Sustainable Energy Mix

1
Sustainable Energy Mix
Ziemowit Iwanski GE Energy
2
2009
GE Company Proprietary
3
2030
Powering the world responsibly
GE Company Proprietary
4
Diverse portfolio need to meet any outcome
Gas
Smart Grid
Nuclear
Wind
Solar
Oil Gas
Pipeline Integrity
Biomass
Cleaner Coal
Water Technologies
5
CO2 Emissions with Todays Fuels
CO
Emissions per MWh
2
Coal Plant (41)
Coal Plant (45)
IGCC at 25 removal
Heavy-Duty SC GT (37)
Technology
Natural Gas Fired Steam Plant (38)
IGCC at 70 removal
FB Combined Cycle (58)
H Combined Cycle (60)
IGCC at 90 removal
0
250
500
1000
750
kg per MWh
6
Invest in renewables
Biogas

• Efficiency, reliability fuel flexibility
• 2 GW total installed GE gas engine base
  biomass
• 2,600 units delivered for use of biogas,
  landfill gas, and sewage gas
• Patented combustion technology CO2 neutral

Bio power growth
Global installed capacity (GW)
16
Asia rest of world
Europe
3.5
U.S.
'02
'20
Source FrostSullivan
7
Wind...
Industry installation forecast
Products
(GWs)
32
1.5 MW platform
ROW 2
Asia Pacific32
2.5 MW platform
North America 29
15.0
7.8
Europe 37
offshore
03
06
09E
Source BTM Consult, March 08
8
Invest in combined cycle gas turbines
GE leads advanced technology field experience
25 million fired hours
9
Rapid Response combined cycle
109FA/B 209FA/B rapid response Time from
Loadhot start Std Rapid Response 10
minutes 0 10 20 minutes 0 65 55
minutes 15 100 110 minutes 100 100 option
available to achieve 30 load in 10 minutes

• Benefits
• Respond to electricity ancillary market
  opportunities
• 70-65 reduction in start-up fuel
• 65-55 reduction in NOx emissions

10
LM6000-Reliable and flexible
11
LMS-100 Combining the best of both worlds
12
Proven Experience of GEs Aeroderivative and
Flight Engines
Aeroderivatives
Number of
Operating
LM (Aircraft engine)
engines produced
hours
Simplified Installation Requirements
LM1600 (F404)
162
7,409,593
LM2500 (TF39/CF6-6)
807
39,534,166
LM2500
172
2,458,686
LM2500/ Marine
1,006
9,850,000
LM5000 (CF6-50)
103
6,160,187
LM6000 (CF6-80C2)
710
10,138,252
Totals
2,960
75,550,884
Switch Gear
Aircraft engines
Number of
Operating
LM (Aircraft engine)
engines
hours
LM1600 (F404)
3,347
10,000,000
LM2500 (TF39/CF6-6)
1,092
36,000,000
LM5000 (CF6-50)
2,048
117,000,000
LM6000 (CF6-80C2)
3,460
113,000,000
Totals
9,947
276,000,000
Control House
13
Reliable 10 minute starts for faster response to
grid demand
14
Invest in gasification
Imperatives for cleaner coal

• Reference plant commercialization
• Duke Edwardsport - Site work and detail design
  underway
• Carbon solution
• Carbon policy
• Total carbon solution Schlumberger CCS alliance
• Next generation technology
• Powder River Basin
• Advanced gasification technology center

• Global growth in applications beyond IGCC
• Business investment up 6X resource growth
  350MM investment

GE Company Proprietary
15
Integrated Gasification Combined Cycle
16
IGCC/USC CCS capability
Pollution Prevention vs. Pollution Control
WESP
Carbon Injection
Boiler
ESP/ FF
FF
SCR
FGD
CO2
Pre-Combustion PM, Hg, Su, CO2

• USC Pulverized Coal
• Removing pollutants requires treating 100 times
  the gas volume of an IGCC plant.
• CO2 concentration is low (14 - 1/3 that of
  syngas)
• Higher criteria HAPS emissions than an average
  IGCC plant
• Limestone sulfur removal adds 3-4 to CO2
  emissions

• IGCC
• Gasification cleans the coal before it is burned
  instead of cleaning up the pollution after it is
  produced.
• CO2 concentration in syngas is high (40-50)
• The IGCC Cleaner Coal option increases fuel
  diversity, reduces emissions, and increases
  siting and permitting flexibility.

17
The Technology of CCS
CO2
Precombustion decarbonization

• Power
• Heat

H2 CO2

• Underground storage
• Enhanced oil recovery (EOR)

18
Invest in nuclear

• Expanding fuel cycle offerings
• Advancing Boiling Water Reactor (BWR) technology
  and services alliance with Hitachi
• Investing in the latest ABWR Gen III ESBWR
  technology
• Design certification underway
• Launch customer identified
• Implementing on-going maintenance, power up-rates
  and modifications to existing fleet of BWRs

Nuclear facility expansion in Wilmington, SC
19
ABWR/ESBWR

• ESBWR
• Simplified design reduces plant capital and
  operating costs
• Passive systems improves safety
• Standardized plant shortens construction
  schedule and reduces risk
• Competitive base load generation no greenhouse
  gases from energy generation

• ABWR
• First Generation III reactor to begin commercial
  operation anywhere in the world.
• Proven technology and performance
• Certified design in the United States, Japan,
  Taiwan
• Improved safety and reliability
• Enhanced operability and maintainability

20
Product performance
our commitment
Environmental performance
Operating performance
