FE8113

1
FE8113 High Speed Data Converters
2
Course outline

• Focus on ADCs. Three main topics
• 1 Architectures
• CMOS Integrated Analog-to-Digital and
  Digital-to-Analog Converters, 2nd ed., Rudy van
  de Plassche, Kluwer Academic Publishers, Ch. 1-3
• 2 Digital background calibration
• Selected papers
• 3 State-of-the-art converters
• Selected papers

3
Part 1 Architectures

• First three chapters of van de Plassches
  textbook
• Ch.1 The Converter as a black box
• Ch.2 Specifications of converters
• Ch.3 High-Speed A/D Converters

4
Chapter 2Specifications of converters
5
Digital data coding
TTL, CMOS, ECL Serial to parallel conversion -
Data latched out by latch clock - Directly
drives switches in DA-converters - Output
glitches - Deglitching - Switch
optimization - Accurate board layout for
matched delays
6
Digital coding schemes

• Offset binary code
• Major carry transition for signal around zero
• Glitch sensitive
• Sign-magnitude code
• Signal inversion around zero
• Low-level linearity issues
• Twos complement
• Used for computational operations

7
DC specifications

• Absolute accuracy
• Full-scale input or output compared to the
  absolute standard of the National Bureau of
  Standards
• Mostly related to the reference source
• Relative accuracy
• Deviation of the output signal or code from a
  straight line
• Also called integral non-linearity (INL)
• No missing codes (monotonicity) INLlt1/2LSB

8
Nonlinearity calculation

• Binary w. output bit
• Full-scale value B
• Ideal step-size
• Linearity error of kth bit
• INL

9
Nonlinearity calculation II

• Monotonicity
• D/A No increase in analog output value when
  input increases by a value of one LSB

• To guarantee monotonicity the sum of errors for
  all bits must never exceed ½ LSB level

10
Other static specifications

• DNL
• Quote from book The difference between two
  adjacent analog signal values compared to the
  step-size (LSB-weight) of a converter generated
  by transitions between adjacent pairs of digital
  code numbers over the full range of the
  converter (...)
• Offset
• Non-zero output when zero input.
• Temperature dependence
• For thermal mismatch below ¼ LSB
• Supply voltage variations
• Typically specified, e.g. 5

11
Dynamic specification

• SNR
• Signal power divided by integrated noise power.
• Harmonics not included
• If harmonics included
• SNDR Signal to noise and distortion ratio
• 6.02n1.76 dB
• SFDR
• Ratio between full-scale fundamental and largest
  harmonic distortion component
• ENOB
• (SNDR-1.76)/6.02

12
Element matching vs. INL

• Requirements INL ½ LSB
• See book for details.
• Based on measurement of many samples.
• smismatch standard variation.

13
ENOB and SDNR vs. INL model

• Transfer-function with INL
• INL-model (differential)
• Out vs. in with three coefficients in INL-model
• Gives odd harmonics
• Only one coefficient
• Resulting ENOB

14
SFDR and IMD vs. INL model

• Distortion
• Quantization component
• SFDR
• Intermodulation

15
Glitches

• Important for performance of DAC
• Major carry-code transition
• Modelled with square glitch with area/energy (for
  MSB glitch)
• Compare to LSB-energy

16
Noise

• Thermal noise
• No correlation with q-noise
• In a 16b DAC with 98.1dB quantization-SNR, the
  thermal noise must be less than -108dB
  for 0.5dB loss in total SNR.

17
Noise

• ADC Noise dithers the comparator in an ADC
• Estimating comparator output-noise by using
  probability of wrong desicion
• Noise s ½ LSB
• Bias quantizer ½ LSB over quantization-level

18
Other error sources
k 2Q(k)
3 2.910-3
4 6.710-5
5 5.910-7
6 2.010-9
7 2.610-12
8 1.310-15

• Minimum reference step-size
• The possibility noise amplitude is bigger than ks
• Min. Reference step size should be 6-7 times
  greater than comparator RMS-noise
• Bit-error rate
• Number of desicion errors
• For ADC typically 10-15 to 10-10
• Max sampling-rate
• Rate where DR is decreased 3dB
• Digital signal feed-through
• Couple HF signals to the output

19
Other error sources

• Distortion
• Signal band also present at multiples of fs.
• Inter-modulation products may occur when applied
  to analog amplifier.
• Mixing fs-fin with fsfin
• Product at 2fs
• Harmonic
• Mixing 2(fs-fin) with fsfin
• Product at fs-3fin
• Non-harmonic
• Only harmonics in baseband if fsgt4fin.
• PSRR
• Immunity no power-supply noise
• Settling-time
• Very important in any successive approximation
  ADC (internal DAC)
• Aquisition-time
• Track-command to response delay
• Limits max fs

20
Other error sources

• Aperture-time
• Time-difference between hold-command and the time
  the sample is taken
• Can give input-dependent error in sample-and-hold
  amplifier
• Sample-and-hold step
• Charge-feedthrough can give step in transition
  from sample-to-hold phase
• Droop-rate
• Discharge of hold-capacitor in hold-phase
• Signal feed-through
• To capacitor in hold mode
• Must be attenuated 70-80dB in 8-10bit ADC
• Noise in S/H-amplifier
• Input-noise will be tracked
• Peak-noise must be below LSB-level

21
Other error sources

• Overview of S/H-specifications
• Settling-time
• Aquisition-time
• Aperture time / jitter
• S/H step
• Droop rate
• Hold-mode feedthrough
• S/H amplifier noise

22
Other error sources

• Analog system bandwidth
• In an ideal converter system the maximum analog
  bandwidth is equal to fs/2.
• ERB
• Effective resolution bandwidth
• Bandwidth where resolution is within -3dB of
  nominal.
• Figure of merit
• Standard for comparison
• FOM expected to drop factor 10 every 10th year

23
Discussion...
