XML Information Retreival

1
XML Information Retreival

• Hui Fang
• Department of Computer Science
• University of Illinois at Urbana-Champaign

Some slides are borrowed from Nobert Fuhrs XML
Tutorial.
2
Outline

• XML basics
• Research Topics
• XML IR
• Tasks
• Retrieval methods
• Clustering XML documents

3
XML standards
4
Basic XML

• Hierarchical document format for information
  exchange in WWW
• Self describing data (tags)
• Nested element structure having a root
• Element data can have
• Attributes
• Sub-elements

(Slides from Jayavel Shanmugasundaram)
5
Example XML document

• lt?xml version"1.0" encoding"ISO-8859-1" ?gt -
• lt!-- Edited with XML Spy v4.2   --gt
• ltbookgt
• lttitlegt Finding Out About A Cognitive
  Perspective on Search Engine Technology and the
  WWWlt/titlegt
• ltauthor id rbelewgt
• ltnamegt
• ltfirstnamegt Richard lt/firstnamegt
• ltlastnamegt Belew lt/lastnamegt
• lt/namegt
• ltaddressgt
• ltcitygt San Diego lt/citygt
• ltzipgt 92093 lt/zipgt
• lt/addressgt
• lt/authorgt
• lt/bookgt

6
Tree structure of XML documents
book
author
title
idrbelew
name
address
Finding.
First name
Last name
city
Zip code
Richard
Belew
San Diego
92093
7
Basic XML standard does not deal with

• Standardization of element names
• ?XML namespaces
• Structure of element content
• ?XML DTDs
• Data types of element content
• ?XML schema

8
XML namespace
Provide a method to avoid element name conflicts

• lttablegt
• lttrgt
• lttdgtAppleslt/tdgt
• lttdgtBananaslt/tdgt
• lt/trgt
• lt/tablegt

• lttablegt
• ltnamegtGPA Tablelt/namegt
• ltwidthgt80lt/widthgt
• ltlengthgt120lt/lengthgt
• lt/tablegt

9
XML namespace(Cont.)
Provide a method to avoid element name conflicts

• lthtable xmlnsh"http//www.w3.org/TR/html4/"gt
• lthtrgt
• lthtdgtAppleslt/htdgt lthtdgtBananaslt/htdgt
• lt/htrgt
• lt/htablegt

• ltftable xmlnsf"http//www.w3schools.com/gpa"gt
• ltfnamegtGPA Tablelt/fnamegt ltfwidthgt80lt/fwidthgt
  ltflengthgt120lt/flengthgt
• lt/ftablegt

10
XML Document Type Definition
Define the document structure with a list of
legal elements

• lt?xml version"1.0"?gt
• lt!DOCTYPE note SYSTEM "note.dtd"gt
• ltnotegt
• lttogtTovelt/togt
• ltfromgtJanilt/fromgt ltheadinggtReminderlt/headinggt
  ltbodygtHave a rest!lt/bodygt
• lt/notegt

lt!ELEMENT note (to,from,heading,body)gt lt!ELEMENT
to (PCDATA)gt lt!ELEMENT from (PCDATA)gt lt!ELEMENT
heading (PCDATA)gt lt!ELEMENT body (PCDATA)gt
11
Research Topics related to XML
12
Research Topics

• IR areas
• Retrieval Models
• Query Languages

• DB areas
• Query Languages
• System architecture
• Apply relational DB technology to XML data
• Streaming XML
• XML Query Processing
• XML indexing and compression

13
XML IR
14
INEXInitiative for the Evaluation for XML
Retrieval

• Documents 12,107 articles in XML format
• Queries 30 Content-only
• 30 Content and structure
• Relevance Assessments by participating groups
• Participants 36 active groups in 2003

15
CO search task

• Document as hierarchical structure of nested
  elements
• Type of elements is not considered
• Query refers to content only
• Query syntax as in standard text retrieval
• Task Find smallest subtree(element) satisfying
  the query

16
Example of CO Topic

• ltINEX-Topic topic-id45 query-typeCO
  ct-no056gt
• ltTitlegt ltcwgtaugmented reality and
  medicinelt/cwgtlt/Titlegt
• ltDescriptiongt
• How virtual (or augmented )reality can contribute
  to improve the medical and surgical practice.
• lt/Descriptiongt
• ltNarrativegt
• In order to be considered relevant, a
  document/component must include considerations
  about applications of computer graphics and
  especially augmented (or virtual) reality to
  medice(including surgery).
• lt/Narrativegt
• ltKeywordsgt
• Augmented virtual reality medicine surgery
  improve computer assisted aided image
• lt/Keywordsgt
• lt/INEX-Topicgt

17
CAS search Task

• Queries contain explicit references to the XML
  structure, by restricing
• The context of interest
• lttegttarget element
• The context of certain search concepts
• (ltcwgt,ltcegt) pairs

18
Example of CAS topic

• ltINEX-Topic topic-id09 query-typeCAS
  ct-no048gt
• ltTitlegt
• lttegtarticlelt/tegt
• ltcwgtnon-monotonic reasoninglt/cwgtltcegtbdy/seclt/cegt
• ltcwgt1999 2000lt/cwgt ltcegthdr//yrlt/cegt
• ltcwgt-calendarlt/cwgtltcegtlttig/at1ltcegt
• ltcwgtbelief revisionlt/cwgt
• lt/Titlegt
• ltNarrativegt
• Retrieve all articles from the years 1999-2000
  that deal with works on non-monotonic reaonsing.
  Do not retrieve CfPs/calendar entries
• lt/Narrativegt
• ltKeywordsgtnon-monotonic reasoning belief revision
  lt/Keywordsgt
• lt/INEX-Topicgt

19
XML Retrieval Methods

• XIRQL
• XML query languages with IR-related features
• Language models
• JuruXML

20
XIRQL(I)

• CO Approaches
• Split document text into disjoint nodes
• Index nodes separately
• Aggregate indexing weights for higher-level
  elements (subtrees)

21
Index nodes as units for term weighting

• Application of known indexing functions (e.g.
  tfidf)

22
Index nodes for relevance-oriented search
document
class"H.3.3"
chapter
chapter
author
title
section
heading
section
John Smith
heading
This. . .
XML Query
We describe
heading
heading
syntax of XQL
Lang. XQL
XML Retrieval
Introduction
1
3
2
Syntax
Examples
Q1 syntax ? example Q2 XQL
4
5
23
Combining weights
by disjunction
chapter
0.3 XQL
section1
section2
0.5 example
0.8 XQL
0.7 syntax
Need to return most specific element satisfying
the query!
Q1 syntax ? example Q2 XQL
24
Combining weights
with augmentation weight
chapter
0.3 XQL
section1
section2
0.5 example
0.8 XQL
0.7 syntax
Q2 XQL
25
XIRQL(II)

• CAS approaches
• Extension of XQL by
• Weighting and ranking
• Data types with vague predicates
• Structural relativism

26
XQL Expressions

• Path condition
• search for single elements
• heading
• parent-child
• chapter/heading
• ancestor-descendant
• chapter//section
• document root
• /book/
• Filter wrt. structure
• //chapterheading
• Filter wrt. content
• /document_at_classH.3.3 and authorJohn
  Smith

27
Data types with vague predicates

• Compares two values of a specific data-type
• E.g. Near, broader, narrower
• Returns (probabilistic) matching value
• E.g. Search for an artist named Ulbrich, living
  in Frankfurt, Germany about 100 years ago
• ?Ernst Olbrich, Darmstadt, 1899
• P(Olbrich Ulbrich)0.8 (phonetic similarity)
• P(1899 1903)0.9 (numeric similarity)
• P(Darmstadt Frankfurt)0.7 (geographic
  distance)

28
Semantic Relativism

• Drop distinction attribute/element
• author searches for attribute or element
• Generalize to data types
• personname searches for attribute/elements of
  specific data type

29
Language models

• Generate language models for each node in the
  tree
• Combine the children language models using linear
  interpolation
• Use EM approach to train the linear interpolation
  parameters

30
Element-specific language models---CO Approaches
31
Higher level nodes mixture of language models
Query dog and cat
32
Type-specific language models--- CAS approaches
33
0.5
0.5

• Return components of type x where it has
  component y that contains the query term w
• e.g. return documents where the title is
  contains the word bird

e.g. return documents where the bodys first
section is contains the word dog
34
Juru-XML

• Element-specific indexingvector space model
• Transform query into set of (term,path)-conditions

• Vague matching of path conditions
• Modified cosine similarity as retrieval function

35
JuruXML(1)---Transform Query
36
JuruXML(2)---Vague matching of path conditions
37
JuruXML(3)---Retrieval function

• Modified cosine similarity
• wQ(ti ,ciQ) query term weight of pair (ti,ciQ)
• wD(ti ,ciD) indexing weight of pair (ti,ciD) in
  the document

• Standard cosine similarity
• wQ(ti) query term weight of term ti
• wD(ti) indexing weight of term ti in the
  document

38
JuruXML(4)---Alternative approach (Merging
contexts)

• For each query term (ti,ciQ) treat all matched
  document terms (ti,cjD) equally from the user
  perspective.
• Define a weight function w(ciQ)
• E.g.

39
Clustering XML documents
40
Document similarity

• Document representation
• document?N-dimensional vector
• N document features
• Feature sets
• Text only
• Tags only
• Text Tags
• Feature weighting in the document vector
• Similarity measure--- vector similarity
• E.g. cosine measure

41
Clustering methods

• Hierarchical clustering
• Main weakness quadratic complexity
• Partitional clustering
• K-means
• Linear time complexity
• Simplicity of its algorithm

42
K-Means clustering algorithm
43
Measuring clustering quality

• External quality comparison of clusters with
  external classification
• Entropy distribution of classes within clusters
• Purity largest class in a cluster/cluster size
• Internal quality calculate average inter- and
  intra- cluster similarities.
• cohesiveness ( overall similarity)

44
Discussion

• Text alone give best results
• Texttags problem with weighting of tags vs.
  terms

45
Conclusion

• XML basics
• XML Retrieval Tasks and methods
• Clustering XML documents

46
Bayesian Networks
47
Context-dependent Retrieval

• The score of one element is given by
  RSV(Retrieval Status Value).
• RSV of node depends on RSVs of nodes in the
  context(parent nodes)
• Elements with highest values are then presented
  to the user.

48
Bayesian Networks
49
Bayesian Networks(Cont.)
