CSE 494 Electronic Design Automation

• Lecture 2
• VLSI Design, Physical Design Automation, Design
  Styles

2
Organization

• Introduction
• VLSI Design Cycle
• Physical Design Cycle and Automation
• Design Styles
• Packaging

3
Electronic Design Automation (EDA)

• Also known as VLSI CAD.
• It refers to the utilization of CAD techniques
  for VLSI design.
• The course will cover CAD algorithms for physical
  design automation (primary focus) and logic
  synthesis (secondary focus).

4
Why EDA?

• Complexity of current day electronic design (P4
  55 million transistors, P4 EE 178 million
  transistors).
• Manual design is unrealistic.
• Fewer errors.
• Time to market.

5
Industry perspective

• Major EDA tool vendors
• Synopsys, Cadence, Mentor graphics
• Major semiconductor design houses
• Intel, IBM, Motorola, Xilinx
• Course offers key skill set for CAD Engineer.

6
Research perspective

• Active area of research.
• Major conferences
• Design Automation Conference (DAC)
• Design and Test in Europe (DATE)
• International Conference on CAD (ICCAD)
• International Conference on Low Power Electronic
  Design (ISLPED)
• International Conference on Computer Design
  (ICCD)
• ...
• Course acts a stepping stone for research in VLSI
  CAD.

7
VLSI Design Cycle
System Specification
Circuit Design
Architectural Design
Physical Design
Functional Design
Fabrication
Logic Design
Packaging and Testing
Functional verification by simulation
8
VLSI Design Cycle

• System specification High level functional
  description (informal) of the design with size,
  speed, and power constraints.
• Architectural design Micro-architectural
  specification (informal) of the design with
  architecture style number of ALUs, floating point
  units, number and structure of pipelines, and
  size of caches.
• Functional design The functionality of each unit
  and their interconnection is described by HDL.
  The area, power, and time of each unit is
  identified.

9
VLSI Design Cycle

• Logic design Register transfer level (RTL)
  description of the design in HDL is generated. It
  consists of boolean expressions and timing
  information.
• Circuit design A circuit description in logic
  gates (or netlist) is developed. Automated
  circuit design is called logic synthesis.
• Physical design The circuit representation (or
  netlist) is converted into a geometric
  representation called the layout. Automated
  physical design is called physical synthesis.

10
VLSI Design Cycle

• Fabrication After a layout is generated the
  design is ready for actual fabrication or
  manufacturing.
• Packaging, Testing and Debugging The fabricated
  wafer is diced into individual chips that are
  then packaged, tested, and de-bugged.

11
New Trends in VLSI Design

• Increased interconnect delay interconnect not
  scaling at the same pace as the device.
• Increasing interconnect area Upto 40 of the
  area devoted to interconnect.
• Increasing number of metal layers Upto 5 layers
  for microprocessors.
• Increasing planning requirements Physical design
  early on in the design cycle.
• Automated synthesis Logic and high-level.

12
Physical Design Cycle

• Input A netlist of gates (or blocks) and their
  interconnections.
• Output A geometrical layout of the netlist
  within an area constraint.
• Other goals Minimize signal delays,
  interconnection area, power, cross-talk.

13
An Example Netlist
14
An Example Layout
15
An Example Layout
16
An Example Layout
17
Physical Design Cycle

• Partitioning Divide the net-list into sub-sets.
• Floorplanning and placement Determine the
  dimensions of the various units and their
  placement.
• Global routing Determine the regions through the
  chip that the wires or net would be routed.

18
Physical Design Cycle

• Detailed routing Determine the actual layout of
  the nets within each routing region.
• Compaction Compress the layout to reduce the
  area.
• Extraction and verification Design rule
  checking for ensuring that the layout meets the
  fabrication constraints. Extraction and
  simulation against previous specification.

19
Physical Design Automation

• Physical design automation refers to the
  computer-aided physical design cycle.

20
Design Styles

• Full Custom
• Utilized for large production volume chips such
  as microprocessors.
• No restriction on the placement of functional
  blocks and their interconnections.
• Highly optimized, but labour intensive.
• Standard Cell
• Utilized for smaller production ASICs that are
  generated by synthesis tools.
• Layout arranged in row of cells that perform
  computation.
• Routing done on channels between the rows.

21
Full Custom Layout
22
Standard Cell Layout
23
Standard Cell Layout
24
Design Style

• Gate Arrays
• Pre-fabricated array of gates (could be NAND).
• Design is mapped onto the gates, and the
  interconnections are routed.
• Field programmable gate arrays
• Pre-fabricated array of programmable logic and
  interconnections.
• No fabrication step required.

25
Field Programmable Gate Array (FPGA)
26
Configurable Logic Block
27
Design Style

• Sea of gates
• Pre-fabricated sea of gates with no area for
  routing.
• Simpler gates with very high density.
• Routing through gates or by fabricating over the
  cell routing.

28
Design Style Comparisons
STYLE
Full Custom Standard Cell Gate Array FPGA
Cell size Variable Fixed height Fixed Fixed
Cell type Variable Variable Fixed Prog.
Cell placement Variable In row Fixed Fixed
Interconnections Variable Variable Variable Prog.
Design cost High Medium Medium Low
29
Design Style Comparisons
STYLE
Full Custom Standard Cell Gate Array FPGA
Area Compact Compact to Moderate Moderate Large
Performance High High to Moderate Moderate Low
Fabricate All Layers All Layers Routing None
30
Packaging

• Printed Circuit Boards
• Packaged chips are soldered on a substrate.
• Larger wire delays, lower integration.
• Multichip Modules (MCM)
• Un-packaged chips are soldered on a substrate.
• Medium wire delays, medium integration.
• Wafer Scale Integration
• Multiple chips are fabricated on a single wafer.
• High performance, high integration, lower yields.

31
Summary

• VLSI Design Cycle was explained.
• PDA defined, and introduced.
• Overview of design styles and packaging.
