
  • and more...

31
PKI Components
  • X.509 v3 certs - profiles and uses
  • Validation - Certificate Revocation Lists, OCSP,
    path construction
  • Cert management - generating certs, using keys,
    archiving and escrow, mobility, etc.
  • Directories - to store certs, and public keys and
    maybe private keys
  • Trust models and I/A
  • Cert-enabled apps

32
Directories
  • to store certs
  • to store CRL
  • to store private keys, for the time being
  • to store attributes
  • implement with border directories, or ACLs within
    the enterprise directory, or proprietary
    directories

33
Certificate Policies (CP) and Practices
Statements (CPS)
  • Policies legal responsibilities and liabilities
    (indemnification issues)
  • Operations of certificate management systems
  • Will hopefully be somewhat uniform across the
    community
  • Assurance levels - varies according to I/A
    processes and other operational factors
  • Practices - site-specific details of operational
    compliance with a cert policy
  • A Policy Management Authority (PMA) determines if
    a CPS is adequate for a given CP.

34
Inter-organizational trust model components
  • verifying sender-receiver assurance by finding a
    common trusted entity
  • must traverse perhaps branching paths to
    establish trust paths
  • must then use CRLs etc. to validate assurance
  • if policies are in cert payloads, then validation
    can be quite complex
  • delegation makes things even harder
  • Hierarchies vs. Bridges
  • a philosophy and an implementation issue
  • the concerns are transitivity and delegation
  • hierarchies assert a common trust model
  • bridges pairwise agree on trust models and policy
    mappings

35
VidMid
  • Middleware for video
  • Videoconferencing
  • authenticated, identified video clients - work
    with commercial clients to use the underlying
    middleware plumbing
  • H.323, VRVS, and new SIP-oriented clients
  • Video on demand
  • access controls for video resources
  • schema for meta information
  • Works closely with ViDe (www.vide.org)
  • http//middleware.internet2.edu/video/
  • aggressive time frames

36
Mace-Med
  • Unique requirements - HIPAA, disparate
    relationships, extended community, etc.
  • Unique demands - 7x24, visibility
  • PKI seen as a key tool
  • Mace-Med recently formed to explore the issues

37
HEPKI (www.educause.edu/hepki/)
  • HEPKI - Technical Activities Group (TAG)
  • universities actively working technical issues
  • topics include Kerberos-PKI integration, public
    domain CA, profiles
  • regular conference calls, email archives
  • HEPKI - Policy Activities Group (PAG)
  • universities actively trying to deploy PKI
  • topics include certificate policies, RFP sharing,
    interactions with state governments
  • regular conference calls, email archives

38
Internet2 PKI Labs
  • At Dartmouth and Wisconsin in computer science
    departments and IT organizations
  • Doing the deep research - two to five years out
  • Policy languages, path construction, attribute
    certificates, etc.
  • National Advisory Board of leading academic and
    corporate PKI experts provides direction
  • Catalyzed by startup funding from ATT

39
OKI, JA-SIG and Grids
  • OKI
  • major open learning management system being
    developed by MIT, Stanford, and North Carolina
    State, funded by the Mellon Foundation reference
    architecture and open source implementation
  • http//web.mit.edu/oki/intro.html
  • JA-SIG
  • uPortal is a major portal architecture and
    implementation being developed by a number of
    schools with funding from the Mellon Foundation
    also hopes to share administrative Java applets
  • http//www.ja-sig.org/ and http//mis105.mis.udel
    .edu/ja-sig/uportal/index.html
  • GRIDS Center
  • expanding use of Grids will reach to many
    campuses
  • integration efforts underway
  • http//www.globus.org and http//www.gridforum.org

40
NSF Middleware Initiative (NMI)
  • NSF award for integrators to
  • Internet2, EDUCAUSE, and SURA
  • The GRIDs Center (NCSA, UCSD, University of
    Chicago, USC/ ISI, and University of Wisconsin)
  • Build on the successes of the Internet2/MACE
    initiative and the Globus Project
  • Three year cooperative agreement effective 9/1/01
  • To develop and deploy a national middleware
    infrastructure for science, research and higher
    education
  • Separate awards to academic pure research
    components

41
The Grid
  • a model for a distributed computing environment,
    addressing diverse computational resources,
    distributed databases, network bandwidth, object
    brokering, security, etc.
  • Globus (www.globus.org) is the software that
    implements most of these components Legion is
    another such software environment
  • Needs to integrate with campus infrastructure
  • Gridforum (www.gridforum.org) umbrella activity
    of agencies and academics
  • Look for grids to occur locally and nationally,
    in physics, earthquake engineering, etc.

42
NMI The Problem to Solve
  • To allow scientists and engineers the ability to
    transparently use and share distributed
    resources, such as computers, data, and
    instruments
  • To develop effective collaboration and
    communications tools such as Grid technologies,
    desktop video, and other advanced services to
    expedite research and education
  • To develop a working architecture and approach
    which can be extended to Internet users around
    the world
  • Middleware is the stuff that makes transparently
    use happen, providing consistency, security,
    privacy and capability

43
NMI
  • Work areas
  • Identifiers
  • Directories
  • Authentication
  • Authorization
  • GRIDs
  • PKI
  • Video
  • Work products
  • Community standards
  • Best practices
  • Schema and object classes
  • Reference implementations
  • Open source services
  • Corporate relations

44
More information
  • Early Harvest / Early Adopters
    http//middleware.internet2.edu/earlyadopters/
  • Mace middleware.internet2.edu
  • LDAP Recipe http//www.georgetown.edu/giia/inter
    net2/ldap- recipe/
  • EduPerson www.educause.edu/eduperson
  • Directory of Directories middleware.internet2.e
    du/dodhe
  • Shibboleth middleware.internet2.edu/shibboleth
  • HEPKI-TAG www.educause.edu/hepki
  • HEPKI-PAG www.educause.edu/hepki
  • Video http//middleware.internet2.edu/video/
Write a Comment
User Comments (0)
About PowerShow.com
