Dimensional Modeling

1
Dimensional Modeling

• Overview and Fundamentals

2
What Is Dimensional Modeling?
3
Dimensional Modeling

• An Overview
• Structure
• Terminology
• Benefits
• The Fundamentals
• Facts and Dimensions
• The 4 Step Design Process

4
What does Data Warehouse look like

• Kimball Data Warehouse
• Back Room Staging Area (The kitchen)
• Data Presentation Area (The Dinning Room)
• Star Schema
• Corporate Information Factory (CIF)
• Normalized Dimensions
• Dual ETL Loading, Warehouse and Data Marts
• Operational Data Store (ODS)
• Hybrid Data Warehouse

5
Kimball Data Warehouse
6
Corporate Information Factory
7
Terminology

• Dimensions
• The time independent, textual and descriptive
  attributes by which users describe objects.
• Combining all the attributes including
  hierarchies, rollups and sub-references into a
  single dimension is denormalization.
• Often the by word in a query or report
• Not time dependent

• Facts
• Business Measurements
• Most Facts are Numeric
• Additive, Semi-Additive, Non-Additive
• Built from the lowest level of detail (grain)
• Very Efficient
• Time dependent

8
Star Schema

• Singe data (fact) table surrounded by multiple
  descriptive (dimension) tables

9
Benefits

• Performance (Integer relationships, natural
  partitioning, Single joins benefit SQL optimizer)
• Source system independence and multiple
  integration
• Supports Change management
• Usability/Simplicity (easy to read, interpret,
  join, calculate)
• Presentation (Consistency, Taxonomy, Labeling)
• Reuse (Conformed dimensions reduce redundancy,
  Role-plays)

10
Dimension Change Strategy

• Type 1 Is used when the old value of the
  attribute has no significance or can be
  discarded.
• Easy and Fast
• Type2 Partitions history so that fact tables
  properly reflect original values.
• Requires use of Surrogate Keys
• Causes table growth due to additional history
  rows
• Users must be aware of the added complexity
• Effective Dates used secondary to cleaner fact
  joins

11
Dimension Change Strategy

• Type 3 Additional attribute used to capture
  changes.
• Used less frequently then Type 1 or 2.
• Simultaneously supports two views of the world.
• Does not trend changes over time.
• Current and Prior or Current and Original
  Attributes
• Hybrid Type Combination 1, 2 3 changes
• New attribute for predictable series (such as
  yearly changes)
• Type 2 changes with prior or original attributes
  included
• Expanded dimension table for durable key
  inclusion in fact
• Added complexity to users

12
Dimension Role Playing

• A single table that plays multiple roles (using
  views) to create synonym dimension attributes.
• Most common role playing dimension is the Date
  Dimension. i.e. separate role playing dimensions
  for order date and ship date.

13
Fact Table Types
14
Modeling Design Process

• Identify the Business Process
• Source of measurements
• Identify the Grain
• What does 1 row in the fact table represent or
  mean?
• Identify the Dimensions
• Descriptive context, true to the grain
• Identify the Facts
• Numeric additive measurements, true to the grain

15
Step 1 - Identify the Business Process

• This is a business activity typically tied to a
  source system.
• Not to be confused with a business department or
  function. An Orders dimensional model should
  support the activities of both Sales and
  Marketing.
• If we establish departmentally bound dimensional
  models, well inevitably duplicate data with
  different labels and terminology.

16
Step 2 - Identify the Grain

• The level of detail associated with the fact
  table measurements.
• A critical step necessary before steps 3 and 4.
• Preferably it should be at the most atomic level
  possible.
• How do you describe a single row in the fact
  table?

17
Step 3 - Identify the Dimensions

• The list of all the discrete, text-like
  attributes that emanate from the fact table.
• They are the by words used to describe the
  requirements.
• Each dimension could be though of as an
  analytical entry point to the facts.
• How do business people describe the data that
  results from the business process?

18
Step 4 - Identify the Facts

• Must be true to the grain defined in step 2.
• Typical facts are numeric additive figures.
• Facts that belong to a different grain belong in
  a separate fact table.
• Facts are determined by answering the question,
  What are we measuring?
• Percentages and ratios, such as gross margin, are
  non-additive. The numerator and denominator
  should be stored in the fact table.

19
For More Information

• Articles, Design Tips and Newslettershttp//www.k
  imballgroup.com
• Designing A Scalable DW/BI Systemhttp//msevents.
  microsoft.com/cui/WebCastEventDetails.aspx?EventID
  1032297070EventCategory4cultureen-USCountryC
  odeUS
• Microsoft BI Using the Kimball Methodhttp//mseve
  nts.microsoft.com/cui/WebCastEventDetails.aspx?Eve
  ntID1032297084EventCategory4cultureen-USCoun
  tryCodeUS
• Using SSIS to Populate a Kimball Method Data
  Warehousehttp//msevents.microsoft.com/cui/WebCas
  tEventDetails.aspx?EventID1032297072EventCategor
  y5cultureen-USCountryCodeUS
