Hardware

1
Hardware flow control

• How we can activate our NICs ability to avoid
  overwhelming the capacities of its link partner

2
Our txburst.c demo

• This module is intended to let us explore a
  problem that can arise in using our nic.c
  character-mode device-driver
• It lets the user trigger the transmission of
  multiple ethernet-packets in a single burst
• When using the cat command, our nic.c
  device-driver cannot seem to keep up with the
  amount of arriving packet-data

3
In-class demonstration

• Install nic.ko on one of our anchor-cluster
  machines and execute the cat command
• cat /dev/nic
• Compile our txburst.c module and install it on
  another of the anchor-cluster stations, then
  execute the following cat command
• cat /proc/txburst

Timeout for this classroom demonstration
4
Some packets got lost

• The burst of packets being transmitted are
  arriving too rapidly for our device-driver to
  service all of them hence lost packets!
• Modern ethernet controllers (like 82573L) offer a
  convenient way for the hardware to assist a
  device-driver in overcoming this
  data-congestion problem
• Its an IEEE 802.3 flow control standard

5
How it works
An Overview of the IEEE 802.3 Flow Control
Sequence
Courtesy of Cisco Systems Documentation online
6
Format a of PAUSE frame
the standard pause opcode
a special reserved multicast-address
a special reserved frame Type
01 80 C2 00 00 01
source MAC-address
88 08
00 01
delay-time
00 00 00 00 00 00 00 00 00 00 00 00
00 00
00 00 00 00 00 00 00 00 00 00 00 00
00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00
frame checksum
the desired maximum duration of the pause
(expressed in 512 bit-times)
7
Automatic XOFF/XON

• In principle it would be possible for the
  device-driver programmer to include code that
  would transmit a PAUSE frame
• But its much simpler to just delegate that
  functionality to the network hardware and avoid
  consuming CPU-time setting it up
• The 82573L makes it easy for a driver to turn
  on the flow control mechanism

8
The Flow Control registers

enum E1000_FCAL 0x0028, // Flow Control
Address Low E1000_FCAH 0x002C, // Flow Control
Address High E1000_FCT 0x0030, // Flow Control
frame Type E1000_FCTTV 0x0170, // Flow
Control Tx Timer Value E1000_FCRTL 0x2160, //
Flow Control Rx Threshold Low E1000_FCRTH
0x2168, // Flow Control Rx Threshold High
9
Packet Buffer Allocation
000C 0014
the default allocation 20-KB for TX
12-KB for RX
PBA
32-KB FIFO
Receive FIFO
Transmit FIFO
when space consumed in the Rx FIFO reaches the
high-water mark, the NIC transmits an XOFF frame
to PAUSE any further reception until some data
drains from the FIFO enough that the space
consumed drops beneath the low-water, at which
time the NIC transmits an XON frame to request
its Link-Partner to RESUME sending packets
FCRXH
FCRXL
10
Programming details
setting up the 82573L Flow Control
registers iowrite32( 0x00C28001, io
E1000_FCAL ) iowrite32( 0x00000100, io
E1000_FCAH ) iowrite32( 0x00008808, io
E1000_FCT ) iowrite32( 0x00000680, io
E1000_FCTTV ) iowrite32( 0x800047F8, io
E1000_FCRTL ) iowrite32( 0x00004800, io
E1000_FCRTH )
11
The Flow Control statistics

enum E1000_XONRXC 0x4048, // XON Received
Count E1000_XONTXC 0x404C, // XON
Transmitted Count E1000_XOFFRXC 0x4050, //
XOFF Received Count E1000_XOFFRXC 0x4054, //
XOFF Transmitted Count
12
Device Control (0x0000)
31 30 29 28 27 26
25 24 23 22 21
20 19 18 17 16
PHY RST
VME
R 0
TFCE
RFCE
RST
R 0
R 0
R 0
R 0
R 0
ADV D3 WUC
R 0
D/UD status
R 0
R 0
15 14 13 12 11
10 9 8 7 6 5
4 3 2 1 0
R 0
R 0
R 0
FRC DPLX
FRC SPD
R 0
SPEED
R 0
S L U
R 0
R 0
R 1
0 0
F D
GIO M D
R 0
FD Full-Duplex SPEED (0010Mbps, 01100Mbps,
101000Mbps, 11reserved) GIOMD GIO Master
Disable ADVD3WUP Advertise Cold Wake Up
Capability SLU Set Link Up D/UD Dock/Undock
status RFCE Rx Flow-Control Enable FRCSPD
Force Speed RST Device Reset TFCE Tx
Flow-Control Enable FRCDPLX Force Duplex PHYRST
Phy Reset VME VLAN Mode Enable
82573L
We used 0x040C0241 to initiate a device reset
operation
13
Receive Control (0x0100)
31 30 29 28 27 26
25 24 23 22 21
20 19 18 17 16
R 0
0
0
FLXBUF
SE CRC
BSEX
R 0
PMCF
DPF
R 0
CFI
CFI EN
VFE
BSIZE
15 14 13 12 11
10 9 8 7 6 5
4 3 2 1 0
B A M
R 0
MO
DTYP
RDMTS
I L O S
S L U
LPE
UPE
0 0
R 0
SBP
E N
LBM
MPE
EN Receive Enable DTYP Descriptor
Type DPF Discard Pause Frames SBP Store Bad
Packets MO Multicast Offset PMCF Pass MAC
Control Frames UPE Unicast Promiscuous Enable
BAM Broadcast Accept Mode BSEX Buffer Size
Extension MPE Multicast Promiscuous Enable
BSIZE Receive Buffer Size SECRC Strip
Ethernet CRC LPE Long Packet reception Enable
VFE VLAN Filter Enable FLXBUF Flexible
Buffer size LBM Loopback Mode CFIEN
Canonical Form Indicator Enable RDMTS
Rx-Descriptor Minimum Threshold Size CFI
Canonical Form Indicator bit-value
We used 0x0480801E in RCTL to prepare the
receive engine for flow control
14
Transmit Control (0x0400)
31 30 29 28 27 26
25 24 23 22 21
20 19 18 17 16
R 0
R 0
R 0
MULR
TXCSCMT
UNO RTX
RTLC
R 0
SW XOFF
COLD (upper 6-bits) (COLLISION DISTANCE)
15 14 13 12 11
10 9 8 7 6 5
4 3 2 1 0
COLD (lower 4-bits) (COLLISION DISTANCE)
0
ASDV
I L O S
S L U
TBI mode
P S P
0 0
R 0
R 0
E N
SPEED
CT (COLLISION THRESHOLD)
EN Transmit Enable SWXOFF Software XOFF
Transmission PSP Pad Short Packets RLTC
Retransmit on Late Collision CT Collision
Threshold (0xF) UNORTX Underrun No
Re-Transmit COLD Collision Distance
(0x3F) TXCSCMT TxDescriptor Minimum
Threshold MULR Multiple Request Support
We used 0x0103F0F8 in TCTL to setup the transmit
engine before enabling it
82573L
15
Our txburst.c again

• The statement that enables flow control in the
  Device Control register originally was commented
  out for our earlier demo
• Now we restore that statement as part of the
  executable code during initialization
• This time we observe a different effect!

Timeout for this second classroom demonstration
16
In-class exercise 1

• Can you reduce the value in the FCTTV-register
  (to PAUSE for a briefer time) and still avoid
  losing any transmitted packets?
• How small can FCTTV be?

17
In-class exercise 2

• Is it necessary to turn on BOTH of the bits in
  the Device Control register that enable the
  controllers hardware flow control?
• The RFCE-bit (bit 23)
• The TFCE-bit (bit 24)

18
In-class exercise 3

• Must the receive engine be enabled?
• Must the PMCF-bit (bit 23) be turned on in the
  RCTL register?
• PMCF Pass MAC Control Frames
• Could the DPF-bit (bit 324) be turned on?
• DPF Drop PAUSE Frames

19
Out-of-class exercise

• Can you design module-code that would demonstrate
  the use of the SWXOFF-bit (bit 22) in the
  Transmit Control register?
