Title: BEZIER CURVES


1
BEZIER CURVES
  • Dr. Regalla Srinivasa Prakash

2
Bezier Curves
  • Approximator Adds flexibility and intuitive
    feel in mechanical design
  • Credited to P. Bezier P. De Casteljau also
    developed independently
  • Only control points (not necessarily only 2 per
    segment) form the input, no specification of
    tangent vectors provides more direct relation
    between input (points) and output (curve)
  • The order of the Bezier is variable (unlike HCC)
    and depends on the number of control points,
    (n1)
  • (n1) number of control points define an nth
    degree curve (we will term degree of curve as
    (k-1)
  • Bezier curve can be smoother than HCC

3
  • The Bezier curve is defined in terms of (n1)
    control points, called as control points
  • These control points form the vertices of the
    control or Bezier characteristic polygon
  • The control or Bezier characteristic polygon
    uniquely defines the curve

4
  • The curve shape tends to follow the polygon shape
    and thus easy to guess and sketch
  • Order of the control points is very essential
    because changing the order can change the shape
    of the curve

5
Bezier Curve
  • The user supplies (n1) control points, Pi
  • Write the curve as

6
  • The functions Bi,n are the Bernstein polynomials
    of degree (k-1)n
  • We can write the complete form of Bezier curve
    while observing that C(n,0)C(n,n)1

Special case, 3 control points B(u) P0 ( 1 -
u ) 2 P1 2 u ( 1 - u ) P2 u2 Special
case, 4 control points B(u) P0 ( 1 - u )3
P1 3 u ( 1 - u )2 P2 3 u2 ( 1 - u )
P3 u3
7
  • Substitute u0 and u1,?
  • The curve is tangent to the first and last
    segments of control polygonal segmentsproof?
  • Deriving the parametric form r times

8
Bezier Basis Functions for (n1)4
9
Some Bezier Curves
What did you observe??
10
Characteristics of Bezier Curve
  • 1) The curve interpolates the first and last
    control points.
  • It passes through Po and Pn if we substitute u0
    and u1

11
  • 2) The curve is tangent to the first and last
    curve segments of the control polygon.
  • Can you find the second derivative at P0? What do
    you observe?
  • Ans It is determined by Po, P1 and P2. In
    general, the rth derivative at an endpoint is
    determined by its r neighbouring control points.

12
  • 3) The curve is symmetric with respect to u and
    (1-u).
  • That is, reversing the direction of
    parametrization does not change the curve shape.
    To check this property substitute 1-u v.
  • The symmetry of the Bezier curve is due to the
    symmetry (NOT equality) of the Bernstein basis,
    which in turn is due to the property of the
    binomial functions C(n, i) C(n, n-i)
  • Which makes Bi,n(u) and Bn-i,n(u) to be symmetric
    when plotted with respect to u.
  • Be careful, Bi,n(u) ? Bn-i,n(u), never, except
    at u0.5.

13
  • 4) The polynomial Bi,n has a maximum value of
    C(n,i)(i/n)i(1 i/n)n-i occuring at ui/n
  • This can be obtained by setting dBi,n/du 0
  • This means that each ith control point is most
    influential on the shape of the curve at ui/n,
    where (n1) are the total control points.
  • For example in a cubic Bezier curve defined by
    Po, P1, P2 and P3, these points are most
    influential at u0, 1/3, 2/3 and 1.

14
  • 5) The shape of the curve (for a given set of
    control vertices) can be changed by two methods.
  • By moving a control point
  • By providing multiple control points at a vertex
    of control polygon. Multiplicity of control
    points makes the curve pulled towards that point.

Multiple control points are specified here
K3
K2
K1
15
  • 6) A closed Bezier curve can be obtained by
    making Po and Pn coincident. Will the degree of
    the curve change?

By making the last point co-incide with the first
point
By adding additional control point at the first
point
16
  • 7) Partition of Unity Property
  • For any valid value of u, for any degree of given
    curve

This provides for invariance of Bezier curve
(or invariance of the relationship between the
Bezier curve and its control polygon) under
affine transformations. Method to check
numerical computation and software developments.
17
  • 8) Positivity
  • For any value of u, given any degree of curve,
    each Bernstein polynomial satisfies

This ensures that the Bezier curve lies entirely
in its convex hull.
18
The Convex Hull Property of Bezier Curve
  • A curve is said to have convex hull property if
    it entirely lies in its convex hull defined by
    its control polygon.
  • The Bezier curve defined with Bernstein
    polynomial basis possesses the convex hull
    property

19
How to get the Convex Hull of a Bezier curve?
  • The convex hull of a Bezier curve is the maximum
    area obtained by joining all control points to
    all control points.

Convex Hull (Hatched region)
Example 1 Degree 3
Example 2 Degree 3
20
Convex Hull (Hatched region)
Example 3 Degree ?
Example 4 Degree ?
21
Consequences of Convex Hull Property
  • There are three important aspects
  • Degeneration to a straight line useful
  • Clipping like manipulations become easy
  • Wild oscillations of the curve about any control
    point is avoided

22
Repeated SlideConsequences of Convex Hull
Property
  • There are three important aspects
  • If the control polygon degenerates to a straight
    line, the curve segment also should become
    straight line. This is a useful design feature
    and is assured by convex hull property.
  • Clipping like manipulations need to clip only the
    control polygon not the actual curve, thus saving
    in computational time.
  • Wild oscillations of the curve about any control
    point is avoided.

23
Composite Bezier Curves Blending
  • For Co continuity the last control of the first
    Bezier curve segment be coincided with the first
    point of the second Bezier curve segment.
  • For C1 continuity The end slope of the first
    segment need to be equal to the starting slope of
    the second segment. This requires that the
    (n-1)th point of the first segment, the joining
    point and the second point of the second segment
    be collinear.
  • Now
  • (n1) Number of the control points of the first
    segment
  • (m1) Number of the control points of the
    second segment
  • Equating the tangent vectors
  • n(Pn Pn-1)first segment m(P1 Po)second
    segment
  • (Pn Pn-1)first segment (m/n)(P1
    Po)second segment

24
Example
  • If the first segment is formed by Po, P1, P2 and
    P3 and second segment is formed by P4, P5, P6, P7
    and P8, then P2, P3 (coinciding with P4) and P5
    must be collinear. Therefore
  • (P4 P3) (4/3)(P5 P4)

P7
P2
P4
P1
P8
P3
P5
P6
Po
25
Sub-Dividing Bezier Curves de Casteljaus
Algorithm
  • Step 1 Find the midpoints of the lines joining
    the original control vertices. Call them M01,
    M12, M23
  • Step 2 Find the midpoints of the lines joining
    M01, M12 and M12, M23. Call them M012, M123
  • Step 3 Find the midpoint of the line joining
    M012, M123. Call it M0123
  • The curve with control points P0, M01, M012 and
    M0123 exactly follows the original curve from the
    point with u0 to the point with u0.5
  • The curve with control points M0123 , M123 , M23
    and P3 exactly follows the original curve from
    the point with u0.5 to the point with u1

26
Sub-Dividing Bezier Curves
M12
P1
P2
M012
M0123
M123
M01
M23
P0
P3
27
Sub-Dividing Bezier Curves
P1
P2
P0
P3
28
de Casteljaus Algorithm
  • You can find the point on a Bezier curve for any
    parameter value u with a similar algorithm
  • Say you want u0.25, instead of taking midpoints
    take points 0.25 of the way

M12
P2
P1
M23
t0.25
M01
P0
P3
29
  • Bit questions

30
  • Who invented Bezier curve?
  • Bézier curve is attributed and named after a
    French engineer, Pierre Bézier, who used them for
    the body design of the Renault car in the 1970's.

31
  • What are the applications of Bezier curve, past
    and present?
  • They have since obtained dominance in the
    typesetting industry and in particular with the
    Adobe Postscript and font products.

32
  • If only one control point is given, what will be
    the Bezier curve?
  • If there is only one control point P0, i.e., n0,
    then P(u) P0 for all u.

33
  • If there are only two control points P0 and P1,
    what will be the nature of Bezier curve?
  • i.e., n1, then the formula reduces to a line
    segment between the two control points.

34
  • Prove that the Bezier curve with Bernstein
    polynomials in general does not pass through any
    of the control points except the first and last.
  • Solution
  • From the formula P(0) P0 and P(1) Pn.

35
  • Prove that the curve is always contained within
    the convex hull of the control points and that it
    never oscillates wildly away from the control
    points.
  • Solution Positivity property.

36
  • How do you obtain the closed Bezier curve? What
    is the effect on the degree of the curve?
  • Solution Closed curves can be generated by
    making the last control point the same as the
    first control point. First order continuity can
    be achieved by ensuring the tangent between the
    first two points and the last two points are the
    same.

37
  • What is meant by multiplicity of control points
    and what is the consequence of it? Will multiple
    control points at a coordinate location change
    the degree of the curve?
  • Solution
  • Adding multiple control points at a single
    position in space will add more weight to that
    point "pulling" the Bézier curve towards it.

38
  • Why it is necessary to blend multiple Bezier
    curve segments to model a part represented by a
    set of data points, instead of building a single
    curve?
  • Solution
  • As the number of control points increases it is
    necessary to have higher order polynomials and
    possibly higher factorials. It is common
    therefore to piece together small sections of
    Bézier curves to form a longer curve. This also
    helps control local conditions, normally changing
    the position of one control point will affect the
    whole curve. Of course since the curve starts and
    ends at the first and last control point it is
    easy to physically match the sections. It is also
    possible to match the first derivative since the
    tangent at the ends is along the line between the
    two points at the end.

39
  • Does Bezier curve provide C2 continuity at the
    blend point?
  • Solution
  • Second order continuity is generally not
    possible.

40
  • Is it possible to build two parallel Bezier
    curves?
  • Solution
  • Except for the redundant cases of 2 control
    points (straight line), it is generally not
    possible to derive a Bézier curve that is
    parallel to another Bézier curve. It isn't
    possible to create a Bézier curve that is
    parallel to another, except in the trivial cases
    of coincident parallel curves or straight line
    Bézier curves.

41
  • Can a circle be exactly represented by a Bezier
    curve?
  • Solution
  • A circle cannot be exactly represented with a
    Bézier curve.

42
  • What are the advantages of Bezier curve? Is it
    possible to build interpolating Bezier curve?
  • Solution
  • Bézier curves have wide applications because they
    are easy to compute and very stable. There are
    similar formulations which are also called Bézier
    curves which behave differently, in particular it
    is possible to create a similar curve except that
    it passes through the control points.

43
How the degree of Bezier curve is decided? Is the
curve ever symmetric?
  • Soution
  • The degree of the curve is one less than the
    number of control points, so it is a quadratic
    for 3 control points. It will always be symmetric
    for a symmetric control point arrangement.

Courtesy http//astronomy.swin.edu.au/pbourke/cu
rves/bezier/
44
What is the advantage of tangency of Bezier curve
to the first and last control polygonal segments?
  • The curve always passes through the end points
    and is tangent to the line between the last two
    and first two control points. This permits ready
    piecing of multiple Bézier curves together with
    first order continuity.

45
What is meant by the curve well behaving?
  • The curve always lies within the convex hull of
    the control points. Thus the curve is always
    "well behaved" and does not oscillating
    erratically.

Courtesy http//astronomy.swin.edu.au/pbourke/cu
rves/bezier/
46
What are the limitations of Bezier Curve?
  • Solution
  • When interpolation is required, Bezier curve can
    not provide that feature.
  • There is no local control, only global control is
    available
  • When a large number of control points are to be
    modeled by a single curve segment, Bezier curve
    is practically impossible because the degree of
    the curve has to be very high, exactly one less
    than the number of control points. Moreover, it
    will only be local control over the entire
    portion the curve.

47
What is invariance of Bezier curve?
  • Translational invariance means that translating
    the control points and then evaluating the curve
    is the same as evaluating and then translating
    the curve
  • Rotational invariance means that rotating the
    control points and then evaluating the curve is
    the same as evaluating and then rotating the
    curve
  • These properties are essential for parametric
    curves used in graphics
  • It is easy to prove that Bezier curves, Hermite
    curves and everything else we will study are
    translation and rotation invariant
  • Some forms of curves, rational splines, are also
    perspective invariant
  • Can do perspective transform of control points
    and then evaluate the curve
Write a Comment
User Comments (0)
About PowerShow.com
