GPS Cartography of the Minneapolis Streetlight Grid

1
GPS Cartography of the MinneapolisStreetlight
Grid
City of Minneapolis Public Works Traffic
Engineering Division
2
Contributors

• Supervisor Darryn Proch
• Project Leader Jesse Sonju
• Surveyors Nick Pratt (Year 1 2)
• Lance Allison (Year 2)
• Ken Brubaker (Year 1)

3
Goal

• Accurately map all the street lights in the City
  of Minneapolis.

4
Main Light Fixtures
High Level
Low Level
NavigationLights
WallPack
5
Sources of Power
Pole Mounted
Cabinet
6
Daily Procedure

• Obtain as-built or drawings of area to be
  surveyed from office.
• Head to a known survey control point to
  collaborate coordinates
• Move to area of work to start collecting data
• At the end of the week, download data into GIS
  software

7
Equipment Used
This type of GPS unit uses two parts, a receiver
and a data collector
8
Technological Process

• The receiver calculates coordinates using
  satellites
• The data collector averages and stores those
  points
• Downloading into the system allows us to view the
  GIS over given maps

9
Results

• Successfully surveyed remaining streetlights in
  the city in year 2
• Averaged approximately 165 lights per day
• Completed mapping of all street lights in
  Minneapolis, and is now in the process of being
  imported into GIS

10
Hiawatha Ave
11
Lake of the Isles Lowry Hill
12
Hennepin Ave Bridge Lights
13
Lake Street
14
Downtown (Target Center)
15
(No Transcript)
16
Difficulties Encountered

• Tree Cover
• Building Cover
• Integration of new GPS hardware and software

17
Benefits of Project

• All street lights on one map
• Visual Representation of lighting grid
• Easier light pole identification
• Ability to display queries of lighting data
• Changes in real-time
• Faster service location for maintenance work

18
The Next Phase

• Implement a labeling system to affix a barcode to
  each light pole
• Incorporate into 311 and Gopher State One
• Street lighting information available to
  enterprise

19
Questions

• ?
