Section 1B: Digital Signal Processor Hardware Architecture

1
Section 1B Digital Signal Processor Hardware
Architecture

• DSP Architecture Types
• von Neumann
• Harvard, modified Harvard
• VLIW, superscalar

2
Overview

• Chapter 1 Architecture

Fix Point Arithmetic Architecture
Types Selection Criteria
3
Outline

• Why a DSP processors?
• Architecture Types
• von Neumann
• Harvard / Modified Harvard
• Very Large Instruction Word (VLIW)
• Super Scalar

4
Why specialized DSP processors?

• Difference between digital signal processing
  applications and typical applications
• is the number of multiplications required

• Example
• Typical application (word processing, spread
  sheet)
• lt10 Multiply and ACcumulate (MAC)
• DSP Application
• Digital filtering, modulation, sounds, graphics
• 50-95 MAC

5
Why specialized DSP processors?

• General purpose processors for DSP applications
  are designed to speed up the multiply and
  accumulate (MAC)

MAC

• A one clock-cycle hardware multiplier is used
• General purpose processors may use micro-code for
  multiplier (several additions and shifts)
• May also have multiple data buses for fast data
  access

6
Why specialized DSP processors?

• Common features for DSP

• Fast multiplier (hardware)
• Hardware for scaling data (barrel shifter)
• on-chip memory (RAM, ROM, FLASH)
• on-chip peripherals
• A/D and D/A converters
• Serial ports
• H/W for compression and encoding data (Verterbi
  encoder)
• low-cost, low-power (or high performance)

7
NEXT

• Why a DSP processors?
• Architecture Types
• von Neumann
• Harvard / Modified Harvard
• Very Large Instruction Word (VLIW)
• Super Scalar

8
Architecture Types

• Here are four main architectures

• von Neumann (Ex HC12)
• Harvard/ Modified Harvard (Ex C5416 de TI)
  Architectures Multi-Issues
• Very Large Instruction Word (VLIW) (Ex C62x)
• Super Scalar (Ex Pentium 4,..C64x..)

• von Neumann
• Harvard/ Modified Harvard Architectures
  Multi-Issues
• Very Large Instruction Word (VLIW)
• Super Scalar

• In the past DSPs used primarily

• Modified Harvard, VLIW

9
NEXT

• Why a DSP processors?
• Architecture Types
• von Neumann
• Harvard / Modified Harvard
• Very Large Instruction Word (VLIW)
• Super Scalar

10
von Neumann
1 Bus only

• data/instructions in memory
• 1 bus for data /instructions
• executes in linear manner PC lt- PC1
• fetches 1 word per cycle
• easy to interface

11
von Neumann DSP Processor

• Basic processor with functional blocks shown
• Note One bus for instructions and data

12
von Neumann Basic Operation

• Program and data reside in memory for maximum
  flexibility
• Basic operation of the computer

• fetch next instruction
• execute instruction
• repeat

13
von Neumann Control Registers

• PC program counter
• IR instruction register
• MAR memory address register
• MDR memory data register
• IO AR i/o address register
• IO DR i/o data register
• IMR interrupt mask register
• IFR interrupt flag register
• ACC accumulator (general purpose register)

14
von Neumann Diagram

• Program and data are stored in same memory space
• MAR, MDR and IR are not visible to user
• This is a simple interface to allow flexible
  coding

15
von Neumann Steps to execute

• Instruction address calculation
• MAR PC, PCPC1
• Fetch instruction MDR (MAR), IR MDR
• Decode instruction
• Operand address calculation MARaddress
• Fetch operand MDR (MAR)
• repeat 4 and 5 for multiple operands
• Execute operation
• Calculate output operand address
• MAR address destination
• Store result (MAR) (MDR)

16
Example Execution of an addition

• ADD B,A memory to memory operation
• (A) lt (B) (A)
• .
• .
• .
• .
• .
• .

Fetch operand (add) Fetch memory contents
(A) Fetch memory contents (B) Add (A) and
(B) Store result in A
17
Example Addition Requirements

• 4 memory accesses
• (PC) , (A) read, (B) read, (A) write
• addresses for two operands
• A, B addresses must be included in instruction
• may require many words
• instructions take varying execution time
• depending on memory accesses required.

18
Quick Quiz

• What is the main reason for which you would
  choose a DSP processor within your designed
  system?
• What is the main characteristic of the von
  Newmann architecture?

19
NEXT

• Why a DSP processors?
• Architecture Types
• von Neumann
• Harvard / Modified Harvard
• Very Large Instruction Word (VLIW)
• Super Scalar

20
Harvard Architecture

• Separate program and data buses
• Program-bus-address program-bus-data on one bus
• Data-bus-address and data-bus-data on another bus

21
Harvard Architecture

• Main feature
• separate data and program bus
• can fetch instruction/data in parallel
• Allows for pipelining of instructions
• Hast repetitive operations
• Pipeline Address calculation of one instruction,
  while fetching the previous instruction, while
  executing the ex-previous instruction.

22
Modified Harvard Architecture

• Many constants are stored in the code
• These constants are read from the program bus
  (e.g. 2M_PI)

• In a pure Harvard architecture, there is no way
  to get these constants to the ALU to use them as
  data
• The modified Harvard architecture allows data
  (constants) to be read from the PB

23
Modified Harvard Architecture C54x
Prog.
Data
24
Modified Harvard Architecture C54x

• Program bus
• Three data buses

• PAB program address bus
• PB program data bus
• CAB, CB, DAB, DB data read / io read
• EAB, EB data write / io write

25
Modified Harvard Architecture C54x

• Modifications of DSP C54x
• can read data from program bus
• macd, firs, Smem prog(pmad)
• multiple buses for on-chip memory

26
NEXT

• Why a DSP processors?
• Architecture Types
• von Neumann
• Harvard / Modified Harvard
• Very Large Instruction Word (VLIW)
• Super Scalar

27
Recap Architecture types

• Here are 4 main architectures
• Architectures Single-Issue
• von Neumann
• Harvard / Modified Harvard
• Architectures Multi-Issues
• Very Large Instruction Word (VLIW)
• Super Scalar

28
Multi-issues Architectures

• single issue architecture
• one command issued per cycle
• pipelining
• partially execute several commands per cycle
• multi-issue architecture
• group commands in parallel

29
VLIW Architecture

• Very Large Instruction Word (VLIW)
• Multi-issues Architecture
• Programmer/compiler must group instructions
• Grouped instructions result in a
• very long instruction word
• Requires parallel algorithms

30
VLIW Architecture C62x/67x
Duplicated Hardware
2 possible paths
31
VLIW Architecture C62x

• VLIW Example
• TMS320C62x

32
VLIW Architecture
(Parallel Calculation)

• Advantages
• Typically use 32 bit instructions
• General purpose registers
• Simple instructions
• p.ex. macd besoin de mult, add, dmov, ARx
• C54x 1 word (16 bits)
• C67x 4 words (128 bits)

(Flexibility for programmer)
(Simple HW, hence ? cost )
33
VLIW Architecture
Ex MACD ? 32bit 32 32 32 32

• Disadvantages
• compiler groups instructions
• difficult for designer
• requires recompilation for new generations
• Large code size
• large word size
• 1 instruction per functional unit
• simple instructions
• often have cache memory
• C67x 8 units, 256 bit instructions per cycle

() Go away from assembly
(Costly in terms of Power and memory)
(Sequential operation could be slow)
34
VLIW Architecture

• TI has made compromises on C64x
• 16 bit instructions and 32 bit instructions
• 32 instructions for critical code (fast)
• 16 bit instructions to reduce code size
  (limited)
• complex instructions added (eg macd)
• more difficult for compiler
• increase execution speed
• assembly optimized libraries included

(? speed)
(? cost in power and memory)
(? )
(? speed)
(mitigates effects of Complex commands )
35
NEXT

• Why a DSP processors?
• Architecture Types
• von Neumann
• Harvard / Modified Harvard
• Very Large Instruction Word (VLIW)
• Super Scalar

36
Super Scalar Architecture

• multi-issue
• groups of instructions issued in parallel
• dedicated HW on-chip
• determines instructions to execute in parallel
• based on
• data dependencies
• resources available

• Eg Pentium II
• code compatible with 486
• issues 2 486 commands in parallel where possible

37
Super Scalar Architecture Example

• C64x DSPs

Distribution module (Advanced instruction
packing) added
38
Super Scalar Architecture

• Advantages
• code compatible with older processors
• easier to program
• Disadvantages
• More complicate HW than VLIW
• larger power consumption
• unpredictable execution time

39
Super Scalar Architecture Problem

• DSP applications are hard real-time
• require predictable execution time
• DSP applications use almost all cycles
• cell phones 98
• HDTV 90
• Can use worst case execution time
• wastes power/clock cycles

some DSP use superscalar due to high speed
40
Quick Quiz

• You are building a cell-phone and need to choose
  a DSP. You need to digitally process the voice,
  modulate and demodulate the signal, compress and
  expand the voice and maximize the length of your
  batteries.
• What architecture of DSP would you choose?
• (von Neumann, Harvard, VLIW, superscalar)
• Justify your answer?

41
Answer

• Von Neumann
• Will not meet computational requirements
• Harvard (or Modified)
• adequate processing power
• Low power consumption
• cheap
• VLIW
• more program memory and power consumption than
  Harvard
• Processing power not required
• Superscalar
• do not need extra performance
• - Takes much more power (less battery life)

42
Quick Quiz 2

• You are building a new Sony Wi. You need to
  digitally process images and sound. You need to
  play DVDs. As well you need to process user
  movements in real-time.
• What architecture of DSP would you choose?
• (von Neumann, Harvard, VLIW, superscalar)
• Justify your answer?

43
Answer

• Superscalar
