Marine Corps On-Board Vehicle Power
Joint Service Power Expo May 2005
2
  • WHAT WE DO TODAY

3
  • WHAT WE WILL DO TOMORROW

4
Required Capabilities
  • Ship to Objective Maneuver
  • Launch from Expeditionary Strike Force at sea
  • Maneuver space includes Air, Land, and Sea
  • Tailorable forces
  • Rapidly executable
  • Highly Maneuverable
  • Self-sufficient
  • Combined Arms capability

5
Implications on Power
  • Appetite for electric power is increasing
  • Space and weight are at a premium
  • Efficiency of energy use
  • Power sources to support maneuver forces
  • Rapid Reconstitution
  • Joint Services approach
  • Commonality across Marine Units Reserves

6
Mobile Power Options
10 w 100 w 1 kW 10 kW 100 kW
7
Vehicle Power Initiatives
  • On-Board Vehicle Power Small
  • On-Board Vehicle Power Medium
  • On-Board Vehicle Power Large
  • Power Distribution / Solar Charging

8
On-Board Power Layout
Operator controller/safety
Power conditioning

Engine controller
Power convenience plugs
Engine mounted rotating machinery
9
On-Board Power Payoff
Power Generation System Cost per kilowatt Weight Lbs. per kilowatt Embarkation Sq ft required
3 kW Tactical Quiet Generator 3200 108 lbs 7 ft2
10 kw Tactical Quiet Generator 1455 101 lbs 14 ft2
5-8 kw On-Board Vehicle Power System 1100 - 1800 18-30 lbs 0
10
On-Board Power Activities
  • Purpose is to prepare USMC
  • For future power needs / requirements
  • For potential future acquisition programs
  • For assisting the FMF when they take action on
    their own
  • MCSC efforts at this time are toward supporting
    users / buyers with
  • Performance data cost data
  • Market availability to deliver via GSA schedule /
    NSNd items
  • Limited Users Evaluation
  • 22nd MEU (Deployment) - 4 systems in FY04
  • Integration, Power, Reliability Qualification
    Testing (3 vendors)
  • Completed at Aberdeen Test Center
  • Power Inverter Testing
  • Currently underway at NSWC-Crane and Dayton T.
    Brown
  • Results in Summer 2005
  • Durability Testing (single system)
  • Nevada Automotive Test Center
  • Results in Summer 2005

11
On-Board Power Test Results
12
On Board Power Path Forward
  • This is USMC decision direction only
  • Joint PM Power and PM Motor Transport decision
  • Aberdeen Test Center Reports delivered
  • C.E. Neihoff System Rpt ATC-8929, Feb 2005
  • Raven Technology Rpt ATC-8930, Feb 2005
  • AuraGen System Rpt ATC-8933, Feb 2005
  • Release Authority Marine Corps Systems Command
  • No formal requirement exists
  • No formal source selection was made
  • But when asked, our recommendation will be to
    utilize the C. E. Neihoff system when 5-8 kW of
    on-board AC power is needed
  • C.E. Neihoff system will be taken to NATC for
    durability tests
  • USMC is continuing DC-AC Inverter evaluations

13
DC-AC Inverter Evaluation
  • Steady-state load test.
  • Output loading set to 0, 50, and 100 of full
    load
  • Power factor set to 0.8 leading and unity
  • Dynamic load test
  • Overload test
  • Steady-state line regulation test
  • Environmental testing IAW MIL-PRF-28800
  • Temperature tests _at_ 50 and 70 of full nominal
    load
  • Electromagnetic Interference.
  • Excepted tests from MIL-PRF-28800F not be
    performed
  • Splash proof Watertight
  • Fungus Resistance Explosive Atmosphere
  • Solar Radiation Humidity
  • Drip-proof

14
DC-AC Inverter Evaluation
15
Battery Charger on the Move
  • Statement of Need for Battery Management /
    Sustainment Systems
  • Overarching program for Alternative Power
    Sources for Communication
    Equipment
  • Response to OIF battery shortage
  • Garrison and Mobile needs addressed
  • Runs off AC or DC power
  • Mounts in vehicle or used on bench-top
  • Initial issue quantity to be fielded by
    MARCORSYSCOM in 2005-2006
  • Field User Evaluation with II MEF _at_ OIF III

16
Vehicle Power System
  • Solar Charging Panel
  • Part of Battery Management Statement of Need
  • Provides charging (not desulfating)
  • Overcomes battery self-discharge and helps ensure
    vehicles start on demand.
  • First fielding to MARFORRES
  • Vehicle Power Distribution
  • Fuse and Circuit Breaker Protection
  • Waterproof enclosure
  • Waterproof connectors
  • Fielding concept TBD

17
On-Board Vehicle Power Medium Large
  • Funded by Office of Naval Research
  • Future Naval Capability ACES
  • Expeditionary Warfare Tech Div (353)
  • Cooperative with Army
  • Full and Open competition to Industry
  • Solicitation in FY04
  • Source Selection complete
  • Multiple vendors in Phase I
  • Trade-offs / Preliminary Design
  • Down-select vendors for Phase II
  • Hardware build one system each
  • Technical Testing in 2006/07
  • System Evaluation 2007/08

Applicable to mounted systems that require
dedicated power sources (Radar, OpsCenter,
Mobile Command Posts, APU applications, etc.)
18
On-Board Vehicle Power-Medium
  • 20 30 kilowatts continuous
  • HMMWV M1123
  • 120 VAC, 60 hz electric power
  • Two vehicles can be connected in parallel
  • Parallelable with Tactical Quiet Generator
  • Phase I Vendors
  • BAE Systems, Oswego, NY
  • General Dynamics Land Systems, Muskegon, MI
  • DRS Technologies, Huntsville, AL

19
On-Board Vehicle Power - Large
  • 60 kilowatts minimum
  • MTVR Mk 23
  • 120 VAC, 60 hz electric power
  • Parallelable with TQG
  • Phase I Vendor
  • Oshkosh Truck Company, Oshkosh, WI

20
Questions
