Title: CS455 Introduction to Computer Networks


1
CS455 Introduction to Computer Networks
WSU Vancouver
  • Dr. Wenzhan Song
  • Assistant Professor, Computer Science

2
Course roadmap
  • Introduction
  • Application Layer WWW, FTP, email, DNS,
    multimedia
  • Transport Layer reliable end-end data transfer
    principles, UDP, TCP
  • Network Layer IP addressing, routing and other
    issues
  • Data Link Layer framing, error control, flow
    control
  • Medium Access Control (MAC) Layer
    multiple-access, channel allocation
  • Physical Layer wired, wireless, satellite
  • Other Topics network security, social issues,
    hot topics, research directions

3
Roadmap Network Layer
  • Network layer design issues
  • overview of service models
  • Virtual circuits and datagram networks
  • IP Internet Protocol
  • datagram format, IPv4 addressing
  • NAT, IPv6
  • ICMP, ARP, DHCP
  • Routing algorithms
  • distance vector
  • link state
  • Routing Protocol in Internet
  • RIP
  • OSPF
  • BGP
  • Other issues in network layer

4
Network Layer
  • Goals
  • understand principles behind network layer
    services
  • routing (path selection)
  • dealing with scale
  • how a router works
  • instantiation and implementation in the Internet
  • IPv4, IPv6, mobility
  • routing and control protocols

5
Overview of network layer
  • transport segment from sending to receiving host
  • sending side encapsulates segments into datagrams
  • rcving side delivers segments to transport layer
  • network layer protocols in every host, router
  • Router examines header fields in all IP datagrams
    passing through it

6
Overview of network layer
Two processes in router Forwarding forward
packets according to routing table Routing
change and fill routing table according to
routing algorithms
7
Network service model
Q What service model for channel transporting
datagrams from sender to rcvr?
  • Example services for a flow of datagrams
  • In-order datagram delivery
  • Guaranteed minimum bandwidth to flow
  • Restrictions on changes in inter-packet spacing
  • Example services for individual datagrams
  • Guaranteed delivery
  • Guaranteed delivery with less than 40 msec delay

8
Network layer service models
Guarantees ?
Network Architecture Internet ATM ATM ATM ATM
Service Model best effort CBR VBR ABR UBR
Congestion feedback no (inferred via
loss) no congestion no congestion yes no
No Loss no yes yes no no
Bandwidth none constant rate guaranteed rate gua
ranteed minimum none
Order no yes yes yes yes
Timing no yes yes no no
CBR, Constant bit rate ABR, Available bit
rate VBR, Variable bit rate UBR, unspecified
bit rate
9
Datagram network vs VC network
  • Datagram network (e.g., Internet) provides
    network-layer connectionless service
  • VC network (e.g., ATM) provides network-layer
    connection-oriented service
  • Analogous to the transport-layer services, but
  • Service host-to-host
  • Implementation in the core
  • Both of them are packet-switched networks

10
Virtual circuits
  • source-to-dest path behaves much like telephone
    circuit
  • performance-wise
  • network actions along source-to-dest path
  • call setup, teardown for each call before data
    can flow
  • each packet carries VC identifier (not
    destination host address)
  • every router on source-dest path maintains
    state for each passing connection
  • link, router resources (bandwidth, buffers) may
    be allocated to VC

11
VC implementation
  • A VC consists of
  • Path from source to destination
  • VC numbers, one number for each link along path
  • Entries in forwarding tables in routers along
    path
  • Packet belonging to VC carries a VC number.
  • VC number must be changed on each link.
  • New VC number comes from forwarding table

12
Forwarding table in VC network
VC number
B
R1
R2
A
22
32
12
2
1
3
Forwarding table in Router R1
R4
R3
interface number
Routers maintain connection state information!
13
Virtual circuits signaling protocols
  • used to setup, maintain teardown VC
  • used in ATM, frame-relay, X.25
  • not used in todays Internet

6. Receive data
5. Data flow begins
4. Call connected
3. Accept call
1. Initiate call
2. incoming call
14
Datagram networks
  • no call setup at network layer
  • routers no state about end-to-end connections
  • no network-level concept of connection
  • packets forwarded using destination host address
  • packets between same source-dest pair may take
    different paths

1. Send data
2. Receive data
15
Router Architecture
  • Two key router functions
  • run routing algorithms/protocol (RIP, OSPF, BGP)
  • forwarding datagrams from incoming to outgoing
    link

223.1.1.4
223.1.3.27
223.1.2.9
223.1.4.5
Each router may have multiple interfaces (or
ports) and each interface typically has different
IP address.
16
Routing table
4 billion possible entries
Destination Address Range
Link
Interface 11001000 00010111 00010000
00000000
through
0 11001000
00010111 00010111 11111111 11001000
00010111 00011000 00000000
through
1
11001000 00010111 00011000 11111111
11001000 00010111 00011001 00000000
through

2 11001000 00010111 00011111 11111111
otherwise

3
17
Longest prefix matching
Prefix Match
Link Interface
11001000 00010111 00010
0 11001000 00010111
00011000 1
11001000 00010111 00011
2
otherwise
3
Examples
Which interface?
DA 11001000 00010111 00010110 10100001
Which interface?
DA 11001000 00010111 00011000 10101010
18
Datagram or VC network why?
  • Internet
  • data exchange among computers
  • elastic service, no strict timing req.
  • smart end systems (computers)
  • can adapt, perform control, error recovery
  • simple inside network, complexity at edge
  • many link types
  • different characteristics
  • uniform service difficult
  • ATM
  • evolved from telephony
  • human conversation
  • strict timing, reliability requirements
  • need for guaranteed service
  • dumb end systems
  • telephones
  • complexity inside network

19
Design Principles for Internet
  • Make sure it works.
  • Keep it simple.
  • Make clear choices.
  • Exploit modularity.
  • Expect heterogeneity.
  • Avoid static options and parameters.
  • Look for a good design it need not be perfect.
  • Be strict when sending and tolerant when
    receiving.
  • Think about scalability.
  • Consider performance and cost.

20
Comparison
5-4
21
Roadmap Network Layer
  • Network layer design issues
  • overview of service models
  • Virtual circuits and datagram networks
  • IP Internet Protocol
  • datagram format, IPv4 addressing
  • NAT, IPv6
  • ICMP, ARP, DHCP
  • Routing algorithms
  • distance vector
  • link state
  • Routing Protocol in Internet
  • RIP
  • OSPF
  • BGP
  • Other issues in network layer

22
The Internet Network layer
  • Host, router network layer functions

Transport layer TCP, UDP
Network layer
Link layer
physical layer
23
IP datagram format
IP protocol version number
32 bits
total datagram length (bytes)
header length (bytes)
type of service
head. len
ver
total length
for fragmentation/ reassembly
fragment offset
type of data (e.g., file, voice)
flgs
16-bit identifier
max number remaining hops (decremented at each
router)
upper layer
time to live
header checksum
32 bit source IP address
32 bit destination IP address
upper layer protocol (e.g., TCP/UDP) to deliver
payload to
E.g. timestamp, record route taken, specify list
of routers to visit.
Options (if any)
  • how much overhead with TCP?
  • 20 bytes of TCP
  • 20 bytes of IP
  • 40 bytes app layer overhead

data (variable length, typically a TCP or UDP
segment)
24
IP Fragmentation Reassembly
  • network links have MTU (max.transfer size) -
    largest possible link-level frame.
  • different link types, different MTUs
  • large IP datagram divided (fragmented) within
    net
  • one datagram becomes several datagrams
  • reassembled only at final destination
  • IP header bits used to identify, order related
    fragments

fragmentation in one large datagram out 3
smaller datagrams
reassembly
25
IP Fragmentation and Reassembly
  • Example
  • 4000 byte datagram
  • MTU 1500 bytes

1480 bytes in data field
offset 1480/8
How to get 1040 as length of last segment? Show
calculation.
26
IP Addressing introduction
223.1.1.1
  • IP address 32-bit identifier for host, router
    interface
  • interface connection between host/router and
    physical link
  • routers typically have multiple interfaces
  • host may have multiple interfaces
  • IP addresses associated with each interface
  • Classful addressing and CIDR addressing

223.1.2.9
223.1.1.4
223.1.1.3
223.1.1.1 11011111 00000001 00000001 00000001
223
1
1
1
27
Classful addressing
  • A 128 networks with 16 million host each
  • B 16,384 networks with 64K hosts each
  • C 2 million networks with with 256 hosts each
  • Classful addressing method is not used by todays
    Internet anymore,
  • since it is not flexible and may waste many IP
    addresses
  • ? CIDR(Classless InterDomain Routing)

28
Subnets
  • A campus network consisting of subnets for
    various departments.

29
Subnets
?-------------- 22 -----------------------?
  • A class B network subnetted into 64 subnets,
    subnet mask /22

30
Subnets
223.1.1.1
  • IP address
  • subnet part (including all high order bits)
  • host part (low order bits)
  • Whats a subnet?
  • device interfaces with same subnet part of IP
    address
  • can physically reach each other without
    intervening router

223.1.2.1
223.1.1.2
223.1.2.9
223.1.1.4
223.1.2.2
223.1.1.3
223.1.3.27
LAN
223.1.3.2
223.1.3.1
network consisting of 3 subnets
31
Subnets
  • Recipe
  • To determine the subnets, detach each interface
    from its host or router, creating islands of
    isolated networks. Each isolated network is
    called a subnet.

Subnet mask /24
32
Subnets
223.1.1.2
  • How many?

223.1.1.1
223.1.1.4
223.1.1.3
223.1.7.0
223.1.9.2
223.1.9.1
223.1.7.1
223.1.8.0
223.1.8.1
223.1.2.6
223.1.3.27
223.1.2.2
223.1.2.1
223.1.3.2
223.1.3.1
33
Subnets
223.1.1.1
223.1.2.1
223.1.1.2
223.1.2.9
223.1.1.4
223.1.2.2
223.1.1.3
223.1.3.27
LAN
223.1.3.2
223.1.3.1
network consisting of 3 subnets
Subnet mask /24
34
IP addressing CIDR
  • CIDR Classless InterDomain Routing
  • To allocate the remaining IP addresses in
    variable-sized blocks, without regard to the
    classes
  • subnet portion of address of arbitrary length
  • address format a.b.c.d/x, where x is bits in
    subnet portion of address

host part
subnet part
11001000 00010111 00010000 00000000
200.23.16.0/23
35
CIDR Examples
5-59
  • A set of IP address assignments.

36
IP addresses how to get one?
  • Q How does host get IP address?
  • hard-coded by system admin in a file
  • Wintel control-panel-gtnetwork-gtconfiguration-gttcp
    /ip-gtproperties
  • UNIX /etc/rc.config
  • DHCP Dynamic Host Configuration Protocol
    dynamically get address from as server
  • plug-and-play

37
IP addresses how to get one?
  • Q How does network get subnet part of IP addr?
  • A gets allocated portion of its provider ISPs
    address space

ISP's block 11001000 00010111 00010000
00000000 200.23.16.0/20 Organization 0
11001000 00010111 00010000 00000000
200.23.16.0/23 Organization 1 11001000
00010111 00010010 00000000 200.23.18.0/23
Organization 2 11001000 00010111 00010100
00000000 200.23.20.0/23 ...
..
. . Organization 7
11001000 00010111 00011110 00000000
200.23.30.0/23
38
Hierarchical addressing route aggregation
Hierarchical addressing allows efficient
advertisement of routing information
Organization 0
Organization 1
Send me anything with addresses beginning
200.23.16.0/20
Organization 2
ISP-1
Internet
Organization 7
Send me anything with addresses beginning
199.31.0.0/16
ISP-2
39
Hierarchical addressing more specific routes
Later, ISP1 acquires ISP2, and asks Organization
1 to connect with ISP2. Hence ISP2 need a more
specific route to Organization 1
Organization 0
Send me anything with addresses beginning
200.23.16.0/20
Organization 2
ISP-1
Internet
Organization 7
Send me anything with addresses beginning
199.31.0.0/16 or 200.23.18.0/23
ISP-2
Organization 1
Recall longest prefix routing
40
IP addressing the last word...
  • Q How does an ISP get block of addresses?
  • A ICANN Internet Corporation for Assigned
  • Names and Numbers
  • allocates addresses
  • manages DNS root servers
  • assigns domain names, resolves disputes
  • Special IP address

41
NAT Network Address Translation
rest of Internet
local network (e.g., home network) 10.0.0/24
10.0.0.1
10.0.0.4
10.0.0.2
138.76.29.7
10.0.0.3
All datagrams leaving local network have same
single source NAT IP address 138.76.29.7, differe
nt source port numbers
Datagrams with source or destination in this
network have 10.0.0/24 address for source,
destination (as usual)
Three reserved IP range for local network only
10.0.0.0 10.255.255.255/8 (16,777,216
hosts)172.16.0.0 -172.31.255.255/12(1,048,576
hosts)192.168.0.0 192.168.255.255/16(65,536
hosts)
42
NAT Network Address Translation
  • Motivation local network uses just one IP
    address as far as outside word is concerned
  • no need to be allocated range of addresses from
    ISP - just one IP address is used for all
    devices
  • can change addresses of devices in local network
    without notifying outside world
  • can change ISP without changing addresses of
    devices in local network
  • devices inside local net not explicitly
    addressable, visible by outside world (a security
    plus).

43
NAT Network Address Translation
  • Implementation NAT router must
  • outgoing datagrams replace (source IP address,
    port ) of every outgoing datagram to (NAT IP
    address, new port )
  • . . . remote clients/servers will respond using
    (NAT IP address, new port ) as destination
    addr.
  • remember (in NAT translation table) every (source
    IP address, port ) to (NAT IP address, new port
    ) translation pair
  • incoming datagrams replace (NAT IP address, new
    port ) in dest fields of every incoming datagram
    with corresponding (source IP address, port )
    stored in NAT table

44
NAT Network Address Translation
NAT translation table WAN side addr LAN
side addr
138.76.29.7, 5001 10.0.0.1, 3345

10.0.0.1
10.0.0.4
10.0.0.2
138.76.29.7
10.0.0.3
4 NAT router changes datagram dest addr
from 138.76.29.7, 5001 to 10.0.0.1, 3345
3 Reply arrives dest. address 138.76.29.7,
5001
45
NAT Network Address Translation
  • 16-bit port-number field
  • 60,000 simultaneous connections with a single
    LAN-side address!
  • NAT is controversial
  • routers should only process up to layer 3
  • violates end-to-end argument
  • NAT possibility must be taken into account by app
    designers, eg, P2P applications
  • address shortage should instead be solved by IPv6

46
IPv6
  • Initial motivation 32-bit address space soon to
    be completely allocated.
  • 16 byte(or 128 bits) addresses. E.g.,
    80000000000000000123456789ABCDEF
  • IPv4 address 192.31.20.46 can be written as
    192.31.20.46
  • Additional motivation
  • header format helps speed processing/forwarding
  • header changes to facilitate QoS
  • IPv6 datagram format
  • fixed-length 40 byte header
  • no fragmentation allowed

47
IPv6 Header (Cont)
Priority identify priority among datagrams in
flow Flow Label identify datagrams in same
flow. (concept offlow
not well defined). Next header identify upper
layer protocol for data
48
Other Changes from IPv4
  • Checksum removed entirely to reduce processing
    time at each hop
  • Options allowed, but outside of header,
    indicated by Next Header field
  • ICMPv6 new version of ICMP
  • additional message types, e.g. Packet Too Big
  • multicast group management functions

49
Transition From IPv4 To IPv6
  • Not all routers can be upgraded simultaneous
  • no flag days
  • How will the network operate with mixed IPv4 and
    IPv6 routers?
  • Tunneling IPv6 carried as payload in IPv4
    datagram among IPv4 routers

50
Tunneling
51
Tunneling (2)
  • Tunneling a car from France to England.

52
ICMP Internet Control Message Protocol
  • used by hosts routers to communicate
    network-level information
  • error reporting unreachable host, network, port,
    protocol
  • echo request/reply (used by ping)
  • network-layer above IP
  • ICMP msgs carried in IP datagrams
  • ICMP message type, code plus first 8 bytes of IP
    datagram causing error

Type Code description 0 0 echo
reply (ping) 3 0 dest. network
unreachable 3 1 dest host
unreachable 3 2 dest protocol
unreachable 3 3 dest port
unreachable 3 6 dest network
unknown 3 7 dest host unknown 4
0 source quench (congestion
control - not used) 8 0
echo request (ping) 9 0 route
advertisement 10 0 router
discovery 11 0 TTL expired 12 0
bad IP header
53
ARP Address Resolution Protocol
  • Find out which Ethernet address corresponds to a
    given IP address

54
ARP Address Resolution Protocol
  • Each IP node (Host, Router) on LAN has ARP table
  • ARP Table IP/MAC address mappings for some LAN
    nodes
  • lt IP address MAC address TTLgt
  • TTL (Time To Live) time after which address
    mapping will be forgotten (typically 20 min)

237.196.7.78
1A-2F-BB-76-09-AD
237.196.7.23
237.196.7.14
LAN
71-65-F7-2B-08-53
58-23-D7-FA-20-B0
0C-C4-11-6F-E3-98
237.196.7.88
55
ARP protocol Same LAN (network)
  • A wants to send datagram to B, and Bs MAC
    address not in As ARP table.
  • A broadcasts ARP query packet, containing B's IP
    address
  • Dest MAC address FF-FF-FF-FF-FF-FF
  • all machines on LAN receive ARP query
  • B receives ARP packet, replies to A with its
    (B's) MAC address
  • frame sent to As MAC address (unicast)
  • A caches (saves) IP-to-MAC address pair in its
    ARP table until information becomes old (times
    out)
  • soft state information that times out (goes
    away) unless refreshed
  • ARP is plug-and-play
  • nodes create their ARP tables without
    intervention from net administrator

56
Routing to Another LAN
  • walkthrough send datagram from A to B via R
  • assume A knows B IP address
  • Two ARP tables in router R, one for each IP
    network (LAN)
  • In routing table at source Host, find router
    111.111.111.110
  • In ARP table at source, find MAC address
    E6-E9-00-17-BB-4B, etc

A
R
B
57
Routing to Another LAN
  • A creates datagram with source A, destination B
  • A uses ARP to get Rs MAC address for
    111.111.111.110
  • A creates link-layer frame with R's MAC address
    as dest, frame contains A-to-B IP datagram
  • As adapter sends frame
  • Rs adapter receives frame
  • R removes IP datagram from Ethernet frame, sees
    its destined to B
  • R uses ARP to get Bs MAC address
  • R creates frame containing A-to-B IP datagram
    sends to B

A
B
R
58
DHCP Dynamic Host Configuration Protocol
send through a UDP packet to port 67
  • Find out which IP address corresponds to a given
    Ethernet address
  • First solution RARP (Reverse Address Resolution
    Protocol)
  • Limited broadcast, which can not be forwarded by
    router. While RARP server might not be in same
    LAN
  • New solution BOOTP manual configuration ?
    extend to ? DHCP dynamic configuration
  • Based on UDP, hence it can be forwarded by router
Write a Comment
User Comments (0)
About PowerShow.com
